Product type	Smart home plug receiver
Brand	ebode
Model	RPA
Category	Smart home
Power supply	Mains 230 V ~ 50 Hz
Dimensions (approx.)	6 x 4 x 4 cm
Weight (approx.)	100 g
Number of memory channels	Up to 8 channels in X10 mode
LED indicators	Red LED (reception/transmission), green LED (initialization)
Communication protocol	X10 (powerline), radio, infrared (with converter)
Range	Up to 100 m (depending on environment)
Operating temperature	-10 °C to +40 °C
Operating humidity	20% to 80% (non-condensing)
Installation	Plug into a mains socket, initialize with a compatible controller
Maintenance	Clean with a dry, soft cloth. Do not use solvents.
Safety	Do not open. Risk of electric shock. No user-serviceable parts.
Compatibility	X10 controllers: TPC, EM, IMRF remote controls; converters RPT, RMA, RMV, CM15, TM13, SC28
Compliance	Directive 1999/5/EC

Frequently Asked Questions - RPA EBODE

How to install the RPA plug receiver?

Plug the device or lamp into the receiver, then plug the receiver into a mains socket. The device switch must remain in the on position.

How to initialize a channel on the plug receiver?

With a paperclip, briefly press into the hole between the two LEDs. The green LED flashes. Press the button on your controller (remote control, wireless wall switch, timer) to associate the channel. The LED turns off.

How many channels can the receiver memorize?

The receiver can memorize up to 8 channels in X10 mode.

How to erase all memorized channels (reset)?

Hold a paperclip pressed into the hole between the LEDs for 3 to 4 seconds until the green LED lights up. Release, both LEDs flash then turn off: all channels are erased.

What to do if the remote control does not work?

Check the remote control batteries. Make sure the appropriate converter (RPT, RMA, etc.) is plugged into the mains. Perform a reset of the receiver and reinitialize the channel.

Can I use the receiver on a power strip?

Yes, provided the power strip is not of surge protection or lightning protection type.

What types of controllers are compatible?

Wireless X10 controllers (TPC, EM, IMRF) and those with radio converter (RPT, RMA, etc.) or infrared (IR7243) are compatible.

What does the red LED indicator mean?

The red light turns on temporarily when the receiver receives or transmits a command from a controller.

The receiver no longer responds to powerline commands, what to do?

Perform a reset of the receiver (see procedure) then reinitialize the chosen channel.

Can I repair the receiver myself?

No, do not open it. There are no user-serviceable parts. Have any repairs carried out by a professional.

USER MANUAL RPA EBODE

White electronic device with three pins and a 'X' logo, no visible text or symbols beyond the brand name.

Receiver Plug-In Appliance Module

User guide 6

General Security Note

For carefree and safe use of this product, please read this manual and safety information carefully and follow the instructions. Technical manipulation of the product or any changes to the product are forbidden, due to security and approval issues.

Please take care to set up the device correctly - consult your user guide. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel.

Important: the product must be used according the instructions in this manual and is not suitable for other purposes.

Please avoid the following: strong mechanical wear and tear, high temperature, strong vibrations, and high humidity.

Please also respect the additional security notes in the various user guide chapters. To ensure correct set up please read the manual and security notes carefully.

1. Plug the appliance or lamp into the module.

White plug with black plastic plug inserted into a white socket, showing a red arrow pointing to the socket (no text or symbols visible)

1. Plug the module into a socket.

NOTE: Make sure the appliance or light is powered on.

X10 address

The X10 address consists of a House Code and a Unit Code. In order for this module to respond to a command sent via the Power line, the module needs to be initialized. It is possible to configure multiple addresses for this module.

General information:

• The RPA appliance module can be configured to respond to up to 8 X10 addresses.
• The led will blink Red when ON/OFF commands are received.

Programming the RPA:

If you want to control the RPA via a RF remote like e.g. the ebode TPC, EM or IMRF, you need to install a RF transceiver (e.g. RPT, CM15, TM13 or SC28 security console).

Close-up of a hand holding a white circular object with a small black object inside, possibly part of a mechanical or architectural component (no visible text or symbols)

1. Use a small sharp object, e.g. a paper clip, to shortly press the setup button. This button is situated in the small opening between the two LEDs. When the button is pressed, the green led will blink quickly, waiting for a command.
2. Send the 'power on' command for the desired address.
3. The led will stop blinking.
4. The appliance module address is now stored.
5. If you wish to configure additional addresses repeat this procedure form from step 1.

Close-up of a hand holding a white circular object with a black textured base, possibly part of a container or mechanical component (no visible text or symbols)

Reset appliance module addresses

1. Use a small sharp object, e.g. a paper clip, to press and hold the setup button until the green led turns on. (about 3 or 4 seconds)
2. Release the button, the led will blink red and green and then turn off.
3. When the red and green LEDs are off, the module is reset.

Operating the RPA module

Gently press the upper key (ON) on i.e. EM, TPC, to turn on the appliance/light.

Gently press the lower key (OFF) on i.e. EM, TPC, to turn of the appliance/light.

Tips - Knowledge base available on www.ebodeelectronics.eu.

Can I plug appliance receiver into a power strip?

This is no problem with a simple power strip however you can not use the module with a surge protected power strip.

I'm using a X10 compatible wireless remote, e.g. TPC, IMRF, EM, SS13, KR22, SH600 or HR10, but the RPA is not responding?

• Check and/or change remote control battery.
• Check if your transceiver is correctly connected.
• Reset the RPA (see paragraph 3) then reprogram the address.

The RPA does not respond to command sent via the power line?

Reset the RPA (see paragraph 3) then initialize the address.

White plug plugged into a white socket with a red arrow pointing upward (no text or symbols visible)

Close-up of a hand holding a white circular object with a small square mark, partially obscured by a black object (no text or symbols visible)

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or electronic component (no visible text or symbols)

White plug plugged into a wall socket with a red arrow indicating the cable (no text or symbols visible)

1. Plaats de RPA module in de wandcontactdoos.

Close-up of a hand holding a white circular object with a small square mark, partially submerged in dark material (no text or symbols visible)

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or electronic component (no visible text or symbols)

Reset de RPA apparaat module adressen

White plug with black plastic plug inserted into a wall socket, showing red arrow indicating direction (no text or symbols)

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or architectural component (no visible text or symbols)

Close-up of a hand holding a white circular object with a black textured base, possibly part of a container or mechanical component (no visible text or symbols)

White electrical plug with a red arrow pointing to its outlet, no visible text or symbols

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or electronic component (no visible text or symbols)

Close-up of a hand holding a white circular object with a black textured base, possibly part of a mechanical or electronic component (no visible text or symbols)

Close-up of a white mechanical component with a red arrow pointing to it, no visible text or symbols

White electrical plug with a red arrow pointing to its socket (no text or symbols visible)

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or electronic component (no visible text or symbols)

White plug plugged into a white socket with a red arrow pointing upward (no text or symbols visible)

Close-up of a hand holding a white circular object with a black handle, possibly part of a mechanical or architectural component (no visible text or symbols)

3D rendering of a white mechanical component with a red arrow pointing to it, no visible text or symbols

White electrical plug with a red arrow pointing to its socket, no text or symbols visible

Close-up of a hand holding a white circular object with a black handle, possibly part of a lamp or lamp (no visible text or symbols)

Close-up of a hand holding a white circular object with a small square mark, partially submerged in black material (no text or symbols visible)
