USER MANUAL GSR 12V20 HX Professional BOSCH
Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical Data Cordless screwdriver GSR 12V-20 GSR 12V-20 HX Article number 3 601 JD4 0.. 3 601 JD4 1.. Rated voltage V = 10.8/12 10.8/12 No-load speed – First gear – Second gear rpm rpm 0–400 0–1 300 0–400 0–1 300 Maximum torque, soft screwdriving applica- tion according to ISO5393 Nm 18
Max. drilling diameter (first/second gear) – Wood – Steel
Max. screwdriving diameter mm 7 7 Tool holder 1–10 6.35 (¼") Weight according to EPTA-Procedure 01:2014 kg 0.88–1.1
Permitted ambient temperature – during charging °C 0... +45 0... +45 – during operation
(triax vector sum) and uncertainty K determined according to EN 60745-2-1, EN 62841-2-2: Drilling into metal: a
GSR 12V-20GSR 12V-20 HX
GSR 12V-20GSR 12V-20 HX
GSR 12V-20GSR 12V-20 HX
GSR 12V-20GSR 12V-20 HX
EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Cordless Screw- driver Article number
