USER MANUAL WS 8006 Techno Line

Language French Italian Dutch Weekday FRE ITA DUT Monday LUN LUN MAR Tuesday MAR MAR DIN Wednesday MER MER WOE Thursday JEU GIO DON Friday VEN VEN VRI Saturday SAM SAB ZAT Sunday DIM DOM ZON

Setting the daily alarms: This clock possesses one daily alarms. To view the set alarm times, press the “ALARM” button briefly, the display switches from the clock to Alarm. If you press the button again, the clock switches back to the normal time display. Proceed as follows to set the daily alarms: Press and hold down the “ALARM” button for two seconds until alarm time and the flashing icon are displayed. The hour display of the Alarm time starts to flash. Use the “▲” and “▼“buttons to set the required hour. Press “ALARM” button to confirm your setting The minute display of the Alarm time starts to flash. Use the “▲” and “▼buttons to set the required minute. Press “ALARM” button to confirm your setting and to end the setting procedure. To activate or deactivate the daily alarms, in the alarm mode, press “UP” button to switch alarm function. Notes: After 7 seconds without pressing any button the clock switches automatically from setting mode to Normal clock mode. The alarm will sound for 2 minutes if you do not deactivate it by pressing any button. In this case the alarm will be repeated automatically after 24 hours. Rising alarm sound (crescendo, duration: 2 minutes) changes the volume 4 times whilst the alarm signal is heard. Automatic SNOOZE function: To activate the automatic snooze function: While the alarm is sounding, press the “SNOOZE” button to activate the snooze function. When the snooze function is activated, the Alarm symbol appears in the display. This operation moves the alarm back by 5 minutes and the alarm will restart at this time. The snooze function can be interrupted by pressing any button and can be repeated up to seven times. °C/°F temperature display: The temperature is displayed either in °C or °F. Briefly pressing the “▼ “button allows you to switch between the individual models.EN3 Reception of the Radio signal: The clock automatically starts the DCF signal search after 7 minutes of any restart or changing of new fresh batteries. The radio mast icon starts to flash. At 1:00 am, the clock automatically carries out the synchronization procedure with the DCF signal to correct any deviations to the exact time. If this synchronization attempt is unsuccessful (the radio mast icon disappears from the display), the system will automatically attempt another synchronization at the next full one hour. This procedure is repeated automatically up to total 5 times. To start manual DCF signal reception, press the “WAVE“ button. If no signals received within 7 minutes, then the DCF signal search stops (the radio mast icon disappears) and start again at the next full one hour. During RC reception，to stop searching radio signal, Press and hold the “WAVE” button for two seconds. Notes: A flashing radio mast icon indicates that the DCF signal reception has started A continuously displayed radio mast icon indicates that the DCF signal was received successfully We recommend a minimum distance of 2.5 meters to all sources of interference, such as televisions or computer monitors Radio reception is weaker in rooms with concrete walls (e.g.: in cellars) and in offices. In such extreme circumstances, place the system close to the window. Hereby, Technotrade declares that this product WS8006 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and ROHS 2011/65/EC. The original EU declaration of conformity may be found at: www.technoline.de/doc/4029665080062

Environmental reception effects The clock obtains the accurate time with wireless technology. Same as all wireless devices, the reception is maybe affected by the following circumstances: long transmitting distance nearby mountains and valleys near freeway, railway, airports, high voltage cable etc. near construction site among tall buildings inside concrete buildings near electrical appliances (computers, TV’s, etc) and metallic structures inside moving vehicles Place the clock at a location with optimal signal, i.e. close to a window and away from metal surfaces or electrical appliances. Precautions This main unit is intended to be used only indoors. Do not subject the unit to excessive force or shock. Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity. Do not immerse in water. Avoid contact with any corrosive materials. Do not dispose this unit in a fire as it may explode. Do not open the inner back case or tamper with any components of this unit. Batteries safety warnings Use only alkaline batteries, not rechargeable batteries. Install batteries correctly by matching the polarities (+/-). Always replace a complete set of batteries.EN4 Never mix used and new batteries. Remove exhausted batteries immediately. Remove batteries when not in use. Do not recharge and do not dispose of batteries in fire as the batteries may explode. Ensure batteries are stored away from metal objects as contact may cause a short circuit. Avoid exposing batteries to extreme temperature or humidity or direct sunlight. Keep all batteries out of reach from children. They are a choking hazard. Use the product only for its intended purpose! Consideration of duty according to the battery law Old batteries do not belong to domestic waste because they could cause damages of health and environment. You can return used batteries free of charge to your dealer and collection points. As end-user you are committed by law to bring back needed batteries to distributors and other collecting points! Consideration of duty according to the law of electrical devices This symbol means that you must dispose of electrical devices separated from the General household waste when it reaches the end of its useful life. Take your unit to your local waste collection point or recycling centre. This applies to all countries of the European Union, and to other European countries with a separate waste collection system.FR1 WS 8006 Notices d’utilisation Données techniques Réveil radio synchronisé Réglage manuel Affichage fuseaux horaires Calendrier perpétuel jusqu’en 2099 Affichage de la température en ° C et °F 2 sonneries Affichage en 12 ou 24 h. Fonction répétitive Thermomètre Domaine de mesure : 0°C (32°F) 50 °C (122°F) (fréquence de transmission : toutes les 30 secondes)
