USER MANUAL 48016 UNOLD

Technical Data 22
Explanation of symbols. 22
Safety Information 22
General information and tips on vacuum packing. 24
Preparing the appliance for operation 25
Vacuum packing in bags. 25
Vacuum packing with film from the roll.....26
Vacuum packing in the container 27
Vacuum packing in bottles. 28
Cleaning and Care 29
Troubleshooting 30
Guarantee Conditions 32
Waste Disposal / Environmental Protection..32
Accessories 33
Service 20

1 Cover
2 Sealing gasket
3 Vacuum chamber
4 Rubber gasket
5 Catches
6 Indicator lamp
7 Control buttons
8 Hspe connection

F Page 34

E-Mail [e-mail]

SCHWEIZ

MENAGROS SA

Route der Servion

CH-1083 Mezières

Telefon [phone]

Telefax [phone]

E-Mail [e-mail]

Internet www.menagros.ch

POLEN

"Quadra-net" Sp. z o.o.

Skadowa 5

61-888 Poznan Skadowa 5

Internet www.quadra-net.pl

TSCHECHIEN

befree.cz s.r.o.

Skroupova 150

537 01 Chrudim

Telefon [phone]

capacity: 11 liters_per Minute

Pump vacuum: 0.711 Bar

Features: Hose for creating a vacuum in the container, buttons for creating a vacuum and sealing, power cord storage compartment, multicolor indicator lamp

Accessories: 1 hose, 10 vacuum bags 20 × 30 cm, 10 vacuum bags 28 × 40 cm, 1 vacuum bottle stopper, instructions

Equipment features, technology, colours and design are subject to change without notice. Errors and omissions excepted

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

SAFETY INFORMATION

Please read the following instructions and keep them on hand for later reference.

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the applicance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children without supervision.

1. Children of less than 3 years should be kept away unless continuously supervised.
2. Children aged from 3 years and less than 8 years shall only swith on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

1. Children should be supervised in order to ensure that they do not play with the appliance.

2. Keep the appliance out of the reach of children.

3. Connect appliance only to an AC power supply with voltage corresponding to the voltage on the rating plate.

4. Do not operate this appliance with an external timer or remote control system.

5. Never immerse the appliance in water or other liquids.

6. Do not clean the appliance in a dishwasher.

7. The vacuum packing machine should never come into contact with water or other liquids. In case this ever happens, all parts must be completely dry before operating the appliance again.

8. This appliance is intended for domestic and similar use such as:

9. staff kitchen areas in shops, offices and other working environments;

10. agricultural enterprises; 2

11. by clients in hotels, motels and other accommodation facilities;

12. bed and breakfast accommodations and holiday homes.

13. Never touch the appliance or power cord with wet hands.

14. For safety reasons, never place the appliance on hot surfaces, a metal tray or a wet surface. Do not place the appliance or power cord near open flames during operation.
15. Always use the vacuum packing machine on a level, uncluttered surface.
16. Make sure that the power cord does not hang over the edge of the countertop or table, since this can cause accidents, for example if small children pull on the cord.
17. Keep the films and bags out of the reach of children so that they do not place them over their heads - danger of suffocation!
18. The sealing gasket becomes hot during operation of the appliance. Therefore, do not touch the seal, since otherwise there is a danger of being burned.
19. Do not operate or store the vacuum packing machine outdoors.
20. Do not use the appliance with accessories of other manufacturers or brands, in order to prevent damage.

21. Unplug the appliance from its the power supply after use and prior to cleaning. Never leave the appliance unattended when it is plugged in to the power supply.

22. Clean the appliance after every use (see chapter on Cleaning and Care).

23. Check the appliance, the plug and the power cord regularly for wear or damage. In case of damage to the

power cord or other parts, please send the appliance for inspection and repair to our after sales service. Unauthorized repairs can result in serious risks to the user and void the warranty.

Never open the housing of the appliance. This can result in electric shock.

The sealing gasket becomes hot during operation of the appliance. Therefore, do not touch the seal, since otherwise there is a danger of being burned.

The manufacturer will not be liable in the event of improper or incorrect use or if repairs are carried out by unauthorized third parties.

GENERAL INFORMATION AND TIPS ON VACUUM PACKING

Vacuum packing can be used to keep vegetables, meat, etc. longer. Vacuum packed food does not take on odors and it is well protected against bacteria, mold, etc.

Vacuum packing can also be used to preserve tea or dried foods purchased on sale, for example.

Please use only bags and films that are suitable for vacuum packing, or use the container (available separately). Other bags can melt as a result of high temperatures and damage the appliance! Other containers could be destroyed by the high pressure, resulting in injury.

Our vacuum bags and films are made of a special patented five-ply plastic. This material is ideal for preserving foods.

The bags included with your vacuum packing machine are washable and can be reused; you can even wash the bags in the dishwasher. For detailed information, please refer to the chapter "Cleaning and care".

If you need foods more frequently, we recommend using the container. But it can also be used to keep lettuce fresh longer (in this case, place a paper towel in the container before putting in the lettuce and vacuum packing).

The bags are ideal for vacuum packing meat or fish; complete meals can also be packaged in portions so that they keep longer.

Please note that if the food to be vacuum packed is moist, it should be partially frozen first, since otherwise the liquid can run out during vacuum packing, which would prevent a vacuum from forming.

Also, make sure that no liquid, fat, etc. is in the vicinity of the bag's seal, since this will also prevent a vacuum from forming.

By the way, you can vacuum seal other things than just food. Old photographs, stamps, documents or silverware can be vacuum packed to protect it from damaging effects of the environment.

Bags or containers with vacuum packed food can be heated directly in hot water or the microwave. In this case, punch a small hole in the bag so that the pressure can escape. To heat foods in the container, the lid first has to be opened briefly. We recommend that you do not reuse bags that have been used for heating foods.

Meat, for example sauerbraten, can be marinated much more quickly in the vacuum container, since the effect of the vacuum causes the marinade to penetrate the meat more quickly and more thoroughly.

Please note, however, that vacuum packed foods also have to be stored properly. Perishable goods, for example, have to be cooled even if they are vacuum packed.

Please do not vacuum pack garlic or mushrooms. Vacuum packing of these foods causes a chemical reaction, which can result in spoilage.

PREPARED THE APPLIANCE FOR OPERATION

1. Remove all packaging material and any transport safety devices.
2. Clean all components with a damp cloth, as described in the chapter "Cleaning and care".
3. Place the appliance on a suitable level surface.

4. Make sure that there is enough space in front of the appliance for the bag to be vacuum packed.

5. Connect the appliance via the power cord to the power supply (AC, 220-240 V~, 50 Hz). The indicator lamp lights up green, indicating that the appliance is ready for operation.

VACUUM PACKING IN BAGS

1. Prepare the appliance as described in the section "Preparing the appliance for operation".
2. Open the cover of the appliance. Check to make sure the seal is

inserted properly. If there are any foreign objects such as crumbs on the seal, they have to be removed, since otherwise no vacuum can be created.

1. Fill the bag with the food to be vacuumed. For optimal results, the bag should not be too full. Leave about 8 cm between the contents and the edge of the bag.
2. Place the open end of the bag in the middle of the vacuum packing chamber.
3. Close the cover and press the two catches on the right and left of the appliance inward at the same time.
4. Press the button "Vacuum & Seal". The indicator lamp lights up red to indicate that vacuum packing is in progress.
5. When the optimal vacuum result has been achieved, the bag is sealed: the indicator lamp shows this by lighting orange.

6. The appliance starts with sealing, the vacuum pump no longer works.

7. When the process is completed, the indicator lamp lights green and the two catches on the appliance open automatically.

8. Now open the lid and remove the bag.
9. The vacuum packing process is completed and the food in the bag is vacuum sealed.
10. If you only wish to seal the bag without a vacuum, just press the button "Seal Now".
11. If you wish to interrupt the vacuum packing process, press the button "Vacuum & Seal" again.
12. Always check whether the vacuum result meets your requirements and ensure that the sealing strip is complete and flawless.

VACUUM PACKING WITH FILM FROM THE ROLL

1. Prepare the appliance as described in the section "Preparing the appliance for operation".
2. Open the cover of the appliance. Check to make sure the seal is inserted properly. If there are any foreign objects such as crumbs on the seal, they have to be removed, since otherwise no vacuum can be created.

3. Cut the required amount of film from the roll. Caution: Add at least 7.5cm for vacuum packing. If you wish to reuse the bag, you have to add even more: allow 2.5cm for each vacuum packing process.

4. Place one open end of the film over the sealing gasket. You do not have to insert this end of the bag into the vacuum packing chamber, since the bag first has only to be sealed, without creating a vacuum.

5. Close the cover and press the two catches on the right and left of the appliance inward at the same time.

6. Press the button „Seal Now“. The indicator lamp lights up orange to indicate that the appliance is sealing. The vacuum pump is still off.

7. After a short time the indicator lamp lights up red, the appliance works for another approx. 2 seconds.

8. Once the process is completed, the cover of the appliance opens slightly and the indicator lamp lights green.

9. Open the lid and remove the bag.

10. Now you can start vacuum packing, as described.
11. If you wish to interrupt the vacuum packing process, press the button "Vacuum & Seal".

VACUUM PACKING IN THE CONTAINER

Please use only containers that are suitable for vacuum packing.

If you wish to vacuum pack liquids in the container, cool them in the refrigerator first. If you wish to vacuum pack ground or granulated foods in the container, please place a paper towel on top of the food before closing the lid and starting the vacuum packing process.

1. Prepare the appliance as described in the section "Preparing the appliance for operation".
2. Place the food to be vacuum packed in the container. Leave a space of at least 1 cm between the contents and the top edge of the container.
3. The lids of the vacuum container are labeled "Öffnen" (Open), "Vakuum" (Vacuum) and "Verriegeln" (Lock). Turn the button on the lid of the container so that the arrow points to the "Vakuum" position and close the container with this lid.
4. Insert one end of the hose included with your vacuum packing machine into the connection on the appliance and the other end into the valve on the lid of the vacuum container.
5. Close the cover of the vacuum packing machine and press the

two catches on the right and left of the appliance inward at the same time.

1. Press the button "Vacuum & Seal". The indicator lamp lights up red and then orange to indicate that the appliance is in operation. Then the indicator lamp lights up green. Now turn the button on the lid of the container so that the arrow points to "Öffnen"; the vacuum packing process is completed.
2. Remove the hose from the appliance and from the container.
3. The vacuum packing process is completed and the food in the container is vacuum packed.
4. If you wish to interrupt the process, press the button "Vacuum & Seal" again.

Opening the vacuum packed container

When you wish to open a vacuum packed container, please turn the button on the lid of the container so that the arrow points to "Öffnen". Then you can easily open the lid.

VACUUM PACKING IN BOTTLES

The vacuum bottle stopper included with your vacuum packing machine can be used on wine or oil bottles, for example, so that you can easily preserve the aroma and freshness of any liquid.

Caution: Do not use the vacuum packing bottle stoppers for very thin glass bottles, for crystal, plastic or aluminum bottles or for damaged bottles.

Please do not vacuum pack any carbonated liquids. These liquids have to be preserved under pressure. Vacuum packing causes them to lose the carbonation.

1. Prepare the appliance as described in the section "Preparing the appliance for operation".
2. Insert the bottle stopper into the opening in the bottle. There must be at least 2.5cm of air between the liquid in the bottle and the lower edge of the vacuum packing bottle stopper.
3. Insert one end of the hose including with your vacuum packing machine into the connection on the appliance and the other end into the hole in the vacuum packing bottle stopper.
4. Close the cover of the vacuum packing machine and press the two catches on the right and left

of the appliance inward at the same time.

1. Press the button "Vacuum & Seal". The indicator lamp lights up red and then orange to indicate that the appliance is in operation. Then the indicator lamp lights up green.
2. Remove the hose from the appliance and from the vacuum packing bottle stopper.
3. The vacuum packing process is now completed.
4. If you wish to interrupt the process, press the button "Vacuum & Seal" again.

Opening the vacuum packed bottles

If you wish to open a vacuum packed bottle, simply pull the stopper out of the bottle.

Cleaning the appliance

Before cleaning, always turn off the appliance and unplug it from the power supply.

Do not immerse the appliance and power cord in water or other liquids.

Allow the appliance to cool before cleaning it.

1. Wipe off the vacuum packing machine with a damp cloth. Do not use any abrasive scouring agents, steel wool, metal objects,

hot cleaning agents or disinfectants.

1. Remove any food residue on the appliance using a damp cloth.
2. The appliance and power plug must be completely dry before the appliance can be operated again.
3. When completely dry, store the vacuum packing machine in a dry, safe place so that it is protected from dust, shocks, heat and moisture.

Cleaning the vacuum packing bags

1. The vacuum packing bags can be cleaned in warm water with a little dishwashing detergent added.
2. The bags can also be washed in the dishwasher. To do so, carefully turn the bag inside out and place it in the top basket of
3. the dishwasher. Make sure that all surfaces of the bag come into

contact with water.Dry the bags carefully before reusing them.

1. We recommend that you do not reuse bags in which raw meat or fish has been vacuum packed.
2. If you have vacuum packed foods with a high fat content, it is possible that the bags likewise cannot be reused.

Cleaning the vacuum packing container

1. The vacuum packing container can be cleaned in warm water with a little dishwashing detergent added.
2. The container (without the lid) can also be washed in the dish

washer. Please place the basket only in the top basket of the dishwasher.
3. Dry the container and the lid carefully before reusing them.

TROUBLESHOOTING

Problem Solution

No function when a button is pressed.

• Check to make sure that the appliance is correctly plugged into the power supply.
• Check for damage to the power cord.
• Check to make sure that the power outlet you are using functions properly by plugging another appliance into it.

No vacuum can be created.

• Check for holes in the bag. To do so, you can seal the bag so that there is still some air in it. Place the bag in water and press down on it somewhat. If air bubbles rise from the bag, there is a hole in it. Please use a new bag.

If you are using a bag you have made yourself, check the sealing strip of the bag. If there is a crease in the sealing strip, this prevents air from being drawn from the bag. Cut the bag off at this point and seal it again.

The bag loses the vacuum.

• Check the sealing strip of the bag. If there is a crease in the sealing strip, no vacuum can be created. Open the bag and vacuum pack it again.

Remnants of fat, liquids, crumbs, etc. in the vicinity of the sealing bar can cause the air to escape. Open the bag, clean the affected area thoroughly and vacuum pack it again.

• Foods with sharp edges, such as bones, can damage the bag. In this case, you will have to use a new bag. If you wish to vacuum pack such foods, first wrap them in a paper towel.

Problem Solution

The bag cannot be sealed.

• Check to make sure that the cover of the vacuum packing machine is properly closed. If the cover is loose, the appliance will continually create a vacuum and cannot seal the bag or container.

Remnants of fat, liquids, crumbs, etc. in the vicinity of the sealing strip can keep the bag from sealing. Open the bag, clean the affected area thoroughly and seal it again.

No vacuum can be created in the container.

• Check to make sure that the arrow on the lid of the container is set to "Vacuum".
  Make sure that the hose is correctly connected.
• Check to make sure that there is at least 1cm of space between the contents and the top edge of the container, since otherwise no vacuum can be created.
  Make sure that the container and the lid are not damaged by hairline cracks. Hairline cracks can cause the container to leak, and no vacuum can be created. In this case, the container has to be replaced.

The vacuum bottle stopper does not create a vacuum.

• Make sure that the vacuum bottle stopper is properly inserted in the bottle. If it is too loose, air can enter the bottle, preventing a vacuum from forming.

Make sure that the edge of the bottle and the bottle stopper are undamaged and free of fat, crumbs, etc. Impurities on the bottle stopper or the bottle can prevent a vacuum from forming.
Make sure that the hose is correctly connected.

The appliance is working but can not seal the bag.

• When the appliance is working time too long, the heating thread is overheated. In order to ensure the machine safety and the sealing performance, the heating thread is stopped by the temperature controller. In this case please stop the appliance working for about two minutes; the heating thread will cool down. Then restart the appliance.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged and postage paid, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. If the defect is covered by the warranty, the customer will be reimbursed for the shipping costs only in Germany and Austria. The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal.

Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products.

By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

ACCESSIONS

The following accessories can be ordered directly from our after sales service.

4801001 Vacuum bag 15 x 25 cm Qty 100
4801002 Vacuum bag 20 x 30 cm Qty 100
4801003 Vacuum bag 28 x 40 cm Qty 100k
4801004 Vacuum film 20 x 600 cm 1 package	with 2 rolls
4801005 Vacuum film 28 x 600 cm 1 package	with 2 rolls
4801007 Vacuum container, round, 0.6 liter volume Qty 1
4801008 Vacuum container, square, 2.4 liter volume	Qty 1

NOTICE D'UTILISATION MODELE 48016

DONNÉES TECHNIQUES

Puisance: 110 W, 220-240 V\~, 50 Hz

Dimensions: Env. 39 × 16 × 8,5 ~cm (L x l x h)

Cable d'alimentation: Env. 150 cm

Poids: Env. 1,57 kg

CONDITIONS DE GARANTIE

DIAGNOSTICA DEI PROBLEMI

Problema Soluzione

1. Reparaciones inadequadasSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEOSEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO SEO
