OT 13 - Oven TEAM - Free user manual and instructions

Product type	Table oven
Brand	TEAM
Model	OT 13
Power supply	230 V ~ 50 Hz
Power	1200 W
Main functions	Cooking with lower heating element, cooking and grilling with both elements, adjustable thermostat, 60-minute timer with bell
Included accessories	Metal grid, baking tray, crumb tray, removal handle
Maintenance and cleaning	Unplug and allow to cool before cleaning. Clean the interior with paper towel and a little oil, then mild detergent. Do not use abrasive products or steel wool. Clean the exterior with a dry soft cloth. Do not immerse in water.
Safety	Do not leave unattended. Do not touch hot surfaces. Keep away from children. Ensure a minimum distance of 10 cm from walls and objects. Use an extension cord of at least 16 A if necessary. Do not use outdoors.
Spare parts and repairability	Repairs must be carried out by an approved qualified service. Use only accessories recommended by the manufacturer.
General information	Short power cord to reduce risks. Do not wrap the cord around the appliance. Temperature of accessible surfaces may be high during operation.

Frequently Asked Questions - OT 13 TEAM

What to do if smoke or a new smell comes out during first use?

It is normal for some smoke or new smells to be emitted during first use. Run the appliance empty for a few minutes before first use to remove these manufacturing residues.

How to clean the inside of the oven after use?

Make sure the appliance is unplugged and completely cool. Wipe the tray with paper towel. For stubborn residues, pour a little cooking oil, wait 5-10 minutes, then rub with paper towel. If necessary, use a damp cloth with mild detergent. Never use abrasive products or steel wool.

Can I use an extension cord with this oven?

Yes, but make sure the extension cord's amperage is at least 16 amps. An extension cord of less than 16 A may overheat. Also ensure it does not hang or drag on the floor to avoid any risk of accident.

What safety distance should be maintained around the oven?

Ensure there is a distance of at least 10 cm between the sides of the oven and a wall or any other object. Also leave enough free space above the appliance for proper ventilation. Place the oven on a heat-resistant surface.

How to stop cooking before the set time ends?

To stop cooking before the end, simply turn the timer knob to the '0' position. A bell rings when the time is up.

Can I cook food in paper or plastic?

No, never place paper, cardboard, or plastic in the oven. Only foods suitable for cooking and fit for consumption can be cooked.

What to do if the oven door has a deformity?

Immediately disconnect the appliance and have it checked by a qualified service (manufacturer's after-sales service or a qualified person). Do not use the appliance until it has been repaired.

How to use the supplied handle?

Use the handle to remove the tray or grid from the oven, as these parts become very hot. Be careful to avoid burns.

Is it normal for the oven door to heat up?

Yes, the temperature of accessible surfaces, especially the door and metal walls, may be high during operation. Do not touch them and only handle the knobs during and after cooking until completely cool.

How to set the temperature and cooking time?

Set the temperature using the thermostat. Set the cooking time with the timer (the numbers indicate minutes). Cooking starts only when a time is selected. The indicator light turns on to show that the oven is heating.

USER MANUAL OT 13 TEAM

1. Thermostat
2. Function selector
3. Pilot light
4. Timer
5. Crumb tray
   6.Rack
6. Baking tray
7. Handle to remove the rack and baking tray

F

Please read these instructions carefully before using the appliance.
Check that your mains voltage corresponds to that stated on the appliance.
Never leave the appliance unsupervised when in use. Keep out of reach of children or incompetent persons.
From time to time check the cord for damages. Never use the appliance if cord or appliance shows any signs of damage. Should the cord be damaged, it must be replaced by a competent qualified electrician. All repairs should be made by a competent qualified electrician.
Only use the appliance for domestic purposes and in the way indicated in these instructions.
Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.
Never use the appliance near hot surfaces.
Before cleaning, always unplug the appliance from the power supply.
Never use the appliance outside and always place it in a dry environment.
Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
In order to avoid fire, make sure there is a distance of at least 10cm between the sides of the oven and a wall or other object and also make sure that there is enough free space above the appliance. During operation, make sure there is enough ventilation in the room around this appliance. Stand the appliance on a stable heat resistant surface (not a varnished table or a table cloth).
Make sure the appliance has cooled down before cleaning and storing it.
Make sure the cord never comes into contact with the hot parts of the appliance.
Only cook consumable food. Never place the following materials in the oven: paper, cardboard or plastic...
Please do not pass 10 min using your toaster, as otherwise your bread will be burned. This remark is important as the maximum time is 60 minutes but this period of time should be used for other things than re-heating your bread.
It is absolutely necessary to keep this appliance clean at all times as it comes into contact with food.
During use, the metal parts of the oven, as well as the door can reach very high a temperature. Never touch these hot parts of the appliance. Always use gauntlets when handling the appliance and only tough the knobs.
Make sure the hot parts of the appliance never come into contact with inflammable materials, such as curtains, cloth, etc. ... when it is in use, as a fire might occur. Also make sure not to cover the appliance and do not put anything on top of it. Make sure nothing comes into contact with the heating element of the appliance.
Be extremely cautious as oil and fat preparations might catch fire if overheated.
If you use the appliance under a cooking hob, make sure to respect the minimum distance advised by the manufacturer.
Unplug the appliance immediately if you notice a crack in the oven door and have it repaired by a competent qualified electrician ()

Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

SHORT CORD INSTRUCTIONS

A short power supply cord is provided to reduce the risk resulting from becoming entangled in, or tripping over a longer cord. Extension cords may be used if care is exercised in their use.

The electrical rating of the extension cord should be at least 16 amp. An extension cord of less than 16 amp could overheat and get damaged.
- The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over.

BEFORE USE

• Unpack the appliance and accessories, then wash and wipe these accessories.
  It is normal if some smoke or smell emanates from the appliance when using it for the first time. Operate the appliance for 15 minutes, putting the thermostat on 250^ .

OPERATING INSTRUCTIONS

Before using the appliance for the first time, clean the surface of the tray with a damp cloth and wipe dry. Then grease the tray with butter, margarine or cooking oil.
- Slide the crumb tray underneath the lower heating elements.
- Put the function selector in OFF position.
- Plug the unit into the power supply socket.
- Turn the function selector to the desired position:

: only the lower heating element heats up to bake or reheat a preparation without roasting it.
- only the upper heating element heats up in order to roast the preparation.
- both heating elements will heat up to bake and roast the preparation.

• Select the cooking temperature using the thermostat knob.
• Then, turn the timer knob to choose the required time, indicated in minutes on the appliance. The heating elements will only turn on when you have selected the cooking time. The pilot light will come on, indicating that the oven is heating.
• When the timer stops, a time-up chime will sound and the appliance will stop automatically.
  If you want to stop before the selected time is over, turn the timer to "0".

• As soon as the food is ready, turn the thermostat to the minimum position and the function selector to OFF

• Carefully open the door, preferably using an oven glove.

To remove the rack or the baking tray, use the handle supplied. Be very careful when removing these parts as they might be very hot and you might get burned.

CLEANING AND MAINTENANCE

Before cleaning, unplug the appliance from outlet and allow to cool.

Inside cleaning

• Wipe trays with absorbent paper towelling or a soft cloth. To remove baked on food pour a little cooking oil on the food and allow to stand for five to ten minutes. This should soften the food and allow it to be removed with absorbent paper towelling or a soft cloth.
  If the above method fails to remove the food we suggest wiping the trays with a damp cloth and a little detergent.
• Never use abrasive products. Never immerse the appliance in water and make sure no water or damp penetrates into the appliance.
  Make sure no water comes on the oven door when the latter is still hot.
• Caution! It is very important to empty the crumb tray regularly. Crumbs or other food residues that have accumulated in the tray might burn and the appliance might catch fire.

Outside cleaning

• Wipe clean with a soft dry cloth or paper towelling
• Do not use steel wool, scouring pads or abrasive cleaners as these might damage the housing of the appliance.

Do not immerse in water or any other liquid.
