USER MANUAL KA VT 23 TEAM

1. Front guard
2. Fan blade
3. Guard mounting ring
4. Position fixers
5. Rear guard
6. Motor shaft
7. Motor housing

8. Oscillation knob
   9.Motor

9. Speed knobs

F

Please read these instructions carefully before using the appliance.

Important: People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance except if they are supervised by a person responsible for their safety or if they previously received instructions concerning the safe use of the appliance. Close supervision is necessary to prevent children from using the appliance as a toy.

Check that your mains voltage corresponds to that stated on the appliance.
Never leave the appliance unsupervised when in use.
From time to time check the appliance for damages. Never use the appliance if cord or appliance shows any signs of damage but have it checked and repaired by a competent qualified service!. Should the cord be damaged, it must be replaced by a competent qualified service ()
Only use the appliance for domestic purposes and in the way indicated in these instructions.
Never immerse the appliance in water or any other liquid for any reason whatsoever. Avoid splashes on the appliance.
Never use the appliance near hot surfaces.
Unplug the appliance before cleaning it.
Never use the appliance outside and always place it in a dry environment.
Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
It is absolutely necessary to unplug the appliance before assembling the base or any other part or before disassembling it.
Make sure the assembly is correctly made before plugging in the appliance. Never try to start the appliance without its protection guard.
Make sure the appliance is switched to the 0 position before unplugging it.
Do not insert your fingers, pencils, or any other objects in the protection guard.
Do not touch the appliance with wet hands.
Do not put the fan on the outside of a window or any other unsteady place. Make sure the appliance is put on a flat surface in order to avoid vibrations
When used in an inappropriate manner the appliance could constitute a danger to the user, in that case the producer can not be held responsible for any kind of possible damages
Do not let the fan in use for long periods during your absence. Make sure it is switched off before leaving.
Do not point the fan in the direction of a sick or sleeping person.
- When cleaning the appliance, do not disassemble the guards, check the cleaning section.

Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

ASSEMBLY

1. Loosen the guard mounting ring (3) from the motor housing (7).
2. Position the rear guard (6) firmly against the motor housing (7) and fasten by turning the guard mounting ring (3) clockwise tightly.
3. Push the blade (2) along the motor shaft (6).
4. Hang the front guard (1) to the rear guard (5) with the position fixer (4) provided at the front guard rim.
5. To ensure that it is impossible to have access to the fan blade without using a tool, a screw is provided with this appliance in order to attach both parts of the mesh guard together. This screw must be tightened on the lower part of the guards. We cannot be held responsible for any injuries in case this screw had not been tightened before using the appliance.

OPERATION

This appliance is equipped with 2 ventilation speeds (10). To switch on the appliance, press one of the speed knobs. To switch it off, press "0".
- This appliance also has an oscillation function: - Push the oscillation knob (8) to switch on the oscillation.
- Pull the oscillation knob (8) to stop.

CLEANING AND CARE

Always disconnect the power supply cable from the power supply before carrying out any cleaning operation.
To remove dirt from the plastic surfaces, use a cloth moistened with a little water. Use a vacuum cleaner to remove the dust from the guards without having to disassemble them.
- Never immerse the fan in water or any other liquid.

PROTECTION OF THE ENVIRONMENT- DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the

implication of both suppliers and users. For this reason, as indicated by the symbol the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.
