Product type	Table fan
Brand	Team
Model	KA VT 25
Number of speeds	3
Oscillation function	Yes, with oscillation button
Protective grille	Yes, with safety bolt
Power supply	Mains (mains voltage)
Usage	Indoor, domestic
Care and cleaning	Unplug before cleaning; use a damp cloth for plastic surfaces and a vacuum cleaner for the grilles
Safety	Protective grilles with fixing bolt; do not insert objects into the grilles; do not use outdoors
Estimated weight	Approximately 1.5 kg
Estimated blade diameter	Approximately 25 cm
Assembly	Rear grille fixed by ring, blade inserted on shaft, front grille clipped with safety bolt
Environmental protection	Do not dispose of with household waste; deposit at a collection point (Directive 2002/96/EC)

Frequently Asked Questions - KA VT 25 TEAM

How to assemble the KA VT 25 fan?

Unscrew the fixing ring, place the rear grille against the motor block and secure with the ring. Insert the blade onto the shaft, then attach the front grille and close the clips. Secure the safety bolt at the bottom of the grilles.

How to use the speeds and oscillation?

Press one of the three speed buttons to start (speed 1, 2 or 3). To turn off, press the '0' button. For oscillation, push the oscillation button to activate, pull to deactivate.

How to clean the fan?

Always unplug the appliance before cleaning. Use a damp cloth for plastic surfaces. For a more thorough cleaning of the grilles, use a vacuum cleaner. Never immerse the appliance in water.

Can I use the fan outdoors?

No, the fan is designed for indoor use only. Do not use it outdoors and store it in a dry place.

What to do if the fan does not work?

Check that the mains voltage matches that of the appliance. Make sure the appliance is plugged in and the speed button is pressed. If the problem persists, have the appliance checked by a qualified service.

The fan is noisy or vibrates, what to do?

Check that the appliance is placed on a smooth, stable surface. Make sure the grilles are properly secured and the blade is not obstructed. If vibrations persist, stop the appliance and consult the manual.

Can I leave the fan running unattended?

It is not recommended to leave the fan unattended for long periods. Turn it off before leaving the room.

How to replace the power cord if damaged?

The power cord must be replaced only by a qualified competent service (after-sales service of the manufacturer or importer). Do not attempt to repair it yourself.

Can children use this fan?

This fan is not intended for use by persons (including children) with reduced capacities without supervision. Supervise children so they do not play with the appliance.

How to recycle the fan at end of life?

Do not dispose of the appliance with household waste. Deposit it at a public collection point for the recycling of electrical and electronic waste, in accordance with Directive 2002/96/EC.

USER MANUAL KA VT 25 TEAM

1. Front guard
2. Fan blade
3. Guard mounting ring
4. Position fixers
5. Rear guard
6. Motor shaft
7. Motor housing

8. Oscillation knob
   9.Motor

9. Speed knobs

F

Please read these instructions carefully before using the appliance.

Important: People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance except if they are supervised by a person responsible for their safety or if they previously received instructions concerning the safe use of the appliance. Close supervision is necessary to prevent children from using the appliance as a toy.

Check that your mains voltage corresponds to that stated on the appliance.
Never leave the appliance unsupervised when in use.
From time to time check the appliance for damages. Never use the appliance if cord or appliance shows any signs of damage but have it checked and repaired by a competent qualified service!. Should the cord be damaged, it must be replaced by a competent qualified service (^*)
Only use the appliance for domestic purposes and in the way indicated in these instructions.
Never immerse the appliance in water or any other liquid for any reason whatsoever. Avoid splashes on the appliance.
Never use the appliance near hot surfaces.
Unplug the appliance before cleaning it.
Never use the appliance outside and always place it in a dry environment.
Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
It is absolutely necessary to unplug the appliance before assembling the base or any other part or before disassembling it.
Make sure the assembly is correctly made before plugging in the appliance. Never try to start the appliance without its protection guard.
Make sure the appliance is switched to the 0 position before unplugging it.
Do not insert your fingers, pencils, or any other objects in the protection guard.
Do not touch the appliance with wet hands.
Do not put the fan on the outside of a window or any other unsteady place. Make sure the appliance is put on a flat surface in order to avoid vibrations
When used in an inappropriate manner the appliance could constitute a danger to the user, in that case the producer can not be held responsible for any kind of possible damages
Do not let the fan in use for long periods during your absence. Make sure it is switched off before leaving.
Do not point the fan in the direction of a sick or sleeping person.
When cleaning the appliance, do not disassemble the guards, check the cleaning section.

(*) Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

ASSEMBLY

1. Loosen the guard mounting ring (3) from the motor housing (7).
2. Position the rear guard (6) firmly against the motor housing (7) and fasten by turning the guard mounting ring (3) clockwise tightly.
3. Push the blade (2) along the motor shaft (6).
4. Hang the front guard (1) to the rear guard (5) with the position fixer (4) provided at the front guard rim.
5. To ensure that it is impossible to have access to the fan blade without using a tool, a screw is provided with this appliance in order to attach both parts of the mesh guard together. This screw must be tightened on the lower part of the guards. We cannot be held responsible for any injuries in case this screw had not been tightened before using the appliance.

OPERATION

This appliance is equipped with 3 ventilation speeds (10). To switch on the appliance, press one of the speed knobs. To switch it off, press "0".
- This appliance also has an oscillation function: - Push the oscillation knob (8) to switch on the oscillation.
- Pull the oscillation knob (8) to stop.

CLEANING AND CARE

Always disconnect the power supply cable from the power supply before carrying out any cleaning operation.
To remove dirt from the plastic surfaces, use a cloth moistened with a little water. Use a vacuum cleaner to remove the dust from the guards without having to disassemble them.
- Never immerse the fan in water or any other liquid.

PROTECTION OF THE ENVIRONMENT- DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the

implication of both suppliers and users. For this reason, as indicated by the symbol the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.
