TKG CV 1000 T - Heating KALORIK - Free user manual and instructions

Product type	Electric convector
Brand	Kalorik
Model	TKG CV 1000 T
Power supply	Mains 220-240 V ~ 50 Hz
Power	3 levels: 750 W, 1250 W, 2000 W
Turbo function	Yes, accelerates air circulation with or without heating
Thermostat	Yes, temperature adjustment
Indicator light	Red operation light
Air outlet grille	Yes, with separate turbo function
Carrying handle	Yes, on the sides
Foot assembly	Yes, two feet with 3 screws each
Thermal safety	Yes, automatic shut-off in case of overheating
Use	Indoors, on a flat and stable floor
Maintenance	Soft damp cloth, vacuum cleaner for grilles
Environmental protection	Do not dispose of with household waste, recycle according to directive 2002/96/EC

Frequently Asked Questions - TKG CV 1000 T KALORIK

How to assemble the feet of the Kalorik TKG CV 1000 T convector?

Attach one foot to each end of the device using the 3 screws provided per foot. Make sure the feet are correctly assembled before use.

What are the available power levels on this convector?

The power button offers 3 levels: I = 750 W (low), II = 1250 W (medium), III = 2000 W (high). Use the Turbo function to speed up heat diffusion.

How to use the Turbo function?

The Turbo function can be activated with heating (power button on I, II or III) to heat faster, or without heating (button on 0) to simply circulate air and cool down.

What to do if the indicator light goes off and the device stops heating?

This may be due to overheating. Unplug the device for at least 10 minutes, clear the air intake and outlet grilles, then plug back in. If the problem persists, contact after-sales service.

Can I use the convector in a bathroom?

No, it is forbidden to use the device near a bathtub, shower, washbasin or swimming pool. Always place it in a dry area, away from water.

How to clean the convector?

Always unplug the device before cleaning. Use a soft damp cloth for the exterior, and a vacuum cleaner or brush for the air outlet grilles. Never immerse the device in water.

The power cord is damaged, what should I do?

The cord must be replaced by a qualified service. Do not use the device until the cord is repaired.

Can I cover the convector with a cloth?

No, it is forbidden to cover the device or block the air intake and outlet grilles, as this could cause overheating and a fire risk.

The convector emits an odor the first time, is this normal?

Yes, a slight odor may occur during first use. This is normal and temporary. Ensure good ventilation of the room until the odor disappears.

How to dispose of the convector at the end of its life?

Do not dispose of it with household waste. Take it to a collection point for recycling electrical and electronic devices, in accordance with directive 2002/96/EC.

USER MANUAL TKG CV 1000 T KALORIK

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The pages must be reproduced and folded in order to obtain a booklet A5 (+/- 148.5 mm width x 210 mm height). When folding, make sure you keep the good numbering when you turn the pages of the I/B. Don't change the page numbering. Keep the language integrity.

D

Please read these instructions carefully before using the appliance, and always follow the safety and operating instructions.

Important: People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance except if they are supervised by a person responsible for their safety or if they previously received instructions concerning the safe use of the appliance. Close supervision is necessary to prevent children from using the appliance as a toy.

Check that your mains voltage corresponds to that stated on the appliance.

Never leave the appliance unsupervised when in use.

From time to time check the cord for damages. Never use the appliance if cord or appliance shows any signs of damage but have it checked and repaired by a competent qualified service. Should the cord be damaged, it must be replaced by a competent qualified service.

Only use the appliance for domestic purposes and in the way indicated in these instructions.

Never immerse the appliance in water or any other liquid for any reason whatsoever. When cleaning the appliance, refer to the instructions in the paragraph "Cleaning and care" because water penetration through the openings can be very dangerous for your appliance.

Never use the appliance near hot surfaces.

Before cleaning and when you do not use the appliance, always unplug the appliance from the power supply. Do not attempt to remove the plug from the wall socket with wet hands.

Never use the appliance outside and always place it in a dry environment.

Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.

Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.

Stand the appliance on a stable surface so that it cannot fall.

Unplug the appliance when it is not in use.

Do not place the appliance under a power socket. The power socket must not be in the hot airflow of the appliance.

Always position the heater in such a way that inflammable materials (such as curtains) cannot be ignited. Ensure at all times that the unit is placed solidly on its base. Make sure that the air inlet and outlet openings are not blocked. To avoid any risk of fire, do not cover the heater (e.g. with clothes).

Make sure that the air inlet and outlet openings are not blocked. To avoid any risk of fire, do not cover the heater (e.g. with clothes).

Warning: Do not operate the heater near baths, showers, washbasins, swimming pools or any other water container. It must be impossible to reach the commands of your appliance when you are in contact with water.

Do not allow the power cord to touch any hot part of the appliance.

The temperature of the grids may be very high when the appliance is in use. Avoid contact with the skin.

Never use the appliance near inflammable or explosive materials.

Do not insert any objects through the grille or into the interior of the appliance.

Competent qualified service: after-sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In case of need you should return the appliance to this service.

CONNECTION TO THE MAINS SUPPLY

Caution: We cannot be held responsible for any damage due to the wrong use or the non-observation of this instruction manual.

The convection heater should only be connected to an earthed socket installed in accordance with the regulations. Make sure that the supply voltage corresponds with the voltage marked on the rating label. This product complies with CE-directives.

MOUNTING

Before using the convection heater for the first time, the feet must be fitted to the base of the unit and then secured with the screws provided (3 screws for each foot). When the appliance is correctly assembled, it will be stable and ready for use. Never use the convection heater if the feet have not been assembled.

OPERATION

After having installed your convection heater, insert the plug into an earthed power socket. When the appliance is switched on for the first time, a slight smell may be emitted. Please ensure sufficient ventilation. This smell will disappear very quickly.

The power knob allows you to choose the desired power level.

The thermostat regulates the temperature in the room. A red pilot light will allow you to check the thermostatic regulation. When the appliance is heating, this pilot light will be on. It will go out when the desired temperature is reached.

Power and turbo

I = reduced power (750W)

II = medium power (1250W)

III = full power (2000W)

The « turbo » can be used either with heating function (power knob in position I, II or III) and in this case it allows you to enhance the air circulation and thus to heat a larger area more rapidly.

Or it can be used without heating function (power knob in position 0) and in this case it just makes the air circulate in order to lower the room temperature a little.

Note: the metallic parts of this appliance become hot during use so if you need to move the appliance during use, use the side handles.

OVERHEATING PROTECTION

This heater is protected with an overheating protection that switches off the appliance automatically in case of overheating, e.g. due to the total or partial obstruction of the grids. In this case, unplug the appliance, wait about 10 minutes for it to cool and remove the object that is obstructing the grids. Then switch it back on as described above. The appliance should operate normally. Should the problem persist, please contact the nearest customer service.

CLEANING AND CARE

Before cleaning the appliance, ensure it is disconnected from the power supply and has cooled down completely.
- To avoid the risk of electric shock, do not clean the heater with water and do not immerse it in water or any other liquid. Clean the housing with a damp cloth.
If necessary, dust particles accumulated in the air outlet openings may be removed with a vacuum cleaner. This maintenance should be done regularly to assure the good operation of the appliance.

PROTECTION OF THE ENVIRONMENT - DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the

implication of both suppliers and users. For this reason, as indicated by the symbol the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.

FR MODE D'EMPLOI

POUR VOTRE SECURITE

I = putere redusa (750W)
II = putere medie (1250W)
III = putere maxima (2000W)
