USER MANUAL FK299.2FTZ AMICA

DISPOSAL OF OLD APPLIANCE 44

DALŠÍ INFORMACE O TEPLOTĚ 88

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• This appliance is intended to be used in household and sim- ilar applications such as:

1. Sta kitchen areas in shops, oces and other working envi-

2. Farm houses and by clients in hotels, motels and other resi-

dential type environments

3. Bed and breakfast type environments

4. Catering and similar non-retail applications

• The manufacturer reserves the right to introduce changes which do not aect the operation of the ap- pliance.

• Some provisions in this user manual are unied for refrigerating products of dierent types (for a refriger- ator, refrigerator-freezer or freezer)

• The Manufacturer shall not be held liable for damage arising from the failure to observe the instructions con- tained in this manual.

• Keep this manual for future reference, or to pass it over to the next user.

• This appliance is not intended for use by persons (in- cluding children) with limited physical or mental capa- bilities and persons who lack experience or familiarity with the appliance.

• Do not allow children to use the appliance. Do not al- low them to play with the appliance. They must not climb inside the drawers and swing on the doors.

• The appliance operates properly at the ambient tem- perature (see product che). Do not use it in the cellar, unheated summer cottage during autumn and winter.

• When placing, moving, lifting the appliance, do not hold the door handles, do not pull the condenser at the rear part of the refrigerator and do not touch the compressor unit.- 38 -

• When transporting, moving or positioning the fridge-freezer do not tilt it by more than 40° from the vertical position. Should such a situation occur, the ap- pliance should be switched on after minimum 2 hours from its replacement in the right position (g.2).

• Pull the plug out from the mains socket before each maintenance activity. Do not pull on the cord, but hold the body of the plug instead.

• The “cracking” sound, which the appliance may emit is caused by the expansion and contraction of parts as a result of temperature variations.

• For safety reasons do not repair the appliance yourself. Repairs carried out by persons who do not have the required qualications may result in serious danger for the user of the appliance.

• Air the room in which the appliance is placed for a few minutes (the size of the room for a product contain- ing isobuthane/R600a must be at least 4m

) to avoid damage to the cooling system.

• Do not refreeze partly thawed products.

• Do not store beverages in bottles and cans, especial- ly carbonated beverages, in the freezer chamber. The cans and the bottles may explode.

• Do not put frozen products, taken out directly from the freezer (lollies, ice cubes, etc.) into your mouth, their low temperature may cause severe frostbite.

• Make sure you do not damage the cooling system, by puncturing the refrigerant pipes in the evaporator or breaking the pipes. The refrigerant is ammable. If the refrigerant makes contact with the eyes, rinse them with clean water and call for medical assistance imme- diately.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similar qualied persons in order to avoid a hazard.

• This appliance is intended for food storage, do not use it for other purposes.

• When performing activities, such as cleaning, mainte- nance or moving, the appliance must be completely- 39 - disconnected from power supply (by pulling the plug out from the socket)

• This appliance can be used by children aged 8 years and older or by persons with physical, mental or sen- sory handicaps, or by those who are inexperienced or unfamiliar with the appliance, provided they are su- pervised or have been instructed how to safely use the appliance and are familiar with risks associated with the use of the appliance. Ensure that children do not play with the appliance. Cleaning and maintenance of the appliance should not be performed by children un- less they are 8 years or older and are supervised by a competent person.

• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufac- turer.

• If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, its service agent or similar qualied persons in order to avoid a hazard.

• In order to obtain more space in the freezer, you can remove the drawers and place the food directly on the shelves. This has no eect on the product mechanical properties and cooling performance. Declared freezer capacity was calculated with the drawers removed.

• WARNING: Do not damage the refrigerant circuit.

• This appliance is not intended for use at altitudes ex- ceeding 2000 m.

WARNING: Risk of re / ammable

• Children aged from 3 to 8 years are allowed to load- 40 - and unload refrigerating appliances.

• WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged. To avoid contamination of food, please respect the fol- lowing instructions:

• Opening the door for long periods can cause a sig- nicant increase of the temperature in the compart- ments of the appliance.

• Clean regularly surfaces that can come in contact with food and accessible drainage systems.

• Store raw meat and sh in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.

• Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-cream and making ice cubes.

• One-, two- and three-star compartments are not suitable for the freezing of fresh food

• WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unles they are of the type recommended by the manufac- turer Compartments TYPE Target storage temp.[

Appropriate food 1 Fridge +2≤+8 Eggs, cooked food, packaged food, fruits and vegetables, dairy products, cakes, drinks and other foods are not suitable for freezing.

≤-18 Seafood (sh, shrimp, shellsh), freshwater aquatic products and meat products (recommended for 3 months, the longer the storage time, the worse the taste and nutrition), suitable for frozen fresh food.

≤-18 Seafood (sh, shrimp, shellsh), freshwater aquatic products and meat products (recommended for 3 months, the longer the storage time, the worse the taste and nutrition), are not suitable for frozen fresh food.

≤-12 Seafood (sh, shrimp, shellsh), freshwater aquatic products and meat products (recommended for 2 months, the longer the storage time, the worse the taste and nutrition), are not suitable for frozen fresh food

≤-6 Seafood (sh, shrimp, shellsh), freshwater aquatic products and meat products (recommended for 1 months, the longer the storage time, the worse the taste and nutrition), are not suitable for frozen fresh food.- 41 -

compartment -6≤0 Fresh pork, beef, sh, chicken, some packaged processed foods, etc. (Recommended to eat within the same day, preferably no more than 3 days). Partially encapsulated processed foods (non-freezable foods) 7 Chill 2≤+3 Fresh/frozen pork, beef, chicken, freshwater aquatic products, etc.(7 days below 0

C is recommended for consumption within that day, preferably no more than 2 days). Seafood (less than 0 for 15 days, it is not recommended to store above 0

8 Fresh Food 0≤+4 Fresh pork, beef, sh, chicken, cooked food, etc. (Recommended to eat within the same day, preferably no more than 3 days) 9 Wine +5≤+20 red wine,white wine,sparkling wine etc.

• Note: please store dierent foods according to the compartments or target storage temperature of your purchased products.

• If the refrigerating appliance is left empty for long periods, switch o, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.

• Water dispenser cleaning (special for water dispenser products): Clean water tanks if they have not been used for 48 h; ush the water system connected to a water supply if water has not been drawn for 5 days.

• Pursuant to Commission Regulation (EU) 2019/2019, the minimum availability period for spare parts nec- essary to repair the appliance is 7 or 10 years de- pending on the type and purpose of the spare part.

• The list of spare parts and the ordering procedure are available on the websites of the manufacturer, importer or an authorized representative.

• For more information about the product, please refer to the EU EPREL Product Database at https://eprel. ec.europa.eu. For more information, please use your mobile device to scan the QR code on the energy la- bel or enter the product model listed on the energy label in the EPREL search engine https://eprel.ec.eu- ropa.eu/- 42 -

INSTALLATION AND OPER-

ATING CONDITIONS OF THE

APPLIANCE This refrigeration appliance is not intended for use as a built-in appliance. Installation before using the appliance for the rst time

• Take the product out of the package, remove the scotch tape protect- ing the door and the equipment. Any remaining adhesive stains may be removed with a mild washing agent.

• Do not throw away the polystyrene elements of the packaging. If it is necessary to transport the fridge-freezer, pack it in the polystyrene elements and lm as well as protect ing it with scotch tape

• Clean the interior surface of the fridge- freezer and the elements of the equipment with a washing agent dissolved in lukewarm water, then wipe it dry.

• Place the fridge-freezer on an even, at and stable surface, in dry, aired and shaded room, far from the heat sources such as: oven, hob, central heating radiators, central heating pipes, hot water in- stallation, etc.

• On the exterior surface of the product may be a protective foil, this foils should be removed.

• Make sure the appliance is placed in a horizontal position by screwing in the 2 adjustable front legs (g. 3)

• To ensure that the door opens freely, the distance between the side of the appliance (on door hinges side) and the wall is shown on gure 5.*

• Ensure adequate ventilation of the room and free air circulation from all sides of the appliance (g. 6).* Minimum distances from the heat sources

• from the electric gas and other ovens - 30 mm,

• from oil or coal red ovens - 300 mm,

• from built-in ovens - 50 mm If there is no possibility of ensuring the above- mentioned distances, provide an appropriate insulation board.

• The rear wall of the refrigerator, in particular, the condenser and oth- er elements of the cooling system must not contact other elements, which may damage them, (e.g. central heating pipes and the water supply pipes).

• It is forbidden to readjust or modify any parts of the unit. It is crucial not to damage the capillary tube visible in the compressor recess. The tube may not be bent, straightened or wound.

• If the capillary tube is damaged by the user the guarantee will be void (g. 8).

• In some models the handle is put into the appliance, You should screw it with Your own screwdriver,

• Do not damage the refrigerant circuit- 43 - Mains connection

• Prior to connection, it is recommended to set the temperature control knob to an „OFF” or other position that disconnects the appliance from the power supply (See page with the control description).

• This appliance should be connected to AC 220-240V 50Hz supply socket. The socket must be tted properly, and must be supplied with an earthing conduit and a 10A fuse.

• It is a legal requirement that the appliance is properly earthed. The manufacturer will not be held liable for any damage or injury which may result from the failure to full this requirement.

• Do not use adapters, multiple sockets and two-wire extension leads. If it is necessary to use the extension lead, it must be equipped with a protection ring and a single socket and must have a VDE/GS safety certicate.

• If an extension lead is used (with a protection ring and safety certif- icate), its socket must be located at a safe distance, away from the sinks, and must not be in a place where it could be ooded by water or waste water.

• See the type plate at the lower part of the internal wall of the appli- ance for detailed specications**. Disconnecting the mains Make sure the appliance can be easily disconnected from the mains, either by pulling the plug out of the mains socket, or by switching the two-pole switch o (g. 9). Climate range The information about the climate range of the appliance is provided on the rated plate. It indicates at which ambient temperature (that is, room temperature, in which the appliance is working) the operation of the appliance is optimal (proper). Climate class Allowable ambient temperature SN Extended Temperate This refrigeration appliance is intended for use at an ambient temperature ranging between 10°C and 32°C N Temperate This refrigeration appliance is intended for use at an ambient temperature ranging between 16 °C and 32°C ST Subtropical This refrigeration appliance is intended for use at an ambient temperature ranging between 16 °C and 38 °C T Tropical This refrigeration appliance is intended for use at an ambient temperature ranging between 16 °C and 43 °C

• Only free-standing appliances ** According to the model- 44 - UNPACKING During transportation, pro- tective packaging was used to protect the appliance against any damage. After unpacking, please dispose of all elements of packaging in a way that will not cause damage to the envi- ronment. All materials used for packaging the appliance are environmentally friendly; they are 100% recyclable and are marked with the appropriate symbol.Important! Packaging materials (bags, polyethylene, polystyrene, etc.) should be kept away from children during unpack- ing.

DISPOSAL OF OLD APPLIANCE

In accordance with European Direc- tive 2012/19/EU and local legislation regarding used electrical and elec- tronic goods, this appliance is marked with the symbol of the crossed-out waste container. This marking indi- cates that the appliance must not be disposed of together with other household waste after it has been used. The user is obliged to hand it over to waste collection centre collecting used elec- trical and electronic goods. The collectors, includ- ing local collection points, shops and local authori- ty departments provide recycling schemes. Proper handling of used electrical and electronic goods helps avoid environmental and health hazards re- sulting from the presence of dangerous compo- nents and the inappropriate storage and process- ing of such goods.- 45 - CONTROLS Appliance controls The control panel is shown in gure 10. For reference it is also shown below: The control panel is located inside the appliance on the top wall of the re- frigerator compartment. It allows you to select the temperature setting according to the following sequence: 2 -> 4 -> 5 -> 6 -> 8 or activate rapid cooling function (Fast Cool). You can change settings by consecu- tive pressing the SET button. Setting 8 The highest temperature inside the appliance (warmer) Settings 4 / 5 / 6 Medium temperature inside the appliance Setting 2 The lowest temperature inside the appliance (cooler) The Fast Cool function - enables rapid cooling of food products so they stay fresh longer. The function will be automatically disabled after 3 hours or when the temperature inside the refrigerator compartment reaches

C. The function may be disabled sooner by selecting the desired tem- perature with the SET button. Refrigerator door opening alarm: When the refrigerator is open over 3 minutes, the buzzer will buzz. Close the door or press any button to stop the alarm, but for the latter, the alarm will go o again after 3 minutes. The control panel is located inside the appliance on the top wall of the re- frigerator compartment. It allows you to select the temperature setting according to the following sequence: 5 -> 4 -> 3 -> 2 -> 1 or activate rapid cooling function (Fast Cool). You can change settings by consecu- tive pressing the SET button.- 46 - Setting 1 The highest temperature inside the appliance (warmer) Settings 2 - 4 Medium temperature inside the appliance Setting 5 The lowest temperature inside the appliance (cooler) The Fast Cool function - enables rapid cooling of food products so they stay fresh longer. The function will be automatically disabled after 26 hours. The function may be disabled sooner by selecting the desired temperature with the SET button. Refrigerator door opening alarm: When the refrigerator is open over 3 minutes, the buzzer will buzz. Close the door or press any button to stop the alarm, but for the latter, the alarm will go o again after 3 minutes. Recommended settings Ambient temperature Setting a value on the panel Set the value on the dial

C- 47 - Additional information on the temperature

• The temperature inside the appliance is inuenced by many factors. How you set the temperature control dial depends on the ambient temperature, sun exposure, how often you open the door and the amount of food stored. The middle setting of the dial is most optimal in most cases.

• Do not put food into the fridge freezer before it has reached its oper- ating temperature, which takes minimum 4 hours.

• Do not change the temperature settings due to the change in the season of the year. The ambient temperature increase will be detect- ed by the sensor and the compressor will be switched on automati- cally for a longer period of time in order to maintain the temperature set inside the chambers.

• The slight changes in temperature are perfectly normal and may oc- cur, for instance during the storage of great quantities of fresh prod- ucts in the fridge, or when the door is open for a longer period of time. This will not aect the condition of the stored foodstu, and the temperature will quickly return to its set value. Adjust the humidity level inside the VitControl box* (Fig. 17) Various products, such as fruit or vegetables, require a suitable level of humidity in order to stay fresh longer. VitControl box is equipped with a slider (Fig. 17), so the box can be supplied with more air, which will change the humidity level inside the box.

Fruits require lower humidity level, therefore air supply must be opened with a slider. With vegetables it is the other way round, to keep them fresh longer, you should close the air ow with a slider. The exact slider position depends on your own preferences. Air ow control slider* (Fig. 18) The temperature inside the refrigerator compartment is also inuenced by the position of the slider controlling the amount of air supplied to the compartment via no-frost system. Setting the slider to min. position will result in supplying less cool air into the refrigerator compartment. This results in minimal increase in temperature. When the slider in max. position, the refrigerator compartment will be supplied with larger amount of air. This results in a slight temperature drop inside the compartment. Fresh Zone box* These are perfect conditions for storing meat, sh, and other food prod- ucts that require special conditions. Lower temperature preserves food products avour, aroma and nutritional values. Due to special guides, access to the Fresh Zone box is extremely simple and convenient.- 48 -

OPERATION AND FUNCTIONS

Storage of food in the fridge-freezer

• The products should be placed on plates, in containers or packed in food wrap. Distribute them evenly over the shelves.

• If the food contacts the rear wall, it may cause frosting or wetting of the products.

• Do not put dishes with hot food into the fridge

• Products which absorb avours easily such as butter, milk, white cheese and products with intense avour, such as sh, smoked meat, hard cheese must be placed on shelves, packed in food wrap or in tightly sealed containers.

• The storage of vegetables containing signicant quantities of water will cause the deposition of condensation on the vegetable contain- ers, it does not impact on the proper functioning of the fridge.

• Before putting the vegetables into the fridge, dry them well.

• Excessive moisture shortens the shelf life of vegetables, especially the leafed vegetables.

• Do not wash the vegetables before storing in the refrigerator. Wash- ing removes the natural protection, therefore it is better to wash the vegetables directly before consumption.

• It is recommended to place the products in freezer drawers 1, 2, 3* up to natural loading capacity (Fig. 11a / 11b).**

• Stacking of products on the freezer shelves is acceptable.*

• It is acceptable to place products beyond the natural loading capacity by 20-30 mm.**

• In order to increase the loading capacity of the freezer chamber and allow the stacking of products on the freezer evaporator wire shelves up to maximum height it is possible to remove drawers 1 and 2.* Freezing food**

• Practically all the food products, except for vegetables consumed raw, such as lettuce can be frozen.

• Only food products of the highest quality, divided into small portions for single use, should be frozen.

• Products should be packed in materials that are odourless, resistant to air and moisture penetration, and not susceptible to fat. Plastic bags, polyethylene and aluminium sheets are the best wrapping ma- terials.

• The packaging should be tight and should stick to the frozen prod- ucts. Do not use glass containers.

• Keep fresh and warm foodstu at ambient temperature away from the products, which have already been frozen.

• We advise you not to place more of fresh food at a time to the freezer per day (see table witch technical specication).- 49 -

• In order to maintain optimum quality of the frozen food, reorganise the food that is in the middle of the freezer, so that it does not touch the products that are not yet frozen.

• It is recommended that you move the already frozen products to one side and place the fresh products that are to be frozen on the oppo- site side, as close to the rear and side walls as possible.

• To freezing products, use space marked

• Bear in mind that the temperature in the freezer is aected by sev- eral factors, including the ambient temperature and the quantity of food products in the chamber, the frequency of opening the door, the amount of frost in the freezer, and the thermostat setting.

• If you cannot open the freezer door immediately after closing it, al- low 1-2 minutes for the negative pressure to compensate, and try again to open the door. The storage time for frozen products depends on their quality before freezing when fresh, and on the storage temperature. The following stor- age periods are recommended when the temperature of -18°C or lower is maintained: Products Months Beef 6-8 Veal 3-6 Giblets 1-2 Pork 3-6 Poultry 6-8 Eggs 3-6 Fish 3-6 Vegetables 10-12 Fruit 10-12 Do not store frozen food in rapid cooling chamber. Ice cubes can be pre- pared and stored in this chamber. Note: If the appliance does not have a freezer compartment (

), it is not suitable for freezing foodstus.

• Applicable to appliances with a freezer compartment at the bottom of the appliance. ** Applicable to appliances with a freezer compartment

*** Not applicable to appliances with a freezer compartment marked !- 50 -

• Do not place fridges or freezers next to radiators, heaters, stoves or in direct sunlight.

• Make sure that air vents are not covered up and clean the dust o them once or twice a year.

• Select the right temperature: 6 to 8°C in your refrigerator and -18°C in your freezer is sucient.

• When on holiday, turn up the temperature in your fridge.

• Only open your fridge or freezer when necessary. It helps if you know what food each contains and where it is located. Return food to the fridge or freezer as soon as possible after you have used it so that it does not warm up too much.

• Wipe the inside of your fridge regularly with a cloth soaked in a mild detergent. Appliances which are not self-defrosting will require regu- lar defrosting. Do not allow frost layers thicker than 10 mm to form.

• Keep the seal around the door clean, otherwise it will not shut prop- erly. Always replace broken seals. Understanding the stars

Temperature is at least -6°C; sucient to store frozen food for about a week. Drawers or compartments marked with one star used to be a feature of (mostly) cheaper fridges.

Food can be stored at -12°C or below for 1-2 weeks without losing its taste. Not suitable for freezing food.

This rating is mainly used to store foods at -18°C or below. Can also be used to freeze up to 1 kilogram of fresh food.

This appliance is suitable for storing foods at -18°C or be- low and freezing larger quantities of fresh foods.- 51 - Practical tips Due to the natural circulation of the air in the appliance, there are dif- ferent temperature zones in the refrigerator chamber.

• The coldest area is directly above the vegetables drawers. Use this area for all delicate and highly perishable food e.g.: - Fish, meat, poultry - Sausage products, ready meals - Dishes or baked goods containing eggs or cream - Fresh dough, cake mixtures - Pre-packed vegetable and other fresh food with a label stating it should be kept at a temperature of approx 4

• The warmest area is in the top section of the door. Use this for storing butter and cheese. Food that should not be stored in a refrigerator

• Not all food is suitable for storing in the refrigerator, particularly: - Fruit and vegetables which are sensitive to cold, such as bananas, avocado, papaya, passion fruit, aubergines, peppers, tomatoes and cu- cumbers. - Fruit which is not yet ripe - Potatoes

Example of storing the food - see gure 12. To achieve the most eective food preservation for the longest possible time and to avoid wasting any food, position the products as shown in Figure 12. In addition, this gure illustrates the layout of drawers, bas- kets and shelves, which allows the most ecient use of energy. Optimal temperature and storage conditions will extend product shelf life and optimize electricity consumption. Optimal storage temperature range should be stated on the food product packaging.- 52 -

DEFROSTING, WASHING AND

MAINTENANCE Never clean the product’s casing or plastic parts using solvents or strong, abrasive detergents (e.g. washing powders or creams)! Use mild liquid detergents and soft cloths only. Do not use sponges. External surfaces made of plastic should be cleaned with a microber cloth, otherwise irreversible micro scratches will appear. Defrosting the fridge***

• Frost settles on the rear wall of the fridge chamber. It is removed automatically. During the defrosting, the condensate, which contains contaminants may clog the opening in the through. Should it occur, carefully unclog the opening with the cleaning plug (g. 13).

• The appliance operates in cycles: it refrigerates (then the frost set- tles on the rear wall), and defrosts (water ows down the rear wall)

• Disconnect the appliance from the mains before cleaning by remov- ing the plug from the mains socket or switching o the fuse. Prevent water from penetrating the control panel or the light.

• Do not use defrosting aerosols. They may cause the formation of an explosive mixture, or contain solvents which may damage the plastic components of the appliance and even be harmful to health.

• Make sure the water used for cleaning does not ow into the evapo- ration container through the discharge opening.

• The whole appliance, except for the door gasket must be cleaned with a mild cleaning detergent. The door gasket should be cleaned with water and wiped dry.

• Wash all the accessories (vegetable containers, door shelves, glass shelves, etc.).

• WARNING: Do not use mechanical devices or other means to accel- erate the defrosting process, other than thode recommended by the manufacturer Defrosting the freezer**

• It is recommended to combine defrosting the appliance with washing it.

• Excessive accumulation of ice on the freezing areas impairs the ap- pliance’s freezing capacity and increases the energy consumption.

• Defrost the appliance at least once or twice a year. In case of a higher ice build-up, defrosting must be carried out more frequently.

• If there is food in the freezer, set the knob to the max. position about 4 hours before the planned defrosting. This will ensure the possibility of storing the food at the ambient temperature for a longer time.

• After taking the food out of the freezer, put it in a container, wrap it with several layers of paper, a blanket and store it at a cool place.

• The defrosting operation should last as short as possible. Long stor- age of food at the ambient temperature shortens their shelf life.- 53 - Defrost the freezer chamber following steps:**

• Switch of the appliance using the control panel and pull the plug out from the socket..

• Open the door and remove the food from the freezer.

• Depending on the model, pull out the drainage tube located in the bottom of the freezer compartment and place a suitable vessel un- derneath.

• Leave the door open, this will speed up the defrost process. Addi- tionally, a pot with hot water (not boiling) may be placed inside the freezer compartment.

• Wash the interior of the freezer and wipe it dry.

• Switch on the appliance as per the relevant point in the manual. Automatic fridge defrosting**** The fridge chamber has been equipped with an automatic defrosting function. However, frost may settle on the rear wall of the fridge cham- ber. This happens usually, when large quantities of fresh food products are stored in the fridge. Automatic fridge defrosting**** The freezer chamber has been equipped with an automatic defrosting function (no-frost). The food is frozen in the cooled circulation air, and the moisture from the freezer chamber is discharged outside. As a result, no ice and frost is produced in the freezer and the products do not freeze on each other. Washing the fridge and freezer chambers manually**** It is recommended to wash the fridge and freezer chambers at least once a year. This prevents the formation of bacteria and bad odours. Switch o the appliance, using button (1), remove the food from the chambers and wash them using water with a mild detergent. Then, wipe the cham- bers dry with a cloth. Taking out and putting in the shelves***** Slide the shelf out, then slide it in as much as possible so that its clamp could t the guide groove (g. 15). Taking out and putting in the door shelf***** Lift the door shelf, remove it and put it back from the top into its required position (g. 16). WARNING! You must not put an electric heater, a heating fan or a hair dryer into the freezer by any means. ** Applicable to appliances with a freezer compartment

Not applicable to appliances with a Frost-free System. *** Applicable to appliances with a refrigerator compartment Not applicable to appliances with a Frost-free System. **** Applicable to appliances with a Frost-free System. ***** Does not apply to freezers- 54 - TROUBLE-SHOOTING Problems Possible causes Remedies The appliance does not work The electric circuit is dis- rupted - check whether the plug is properly inserted into the socket - check whether the power cable of the appliance is not damaged - check whether there is voltage in the socket, by plugging another appliance, e.g. a night lamp - check whether the ap- pliance is switched on by setting the thermostat to a position above 0. The lighting inside the chamber does not work The bulb is loose or fused (only appliances with bulb lightning type) - t the bulb correctly or replace it (see section above “Replacing the interior light bulb) The appliance works contin- uously Incorrect setting of the adjustment knob - reset the knob to a lower position See. ”Temperature inside the appliance is not low enough for description of other possible causes See. ”Temperature inside the appliance is not low enough for description of other possible remedies Water collects in the lower part of the appliance The water discharge open- ing is clogged (depending on the model) - clean the discharge opening (see the operating manual – chapter entitled ”Defrosting the fridge”) Internal air circulation ob- structed - place the food and con- tainers in such a way as that they do not touch the rear wall of the fridge The appliance generates unusual noise Incorrect levelling of the appliance - level the appliance prop- erly The appliance is touch- ing furniture and/or other objects - place the appliance at a location that ensures proper clearances around it- 55 - Problems Possible causes Remedies Temperature inside the appliance is not low enough or too high Incorrect setting of the adjustment knob - reset the knob to a higher position The ambient temperature is higher or lower than the cli- mate range from table with technical specication - the appliance is adapted to operation in the climate range from table with tech- nical specication. The appliance is located in a sunlit place or near heat sources - move the appliance to another place. Observe the guidelines contained in the manual Too much warm food loaded at a time - wait 72 hours until the food becomes cool (freezes) and the required tempera- ture is reached inside the chamber Internal air circulation ob- structed - place the food and con- tainers in such a way that they do not touch the rear wall of the fridge The air circulation at the back of the appliance is obstructed - move the appliance min. 30 mm away from the wall The door of the fridge/freez- er is opened too often and/ or remains open for too long - reduce the frequency of opening the door and/or shorten the time when door remains open The door does not close completely - place the food and con- tainers so that they would not interfere with door closed The compressor is switched on too rarely - check whether the ambi- ent temperature is not lower than climate class Door gasket inserted incor- rectly - press the gasket in Certain sounds can be heard during normal use of the refrigerator, which do not aect its correct operation. Sounds, which can be easily prevented:

• noise caused by the appliance which is not level - adjust the position with the adjustable turn-in front feet. Alternatively, place pads made of soft material under the rear rollers, especially when the appliance is placed on tiles.

• touching the adjacent piece of furniture - move the refrigerator away.

• creaking of the drawers or shelves - take out and put back the drawer or shelf.

• sounds of clinking bottles - move bottles apart. Sounds heard during normal use are mainly due to operation of the ther- mostat, compressor (switching on) and cooling system (thermal expan- sion and contraction of the radiator caused by ow of the cooling agent).- 56 -

SALES SERVICE Warranty The manufacturer shall not be held liable for any damage caused by im- proper use of the product. Service

• The manufacturer recommends that all repairs and adjustments be carried out by the Factory Service Technician or the Manufacturer’s Authorized Service Point. For safety reasons, repairs should be re- ferred to professionals.

• Repairs carried out by unqualied persons may seriously endanger the appliance user.

• The minimum warranty period for the appliance oered by the man- ufacturer, importer or authorized representative is given in the war- ranty card.

• The warranty shall be void if you make any independent adaptations or alterations, tamper with seals or other appliance safety devices or its parts or interfere with the appliance contrary to operating in- structions. In the event of appliance malfunction, request assistance or repair. If your appliance needs repair, please contact the service centre. Please see website for address and contact details of our service centre. Before contacting us, please have ready the appliance serial number, which can be found on the identication sticker: For your convenience, please write it down below: Certifi cate of compliance CE and UKCA The Manufacturer hereby declares that this product complies with the general require- ments pursuant to the following European Directives and analogous UK requirements:

• The Low Voltage Directive 2014/35/EC / Electrical Equipment (Safety) Regulations

VAŽNE SIGURNOSNE INFOR-
