Product type	Soundbar with integrated subwoofer, remote control and wall mount
Brand and model	SilverCrest SSB 36 B2
Dimensions (W x H x D)	Approx. 94 x 8.2 x 11.9 cm
Weight	Approx. 2.2 kg
Output power	2 x 18 W RMS
Power supply	External power adapter: input 100-240 V ~ 50/60 Hz, output 18 V = 2 A
Protection class	Soundbar: III, power adapter: II
Bluetooth version	Bluetooth v3.0, range up to 10 m
Supported audio formats	PCM 2.0 (PCM stereo)
Audio inputs	HDMI (ARC), LINE IN (3.5 mm jack), AUX IN (RCA L/R)
Audio output	SUB OUT (RCA for external subwoofer)
Remote control battery	CR2025 3 V (pre-installed)
Preset sound modes	MUSIC, MOVIE, DIALOG
Sound settings	Volume, bass (BASS), treble (TREBLE), mute (MUTE)
Additional features	Wall mountable (mounting brackets and drilling template included), auto standby after 20 min without signal
Operating temperature	10 °C to 35 °C
Operating humidity	40 to 85 % RH
Warranty	3 years from purchase date (conditions in manual)

Frequently Asked Questions - SSB 36 B2 SILVERCREST

How to connect the soundbar to a TV via HDMI ARC?

Make sure your TV has an HDMI ARC port. Use a compatible HDMI ARC cable. Connect the cable between the HDMI (ARC) port on the soundbar (8) and the HDMI ARC port on the TV. Select the HDMI (ARC) input on the soundbar using the HDMI (ARC) 17 button on the remote. Enable PCM 2.0 audio output on the TV if necessary.

How to pair the soundbar via Bluetooth with a smartphone?

Press the Bluetooth 15 button on the remote or the PAIR 5 button on the device. The blue LED flashes. On your smartphone, enable Bluetooth and search for devices. Select SSB 36 B2. If a password is requested, enter 0000. The connection is established when the blue LED stays on.

What to do if there is no sound after connecting the soundbar?

Check that the volume is not too low (use VOL -/+ 20 buttons). Make sure the correct source is selected (HDMI, AUX, LINE IN, or Bluetooth). Verify that the source device (TV, smartphone) is outputting sound. If using HDMI ARC, confirm the TV is set to PCM audio output. Press MUTE 16 to deactivate mute mode.

How to adjust bass and treble?

To adjust bass and treble, you must first be in MUSIC mode (press the MUSIC 19 button). Use the BASS -/+ 22 buttons for bass and TREBLE -/+ 26 buttons for treble. The settings are not retained if you change the sound mode.

The soundbar turns off automatically, is this normal?

Yes, the soundbar enters standby mode after approximately 20 minutes without an audio signal or active Bluetooth connection. To turn it back on, press the POWER 28 button on the remote.

Can I connect an external subwoofer?

Yes, the soundbar has a SUB OUT 7 output (RCA jack). You can connect an active subwoofer. The subwoofer is automatically controlled by the soundbar.

How to clean the soundbar?

First unplug the power adapter. Use a slightly damp cloth (not wet). For stubborn dirt, you can add a little mild dish soap. Do not use solvents, alcohol, or thinners. Avoid water entering the inside of the device.

What to do if the remote control stops working?

Check that the CR2025 battery is correctly inserted and in good condition. If necessary, replace it. Make sure there is no obstacle between the remote and the soundbar. Also check that the battery contacts are clean.

Can I mount the soundbar on the wall?

Yes, the soundbar can be mounted on the wall using the provided wall mounts. Use the drilling template to mark the holes. Drill with a 5 mm bit if using the supplied wall plugs. Ensure no electrical cables or pipes are behind the wall. The mounts must be securely screwed.

Which cables are included in the box?

The box contains: the soundbar, the power adapter, a remote control with pre-installed CR2025 battery, a stereo RCA cable, two wall mounts, four screws (4x25 mm and 4x50 mm), four wall plugs, a drilling template, and the instruction manual.

USER MANUAL SSB 36 B2 SILVERCREST

Operating instructions

IAN 274307

Deutsch. 2

Francais 12

Italiano 22

English 32

Chere cliente, cher client,

1. Overview 32

2. Intended purpose 33

3. Safety instructions 33

4. Items supplied 35

5.Before using for the first time 35

5.1 Remote control 35
5.2 Setting up / Wall mounting 35
5.3 Overview - Connections 36
5.4 How to use 36

1. Operation 36

6.1 Selecting the type of connection 36

6.2 Sound settings 36
6.3 HDMI (ARC) connection 37
6.4 Bluetooth 37

1. Cleaning and storing 38
2. Disposal 38
3. Troubleshooting 38
   10.Technical specifications 39
   11.Warranty of the HOYER Handel GmbH ..39

Service Centre 40

1. Overview

Please observe the illustrations on the fold-out page.

Soundbar

1	Multi-coloured LED
	Red: Standby operation
	Green: LINE IN
	Yellow: HDMI (ARC)
	White: AUX IN
	Blue: Bluetooth
2	POWER button
3	SOURCE button
4	VOL-/+ buttons
5	PAIR button
6	LINE IN socket
7	SUB OUT socket
8	HDMI(ARC) socket
9	DC IN @@@
10	AUX IN L/R socket

Accessories

11	Power unit
12	Stereo cinch cable
13	2 wall brackets

Remote control

14	Transmission LED
15	Button $
16	MUTE button
17	HDMI (ARC) button
18	AUX button
19	MUSIC, MOVIE, DIALOG buttons
20	VOL -/+ buttons
21	▶I button
22	BASS -/+ buttons
23	Battery compartment
24	▶II button
25	I←A button
26	TREBLE -/+ buttons
27	LINE IN button
28	POWER Ⓞ button

Installation

29	Screw (4x 25 mm / 4x 50 mm)
30	Rawlplug (4)
	Drilling template (no image)

Thank you for your trust!

Congratulations on the purchase of your new soundbar.

For a safe handling of the device and in order to get to know the entire scope of features:

• Thoroughly read these user instructions prior to initial use.
• Above all, observe the safety instructions!
• The device should only be used as described in these user instructions.
• Keep this copy of the user instructions for future reference.
• If you pass the device on to someone else, please include this copy of the user instructions. The user instructions are a part of the product.

We hope you enjoy using your new soundbar!

Trademarks

The Bluetooth® word mark and the Bluetooth logo are registered trademarks of the Bluetooth SIG, Inc. (Special Interest Group), any use of the trademark by the Hoyer Handel GmbH is effected within the framework of a licence.

2. Intended purpose

This is a consumer electronics device. The soundbar is intended for playing sound from audio devices.

The device is designed for private home use and must not be used for commercial purposes. The device must only be used indoors.

3. Safety instructions

Warnings

If necessary, the following symbols and warnings will be used in these user instructions:

DANGER! This symbol, in combination with the note "Danger" means a high risk. Failure to observe this warning may result in injury to life and limb.

DANGER! Risk of electric shock! This symbol, in combination with the note "Danger! Risk of electric shock" means a high risk. Failure to observe this warning may result in injury to life and limb.

WARNING! This symbol, in combination with the note "Warning" means a moderate risk. Failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: failure to observe this warning may result in minor injury or material damage.

NOTE: circumstances and specifics that must be observed when handling the device.

DANGER for children and people with disabilities

Children must not play with packing material. Children must not play with the packing material. There is a risk of suffocation!

This device is not designed to be used by people (including children) with limited physical, sensory or mental capabilities or people without adequate experience and/or understanding, unless they are supervised by someone responsible for their safety or are instructed by them on how to use the device.

Children must not play with the device.

Keep the device out of the reach of children.

DANGER to and from pets and livestock

Electrical devices can represent a hazard to pets and livestock. In addition, animals can also cause damage to the device. For this reason you should keep animals away from electrical devices at all times.

DANGER! Risk of electric shock due to moisture

The device must not be used in extreme conditions, e.g. rooms with high humidity (bathrooms).
Protect the device and power unit from dampness and dripping or splashing water. For instance, never place vases or something similar filled with liquid on or in the vicinity of the device.
- Never touch the device and power unit with wet hands.
Pull the power unit out of the wall socket if liquid gets into the device.
Should liquid enter the device, have it checked by an expert before starting the device up again.

DANGER! Risk of electric shock

• Never put the device into operation if there are visible damages to the device, the power unit or the cable or if the device has been dropped before. Do not use the device again, but have it checked by a specialist workshop.
  Never open the casing of the device or power unit.
  Connect the cable to the device before plugging the power unit into a wall socket.
  Only connect the power unit to a properly installed, easily accessible wall socket, the voltage of which corresponds to the specifications on the rating plate. The wall socket must continue to be easily accessible after the device is plugged in.
  Ensure that the cable cannot be damaged by sharp edges or hot surfaces.
  Ensure that the cable is not trapped or crushed.
  When removing the power unit from the wall socket, always pull the power unit and never the cable.

Pull the power unit out of the wall socket, ...

...if there is a fault,
...before connecting the device to the power unit,
...before you clean the device and
...during thunderstorms.

For a complete mains separation, pull the power unit out of the wall socket. Even if it is switched off, a small amount of power is always used as long as the power unit is plugged in.
To avoid any risk, do not make modifications to the device. Repairs must be carried out by a specialist workshop or the Service Centre.

Batteries

DANGER OF EXPLOSION! Be sure to observe the correct polarity when inserting the battery.

Clean the battery and possibly device terminals before you insert the batteries.
Batteries can be life-threatening if swallowed. Therefore you should store batteries and the remote control out of the reach of young children. If a battery has been swallowed, medical assistance must be sought immediately.
Batteries must not be charged or reactivated by other means, nor must they be dismantled, thrown into a fire or short-circuited.
- Remove the batteries from the remote control if you do not intend to use the remote control for a prolonged period of time, or if the battery runs out of power. The battery might leak and damage the remote control.
Do not subject batteries to extreme conditions, e.g. do not place the remote control on radiators or expose it to direct sunlight. Otherwise, there is an increased danger of batteries leaking.
If battery acid has leaked, avoid contact with the skin, eyes and mucous membranes. In case of contact with the acid, rinse the affected area at once with plenty of clean water and seek medical assistance immediately.
Do not swallow the battery, risk of chemical burn. If the button cell battery in the remote control supplied is swallowed, it can cause severe internal chemical burns within 2 hours, which can result in death.
Keep new and used batteries away from children.
If the battery compartment cannot be closed properly, you must no longer use the remote control, and it must be kept away from children.
If you think the batteries could have been swallowed or have gotten into any part of the body, seek medical help immediately.

WARNING! Risk of material damage

If you notice any irregularities (e.g. unusual noises, strange smells or smoke developing), pull the power unit out of the wall socket immediately. Do not use the device any longer.
If the device is moved from a cold location to a warm location, condensate may form in the device. Leave the device switched off for a few hours.

Place the device on a stable, flat surface.
Protect the device against damage, e.g. from: -Heat, direct sunlight and open flames - Impacts and similar violent effects
Candles and other open flames must be kept away from this product at all times in order to prevent the spread of fire.
Do not cover the power unit to prevent overheating.
Do not use any astringent or abrasive cleaning agents.
The device is fitted with non-slip plastic feet. As furniture is coated with a wide array of varnishes and synthetics, and is also treated with different care products, it cannot be fully ruled out that some of these materials contain ingredients that could attack and soften the non-slip plastic feet. If necessary, place a non-slip mat under the device.
Please ensure the following when mounting on a wall:

• The fixing material must be matched to the properties of the wall. If necessary, use fixing material other than that supplied.
• Make sure that in the installation location there are no pipes or cables in the wall (e.g. electricity, water, gas).
• If necessary, have the wall mounting carried out by an expert.

Notes on Bluetooth

Radio waves are potentially able to affect or even interfere with the operation of heart pacemakers, (sensitive) electronic devices and other radio waves (e.g. WLAN). Therefore, please observe the following notes.

People wearing heart pacemakers, should maintain a distance of 20 cm to the product.
- Radio waves may cause interferences, e.g. in mobile phones or hearing aids.
- Do not use the product in areas subject to explosion hazards.
In case of any interferences in other radio units (e.g. WLAN) occur, check by deenergizing the sound bar if this is the cause.
- Do not use the device in the vicinity of microwave ovens or devices generating magnetic fields.

4. Items supplied

1 soundbar
1 power unit 11
1 remote control
1 CR2025 3 V battery (inserted)
1 stereo cinch cable 12
2x4 screws 29 (25 mm / 50 mm)
4 rawlplugs 30
2 wall brackets 13
1 drilling template
1 copy of the user instructions
- Remove all packing material.
- Check that the device is undamaged.

In the case of incomplete delivery, please contact the responsible service centre of the manufacturer (see "Warranty of the HOYER Handel GmbH" on page 39). Please observe the illustrations on the fold-out page.

5. Before using for the first time

5.1 Remote control

Initial use

• Remove the transport lock from the battery compartment and remote control.

Changing the battery

DANGER OF EXPLOSION! If the battery is not correctly replaced. Replace only with the same or an equivalent type.

1. FIGURE A: open the battery compartment cover by unlocking it and sliding it in the direction of the arrow.
2. Replace the old battery with a new one.

WARNING! Ensure the correct polarity of the battery. The plus sign on the battery must be visible.

1. Close the battery compartment again.

5.2 Setting up / Wall mounting

NOTE: if you connect the device to a television set, place the device as centrally as possible below the set.

Setting up

1. Place the device on a level surface.
2. Connect the power unit 11 to the device.

Wall mounting

WARNING! Risk of material damage!

Please ensure the following when mounting on a wall:

• The fixing material must be matched to the properties of the wall. If necessary, use fixing material other than that supplied.
• Make sure that in the installation location there are no pipes or cables in the wall (e.g. electricity, water, gas).
• If necessary, have the wall mounting carried out by an expert.

In connection with the wall mounting, use HDMI right angle plugs so the plugs cannot be damaged by kinks.

1. FIGURE B: drill 2 holes per wall bracket 40~cm apart. If necessary, use the enclosed drilling template.
2. For the enclosed rawlplugs, use a drill with a diameter of 5mm
3. Insert the rawlplugs 30 into the drill holes.
4. Fasten the wall brackets 13 firmly to the wall using the screws 29.
5. Insert all of the cables used into the connections (see "Overview - Connections" on page 36).
6. Connect the power unit 11 to the device.
7. Hook the device into the wall brackets 13. Both wall brackets 13 must engage safely into the holder on the rear of the device.

5.3 Overview - Connections

CAUTION: make sure that the soundbar and the devices to be connected are switched off before you connect them. Please also read the user instructions for the devices which you are connecting.

NOTE: the HDMI (ARC) 8 connection is only able to function if all components are ARC-enabled. If necessary, old HDMI cables must be replaced with new ARC-enabled ones.

Input Use	Remote control but- ton	LED colour
AUX IN 10	Connection with ste- reo cinch cable 12, e.g. television set, CD player	AUX 18 white
LINE IN 6	Connection with 3.5 mm stereo jack ca- ble, e.g. MP3 play- er, telephone	LINE IN 27	green
HDMI (ARC) 8	Connection with HDMI (ARC) cable, e. g. to the HDMI- ARC connection of the television set, DVD player	HDMI (ARC) 17	yellow
Bluetooth	Radio connection, e.g. smartphone	$ 15	blue

• A subwoofer can be connected to the cinch socket of the SUB OUT 7 output. This is automatically controlled by the device.

5.4 How to use

NOTE: the device remains in standby mode after being switched off. In this mode, the power consumption of the device is low. Pull the power unit 11 out of the wall socket to disconnect it from the mains.

• Connect the power unit 11 with an easily accessible wall socket. The red LED 1 on the device lights up. The device is now in standby mode.

6. Operation

NOTES:

• All adjustments can be conveniently carried out with the remote control. The basic functions can also be carried out with the buttons on the device. Operation of the device in the instructions is usually described with the remote control.
  If you use the HDMI (ARC) 8 connection, the soundbar is usually switched on and off via the remote control of the connected device. The connected device must support this function.
  The device switches into the standby mode, ... if no Bluetooth connection is established within 20 minutes or if it does not receive a signal for 20 minutes.
• Press the POWER button 28 to switch on the device from standby mode.
• Press the POWER button 28 to switch the device into standby operation.

6.1 Selecting the type of connection

1. Press one of the AUX 18, LINE IN 27, HDMI (ARC) 17 or * buttons 15 to switch to the desired connection (see "Overview - Connections" on page 36).
2. On the audio device you can now start playback and select and control the music tracks.

6.2 Sound settings

NOTES:

Changes to the sound settings are acknowledged with brief flashing of the LED 1 until the minimum/maxi- mum value is reached.
- A level control of the treble sounds and basses is only possible with the setting "Music".

Controlling the volume

During play, press the VOL - / + 20 buttons on the remote control or VOL- +4 on the device. For a faster change of the volume, you can also keep the buttons pressed.

Muting the device

1. Press MUTE 16 to switch off the sound. The LED 1 flashes.
2. To switch the sound back on, press MUTE again or one of the VOL - / + 20 / 4 buttons. The LED 1 lights up.

Adjusting the tone quality

The tone quality can only be changed in the mode "Music". The settings are not stored when you change into a different mode

• Press one of the buttons 19 to select the presets for the tone quality for music (MUSIC), films (MOVIE) or dialogue (DIALOG).
• Only in the mode "Music": use the TREBLE - / + buttons 26 to adjust the treble sounds. If MOVIE or DIALOG is activated, an automatic change to MUSIC takes place.
• Only in the mode "Music": use the BASS - / + 22 buttons to adjust the bass sounds. If MOVIE or DIALOG is activated, an automatic change to MUSIC takes place.

6.3 HDMI (ARC) connection

Definition

HDMI stands for High Definition Multimedia Interface. Via this transmission route, digital images and audio signals can be transmitted.
- HDMI (ARC - Audio Return Channel) means that the cable is provided with an ARC channel. Via this channel, audio signals are transmitted in both directions.

The following modern devices are usually provided with an ARC output: television sets, games consoles or digital receivers. In the following, the connection to a television set is described.

Via the ARC channel of the HDMI cable, digital audio signals can be transmitted from the source device (e.g. television set) to the soundbar.

The audio transmission via the HDMI (ARC) socket 8 can only work if all components are ARC-enabled. If the transmission is unsuccessful, you must take one or possibly several of the following items into account:

The old HDMI cable must be replaced with a new ARC-enabled cable.
- Not every HDMI socket on the television set needs to support ARC. In this case, the HDMI cable on the television set must be connected to another ARC-enabled HDMI socket. Usually, the respective HDMI sockets are labelled with ARC. If not, refer to the user instructions of your television set.
For several television sets, the digital audio output must be activated. Select the audio output PCM 2.0 (PCM stereo).

1. Connect the socket HDMI (ARC) 8 by means of an ARC-enabled HDMI cable to an HDMI ARC socket of your television set.

2. Switch on the soundbar with the POWER button 28.

3. By pressing the HDMI (ARC) button 17, select the HDMI input.

4. Switch on the television set. When the connection is established for the first time, it may take several seconds until sound is output from the soundbar.

6.4 Bluetooth

Establishing connection

NOTES:

The identification of the device is "SSB 36 B2".
- After it has been switched over to Bluetooth, the device automatically attempts to establish a connection with the last paired device.
- Please observe that the establishment process of the connection may vary slightly depending on the device and the software used.

1. Press the button 15 to switch over to a Bluetooth connection. LED 1 flashes blue.
2. Switch on the audio device (e.g. smartphone) and start the Bluetooth connection.
3. The audio device will now receive the device identifi-cation "SSB 36 B2". If nothing happens, press the but- ton PAIR 5 on the device or the $ button 15 on the remote control for approximately 1 second. The blue LED 1 flashes rapidly.
4. Establish the connection with the soundbar on the audio device. If you are asked for a password, enter "0000". Both devices are now interconnected. LED 1 now lights up in blue and a beep is heard.

NOTE: usually, audio devices remember the identification of the device. In this case, it may not be necessary to establish the connection manually again if the Bluetooth function is activated.

1. Now play a song on the audio device. The sound is played back from the soundbar.
2. With the 25, 21 and 24 buttons you can select and control the music tracks.

Interruption of the connection

The connection is interrupted if

...one of the devices is switched off;
...the Bluetooth function is switched off;
...the range (approx. 10 metres) is exceeded;
...you press the buttons 15 or PAIR 5 until the blue LED is flashing. In this case, a new connection to another device can be established immediately.

7. Cleaning and storing

DANGER! Risk of electric shock!

Pull the power unit 11 out of the wall socket before you clean the device. Make sure that no liquid gets into the device.

• Clean the device with a slightly damp cloth. In case of persistent contamination, you can also use a slightly more gentle cleaner such as detergent. Solvents, spirits, thinners etc. must not be used, as they can damage the surface of the device.
• When not using the device, store it in a place where neither high temperatures nor moisture can affect it. Remove the battery from the remote control.

8. Disposal

This product is subject to the provisions of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories may symbol. Products identified with this symbol m carded with normal household waste, but mu a collection point for recycling electric and e pliances. Recycling helps to reduce the consum materials and protect the environment.

Batteries must not be discarded with your household waste. Spent batteries must be disposed of properly. Special containers are available for this purpose in shops selling batteries and at municipal collection points.

(Rechargeable) batteries marked with the following letters contain harmful substances such as: Cd (cadmium), Hg (mercury), Pb (lead).

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

9. Troubleshooting

If your soundbar fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock!

Do not attempt to repair the device yourself under any circumstances.

Fault Possible causes / Action
No function	·Has the device been connected to the power supply? Is the LED 1 lit up? ·In the case of a connection to the HDMI ARC 8 socket, the HDMI cable as well as the connected device (e.g. a television set) must also be ARC-enabled. If your television set is not provided with an ARC-enabled HDMI connection, switch to a different type of connection or replace the television set. ·Replace the old HDMI cable with a new, ARC-enabled cable. ·Has the correct audio signal been selected at the audio device (e.g. television set)? Select PCM 2.0 (or PCM stereo) as the audio output.
No Bluetooth connection	·Is the Bluetooth function of the audio device active? ·Did you switch off the device? ·Does a Bluetooth connection to another device exist? Press the button 15 or the button PAIR 5 until the blue LED starts flashing and establish the new connection.
No music play-back	·Is the volume set too low on the audio device? ·Have you selected the correct connection? ·Is the volume too low or switched off?
Interferences during operation	·In the case of any possibly occurring interferences, remove, if necessary, any mobile phones, tablets or other devices with radio wave operation located in the vicinity of the sound-bar.

10. Technical specifications

Model: SSB 36 B2
Power rating: 2x 18 W RMS
Soundbar: Input:	18.0 =¥ Θ-Ω+ A
Protection class of the loudspeaker: III	⑩
Power unit Dongguan City Gangqi Electronic Co, Ltd Model GQ30-180130-AG:	Input: 100 - 240 V ~ 50 / 60 Hz, 1.0 A max Output: 18.0 =¥ , Θ-Ω+ A
Protection class of the power unit:	II ☑
Audio format PCM 2.0 (PCM stereo)
Bluetooth: Range:	v3.0 up to 10 m
Input: LINE IN AUX IN L/R HDMI (ARC) Output: SUB OUT	1x 3.5 mm stereo jack socket 2x cinch sockets 1x HDMI ARC socket 1x cinch socket
Battery for the remote control:	CR2025 3 V
Dimensions (WxDxH):	approx. 94 x 8.2 x 11.9 cm
Weight:	approx. 2.2 kg
Ambient conditions:	only approved for indoor use 10 °C to 35 °C Relative humidity 40 to 85 %

Subject to technical modification.

C

Declaration of conformity

A complete declaration of conformity can be requested from HOYER Handel GmbH, see Service Centre.

11. Warranty of the HOYER Handel GmbH

Dear Customer,

your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us - at our discretion - free of charge to you. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred. If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery.

The warranty applies to material or factory defects.

Excluded from the warranty are wear parts subject to normal wear and damages to fragile parts, e.g. switches, batteries, lamps or other parts manufactured from glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

• Please keep the article number IAN: 274307 and the purchase receipt as a purchase verification for all inquiries.
• If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.
• Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

Please visit www.lidl-service.com to download this and many other manuals, product videos and software.

Service Centre

GB Service Great Britain

Tel.: [phone] [£ 0.10/Min.]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

IAN:274307

Supplier

Please note that the following address is no service address.

First contact the aforementioned Service Centre.

HOYER Handel GmbH

Taskoprustraße 3

22761 Hamburg

Germany

HOYER HANDEL GMBH

Taskoprustraße 3

22761 Hamburg

Germany
