Inverter FTXG35LV1BS - Air Conditioning DAIKIN - Free user manual and instructions
Find the device manual for free Inverter FTXG35LV1BS DAIKIN in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Brand | Daikin |
| Model | Inverter FTXG35LV1BS |
| Product Type | Reversible air conditioning (split) |
| Operating Mode | AUTO, DRY, COOL, HEAT, FAN |
| Refrigerant | R410A (GWP 1975) |
| Intelligent Eye Sensor | Human presence detection, automatic switch to energy-saving mode after 20 minutes |
| Comfort Airflow | Airflow direction upward in cooling, downward in heating |
| Powerful Function | Maximum power for 20 minutes |
| Econo Function | Limitation of maximum current to prevent circuit breaker tripping |
| Reduced Outdoor Unit Noise | Decrease in outdoor unit sound level |
| Weekly Timer | Up to 4 schedules per day, copy possible |
| Timers | On, Off, combinable, with night setting |
| Airflow Direction | Automatic oscillation (horizontal and vertical), 3D |
| Airflow Rate | 7 speeds (Auto, Quiet, Low, Medium-Low, Medium, Medium-High, High) |
| Remote Control | With LCD display, range 6 m |
| Filters | Air filter (clean every 2 weeks), titanium apatite photocatalytic filter (clean every 6 months, replace every 3 years) |
| Photocatalytic Filter Reference | KAF970A46 (1 set, without frame) |
| Power Supply | Separate power circuit, ground fault circuit breaker required |
| Multiple System | Connectable to an outdoor unit with multiple indoor units, with priority room setting |
| Safety | Automatic shutdown in case of anomaly, overvoltage protection, diagnosis via remote control |
| Dimensions (approx.) | Not specified in the manual |
| Weight (approx.) | Not specified in the manual |
Frequently Asked Questions - Inverter FTXG35LV1BS DAIKIN
How to set the remote control clock?
Press the CLOCK button, then use ▲ and ▼ to set the day of the week and time. Confirm by pressing CLOCK again.
Why doesn't the air conditioner start immediately?
An internal protection prevents restart for about 3 minutes after a stop or mode change. Wait a few moments.
How to use the Intelligent Eye function?
Press the COMFORT/SENSOR button until the eye symbol is displayed. The sensor detects movements and adjusts the airflow or switches to energy-saving mode after 20 minutes of no presence.
What to do if the air conditioner makes a water flow noise?
This noise is normal: it corresponds to the circulation of refrigerant or the drainage of condensation water. It is not a malfunction.
How to clean the air filter?
Open the upper front panel, remove the air filter, wash it with water or vacuum, dry it in the shade and replace it. Cleaning recommended every 2 weeks.
When to replace the photocatalytic air purifying filter?
The filter should be cleaned every 6 months and replaced every 3 years. The reference is KAF970A46.
How to program the weekly timer?
Press WEEKLY, then SELECT to choose the day. Use NEXT to set the time and temperature for each program (up to 4 per day). Confirm with SELECT.
What does the flashing indicator light mean?
A flashing may indicate standby mode, defrosting, or a malfunction. Check the error code via the remote control (hold CANCEL for 5s). Consult the manual for the meaning.
How to activate the silent mode of the outdoor unit?
Press ECONO/QUIET until the noise reduction symbol is displayed. This function reduces the sound level of the outdoor unit, useful at night.
What type of refrigerant is used and what to do in case of leak?
The refrigerant is R410A (fluorinated gas). In case of leak, stop use, ventilate the room and contact a professional. Do not expose to an open flame.
