| Product Type | Portable audio docking station |
| Brand | Gear4 |
| Model | CDB50 |
| iPod compatibility | iPod touch, iPod classic, iPod, iPod nano, iPod mini (dock adapters included) |
| CD player | Yes, with 20-track programming |
| Radio | FM/MW with built-in antenna |
| Display | LCD |
| Bass boost | X Bass |
| Power supply | AC mains via included cable (UK and EU plugs) or 8 C batteries (not included) |
| iPod charging | Yes, when connected to the dock |
| Auxiliary input | 3.5 mm AUX jack for external players |
| Remote control | Yes, with included lithium battery |
| Included dock adapters | 3 adapters for different iPod models |
| Box contents | CDB50 unit, 2 power cables, 3 dock adapters, remote control, user manual |
| Care and cleaning | Clean with a soft, dry cloth. Do not use abrasive products. |
| Safety | Do not expose to moisture. Do not open the casing. Use only approved accessories. |
| Repairability | Contact qualified personnel. No spare parts specified. |
| Disposal | Respect the WEEE directive. Do not dispose of with household waste. |
| General information | Works with iPod (latest software version recommended). Made for iPod. |
Frequently Asked Questions - CDB50 GEAR4
User questions about CDB50 GEAR4
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Docking station in PDF format for free! Find your manual CDB50 - GEAR4 and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. CDB50 by GEAR4.
USER MANUAL CDB50 GEAR4
Thank you for buying the GEAR4 CDB-50, portable speaker for iPod with CD player and FM radio. Please ensure you take a few minutes to read this user manual fully before use and retain it for future reference.
2× power cables with UK/EU plug
3 x dock adapters for iPod
Declaration of Conformity
Product Name: GEAR4 CDB-50
Model: PG438
Distributor: Disruptive Ltd.
Address: Windsor House, Turnpike Road, High Wycombe, Bucks, HP12 3NR, United Kingdom.
Declare that the product described below is in conformity with the relevant provisions of the following directives and National Laws and Regulations adopting these directives.
The Low Voltage Directive 73/23/EEC
The EMC Directive 89/336/EEC as amended by 91/263/EEC, 92/31/EEC, 93/97/EEC.
Issued in:
High Wycombe, Bucks, United Kingdom
Authorised Representative: Carl Walastyan Signature:
Position: Products Director
Date: 16/07/09
167
31
Features:
CD player with 20 programmable preset tracks
universal dock for iPod
■M/MW radio
CD screen
Bass Boost (X Bass)
Compatible with all dock connecting iPod
Charges iPod when docked
line-in port for use with other music players
- lowered from mains or 8 × C sized batteries (batteries not included)
Getting started:
Plug the power cable into the back of the unit and then into the mains supply.
Press the STANDBY button on the speaker or on the remote control to power on/off.
To select the mode, slide the switch on the side of the speaker to choose between AUX/iPod/TUNER/CD.
For use with iPod:
Slide the switch on the side of the speaker to select iPod mode.
Select and insert the correct iPod docking adapter to suit your iPod.
- Carefully insert your iPod into the dock, playback will start automatically.
Opaee pause a track - press speaker or remote control.
distoptbadspeakpress remote control.
- oscat tbroth tracks - press speaker or remote control.
To adjust the volume - turn the VOLUME dial on the speaker.
To navigate your iPod menus, you must use the remote control:
- Use the MENU button to navigate through the iPod menus.
-Use a nel buttons to navigate the various options in the iPod menus.
- Use the ENTER button to confirm your selection.
For use with CD:
Slide the switch on the side of the speaker to select CD mode.
Carefully insert your disc into the CD slot, the disc will automatically be read.
Toplayear pause a track - press speaker or remote control.
Stoepaetspokakepress remote control.
- oscat through tracks - press speaker or remote control.
To adjust the volume - turn the VOLUME dial on the speaker.
Repeat / Random play:
Press either the buttons on the remote control or P-MODE on the speaker:
To repeat the current track - press or P-MODE once, REPEAT will appear on the screen.
To repeat the whole CD - press P-MODE twice, REPEAT ALL will appear on the screen.
To play tracks at random - press P-MODE three times, RANDOM will appear on the screen.
To clear the function - press P-MODE four times.
To program specific tracks:
oad the CD you wish to program and makesure it is not playing.
press the PROG button once, the display will flash.
Use / to find the track you wish to programme (Press PROG to store).
Repeat above step until you have stored all the tracks you wish to store.
o.play the stored sequence, press
To clear the memory, press the button once.
For use as a radio:
■ Extend the radio antenna.
■ slide the switch on the side of the speaker to select TUNER mode.
■ slide the FM ST/MW Band dial on the side of the speaker to select either FM or MW.
■se the TUNING dial on the speaker to scan through frequencies.
Use with other audio devices:
Slide the switch on the side of the speaker to select AUX mode.
Plug a 3.5mm audio cable (not included) into your MP3 or MP4 player and connect the other end into the AUX port at the back of the unit.
■ress play on your MP3 or MP4 player.
N.B. The remote will not control devices connected via 3.5mm cable.
To set the clock:
In standby mode press and hold the CLK SET button on the speaker or remote control and select either 24 hour or 12 hour using /buttons (press CLK SET to save).
The hour display will start flashing, press on the speaker or remote control to adjust the hour (press CLK SET to save).
The minute display will start flashing, press on the speaker or remote control to adjust the minutes (press CLK SET to save).
WARNING
To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture.
CAUTION
Use of controls or adjustments of performance of procedures other than those specified may result in hazardous radiation exposure.
UNPACKING AND INSTALLATION
Unpack your unit carefully. We recommend that you save the packaging in case you ever need to store your unit. To avoid damage, never place the unit or it's batteries near radiators, in front of heating vents, under direct sunlight or near water.
FOR YOUR SAFETY
- When disconnecting the power adapter, pull the power plug first. Do not pull the cord by itself.
- Never handle the power plug with wet hands, as this could cause fire or electric shock.
Refer servicing to qualified personnel only. - Replace the lithium remote control battery with the same type to avoid risk of explosion
- Do not open the housing.
- Do not twist or pinch the power supply cord. If the plug or power supply cord needs to be replaced, ensure that it complies with the manufacturer's recommendation.
- Only use GEAR4 approved accessories.
- Do not put anything except a compact disc into the compartment. Other objects may damage the unit.
- Unplug the unit during lightning storms and when unused for extended periods of time.
- This product employs a Laser System. To prevent direct exposure to laser beam, do not try to open enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.
To download some of the finest new music around for FREE, visit:
www.gear4.com/newmusic
All rights reserved. Reproduction in whole or in part is prohibited. GEAR4 and product names are trademarks of Disruptive Ltd. iPod is a trademark of Apple Inc., registered in US and other countries. All other product names are or may be trademarks of and used to identify products or services of their respective owners. Brands are used for illustration purposes only and should not be used to infer any relationship between GEAR4 and respective owners.
Please ensure that your iPod is using the latest software version. To update the software, connect your iPod to iTunes. If there is a newer software version available you will be prompted to upgrade.
"Made for iPod" means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
DISPOSAL
According to the European Directive 2002/96/ EC all electrical and electronic products must be collected separately by a local collection system. Please act according to your local rules and do not dispose of your old products with your normal household waste.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert user to the
presence of uninsulated 'Dangerous Voltage' within the product's enclosure that may be of sufficient magnitude to constitute risk of electric shock to person.
The exclamation point within an equilateral triangle is intended to alert user to the presence of important
operating and maintenance (servicing) instruction in the literature accompanying the appliance.
RISQUE D'ÉLECTROCUTION - NE PAS OUVRIR.
ATTENTION:POUR RÉDUIRE LE RISQUE D'ÉLECTROCUTION,NE PAS RETIRER LE COUVERCLE NI LE FOND.CET APPAREIL NE CONTIENT AUCUNE PIECE REPARABLE PAR L'UTILISATEUR CONSULTER LE PERSONNEL QUALIFIÉ POUR TOUTE RÉPARATION.
www.gear4.com/newmusic
GEAR4 One-Year Warranty
Disruptive Ltd owners of the GEAR4 brand warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase ("Warranty Period").
THE WARRANTY DESCRIBED IN THIS PARAGRAPH SHALL BE IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
This Warranty does not apply to damage or defects caused by failure to follow the enclosed instructions, accident, abuse, misuse, misapplication, product modification, faulty ancillary equipment, improper voltage or current, lightning or other acts of God, commercial non-home use, normal wear and tear, shipping damage or loss, damage to digital media players or damage caused by service performed by anyone other than GEAR4.
GEAR4 will, at its option, repair or replace any product covered by this warranty that proves to be defective in workmanship or materials. If your product is no longer being manufactured or is out of stock, at its option, GEAR4 may replace your product with a similar or better product. GEAR4's liability is limited to the repair or replacement, at our option, of any defective product under warranty and shall not include any incidental or consequential damages. This warranty is valid only in Europe, is not transferable and does not extend to users other than the original purchaser.
Return Policy / Warranty Service
Proof of Purchase as evidence the unit was purchased from an authorised dealer within the Warranty Period is required for warranty service. In order to make a warranty claim, the purchaser must contact GEAR4 within 60 days of occurrence. If service is required, do not return the product without first contacting GEAR4. To get this product repaired or replaced, you must contact GEAR4 during the Warranty Period by email (support@gear4.com). You must include your email address, name, address, telephone number, date and place of purchase, alternative contact and a detailed description of the problem you are experiencing and the name / details of the product.
If the problem appears to be based on a defect in workmanship or materials, GEAR4 will provide a Return to Manufacturer Authorization number and instructions for return shipment. Return shipments are at the customer's expense, and the return MUST be accompanied by the original proof of purchase. GEAR4 is not responsible for lost or damaged product during shipment. Any product returned without the original proof of purchase will be returned at the customer's expense.
To avoid any charges, all returns and exchanges must include the original packing materials, product box, all included accessories which may include, without limitation, power adapter or power cord, connecting cables, remote control, adapters, inserts cards and instruction manuals. Any replacement units or parts may be new or rebuilt. GEAR4 will not be liable for inconvenience, loss of time, loss of use of the product, lost profits or exemplary or consequential damages caused by or relating to this product.
This warranty gives you specific legal rights. You may also have other rights that vary from country to country. Some countries do not allow the exclusion or limitations of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above may not apply to you.
Purchase or use of the GEAR4 product constitutes your acknowledgement of, and agreement to completely abide by, the forgoing warranty and disclaimers.
PRODUCT NO: PG438
INPUT: 240V 50Hz =
