USER MANUAL ToastROven Classic TRO964 Applica

Please Read and Save this Use and Care Book

Toaster Oven/Broiler

Horno tostador-asador

Register your product online at www.prodprotect.com/applica,

for a chance to WIN $100,000!

For US residents only

Accessories/Parts (USA/Canada)

When using electrical appliances, basic safety precautions should always be followed, including the following:

Read all instructions.
Do not touch hot surfaces. Use handles or knobs.
To protect against risk of electrical shock, do not immerse cord, plug, or any non-removable parts of this oven in water or other liquid.
- Close supervision is necessary when any appliance is used by or near children.
Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.
Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is dropped or damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or electrical or mechanical adjustment. Or, call the appropriate toll-free number listed on the cover of this manual.
The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
Do not use outdoors.
Do not let cord hang over edge of table or counter, or touch hot surfaces.
Do not place on or near a hot gas or electrical burner, or in a heated oven.
Extreme caution must be used when moving an appliance containing hot oil or other hot liquid.
To disconnect, turn any control to OFF, then remove plug from wall outlet.
Do not use appliance for other than intended use.
- Oversized foods or metal utensils must not be inserted in this appliance, as they may create a fire or risk of electric shock.
A fire may occur if the toaster oven is covered or touching flammable material including curtains, draperies, walls and the like, when in operation. Do not store any item on top of unit when in operation.
- Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts resulting in a risk of electric shock.
Extreme caution should be used when using containers constructed of other than metal or glass.
Do not store any material, other than manufacturer's recommended accessories, in this oven when not in use.
Do not place any of the following materials in the oven: paper,

cardboard, plastic wrap and the like.

Do not cover crumb tray or any parts of the oven with metal foil. This will cause overheating of the oven.
To stop toasting, broiling or baking turn the controls to OFF.
Use extreme caution when removing tray or disposing of hot grease.

SAVE THESE INSTRUCTIONS.

GROUNDED PLUG

As a safety feature, this product is equipped with a grounded plug, which will only fit into a three-prong outlet. Do not attempt to defeat this safety feature. Improper connection of the grounding conductor may result in the risk of electric shock. Consult a qualified electrician if you are in doubt as to whether the outlet is properly grounded.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
b) Longer detachable power-supply cords or extension cords are available and may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord or extension cord should be at least as great as the electrical rating of the appliance,
2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualified personnel or in Latin America by an authorized service center.

Product may vary slightly from what is illustrated.

1. Temperature control
2. On indicator light
3. Toast shade/timer control with stay on feature

4. Swing-down crumb tray (under unit)

5. 1. Slide rack (Part# 168823-00)
6. 1. Bake pan (Part# 174334-00)

7. Bake/Broil rack guide

+Consumer replaceable/removable parts

Important:

When using the TOAST/

TIMER function, always turn the dial past 20 and then turn back or forward to desired setting.

How to Use

This product is for household use only.

C A UT IO

THIS OVEN GETS HOT WHEN IN USE. ALWAYS USE OVEN MITTS OR POT HOLDERS WHEN TOUCHING ANY OUTER OR INNER SURFACE OF THE OVEN.

Before first use, remove the slide rack and bake pan from oven. Wash in warm, sudsy water, rinse and dry with a dishtowel or paper towel. Replace slide rack in oven.

FOR TOASTING

1. Open oven door and insert the slide rack into position. Do not use the bake pan forasting.
2. Set the temperature control to the TOAST ON position then set the TOAST/TIMER control to the desired setting (Light, Medium or Dark). For best results, select the medium setting for your first cycle then adjust lighter or darker to suit your taste.

Important: When using the TOAST/TIMER function, always turn the dial past 20 and then turn back or forward to desired setting.

The on indicator light comes on and stays on during the toasting cycle.
- When toasting is done, the signal bell sounds, the oven automatically shuts off and the on indicator light goes off.
3. To stopasting at any time, turn the temperature control OFF.

Helpful Tip for Multiple Toasting Cycles

For best results, when making three or more consecutive batches of toast, allow a short cool down period between toasting cycles.

FOR BAKING

• When baking or cooking always preheat the oven for 5 minutes.

• Open oven door and insert slide rack into the oven.

• Turn the temperature control to the desired temperature setting.

Important: You must set the timer or select Stay On for the oven to function.

1. Set the timer to desired number of minutes including preheat time or to Stay On. The upper and lower heating elements cycle on and off to maintain the temperature.
2. Watch for doneness (see "Cooking/Baking Guide").

3. Once cooking cycle is finished:

4. If the timer was on, the signal bell sounds, the On indicator light goes off and the oven automatically turns off.

5. If the timer was not on, turn the TIMER/TOAST selector from the Stay On position to the Off position.
6. Using oven mitt or pot holder, remove bake pan.

FOR BROILING

Note: When broiling, preheat oven for 5 minutes.

1. Turn the temperature control to BROIL.
2. Place food directly on the slide rack with the bake pan inserted on the pan support rails underneath the slide rack to catch drippings.
   Note: Be sure the top edge of the food or container is at least 112 (3.81 cm) away from the upper heating elements.
3. Close the oven door.
4. On the broil setting, only the upper heating elements will operate; they will glow and fade, cycling on and off.
5. Use the chart below as a guide to broiling times. Check food for doneness at minimum time.

6. Once cooking cycle is finished:

7. If the timer was on, the signal bell sounds, the On indicator light goes off and the oven automatically turns off.

8. If the timer was not on, turn the TIMER/TOAST selector from the Stay On position to the Off position.
9. Using oven milt or pot holder, remove bake pan.

Important: When finished baking or broiling, you must turn the temperature control to the OFF position.

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service personnel.

CLEANING YOUR OVEN

Important: Before cleaning any part, be sure the oven is off, unplugged, and cool. Always dry parts thoroughly before using oven after cleaning.

1. Clean the glass door with a nylon pad and sudsy water. Do not use a spray glass cleaner.
2. To remove the slide rack, open the door, pull the rack forward and out. Wash the slide rack in warm, sandy water or in a dishwasher. To remove stubborn spots, use a polyester or nylon pad. To replace the slide rack, open the door completely and slide the rack into the rack support grooves. Be sure the slide rack is seated properly.
3. Wash the bake pan in warm, sudsy water or in dishwasher. To minimize scratching, use a polyester or nylon pad.

CRUMBTRAY

To open crumb tray, tip back oven, pull the crumb tray knob forward and then down (A). Wipe with a dampened cloth or paper towel and dry thoroughly. To close, pull the crumb tray knob forward, swing the crumb tray closed, and then push knob in to lock into place before operating the oven.

A

EXTERIOR AND INTERIOR SURFACES

Be sure the oven has cooled completely. Wipe the top, exterior walls and the interior with a damp cloth or sponge. Do not use abrasive cleaners or scouring pads that may scratch surface, never spray cleaners directly into the oven. Dry thoroughly with cloth or paper towel.

COOKING CONTAINERS

Metal, ovenproof glass or ceramic bakeware without glass lids can be used in your oven.

Follow manufacturer's instructions. Be sure the top edge of the container is at least

112 (3.81 cm) away from the upper heating elements.

FOOD AMOUNT	TEMP.	SETTING APPROX.	TIME	PROCEDURE
MEATS
Chicken Pieces To fit Bake Pan	Place in Bake Pan.
for 40-50 minutes.	Turn and watch
Meatloaf	To fit Bake Pan	Bake following	Place on Bake Pan.
favorite recipes.	If browning too rapidly,cover with foil
Bacon	4 slices	Broil 7-9 minutes.	Place food on BroilRack in Bake Pan, turnwhen slices look brown.
Frankfurlers	8-10 franks	Broil 10-15 minutes.	Place food on BroilRack in Bake Pan, turnfrequently.
Burgers/Chops	4 (1/4 lb.ea./.113 kg)	Broil 25-40 minutes.	Place food on BroilRack in Bake Pan, turnhalfway throughcooking.Time shownis for medium.
BREADS & DESSERTS
Cookies	To fit Bake Pan	Follow package or		Bake on Bake Pan until
recipe directions.	done and browned asdesired.
Biscuits/Dinner Rolls	To fit Bake Pan	Follow package or
recipe directions.
VEGETABLES
Baked Potatoes1 to 1	Medium potatoes	Bake 400°F (200 °C)	Wash and pierce potatoesand place directly on
		% hours.
French Fries/Onion Rings(frozen)	Single layer tofit Bake Pan	Follow package directions:overbrowning.	Turn during baking.Watch to prevent

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

Unit is not heating Electrical outlet is Check to make sure outlet or stops heating, not working or oven is working. Both the

is unplugged, temperature control and the

timer must be set in order

for the oven to function.

Second toasting Setting on toast If doing repeated toasting in

too dark. is too dark. The oven, select a shade.

slightly lighter than the

previous setting.

Moisture forms on The amount of moisture The moisture that forms onthe inside of the glass differs in different the oven door is quite

door during toasting. products, whether bread, common and will usually

bagels or frozen pastries.

cycle. Because the oven is

closed the moisture cannot

evaporate as it would in

a traditional toaster.

Food is overcooked Temperature and cook Because a toaster oven is or undercooked. time may need much smaller than a regular

o be adjusted. oven, it may heat up faster

and cook faster. Try lowering

the temperature 25

the suggested temperature in

a recipe or on a label.

There is burnt food There are remnants of food Refer to the directions in the

or or smoking in crumb tray or on

hen oven is the walls of the oven.

being used. booklet. Make sure all parts

of the oven, baking pan and

rack are clean.

Heating elements The heating elements

not seem to be on. cycle on and off

uring baking.

the top element is on.

Check the oven to make

certain the function desired

nly

PROBLEMA POSIBLE CAUSA SOLUCION

IMPORTANT MISES EN GARDE

PROBLEM CAUSE POSSIBLE SOLUTION

For service, repair or any questions regarding your appliance, call the appropriate "800" number on the cover of this book. Do not return the product to the place of purchase. Do not mail the product back to the manufacturer nor bring it to a service center. You may also want to consult the website listed on the cover of this manual.

One-Year Limited Warranty

(Appplies only in the United States and Canada)

What does it cover?

• Any defect in material or workmanship; provided; however, Applica's liability will not exceed the purchase price of the product.

For how long?

One year after the date of original purchase.

What will we do to help you?

• Provide you with a reasonably similar replacement product that is either new or factory refurbished.

How do you get service?

• Save your receipt as proof of the date of sale.
• Check our on-line service site at www.prodprotect.com/applica, or call our toll-free number, 1-800-231-9786, for general warranty service.
  If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

• Damage from misuse, abuse or neglect

• Products that have been modified in any way
• Products used or serviced outside the country of purchase
  Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some states do not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

• This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or province to province.
