BrandGLORIA
ModelMULTIBRUSH (MultiBrush SC PLUS)
Product typeElectric floor cleaner with rotating brush
ApplicationsCleaning joints and outdoor surfaces (paving stones, cobblestones, wood)
Voltage / Frequency230 V AC / 50 Hz
Nominal power500 W
Joint brush speed650 to 1600 min⁻¹
Surface brush speed450 to 1100 min⁻¹
Working width (surface brush)24 cm
Working width (joint brush)28 cm
Height (min./max.) with surface brush1.15 m / 1.35 m
Height (min./max.) with joint brush1.04 m / 1.24 m
Weight with joint brush2.9 kg
Weight with surface brush3.6 kg
Hand-arm vibration< 3.1 m/s² (+/- 1.5 m/s²)
Sound pressure level LPA71 dB(A)
Sound power level LWA92 dB(A)
Protection classII (double insulation)
Power supplyMains with cable and earth plug
Recommended extension cordCross-section ≥ 1.5 mm², reel fully unrolled
Safety deviceSafety on/off switch (unlock button)
Speed adjustmentKnob (S): positions 1-6 according to brush
Brushes includedSurface brush (cover) + joint brush (cover)
Optional accessoriesWood brush, aerator roller, scarifier, etc.
MaintenanceExternal cleaning with damp cloth, brushes washable with water
Manufacturer warranty24 months (conditions at www.gloriagarten.de)

Frequently Asked Questions - MULTIBRUSH GLORIA

What are the voltage and power of the MULTIBRUSH device?
The device operates on 230 V AC / 50 Hz with a power of 500 W.
Which brushes are supplied with the MULTIBRUSH cleaner?
The kit includes a surface brush (protective cover) and a joint brush (protective cover). Other brushes are available as options.
How to adjust the rotation speed of the brushes?
Use the adjustment knob (S) on the device. Position 1-2 for soft brush (wood), 3-4 for hard brush (stone), 5-6 for metal brush (joints).
What type of extension cord to use with the MULTIBRUSH?
Use an extension cord with earth conductor, cross-section ≥ 1.5 mm², and fully unroll the cable. A residual current device (RCD) ≤ 30 mA is recommended.
Can the device be used on wooden terraces?
Yes, but only with the soft surface brush (yellow/black bristles, available as an option). The hard black brush can damage wood.
How to clean the brushes after use?
Remove the brushes (see chapter 6.1.2). Clean them with water or a hard water jet and a stiff brush. Never immerse the motor unit.
When should the surface brush be replaced?
Replace the surface brush when its diameter is reduced to approximately 90 mm (wear). Same for the joint brush.
Is the device suitable for professional use?
No, the MULTIBRUSH is designed for private use (garden, courtyard). Not suitable for construction sites or intensive use.
How to store the device after use?
Clean it, unplug it, and store it in a dry, frost-free place, hanging or lying down (do not place on brushes). Keep out of reach of children.
Where to find accessories or spare parts?
Original GLORIA accessories and parts are available from authorized dealers or at www.gloriagarten.de. Use only GLORIA parts.
