TASSIMO TAS1102VB - Coffee maker BOSCH - Free user manual and instructions

Product type	Pod coffee maker (T DISC)
Brand	Bosch
Model	TASSIMO TAS1102VB
Dimensions (approx.)	20 x 30 x 30 cm
Weight (approx.)	2.5 kg
Power supply	220–240 V~, 50 Hz, 1400 W
Water tank capacity (approx.)	1.2 L
Brewing system	High-pressure pump, T DISC barcode reading
Main functions	Preparation of hot beverages (coffee, tea, hot chocolate), auto shut-off, standby mode
Maintenance and cleaning	Dishwasher-safe (some parts), automatic descaling, cleaning program with service T DISC
Safety	Automatic shut-off in case of malfunction, overheating protection, brewing system lock
Spare parts and repairability	Original parts available via after-sales service, repair by qualified personnel only
General information	Indoor use only, max altitude 2000 m, do not use chemically demineralized water
Included accessories	Service T DISC, descaling tablets (ref. TCZ6004)
Warranty	According to distributor's terms, proof of purchase required

Frequently Asked Questions - TASSIMO TAS1102VB BOSCH

How to prepare a drink with the TASSIMO TAS1102VB?

Fill the water tank with cold water to the max mark, insert a T DISC into the holder, close the brewing system, place a cup on the cup support, then press the ∩° button. The machine reads the barcode and adjusts the water quantity automatically.

Why won't the machine start?

Check that the appliance is plugged in and the outlet works. If no LED lights up, press ∩° to exit standby mode. Ensure the water tank is properly seated and filled.

What to do if no drink comes out?

Check that the water tank is pushed in all the way until it stops. If there is air in the system, run a cleaning cycle with the service T DISC. If the float is stuck, descale the appliance and then move the float manually.

How to descale the appliance?

When the calc indicator lights up, run the descaling program following steps 44-58 in the manual. Use only Bosch descaling tablets (ref. TCZ6004) and avoid descaling agents based on phosphoric acid.

Why is the red light flashing?

A solid red light indicates the water tank is empty or not positioned correctly. If it flashes, the T DISC barcode is not recognized: clean the barcode reading window with a soft cloth, flatten the T DISC film, or use a new T DISC.

How to clean the machine?

Some parts (T DISC holder, piercing crown, drip grid, receptacle) are dishwasher safe at max 60°C. The water tank and service T DISC must be washed by hand. Wipe the exterior with a damp cloth. Never immerse the appliance in water.

Can I use pods other than T DISC?

No, this appliance is designed exclusively for original Bosch T DISC. Using other pods may damage the machine and void the warranty.

What to do if the brewing system does not close?

Check that the piercing crown and T DISC holder are correctly locked in place (you should hear a click). Ensure the T DISC is positioned correctly with the printed side down and the tab in the notch. Clean the latch with a damp cloth.

How to reduce the drink volume?

Hold down the ∩° button during preparation until the desired quantity is reached. Release to stop. The adjustment is temporary; for a permanent adjustment, refer to the manual.

Where to find the serial number and contact after-sales service?

The serial number (E-Nr.) and manufacturing number (FD) are on the rating plate of the appliance. For after-sales service, call 09 69 39 29 39 (France) or visit www.tassimo.fr. Have these numbers at hand.

USER MANUAL TASSIMO TAS1102VB BOSCH

General information. 26

Intended use. 26

Restriction on user group. 26

Safety information. 27

Familiarising yourself with your appliance. 30

Appliance 30

Controls 30

Before using for the first time..... 30

Performing initial start-up 30

General information 30

Accessories 30

Basic operation 31

To prepare a drink. 31

Cleaning and servicing 31

Dishwasher-safe components...... 31

Cleaning the appliance 31

Descale the appliance. 31

Troubleshooting 32

Malfunctions 32

Information on display panel..... 34

Problem with results. 35

Disposal 36

Disposing of old appliance 36

Customer Service 36

Product number (E-Nr.) and production number (FD) 36

Warranty conditions. 36

Technical specifications 36

Safety

Please read the safety information to ensure that you use the appliance safely.

General information

You can find general information for this instruction manual here.

• Read this instruction manual carefully. Only this will ensure you use the appliance safely and efficiently. This manual is intended for the user of the appliance.
• Follow the safety instructions and warnings.
• Keep the instruction manual and the product information safe for future reference or for the next owner.
• Check the appliance after unpacking it. Do not connect the appliance if it has been damaged in transit.

Intended use

Please read the information on intended use to ensure that you use the appliance correctly and safely.

Only use this appliance:

As specified in this instruction manual. for preparing hot drinks. In private households and in enclosed spaces in a domestic environment. Up to an altitude of max. 2000 m above sea level.

Restriction on user group

Avoid risks to children and vulnerable persons.

This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.

Children must not play with the appliance.

Children must not perform cleaning or user maintenance unless they are at least 8 years old and are being supervised.

Keep children under the age of 8 years away from the appliance and power cable.

Safety information

Follow these safety instructions when using the appliance.

WARNING - Risk of suffocation!

• Children may put packaging material over their heads or wrap themselves up in it and suffocate.
• Keep packaging material away from children. Do not let children play with packaging material.

Children may breathe in or swallow small parts, causing them to suffocate.

• Keep small parts away from children. Do not let children play with small parts.

WARNING - Risk of electric shock!

• Improper installation is dangerous.
• Connect and operate the appliance only in accordance with the specifications on the rating plate.
• Connect the appliance to a power supply with alternating current only via a properly installed socket with earthing.
• The protective conductor system of the domestic electrical installation must be properly installed.

If the appliance or the power cord is damaged, this is dangerous.

• Never operate a damaged appliance.
• Never operate an appliance with a cracked or fractured surface.
• Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
• If the appliance or the power cord is damaged, immediately unplug the power cord or switch off the fuse in the fuse box. "Call Customer Service." → Page 36
• Repairs to the appliance should only be carried out by trained specialist staff.
• Improper repairs are dangerous.
• Repairs to the appliance should only be carried out by trained specialist staff.
• Only use genuine spare parts when repairing the appliance.
• If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.

An ingress of moisture can cause an electric shock.

• Never immerse the appliance or the power cord in water.
• Liquids must not be spilled on the appliance plug connection. Only use the appliance in enclosed spaces.
• Never expose the appliance to intense heat or humidity.
• Do not use steam- or high-pressure cleaners to clean the appliance.

WARNING - Risk of fire!

The appliance will become hot.

• Ventilate the appliance adequately. Never operate the appliance in a cupboard.
• Never leave the appliance unattended while it is switched on.
• It is dangerous to use an extended power cord and non-approved adapters.
• Do not use extension cables or multiple socket strips. If the power cord is too short, contact Customer Service. Only use adapters approved by the manufacturer.

WARNING - Risk of burns!

Some parts of the appliance become very hot.

• Never open the brewing system during operation.
• Never use a damaged T DISC. Never use a drinks T DISC more than once.
• Never touch hot appliance parts.
• Allow hot appliance parts to cool down before touching them.

WARNING - Risk of scalding!

Freshly prepared drinks are very hot.

Leave drinks to cool down if necessary. Do not let escaping liquids or steam come into contact with your skin.

WARNING - Risk of injury!

Improper use of the appliance may endanger the user.

• Use the appliance only for its intended purpose.

WARNING - Danger: Magnetism!

The appliance contains permanent magnets. These may affect electronic implants, e.g. pacemakers or insulin pumps.

People with electronic implants must stand at least 10 cm away from the appliance. This minimum distance of 10 cm must also be observed for the water tank when removed.

WARNING - Risk of harm to health!

Dirt on the appliance may be dangerous to health.

Follow the cleaning instructions for the appliance.

Familiarising yourself with your appliance

Familiarise yourself with the parts of your appliance.

Appliance

You can find an overview of the parts of your appliance here.

Note: Individual details and colours may differ, depending on the appliance model.

→ Fig. 1

1 Float 2 Calc mark 3 Max mark 4 Water tank 5 T DISC reading window 6 T DISC piercing unit 7 T DISC holder 8 Lock 9 Brewing unit 10 Control panel 11 Storage compartment 12 Brief cleaning / descaling instructions 13 Service T DISC 14 Bowl 15 Cup stand 16 Drip grate

Controls

You can find an overview of the symbols on your appliance here.

○	■ Activate the appliance. ■ Start, stop and prolong dispens- ing of drinks. ■ Start service programme.
○	Fill water tank.
✓	Display status.
calc	Descale the appliance.

Before using for the first time

Clean the appliance and individual parts.

Performing initial start-up

Follow the pictorial instructions at the start of these instructions.

→ Fig. 2 - 14

General information

Please bear this information in mind so that you can get the best out of your appliance.

Note: The appliance has been programmed at the factory with standard settings for optimum operation.

Accessories

Only use original accessories. These have been made especially for your appliance. Here, you can find an overview of your appliance's accessories.

Note: Bosch is the manufacturer of the TASSIMO appliance. Therefore Bosch cannot provide any delivery guarantee for the TASSIMO TDISCs.

accessories	Order number / Web shop
Descaling tablets	TCZ6004 / 00311909 www.tassimo.com www.bosch-home.com
Service T DISC	17001491 www.bosch-home.com

Basic operation

You can find out everything you need to know about operating your appliance here.

To prepare a drink

Find out how to prepare a drink of your choice. Follow the pictorial instructions at the start of these instructions.

Tips

• Fill the water tank each day with fresh, cold, non-carbonated water.
• Do not use chemically decalcified water.
• To interrupt the dispensing process, briefly press .

→ Fig. 15 - 27

Cleaning and servicing

To keep your appliance working efficiently for a long time, it is important to clean and maintain it carefully.

Dishwasher-safe components

Find out which components can be cleaned in the dishwasher.

ATTENTION!

Some components are sensitive to heat and may be damaged if they are cleaned in a dishwasher.

• Follow the operating instructions of the dishwasher.
• Only put dishwasher-safe components in the dishwasher. Only use programmes that do not heat the water above 60°C.

Dishwasher-safe components:

T DISC holder, T DISC piercing unit, Drip grate, Bowl

Components that are not dishwasher-safe:

Water tank, Service T DISC

Cleaning the appliance

Follow the pictorial instructions at the start of these instructions.

See Fig. 28 - 43

Descale the appliance

If the calc light illuminates, run the descaling program. Follow the pictorial instructions at the beginning of these instructions.

ATTENTION!

Improper cleaning and descaling, or a delay in doing so, may damage the appliance.

• Immediately perform the descaling process in accordance with the instructions.
• Do not use descaling agents containing phosphoric acid.

→ Fig. 44 - 58

Troubleshooting

You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.

WARNING

Risk of electric shock!

Incorrect repairs are dangerous.

Repairs to the appliance should only be carried out by trained specialist staff. - Only use genuine spare parts when repairing the appliance. - If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service, or a similarly qualified person in order to prevent any risk.

Malfunctions

Fault	Cause	troubleshooting
The appliance is not work- ing.	The appliance has no power supply.	Check to see whether the appliance is connected to the mains.
LEDs do not light up.
Brewing process starts, drink is not dispensed.	Water tank is wrongly insert- ted.	1. Insert the water tank correctly.2. Push the water tank into the appli- ance until it clicks into place.
	The water tank was re- moved during the brewing- stage or there is air in the system.	Start the cleaning process with the T DISC.→ "Performing initial start-up", Page 30
	Float is stuck in the water tank.	1. Remove the water tank.2. Descale the appliance.→ "Descale the appliance", Page 313. Reach into the water tank and move the float up and down.
Brewing process does not start.	T DISC has not been insert- ted.	Check whether the T DISC is insert- ted.
Status display lights up red.	The T DISC bar code is not recognised.	Clean the T DISC reading window with a soft, damp cloth.Smooth out the film of the T DISC.Use a new T DISC.
Brewing process does not start.		▶ Contact the TASSIMO careline if the problem persists.
Status display lights up red.	Brewing unit is not closed properly.	1. Clean the brewing unit with a soft, damp cloth, particularly in the area of the lock. 2. Close the brewing unit.
	The appliance not connec-ted to the power supply when the T DISC was insert-ted.	▶ Connect the appliance to the power supply before inserting the T DISC.
Brewing unit cannot be closed.	T DISC holder or piercing unit has not been correctly inserted.	1. Press the piercing unit into the holder using both thumbs until it clicks audibly into place. 2. Check the position of the T DISC holder.
	T DISC has not been cor-rectly inserted.	1. Insert the T DISC with the printed side facing downwards. 2. Check whether the tab of the T DISC is in the recess.
	T DISC is damaged.	▶ Use a new T DISC.
	Brewing unit is soiled.	1. Clean the brewing unit with a soft, damp cloth, particularly in the area of the lock. 2. Close the brewing unit.
	Lock does not engage.	▶ Press the lock down until it audibly clicks into place.
Brewing unit cannot be opened.	Brewing unit is locked.	▶ Only open the brewing unit when the status display remains lit con- tinuously. 1. Unplug the mains plug. 2. Contact the TASSIMO careline if the brewing unit remains locked.
Water is dripping from the brewing unit.	T DISC is damaged, leaking or not correctly pierced.	▶ Use a new T DISC. ▶ Only use T DISCs once. 1. Wait until the brewing process has come to an end and the appliance has cooled down. 2. Remove the T DISC. 3. Clean the brewing unit. → "Cleaning the appliance", Page 31
	The piercing unit is not inse- ted correctly.	▶ Press the piercing unit into the holder using both thumbs until it clicks audibly into place.
There is water under the cup stand.	Condensation has formed due to technical reasons.	▶ Remove excess water with a soft cloth.

Information on display panel

Fault	Cause	troubleshooting
No LED is lit.	Appliance is in idle mode.	Press □.
All LEDs flashing.	Voltage in the house system is incorrect.	1. Pull out the mains plug and re-insert it.2. If the problem persists for a longer period, have the voltage of your property checked by an electrician.
LED lights up.	Water tank has not been sufficiently filled.	1. Fill the water tank with fresh, cold water up to the mark max.2. Insert the water tank.
LED lights up even though there is enough water in the water tank.	Float is stuck in the water tank.	1. Descale the appliance. → "Descale the appliance", Page 312. Reach into the water tank and move the float up and down.
	Water tank is wrongly inserted.	1. Insert the water tank correctly.2. Push the water tank into the appliance until it clicks into place.
LED calc lights up.	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
calc LED flashes.	Heavy build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
calc LED lights up even though decalcified water has been used.	Decalcified water still contains small amounts of lime.	Descale the appliance. → "Descale the appliance", Page 31
calc LED and LED are simultaneously lit and the brewing process is not possible.	Appliance has a fault.	1. Unplug the mains plug. 2. Contact the TASSIMO careline.
calc LED and LED flash simultaneously.	Descaling process is running.	Wait until the descending process is complete.

Problem with results

Fault	Cause	troubleshooting
Crema has deteriorated.	Beverage outlet is soiled.	Clean the beverage outlet. → "Cleaning and servicing", Page 31 Clean the brewing unit with the T DISC. → "Cleaning and servicing", Page 31
	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
Drink volume has changed.	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
Drink volume has reduced.	Water tank has not been sufficiently filled.	1. Fill the water tank with fresh, cold water up to the mark max. 2. Keep pressed until the desired fill volume is reached.
Drink dispensing halts.

Disposal

Find out here how to dispose of old appliances correctly.

Disposing of old appliance

Valuable raw materials can be reused by recycling.

1. Unplug the appliance from the mains.
2. Cut through the power cord.
3. Dispose of the appliance in an environmentally friendly manner.

This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.

Customer Service

If you have any queries, are unable to rectify faults on the appliance yourself or if your appliance needs to be repaired, contact Customer Service. You can solve many problems yourself by consulting the information on troubleshooting in these instructions or on our website. If this is not the case, contact our after-sales service. We always find an appropriate solution.

With any warranty claims, we will make sure that your appliance is repaired by trained after-sales technicians using genuine spare parts, including after the manufacturer's warranty has expired.

Detailed information on the warranty period and terms of warranty in your country is available from our after-sales service, your retailer or on our website.

If you contact Customer Service, you will require the product number (E-Nr.) and the production number (FD) of your appliance.

The contact details for Customer Service can be found in the Customer Service directory at the end of the manual or on our website.

Product number (E-Nr.) and production number (FD)

You can find the product number (E-Nr.) and the production number (FD) on the appliance's rating plate.

Make a note of your appliance's details and the Customer Service telephone number to find them again quickly.

Warranty conditions

You can make warranty claims for your appliance under the following conditions.

The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.

Technical specifications

Facts and figures for your appliance can be found here.

Voltage	220–240 V ~
Frequency	50 Hz
Power rating	1400 W

Table of contents

Safety 39

General information 39

General operation. 85

WARNING - Fire hazard!

WARNING - Risk of burns!

WARNING - Risk of scalding!

Troubleshooting 183

Disposal 183

Instructions for use 185

Problem with the result of the work of the device 186

Disposal 188

Disposal of the old appliance 188

Customer service 188

Do not allow children under 8 years of age near the appliance and its power cord.

Safety instructions

WARNING - Danger of burns!

Children may wrap themselves in the packaging material or pull it over their heads and suffocate.

Do not allow children near the packaging material. Do not let children play with the packaging material.

Children may inhale or swallow small parts, which could cause them to suffocate.

Do not allow children near small parts. Do not let children play with small parts.

Making the drink

This describes how to make a drink of your choice. Follow the instructions in the pictures at the beginning of these instructions.

Tips

Fill the water tank daily with fresh cold water without carbonation. Do not use chemically softened water. To stop the drink preparation prematurely, briefly press the button

→Fig. 15-27

Cleaning and care

For long-term and proper operation of the appliance, careful cleaning and care are required.

Warranty conditions

You are entitled to warranty service for your appliance in accordance with the following conditions.

You can fix many malfunctions yourself using the information in these instructions or on our website. If this does not work, contact our after-sales service.

We will always find a suitable solution.

During warranty service and after the warranty period, the manufacturer will ensure repair of your appliance by trained specialists of the service department using original spare parts.

You can request detailed information about the warranty period and warranty conditions in your country from our service department, from your dealer, or find it on our website.

24-hour service hotline*: Official website on the Internet:

8 [phone] www.bosch-home.ru

Please contact an authorized service center for all warranty and service information. All information on service is available on the official website: Wosch-beno.nu.

We recommend that you use only authorized service centers.

Original accessories and care products for your household appliances can be purchased in our online store: www.bosch-home.ru/store. You can find out about ordering, payment, and delivery on the website. Original accessories and care products can also be purchased at authorized service centers.

1. Product

1. Model

Enter the product number (E-Nr.) and the manufacturing number (FD) in the table below, if these data are not contained in the purchase documents (cash receipt or warranty card, warranty and delivery note).

The product is intended for use at ambient temperatures above 0°C and relative humidity not exceeding 93%.

Before commissioning, if the product has been stored at low temperatures, it is necessary to keep it at room temperature for several hours.

The product must be disposed of in accordance with the requirements of current legislation.

Instructions for use of the product are contained in the operating instructions and can be clarified by the municipal authorities.

For products sold by the manufacturer within the validity period of the conformity certificate. This certificate is valid for the territory of the Russian Federation and the Republic of Belarus during the service life established in accordance with Article 8 of the Law on the Protection of Consumer Rights. The service life for household appliances is set by the manufacturer in the documentation (information from the manufacturer on warranty and service).

The product number (E-Nr.) and the manufacturing number (Type) and the Bosch trade mark applied to the product, packaging (if applicable) in the operating documents correspond to the internal standards of the manufacturer.

E-Nr. /

The material number is a digital code of no more than 10 characters. Used when selling (with the product number and the trade mark of the product) the Bosch brand. The material number (model) is indicated between the code word E-Nr: and the code word FD /

The service index is a two-digit digital code assigned to each product during the production process and used for service purposes.

The technical documentation is developed in a unified form for a wide range of products. Therefore, the consumer is provided with instructions for the first commissioning of the device in the operating documents both in full and in part, which will allow determining the applicability of these operating documents to a specific device, accompanied by these operating documents. The compliance of the device characteristics with the requirements of the technical regulations of the Customs Union, contained in the attached operating documents, is confirmed by the marking applied in the operating documents.

In the operating documents not provided for by the consumer for a specific product, there may be information, instructions (manual) for operation, information on maintenance and repair.

Marking of products is carried out by the manufacturer on the nameplate of the device, on the packaging label, directly on the device packaging, and can also be done in other ways that ensure accessible and clear presentation of information about the device at points of sale.

Products that have passed the conformity assessment in accordance with the requirements of the technical regulations of the Customs Union or the technical regulations of the Eurasian Economic Union are marked with a single mark of circulation of products on the market of the member states of the Customs Union (Eurasian Economic Union).

The product complies with the following technical regulations of the Customs Union:

TR CU 020/2011 Electromagnetic compatibility of technical equipment

TR CU 004/2011 Safety of low-voltage equipment

-TR EAEU 037/2016 On restriction of the use of hazardous substances in electrical and electronic products

Operating documents and products are manufactured in Russian. Operating documents and products in the state languages of the member states of the Eurasian Economic Union, different from Russian, are provided by the manufacturer or the authorized representative of the manufacturer of the corresponding member state of the Eurasian Economic Union.

Information on the complete set of the product is presented in the product data sheet, the data sheet is available by phone from the hotline [phone], and is also available on the Internet on the manufacturer's website www.bosch-home.ru.

Toporoboe obsochauene	Anpobaionnbl TNI	Septr.No14	Cerkmfikat cootberctb			Ctprna- HKTOBHTB	HH*, B	H***, Γu	HM***, Br
		Per. homep	Дага вдага	Достockут.у.о.	Kamai	Kamai	Kamai	Kamai	Kamai
Kohtakhtne trpin
TFB3302V	CTTK1	C-DE-AR46 B.80643	28.06.2017	27.06.2022	Гамяи	220-240	50/60	1800
TFB4402V	CTTK4	C-DE-AR46 B.80643	28.06.2017	27.06.2022	Гамяи	220-240	50/60	1800
TFB4431V	CTTK4A	C-DE-AR46 B.80643	28.06.2017	27.06.2022	Гамяи	220-240	50/60	2000
Mynbivarka
MUC11W12RU	CNMC01A	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	900-940
MUC22B42RU	CNMC01A	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	900-940
MUC24B64RU	CNMC01B	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	900-940
MUC28B64RU	CNMC01C	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	900-940
MUC48B68RU	CNMC02	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	1200
MUC88B68RU	CNMC04	C-DE-AR46 B.73382	02.02.2016	01.02.2021	Камai	220-240	50/60	1200
Прибся对于我们可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以可以 TAS1002	CTPM12	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1400
TAS1003	CTPM12	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1400
TAS1006	CTPM12	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1400
TAS1007	CTPM12	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1400
TAS1402	CTPM07	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS1403	CTPM07	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS1404	CTPM07	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS3302	CTPM07	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS3303	CTPM07	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS3304	CTPM08	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS3305	CTPM08	C-DE-AR46 B.806270	18.07.2018	17.07.2023	Камai	220-240	50/60	1300
TAS6002	CTPM10	C-DE-AR46 B.81484	11.08.2017	10.08.2022	Словеду	220-240	50/60	1500
TAS6003	CTPM10	C-DE-AR46 B.81484	11.08.2017	10.08.2022	Словеду	220-240	50/60	1500
TAS6004	CTPM10	C-DE-AR46 B.81484	11.08.2017	10.08.2022	Словеду	220-240	50/60	1500
Tosoptb
TAT3A011	CTAT20	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	825-980
TAT3A012	CTAT20	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	825-980
TAT3A014	CTAT20	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	825-980
TAT3A016	CTAT20	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	825-980
TAT8A001	CTAT08A	C-DE-AR46 B.80642	28.06.2017	27.06.2022	Камai	220-240	50/60	915-1090
TAT8A003	CTAT08A	C-DE-AR46 B.80642	28.06.2017	27.06.2022	Камai	220-240	50/60	915-1090
TAT8A004	CTAT08A	C-DE-AR46 B.80642	28.06.2017	27.06.2022	Камai	220-240	50/60	915-1090
TAT6A111	CTAT08B	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT6A113	CTAT08B	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT6A114	CTAT08B	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT6A115	CTAT08B	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860-1050
TAT7A07	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	800
TAT7A25	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	800
TAT8A013	CTAT08A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT8A014	CTAT08A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT8A015	CTAT08A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	915-1090
TAT8A016	CTAT08A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A017	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A018	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A019	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A020	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A021	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A022	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A023	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A024	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A025	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A026	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A027	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A028	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A030	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A031	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A032	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A033	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A034	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A035	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A036	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A037	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A038	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A039	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A040	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860
TAT8A041	CTAT27A	C-DE-AR46 B.8289719	14.03.2019	13.03.2024	Камai	220-240	50/60	860

Nominal voltage or range of nominal voltages of the AC mains in volts; Nominal frequency or range of nominal frequencies of the AC mains in hertz; *** Nominal power consumption or range of nominal power consumption in watts

FB5860 / August 2019

Technical specifications

Here you will find the dimensions and facts related to your device.

Central Service Contacts

Tassimo support: Tel. [phone]

www.tassimo.dk

For information, questions or locations of authorised Bosch service centres nearest you, please contact TASSIMO:

Phone: [phone]

www.tassimo.co.uk

GR TASSIMO Help line

CY Contact

If you need information or support regarding your Tassimo machine, or if you need to contact Bosch customer service, please contact us: Greece Hotline 800973

91 Free of charge

www.tassimo.gr

IE TASSIMO careline

For information, questions or locations of authorised Bosch service centres nearest you, please contact TASSIMO:

Careline: 1800 454501

www.Tassimo.ie

NO TASSIMO-hjelp

Looking for help? You'll find it here.

Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts.

Find out everything about the many ways Bosch can support you:

www.bosch-home.com/service

Contact data of all countries are listed in the attached service directory.

Visit tassimo.com for registration, accessories and more.
