USER MANUAL PS58B850Y1P SAMSUNG

Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre Web Site AUSTRIA www.samsung.com/be (Dutch) www.samsung.com/be_fr (French) CZECH REPUBLIC

800 - SAMSUNG (800-726786)

www.samsung.com/cz DENMARK

8 - SAMSUNG(7267864)

www.samsung.com/dk EIRE

www.samsung.com/ie FINLAND

30 - 6227 515

www.samsung.com/fi FRANCE

• www.samsung.com/fr GERMANY Plasma TV user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No. BN68-02334A-03 job.indb 1 2009-10-22 3:48:51 User Instructions „„ Screen Image retention Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma monitor panel for more than 2 hours as it can cause screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image. „„ Height The PDP can normally operate only under 2000m in height. It might abnormally function at a place over 2000m in height so do not install and operate there. „„ Heat on the top of the PDP TV The top side of the product may be hot after long period of use as heat dissipates from the panel through the vent hole in the upper part of the product. This is normal and does not indicate any defect or operation failure of the product. However, children should be prevented from touching the upper part of the product. „„ The product is making a ‘cracking’ noise. A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding environment such as temperature or humidity. This is normal and not a defect of the unit. „„ Cell Defects The PDP uses a panel consisting of 2,360,000(HD-level) to 6,221,000(FHD-level) pixels which require sophisticated technology to produce. However, there may be few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product. „„ Avoid operating the TV at temperatures below 5°C(41°F) „„ A still image displayed too long may cause permanent damage to the PDP Panel. Watching the PDP TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause similar effect to the screen. Damages caused by the above effect are not covered by the Warranty. „„ Afterimage on the Screen. Displaying still images from Video games and PC for longer than a certain period of time may produce partial afterimages. To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images. „„ Warranty -- Warranty does not cover any damage caused by image retention. -- Burn-in is not covered by the warranty. „„ Installation Be sure to contact an authorized service centre, when installing your set in a location with heavy dust, high or low temperatures, high humidity, chemical substance and where it operates continually such as the airport, the train station etc. Failure to do so may cause a serious damage to your set. Functionalities related to Digital TV(DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you have access to a compatible DVB-C(MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Program Guide), VOD (Video on Demand) and so on, are not included in this specification. So, they cannot be supported at this moment. Although this TV set meets the latest DVB-T and DVB-C standards[August,2008], the compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed. Some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business. Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with all providers. For more information, please contact your local Samsung customer care centre. Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. (See back cover for more informations.) NN Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice in order to enhance product performance. © 2009 Samsung Electronics Co., Ltd. All rights reserved. English - 2 job.indb 2 2009-10-22 3:48:52 English Contents Connecting and Preparing Your TV Home Network Centre Support / Input Recommendations for Use ■■ Teletext Feature p. 64
• ■■ Wall Mount Kit Specifications (VESA) p. 65
• ■■ Preparing before installing Wall- Mount p. 66
• ■■ Securing the TV to the Wall p. 66
• ■■ Assembling the Cables p. 67
• ■■ Securing the Installation Space p. 68
• ■■ How to assemble the Stand-Base (depending on the model) p. 68
• ■■ Troubleshooting p. 69
• ■■ Specifications p. 72
• ■■ Software License p. 73

Note One-Touch Button TOOLS English - 3 job.indb 3 2009-10-22 3:48:52 Connecting and Preparing Your TV Checking Parts Owner’s Instructions Remote Control/ AAA Batteries (2ea) Program CD Cloth-Clean Holder-Ring (4ea) (Refer to page 66) Warranty Card/ Safety Guide Manual (Not available in all locations) Cover-Bottom (PS50B850 only) Screws (5ea) (PS50B850 only) Cover-Bottom/Screw (PS58B850 only) Holder-Wire stand (Refer to page 67) Holder-Wire (3ea) (Refer to page 67) Ext Cable AV Cable Component Cable Holder-Wire Cable (Refer to page 67) The ferrite cores are used to shield the cables from interference. When connecting a cable, open the ferrite core and clip it around the cable near the plug as shown in the figure. Power Cord (2ea) Using the Stand-Base NN Two or more people should carry the PDP. Never lay the PDP on the floor because of possible damage to the screen. Always keep the PDP upright. NN The PDP can rotate 20 degrees in right and left directions. -20° ~ 20° English - 4 job.indb 4 2009-10-22 3:48:55 Viewing the Control Panel Front Panel buttons Touch each button to operate. NN The product colour and shape may vary depending on the model.

1 REMOTE CONTROL SENSOR

Aim the remote control towards this spot on the TV.

2 SOURCE Toggles between all the available input sources (TV, AV, Component, PC, HDMI1/DVI, HDMI2, HDMI3, HDMI4, USB). NN In the on-screen menu, use this button as you would use the ENTERE button on the remote control. Press to change channels. In the on-screen menu, use the buttons as you would use the ▲ and ▼ buttons on the remote control. You can use button to turn on the TV without the remote control. 6 POWER INDICATOR Blinks and turns off when the power is on and lights up in stand-by mode. 3 MENU Press to see an on-screen menu of your TV’s features.

4 + VOL – Press to increase or decrease the volume. In the on-screen menu, use the + VOL – buttons as you would use the ◄ and ► buttons on the remote control. 8 SPEAKERS (POWER) Press to turn the TV on and off. English - 5 job.indb 5 2009-10-22 3:48:56 Viewing the Connection Panel TV Rear Panel

Cable Television Network NN The product colour and shape may vary depending on the model. NN Whenever you connect an audio or video system to your set, ensure that all elements are switched off. NN When connecting an external device, match the colour of the connection terminal to the cable. English - 6 job.indb 6 2009-10-22 3:48:58 NN For best cable connection to this product, be sure to use cables with a maximum thickness as below. Input/Output Specification Connector

• • Below 40 inch model: Max 0.47inch (12mm)
• • 40 inch and above model: Max 0.55inch (14mm) EXT Video Input Audio(L/R) RGB

Output Video + Audio(L/R) Only TV or DTV output is available. 1 COMMON INTERFACE Slot Insert CI(CI+) (Common Interface) card into the slot. (refer to page 23) -- When not inserting CI(CI+) CARD in some channels, Scramble Signal is displayed on the screen. -- The pairing information containing a telephone number, CI(CI+) CARD ID, Host ID, and other information will be displayed in about 2~3 minutes. If an error message is displayed, please contact your service provider. -- When the channel information configuration has finished, the message Updating Completed is displayed, indicating that the channel list is now updated. -- Depending on the model, a message requesting your Parental Lock password may appear when the CI card is reinserted. -- Depending on the model, even if the Parental Lock is set to Allow All a message requesting your password may appear for adult (18 years and above) programmes. Video and audio inputs for external devices, such as a camcorder or VCR. 8 COMPONENT IN Audio (AUDIO L/R) and video (Y/PB/PR) inputs for Component.

9 PC IN / PC/DVI AUDIO IN

Connect to the video and audio output jack on your PC.

0 HDMI IN 1 (DVI), 2, 3, 4

-- No additional Audio connection is needed for an HDMI to HDMI connection. -- Whenusing an HDMI/DVI cable connection, you must use the HDMI IN 1 (DVI) jack. NN What is HDMI? -- High Definition Multimedia interface allows the transmission of high definition digital video data and multiple channels of digital audio. -- The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied). The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio. NN Insert the CI(CI+)-Card in the direction marked on it. NN ‘CI(CI+) CARD’ is not supported in some countries, regions, broadcasting stations check with your authorized dealer. NN The CI+ function is only applicable to PS********P model. If you have some problems, please contact to service provider

2 USB 1 (HDD), USB 2

Connect a USB mass storage device to view photo files (JPEG), play audio files (MP3) and movie files. You can connect to SAMSUNG’s network wirelessly. NN The USB 1 (HDD) port is also used as the HDD. HDD (Hard disk drive) is device which stores digitally encoded data NN We recommend using HDMI cables no more than 14mm wide.

PC/DVI AUDIO IN

DVI audio outputs for external devices. Supported modes for HDMI/DVI and Component Connect the supplied power cord. 4 LAN Connect a LAN cable to this port to connect to the Network (SAMSUNG's Internet@TV Service). 5 ANT IN 75Ω Coaxial connector for Aerial/Cable Network. 480i

! service Connector for service. @ DIGITAL AUDIO OUT (OPTICAL) Connect to a Digital Audio Component. 6 EXT (RGB) Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players. NN In EXT mode, DTV Out only supports MPEG SD Video and Audio. NN In EXT Mode, Game mode is not available English - 7 job.indb 7 2009-10-22 3:48:59 Remote Control You can use the remote control up to a distance of about 23 feet from the TV. NN The performance of the remote control may be affected by bright light. 1 POWER button (turns the TV on and off) 2 Selects the TV mode directly. 3 Number buttons for direct channel access. 4 Press to switch to your favorite channels. 5 Use to see information on the current broadcast. 6 Displays the main on-screen menu. 7 Use to quickly select frequently used functions. 8 Use to select on-screen menu items and change menu values. 9 This function enables you to view Internet@TV. 0 Use these buttons in the Channel list, Media Play, and Internet@TV, etc. ! Available source selection Volume increase Volume decrease $ Use to display Channel Lists on the screen. % Turn the audio description function on or off. ^ Use these buttons in the Anynet+ and Media Play. & Press to backlight the buttons on the remote. This function is convenient for using at night or when the room is dark. (Using the remote control with the ON/OFF( ) light button set to On will reduce the battery usage time.)

• Previous channel ( Electronic Program Guide (EPG) display ) Returns to the previous menu. Next channel Previous channel Temporary sound switch-off. This function enables you to view Content Library. This function enables you to view and play photo, music and movie files from an external device. Digital subtitle display Teletext Functions 2 Exit from the teletext display (depending on the model) 5 Teletext reveal 6 Teletext index 7 Teletext size 0 Fastext topic selection ! Teletext mode selection (LIST/FLOF) # Teletext display/mix both teletext information and the normal broadcast $ Teletext store
• Teletext sub page ) Teletext hold a Teletext cancel :Teletext next page b P :Teletext previous page Installing Batteries in the Remote Control

Lift the cover at the back of the remote control upward as shown in the figure. Install two AAA size batteries. NN Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the compartment.

Close the cover. NN Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a long time. NN If the remote control doesn’t work, check the following

1. Is the TV power on?

2. Are the plus and minus ends of the batteries reversed?

3. Are the batteries drained?

4. Is there a power outage or is the power cord unplugged?

5. Is there a special fluorescent light or neon sign nearby?

English - 8 job.indb 8 2009-10-22 3:49:00 Using the Remote Control Backlight Buttons Use this feature in dark surroundings and when you are unable to see the remote control buttons clearly.

Press the ON/OFF( ) light button NN When ON, the button backlight is turned on for a moment. NN Pressing a remote control button when the remote control is on turns the button backlight on for a moment. Switching On and Off The mains lead is attached to the rear of your set.

Plug the mains lead into an appropriate socket. NN The standby indicator lights up on your set.

Press the POWERP button on your set. NN You also can press the POWERP button or the TV button on the remote control to turn the TV on. NN The programme that you were watching last is reselected automatically.

Press the numeric button (0~9) or channel up / down (< / >) button on the remote control or < > button on your set. NN When you switch the set on for the very first time, you will be asked to choose language in which the menus are to be displayed.

To switch your set off, press the POWERP button again. Placing Your Television in Standby Mode Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example).

Press the POWERP button on the remote control. NN The screen is turned off and a red standby indicator appears on your set.

To switch your set back on, simply press the POWERP, numeric buttons (0~9), TV button or channel up / down (< / >) button again. NN Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example). It is best to unplug the set from the mains and aerial. Viewing the Display The display identifies the current channel and the status of certain audio-video settings. OO Press the INFO button to viewing the information. Press the INFO button on the remote control. The TV will display the channel, the type of sound, and the status of certain picture and sound settings.

• • ▲, ▼: You can view other channel’s information. If you want to move to the currently selected channel, press ENTERE button.
• • ◄, ►: You can view the desired program’s information at the current channel. NN Press the INFO button once more or wait approximately 10 seconds and the display disappears automatically. English - 9 job.indb 9 2009-10-22 3:49:00 Viewing the Menus With the power on, press the MENU button. The main menu appears on the screen. The menu’s left side has icons: Picture, Sound, Channel, Setup, Input, Application, Support.

Press the ▲ or ▼ button to select one of the icons. Then press the ENTERE button to access the icon’s sub-menu.

Press the EXIT button to exit. NN The on-screen menus disappear from the screen after about one minute. Picture

Mode :Standard Cell Light

Contrast : 95 Brightness : 45 Sharpness : 50 Colour : 50 Tint (G/R) : G50/R50 Advanced Settings Using the TOOLS Button You can use the TOOLS button to select your frequently used functions quickly and easily. The Tools menu changes depending on which external input mode you are viewing.

Press the TOOLS button. The Tools menu will appear. Press the ▲ or ▼ button to select a menu, then press the ENTERE button. Press the ▲ / ▼ / ◄ / ► / ENTERE buttons to display, change, or use the selected items. For a more detailed description of each function, refer to the corresponding page.

Tools Anynet+ (HDMI-CEC) Picture Size Picture Mode Sound Mode Sleep Timer

SRS TS HD

Energy Saving Dual l ll Add to Favourite U Move Anynet+ (HDMI-CEC), see page 46 Picture Size, see page 16 Picture Mode, see page 15 Sound Mode, see page 20 Sleep Timer, see page 22 SRS TS HD, see page 20 Energy Saving, see page 25 Dual l ll, see page 21 Add to Favourite (or Delete from Favourite), see page 14 PIP, see page 25 Auto Adjustment, see page 18

Auto Wide Standard Custom Off Off Off Mono E Enter e Exit Plug & Play Feature When the TV is initially powered on, basic settings proceed automatically and subsequently. NN The Screen Saver is activated if there is no remote control key input for longer than 1 minute while Plug & Play is running. NN The Screen Saver is activated if there is no operating signal for longer than 15 minutes. NN If you accidentally select the wrong country for your TV, the characters on the screen may be wrongly displayed.

Press the POWER button on the remote control. Select the OSD Language. menu is automatically displayed. Select the appropriate language by pressing the ▲ or ▼ button. Press the ENTERE button to confirm your choice. Press the ◄ or ► button to select Store Demo or Home Use, then press the ENTERE button. Plug & Play

Select the OSD Language. Language Nederlands

NN We recommend setting the TV to Home Use mode for the best picture in your English Eesti

U Move E Enter home environment. NN Store Demo mode is only intended for use in retail environments. NN If the unit is accidentally set to Store Demo mode and you want to return to Home Use (Standard): Press the Volume button on

the TV. When the volume OSD is displayed, press and hold the MENU button on the TV for 5 seconds. Press the ENTERE button. Select the appropriate country by pressing the ▲ or ▼ button. Press the ENTERE button to confirm your choice. NN After selecting the country in the Country menu, some models may proceed with an additional option to setup the pin number. NN When you input the PIN number, 0-0-0-0 is not available.

Press the ▲ or ▼ button to memorize the channels of the selected connection, then press the ENTERE button.

• • Air: Air antenna signal.
• • Cable: Cable antenna signal. English - 10 job.indb 10 2009-10-22 3:49:01

Press the ▲ or ▼ button to select the Antenna source to memorize. Press the ENTERE button to select Start.

• • Digital & Analogue: Digital and Analogue channels.
• • Digital: Digital channels.
• • Analogue: Analogue channels. NN The channel search will start and end automatically. 6. The message Set the Clock Mode. is displayed. Press the ENTERE button. Press the ▲ or ▼ button to select Auto, then press the ENTERE button. NN If you select Manual, Set current date and time is displayed. (For a more detailed description of Manual, refer to page 22) NN If you have received a digital signal, the time will be set automatically.

7. The brief instruction on How to get the best performance from your new HDTV is displayed. Press the ENTERE button.

NN This menu is available HD Connection Guide in the Support menu. NN You can change previous or next page by pressing the ◄ / ► button.

8. The message Enjoy your TV. is displayed.

NN If you want to view the TV immediately, select the Watch TV. NN If you want to view the See Product Guide, press the ENTERE button.

Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTERE button. Press the ENTERE button again to select Plug & Play. Enter your 4 digit PIN number. The default PIN number of a new TV set is ‘0-0-0-0’. Setup If you want to reset this feature... Time Broadcast Security NN If you want to change PIN(Personal Identification Number), refer to page 24. NN The Plug & Play feature is only available in the TV mode. Network General Channel Control Storing Channels ❑❑ Country „„ Analogue Channel: You can change the country for analogue channels. Channel „„ Digital Channel: You can change the country for digital channels. Country NN The PIN number input screen appears. Enter your 4 digit PIN number. Auto Store ❑❑ Auto Store Scans for all channels with active broadcast stations (and availability depends on your country) and stores them in the TV's memory. You set the TV to memorize the channels of the selected connection.

• • Air: Air antenna signal.
• • Cable: Cable antenna signal.

You can select the antenna source to memorize.

• • Digital & Analogue: Digital and Analogue channels.
• • Digital: Digital channels.
• • Analogue: Analogue channels. NN When selecting Cable,
• • Search Mode: Displays the search mode. (Quick) - Network ID: Displays the network identification code. - Frequency: Displays the frequency for the channel. - Modulation: Displays available modulation values. - Symbol Rate: Displays available symbol rates.
• • Search Mode: Displays the search mode.(Full, Network) - Start Frequency: Displays the frequency start values. - End Frequency: Displays the frequency stop values. - Modulation: Displays available modulation values. - Symbol Rate : Displays available symbol rates. NN If you want to stop Auto Store, press the ENTERE button. The Stop Auto Store? message will be displayed. Select Yes by pressing the ◄ or ► button, then press the ENTERE button. English - 11 job.indb 11 2009-10-22 3:49:01 Scans for a channel manually and stores it in the TV’s memory. NN Digital Channel is only available in DTV mode.

• • Channel: Set the Channel number using the ▲, ▼ or number (0~9) buttons.
• • Frequency: Set the frequency using the number (0~9) buttons.
• • Bandwidth: Set the bandwidth using the ▲ or ▼ buttons. NN When it has finished, channels are updated in the channel list. „„ Analogue Channel Manual store for analogue channel.
• • Programme (Programme number to be assigned to a channel): Sets the programme number using the ▲, ▼ or number (0~9) buttons.
• • Colour System → Auto / PAL / SECAM / NTSC 4.43: Sets the colour system value using the ▲ or ▼ button.
• • Sound System → BG / DK / I / L : Sets the sound system value using the ▲ or ▼ button.
• • Channel (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel). Press the ► button, then press the ▲, ▼ or number (0~9) buttons to select the required number. NN If there is abnormal sound or no sound, reselect the sound standard required.
• • Search (When you do not know the channel numbers): Press the ▲ or ▼ button to start the search. The tuner scans the frequency range until the first channel or the channel that you selected is received on the screen.
• • Store (When you store the channel and associated programme number): Set to OK by pressing the ENTERE button. NN Channel mode - C (Air channel mode): You can select a channel by entering the assigned number to each air broadcasting station in this mode. - S (Cable channel mode): You can select a channel by entering the assigned number for each cable channel in this mode. You can set additional search options such as frequency and symbol rate for cable network searching. (Depending on the each country)
• • Freq.Start : Displays the frequency start values.
• • Freq.Stop : Displays the frequency stop values.
• • Modulation: Displays available modulation values.
• • Symbol Rate: Displays available symbol rates. NN If the Freq.Start value is bigger than Freq.Stop value, the warning message is displayed. The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information becomes available.
• • Full Guide: Displays the programme information as time ordered one hour segments. One hours of programme information is displayed which may be scrolled forwards or backwards in time.
• • Mini Guide: The information of each programme is displayed by each line on the current channel Mini Guide screen from the current programme onwards according to the programme starting time order. You can decide whether to display either the Mini Guide or the Full Guide when the GUIDE button on the remote control is pressed. Channel Channel Mode Channel List Channel Mode : Added Ch. Fine Tune OO You can also display the guide menu simply by pressing the GUIDE button. Continued... English - 12 job.indb 12 2009-10-22 3:49:01 DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information Today 2:00 - 3:00 f tn Freshmen O.. Street Hypn.. ITV Play Mint Extra Kerrang! Loaded Kiss Fresh 40 with Dynamite MC oneword The Distillery Smash Hits! Smash Hits! Sunday Watch Information 2:10 Tue 1 Jun 2:00 2:30 ▼ 5:00 DTV Cable 900 f tn Freshmen On Campus Street Hypnosis Booze Britain Watch Information Page Full Guide Exit Select a programme by pressing the ▲/▼/◄/►/ENTERE button. Toggle between the Mini Guide or Full Guide. Full Guide: Scroll backwards quickly (-24 hours). Full Guide: Scroll forwards quickly (+24 hours). BLUE Exit the guide. INFO INFO button for the detailed information. ❑❑ Channel Mode When the press the P (</>) button, Channels will be switched within the selected channel list. „„ Added Ch.: Channels will be switched within the memorized channel list. „„ Favourite Ch.: Channels will be switched within the favourite channel list. ❑❑ Fine Tune (Analogue channel only) If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, you may have to fine tune the channel manually. NN Fine tuned channels that have been saved are marked with an asterisk * on the right-hand side of the channel number in the channel banner. NN If you do not store the fine-tuned channel in memory, adjustments are not saved. NN To reset the fine-tuning, select Reset by pressing the ▼ button and then press the ENTERE button. Managing Channels NN Select a channel in the All Channels, Added Channels, Favourites, or Programmed An Analogue channel.

A channel selected by pressing the yellow button.

A channel set as a Favourite.

A programme currently being broadcast.

A reserved programme : Full Guide Channel List : Added Ch. Fine Tune

UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A NN Channel Status Display Icons

Default Guide Channel Mode All Channels screen by pressing the ▲ or ▼ buttons, and pressing the ENTERE button. Then you can watch the selected channel.

• • All Channels: Shows all currently available channels.
• • Added Channels: Shows all added channels.
• • Favourites: Shows all favourite channels.
• • Programmed: Shows all current reserved programmes. OO Press the CH LIST button on the remote control to bring up the channel lists. NN Using the Colour buttons with the Channel List -- Red (Channel Type): Toggle between your TV, Radio, Data/Other and All. -- Green (Zoom): Enlarges or shrinks a channel number. -- Yellow (Select): Selects multiple channel lists. -- T TOOLS (Tools): Displays the Delete (or Add), Add to Favourite (or Delete from Favourite), Lock (or Unlock), Timer Viewing, Edit Channel Name, Edit Channel Number, Sort, Select All (or Deselect All), or Auto Store menu. (The Tools menus may differ depending on the situation.) Mini Guide Channel Using this menu, you can Add / Delete or set Favourite channels and use the programme guide for digital broadcasts. All Channel Type Zoom Select Page Tools Continued... English - 13 job.indb 13 2009-10-22 3:49:02 ❑❑ Channel List Tools Menu (in All Channels / Added Channels / Favourites) NN Press the TOOLS button to use the Tools menu. NN The Tools menu items may differ depending on the channel status. „„ Add / Delete

All Channels You can delete or add a channel to display the channels you want. NN All deleted channels will be shown on All Channels menu. NN A gray-coloured channel indicates the channel has been deleted. NN The Add menu only appears for deleted channels. NN You can also delete a channel to the Added Channels or Favourites menu in the same manner.

A 3 A 4 A 5 A 6 A 7 A 8 C -C -C -C -C -C -C -- Add to Favourite

„„ Add to Favourite / Delete from Favourite You can set channels you watch frequently as favourites. All UKTV Gold UKTV style Lock Timer Viewing Edit Channel Name Sort

Channel Type Zoom Select Page Tools You can also add the favourite channel by selecting Tools → Add to Favourite (or Delete from Favourite). OO To select the Favourite channels you have set up, press the FAV.CH button on the remote control. NN The “♥” symbol will be displayed and the channel will be set as a favourite. NN All favourite channels will be shown on Favourite menu. „„ Lock / Unlock You can lock a channel so that the channel cannot be selected and viewed. This function is available only when the Child Lock is set to On. (see page 24) NN The PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is ‘0-0-0-0’. You can change the PIN, by selecting Change PIN from the menu. NN The “\” symbol will be displayed and the channel will be locked. If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List; even when you are watching another channel. To reserve a programme set the current time first. (See page 22) NN Only memorized channels can be reserved. NN You can set the channel, month, day, year, hour and minute directly by pressing the number buttons on the remote control. NN Reserving a programme will be shown on Programmed menu. NN Digital Programme Guide and Viewing Reservation When a digital channel is selected, and you press the ► button, the Programme Guide for the channel appears. You can reserve a programme according to the procedures described above. „„ Edit Channel Name (Analogue channel only) Channels can be labeled so that their call letters appear whenever the channel is selected. NN The names of digital broadcasting channels are automatically assigned and cannot be labeled. „„ Edit Channel Number (Digital channel only) You can also edit the channel number by pressing the number buttons on the remote control. „„ Sort (Analogue channel only) This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using the auto store. „„ Select All / Deselect All You can deselect or select all channels in the channel list. NN You can perform the Add / Delete, Add to Favourites / Delete from Favourites, or Lock / Unlock function for multiple channels at the same time. Select the required channels and press the yellow button to set all the selected channels at the same time. NN The c mark appears to the left of the selected channels. NN You can only select Deselect All when there is a selected channel. „„ Auto Store ❑❑ Channel List Tools Menu (in Programmed ) You can view, modify or delete a reservation. NN Press the TOOLS button to use the Tools menu.

• • Change Info: Select to change a viewing reservation.
• • Cancel Schedules: Select to cancel a viewing reservation.
• • Information: Select to view a viewing reservation. (You can also change the reservation information.)
• • Select All / Deselect All: Select or deselect all reserved programmes. Programmed NN For further details on setting up options, refer to page 11. NN If a channel is locked using the Child Lock function, the PIN input window appears. 1 / 1 / 2009 Zoom Select Change Quincy, Info M.E Cancel Schedules The Equalizer Information McMillan & Wife Select All Picture Control Changing the Picture Settings ❑❑ Mode You can select the type of picture which best corresponds to your viewing requirements. Picture You can also set the picture mode by selecting Tools → Picture Mode. NN When in PC mode, Eco is not available. ❑❑ Cell Light / Contrast / Brightness / Sharpness / Colour / Tint (G/R) Mode : Standard Cell Light

Contrast : 95 Brightness : 45 Sharpness : 50 Colour : 50 Tint (G/R) : G50/R50

Advanced Settings Your television has several setting options that allow you to control the picture quality.

• • Cell Light: Adjusts the pixel brightness.
• • Contrast: Adjusts the contrast level.
• • Brightness: Adjusts the brightness level.
• • Sharpness: Adjusts the sharpness.
• • Colour: Adjusts the colour saturation of the picture using the bar on the screen.
• • Tint (G/R): Adjusts the colour tint of the picture. NN When you make changes to Cell Light, Contrast, Brightness, Sharpness, Colour or Tint (G/R), the OSD will be adjusted accordingly. NN The adjusted values are saved for each picture mode. NN In Analogue TV, Ext., AV modes of the PAL system, you cannot use the Tint Function. NN In PC mode, you can only make changes to Cell Light, Contrast and Brightness. NN Each adjusted setting will be stored separately according to its input mode. NN The energy consumed during use can be significantly reduced if the level of brightness of the picture is reduced, and then this will reduce the overall running cost. ❑❑ Advanced Settings Picture You can adjust the advanced settings for your screen including the colour and contrast. NN Advanced Settings is available in Standard or Movie mode. NN In PC mode, you can only make changes to Dynamic Contrast, Gamma and White Balance from among the Advanced Settings items. Colour : 50 Tint (G/R) : G50/R50 Advanced Settings

You can enhance the picture depth by adjusting the black colour density. „„ Dynamic Contrast → Off / Low / Medium / High You can adjust the screen contrast so that the optimal contrast is provided. „„ Gamma You can adjust the primary colour (Red, Green, Blue) Intensity. „„ Colour Space Colour Space is a colour matrix composed of red, green and blue colours. Select your favourite Colour Space to experience the most natural colour.

• • Auto: Automatically sets the colour range depending on the input video source.
• • Native: Sets the colour range wider than the that of the input video source.
• • Custom: Adjusts the colour range to suit your preference. NN Customizing the Colour Space - Adjusts the Colour range to suit your preference. Colour is available when Colour Space is set to Custom. - Colour → Red / Green / Blue / Yellow / Cyan / Magenta - Red / Green / Blue: You can adjust the RGB values for the selected colour. - Reset: Resets the colour space to the default values. „„ White Balance You can adjust the colour temperature for more natural picture colours.
• • R-Offset / G-Offset / B-Offset / R-Gain / G-Gain / B-Gain: Changing the adjustment value will refresh the adjusted screen.
• • Reset: Resets the default white balance. Continued... English - 15 job.indb 15 2009-10-22 3:49:03 „„ Flesh Tone You can adjust the flesh tone to be more or less red. NN Changing the adjustment value will refresh the adjusted screen. „„ Edge Enhancement → Off / On You can emphasize object boundaries in the picture. „„ xvYCC → Off / On Setting the xvYCC mode to on increases detail and colour space when watching movies from an external device (i.e. DVD player). NN xvYCC is available when the picture mode is set to Movie, and the external input is set to HDMI or Component mode. NN This function may not be supported depending on your external device. You can customize the additional picture settings to suit your preference. NN In PC mode, you can only make changes to the Colour Tone, Size and Screen Burn Protection from among the items in Picture Options. : G50/R50 Advanced Settings Picture Options

Picture Reset „„ Colour Tone → Cool / Normal / Warm1 / Warm2 / Warm3 You can select the most comfortable colour tone to your eyes. NN The adjusted values are stored according to the selected Picture mode. NN Warm1, Warm2, or Warm3 is only activated when the picture mode is Movie. „„ Size → Auto Wide / 16:9 / Wide Zoom / Zoom / 4:3 / Screen Fit You can select the picture size which best corresponds to your viewing requirements.

• • Auto Wide: Sets the picture in Auto Wide format.
• • 16:9: Sets the picture to the 16:9 aspect ratio.
• • Wide Zoom: Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture vertically.
• • Zoom: Stretches the 16:9 aspect ratio picture vertically.
• • 4:3: Sets the picture to the 4:3 aspect ratio.
• • Screen Fit: Displays the full native HD signal that cannot be viewed using a normal TV. NN Depending on the input source, the picture size options may vary. NN The items available may differ depending on the selected mode. NN In PC Mode, only 16:9 and 4:3 mode can be adjusted. NN When Double ( , ) mode has been set in PIP, the Picture Size cannot be set. NN Settings can be adjusted and stored for each external device you have connected to an input of the TV. NN Temporary image retention may occur when viewing a static image on the set for more than two hours. NN Wide Zoom: Press the ► button to select Position, then press the ENTERE button. Press the ▲ or ▼ button to move the screen up / down. Then press the ENTERE button. NN Zoom: Press the ► button to select Position, then press the ENTERE button. Press the ▲ or ▼ button to move the picture up and down. Then press the ENTERE button. Press the ► button to select Size, then press the ENTERE button. Press the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the ENTERE button. NN After selecting Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing the ◄ or ►button. Use the ▲, ▼, ◄ or ► button to move the picture. NN Reset: Press the ◄ or ► button to select Reset, then press the ENTERE button. You can initialize the setting. NN If you use the Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the overscan function. When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS (Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is intended for users to select it. NN This function is available in Auto Wide mode. NN This function is not available in PC, Component or HDMI mode. „„ Digital NR → Off / Low / Medium / High / Auto If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen. NN When the signal is weak, select one of the other options until the best picture is displayed. You can directly select the black level on the screen to adjust the screen depth. NN This function is active only when the external input connects to HDMI (RGB signals). Continued... English - 16 job.indb 16 2009-10-22 3:49:03 Samsung's new generation PDP panels deliver stunning Full HD motion clarity when viewing fast action sports, movies, and games. NN This function is not available in PC, Game or Media Play mode. „„ Film Mode You can optimize the picture mode for watching movies.
• • Off: Turn the Film Mode function off.
• • Auto1: Automatically adjusts the picture for the best quality when watching a film.
• • Auto2: Automatically optimizes the video text when watching a film.
• • Cinema Smooth: Offers the ultimate cinema experience. NN Film mode is supported in TV, Video, Component(480i / 1080i) and HDMI(1080i). You can get a clear distinction between Real 100Hz and 50Hz, especially when watching fast moving scenes. Therefore, when seeing slow moving scenes, you will not be able to distinguish between Real 100Hz and 50Hz. Demo 100Hz works only with 50Hz signal. Real 100Hz demo mode is provided for shop demonstration with special pictures. „„ Blue Only Mode → Off / On This function is for AV device measurement experts. This function displays the blue signal only by removing the red and green signals from the video signal so as to provide a Blue Filter effect that is used to adjust the Colour and Tint of video equipment such as DVD players, Home Theaters, etc. NN Blue Only Mode is available when the picture mode is set to Movie or Standard. „„ Screen Burn Protection To reduce the possibility of screen burn, this unit is equipped with screen burn prevention technology. This technology enables you to set picture movement up/down (Vertical) and side to side (Horizontal). The Time setting allows you to program the time between movement of the picture in minutes.
• • Pixel Shift: Using this function, you can minutely move pixels on the PDP in horizontal or vertical direction to minimize after image on the screen. NN Optimum condition for pixel shift Horizontal Item TV/Ext./AV/Component/HDMI/PC 0~2

Time (minute) 1~4 min 2 min NN The Pixel Shift value may differ depending on the monitor size (inches) and mode. NN This function is not available in the Screen Fit mode.

• • Scrolling: This function helps remove after images on the screen by moving all the pixels on the PDP according to a pattern. Use this function when there are remaining after images or symbols on the screen especially when you displayed a still image on the screen for a long time.
• • Side Grey: When you watch TV with the screen ratio of 4:3, the screen is prevented from any damage by adjusting the white balance on both extreme left and right sides. - Light: When you set the screen ratio to 4:3, it brightens the left and right sides. - Dark: When you set the screen ratio to 4:3, it darkens the left and right sides. Advanced Settings Picture Picture Resets all picture settings to the default values. NN Select a picture mode to be reset. The reset is performed for each picture mode. Picture Options Picture Reset

English - 17 job.indb 17 2009-10-22 3:49:04 Setting up the TV with your PC NN Preset: Press the SOURCE button to select PC mode. ❑❑ Auto Adjustment Picture Auto Adjustment allows the PC screen of set to self-adjust to the incoming PC video signal. The values of fine, coarse and position are adjusted automatically. NN This function does not work in DVI-HDMI mode. Brightness : 45 Sharpness : 50 Auto Adjustment

Screen You can also set the auto adjustment by selecting Tools → Auto Adjustment. Advanced Settings Picture Options Picture Reset ❑❑ Screen The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (Coarse) and Fine-tune again. After the noise has been reduced, readjust the picture so that it is aligned on the center of screen. „„ Coarse Adjusts the frequency when vertical noise appears on the screen. „„ Fine Adjusts the screen to be clearer. „„ PC Position Adjust the PC’s screen positioning if it does not fit the TV screen. Press the ▲ or ▼ button to adjusting the Vertical-Position. Press the ◄ or ► button to adjust the Horizontal-Position. „„ Image Reset You can replace all image settings with the factory default values. English - 18 job.indb 18 2009-10-22 3:49:04 PC Display ❑❑ Setting Up Your PC Software (Based on Windows XP)

The Windows display-settings for a typical computer are shown below. The actual screens on your PC will probably be different, depending upon your particular version of Windows and your particular video card. However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) First, click on ‘Control Panel’ on the Windows start menu. When the control panel window appears, click on ‘Appearance and Themes’ and a display dialog-box will appear. When the control panel window appears, click on ‘Display’ and a display dialog-box will appear. Navigate to the ‘Settings’ tab on the display dialog-box. The correct size setting (resolution) Optimum: 1920 X 1080 pixels If a vertical-frequency option exists on your display settings dialog box, the correct value is ‘60’ or ‘60 Hz’. Otherwise, just click ‘OK’ and exit the dialog box. Both screen position and size will vary depending on the type of PC monitor and its resolution. The resolutions in the table are recommended. NN When using an HDMI/DVI cable connection, you must use the HDMI IN 1(DVI) jack. NN The interlace mode is not supported. NN The set might operate abnormally if a non-standard video format is selected. NN Separate and Composite modes are supported. SOG is not supported. NN Too long or low quality VGA cable can cause picture noise at high resolution modes (1920x1080). „„ D-Sub and HDMI/DVI Input Mode IBM MAC VESA CVT Resolution Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H/V) 640 x 350

1280 x 720 1280 x 960 640 x 480 1024 x 768 VESA DMT 1152 x 864

1280 x 800 1280 x 960 1280 x 1024 1360 x 768 1440 x 900 VESA DMT / DTV CEA VESA GTF English - 19 job.indb 19 2009-10-22 3:49:04 Sound Control Changing the Sound Setting ❑❑ Mode Mode : Custom

Equalizer You can also configure the sound mode by selecting Tools → Sound Mode. ❑❑ Equalizer

Sound You can select the type of special sound effect to be used when watching a given broadcast. „„ Standard / Music / Movie / Clear Voice / Custom SRS TruSurround HD : Off Audio Language

Audio Description Auto Volume The sound settings can be adjusted to suit your personal preferences. Speaker Select Mode: You can select a sound mode to suit your personal preferences. Balance: Controls the balance between the right and left speakers. 100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth Adjustment): Adjusts the level of different bandwidth frequencies Reset: Resets the equalizer settings to the default values. ❑❑ SRS TruSurround HD → Off / On SRS TruSurround HD is the combined technology of TruSurround and FOCUS, TruBass. SRS TruSurround HD enables you to enjoy a virtual 5.1 Surround Sound effect over the TV's two speakers. This function provides not only rich deep bass also improves high frequency resolution. You can also set the SRS TruSurround HD by selecting Tools → SRS TS HD. TruSurround HD, SRS and the symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is incorporated under license from SRS Labs, Inc. NN If the sound is abnormal while TV is playing music, please adjust the equalizer and SRS TruSurround HD (Off/On). ❑❑ Audio Language (Digital channel only) You can change the default value for audio languages. Displays the language information for the incoming stream. NN You can only select the language among the actual languages being broadcast. ❑❑ Audio Format → MPEG / Dolby Digital (Digital channel only) When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function. NN You can only select the language among the actual languages being broadcast. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. ❑❑ Audio Description (Digital channel only) This is an auxiliary audio function that provides an additional audio track for visually challenged persons. This function handles the Audio Stream for the AD (Audio Description), when it is sent along with the Main audio from the broadcaster. Users can turn the Audio Description On or Off and control the volume. OO You can select these options simply by pressing the AD button on the remote control. „„ Audio Description → Off / On Turn the audio description function on or off. „„ Volume Adjusts the audio description volume. NN Volume is active when Audio Description is set to On. Continued... English - 20 job.indb 20 2009-10-22 3:49:05 ❑❑ Auto Volume → Off / On Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume every time the channel is changed. This feature lets you automatically adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low. ❑❑ Speaker Select → External Speaker / TV Speaker If you want to hear the sound through separate speakers, cancel the internal amplifier. NN The – +, MMUTE buttons do not operate when the Speaker Select is set to External Speaker. NN If you select External Speaker in the Speaker Select menu, the sound settings will be limited. TV's Internal Speakers Audio Out (Optical, L / R Out) to Sound System Video No Signal Mute Mute ❑❑ Sound Select When the PIP feature is activated, you can listen to the sound of the sub (PIP) picture.

• • Main: Listen to the sound of the main picture.
• • Sub: Listen to the sound of the sub picture. TT Press the TOOLS button to to display Tools menu. You can also set the sound of the sub picture by selecting Tools → PIP → Sound Select. NN You can select this option when PIP is set to On. „„ Reset All / Reset Sound Mode / Cancel: You can restore the Sound settings to the factory defaults. Speaker Select : TV Speaker Sound Select : Main Sound Reset

Selecting the Sound Mode When you set to Dual l ll, the current sound mode is displayed on the screen. NICAM Stereo Type of broadcast On-screen indication Regular broadcast (Standard audio) Mono (Normal use) Regular + NICAM Mono NICAM Mono (Normal) NICAM-Stereo NICAM Stereo Mono (Normal)

Stereo NICAM Dual-2 NICAM Dual-1 NICAM Dual-I/II Regular broadcast (Standard audio) Mono (Normal) Mono (Normal use) Mono (Forced mono) NN If the stereo signal is weak and an automatic switching occurs, then switch to the mono. NN This function is only activated in stereo sound signal. It is deactivated in mono sound signal. NN This function is only available in TV mode. TT Press the TOOLS button to to display Tools menu. You can also select the sound mode by selecting Tools → Dual l ll. English - 21 job.indb 21 2009-10-22 3:49:05 Function Description Setting the Time ❑❑ Clock Setting the clock is necessary in order to use the various timer features of the TV. NN The current time will appear every time you press the INFO button. NN If you disconnect the power cord, you have to set the clock again. : English Time

Broadcast Security Network „„ Clock Mode General You can set up the current time manually or automatically.

• • Auto: Set the current time automatically using the time from the digital broadcast.
• • Manual: Set the current time to a manually specified time. „„ Clock Set Time You can set the current time manually. NN Set up this item when you have set Clock Mode to Manual. NN You can set the Day, Month, Year, Hour, Minute directly by pressing the number buttons on the remote control. ❑❑ Sleep Timer → Off / 30 min / 60 min / 90 min / 120 min / 150 min / 180 min The sleep timer automatically shuts off the TV after a preset time. (30, 60, 90, 120, 150 and 180 minutes). NN The TV automatically switches to standby mode when the timer reaches 0. NN To cancel the Sleep Timer function, select Off. Clock

Sleep Timer : Off Timer 1 : Inactivated Timer 2 : Inactivated Timer 3 : Inactivated U Move E Enter

R Return You can also set the sleep timer by selecting Tools → Sleep Timer. You can set the TV to turn on or off at a desired time. On Time: Sets the time for the TV to turn on. Off Time: Sets the time for the TV to turn off. Volume: Set the required volume level. Source : Selects TV, USB device. NN When you select the TV, you can set the Antenna and Channel. -- Antenna: Selects Air or Cable. -- Channel: Select the desired channel. NN When you select the USB, you can set the Contents. -- Contents: Selects the desired contents on the USB. NN If the folder containing a music file is not selected or there is no music file on the USB, Timer function does not operate correctly.

• • Repeat : Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or Manual. NN When Manual is selected, press the ► button to select the desired day of the week. Press the ENTERE button over the desired day and the c mark will appear. NN The whole folder on the USB are supports English 64 character. NN You must set the clock first. NN You can set the hour, minute and programme by pressing the number buttons on the remote control. NN Auto Power Off When you set the timer On, the television will eventually turn off, if no controls are operated for 3 hours after the TV was turned on by the timer. This function is only available in timer On mode and prevents overheating, which may occur if a TV is on for too long time. English - 22 job.indb 22 2009-10-22 3:49:05 You can set the menu language. ❑❑ Broadcast Plug & Play Menu Language : English

Time Broadcast „„ Subtitle Security You can activate and deactivate the subtitles. Use this menu to set the Subtitle Mode. Normal under the menu is the basic subtitle and Hard of hearing is the subtitle for a hearing-impaired person.

• • Subtitle → Off / On: Switches subtitles off or on.
• • Mode → Normal / Hard of hearing: Sets the subtitle mode.
• • Subtitle Language: Set the subtitle language. NN If the programme you are watching does not support the Hard of hearing function, Normal automatically activates even though Hard of hearing mode is selected. NN English is the default in cases where the selected language is unavailable in the broadcast. OO You can select these options simply by pressing the SUBT. button on the remote control. Network General If the programme is broadcast with digital text, this feature is enabled. NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) An International standard for data encoding systems used in multimedia and hypermedia. This is at a higher level than the MPEG system which includes data-linking hypermedia such as still images, character service, animation, graphic and video files as well as multimedia data. MHEG is user runtime interaction technology and is being applied to various fields including VOD (Video-On-Demand), ITV (Interactive TV), EC (Electronic Commerce), tele-education, tele-conferencing, digital libraries and network games. „„ Teletext Language You can set the Teletext language by selecting the language type. NN English is the default in cases where the selected language is unavailable in the broadcast. „„ Preference

• • Primary Audio Language / Secondary Audio Language / Primary Subtitle Language / Secondary Subtitle Language / Primary Teletext Language / Secondary Teletext Language Using this feature, users can select one of the languages. The language selected here is the default when the user selects a channel. If you change the language setting, the Subtitle Language, Audio Language, and the Teletext Language of the Language menu are automatically changed to the selected language. The Subtitle Language, Audio Language, and the Teletext Language of the Language menu show a list of languages supported by the current channel and the selection is highlighted. If you change this language setting, the new selection is only valid for the current channel. The changed setting does not change the setting of the Primary Subtitle Language, Primary Audio Language, or the Primary Teletext Language of the Preference menu. „„ Common Interface

• • Installing the CI(CI+) Card

1. Purchase the CI(CI+) CAM module by visiting your nearest dealer or by phone.

2. Insert the CI(CI+) CARD into the CAM in the direction of the arrow until it fits.

3. Insert the CAM with the CI(CI+) CARD installed into the common interface slot.

NN Insert the CAM in the direction of the arrow, right up to the end so that it is parallel with the slot.

4. Check if you can see a picture on a scrambled signal channel.

• • CI(CI+) Menu This enables the user to select from the CAM-provided menu. Select the CI(CI+) Menu based on the menu PC Card.
• • Application Info. This contains information on CAM inserted in the CI(CI+) slot and displays it. The Application Info inserting is about the CI(CI+) CARD. You can install the CAM anytime whether the TV is ON or OFF. NN ‘CI(CI+) CARD’ is not supported in some countries, regions, broadcasting stations check with your authorized dealer. Continued... English - 23 job.indb 23 2009-10-22 3:49:05 ❑❑ Security NN Some models require selecting the set PIN number when operating Plug & Play. „„ Child Lock → Off / On This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by muting out video and audio. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is ‘0-0-0-0’. You can change the PIN by selecting Change PIN from the menu. NN You can lock some channels in Channel List. (refer to page 13) NN Child Lock is available only in TV mode. „„ Parental Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by a 4-digit PIN (Personal Identification Number) code that is defined by the user. NN The Parental Rating item differs depending on the country. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is ‘0-0-0-0’. You can change the PIN by selecting Change PIN from the menu. NN When the parental ratings are set, the “\” symbol is displayed. NN Allow All / Block All: Press to unlock or lock all TV ratings. „„ Change PIN You can change your personal ID number that is required to set up the TV. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number (The default PIN number : ‘0-0-0-0’). NN If you forget the PIN code, press the remote control buttons in the following sequence, which resets the PIN to ‘0-0-0-0’: POWER (Off), MMUTE, 8, 2, 4, POWER (On). ❑❑ General „„ Game Mode → Off / On When connecting to a game console such as PlayStationTM or XboxTM, you can enjoy a more realistic gaming experience by selecting the game menu.
• • When the Game Mode is On -- Picture Mode is automatically changed to Standard and users cannot change the mode. -- Sound Mode is automatically changed to Custom and users cannot change the mode. Adjust the sound using the equalizer. -- The Reset in the Sound menu is activated. Reset function initializes the Equalizer settings to the factory default setting. NN Game Mode is not available in regular TV mode or Game Mode set to Off. NN If the picture is poor when external device is connected to TV, check if Game Mode is On. NN If you display the TV menu in Game mode, the screen shakes slightly. appears on the screen which means that Game Mode is on with the selected source. NN The mark NN This function supports only game function. NN Game mode is not available in PC mode. Wise is a function that enables you automatically to set the optimum condition all connected Samsung devices that support BD Wise. NN This function is active only when an external device is connected to the TV via HDMI. NN When the BD Wise set to On, picture mode is automatically changed under the conditions Continued... English - 24 job.indb 24 2009-10-22 3:49:06 „„ Energy Saving → Off / Low / Medium / High / Picture Off This feature adjusts the brightness of the TV in order to reduce power consumption. When watching TV at night, set the Energy Saving mode option to High to reduce eye fatigue as well as power consumption. If you select Picture Off, the screen is turned off and you can only hear the sound. Press any button to get out of Picture Off. NN In the Tools menu, Picture Off function is not supported. You can also set the Energy Saving option by selecting Tools → Energy Saving. You can set the transparency of the on-screen menu.
• • Bright: Sets the on-screen menu to normal.
• • Dark: changes the on-screen menu to opaque. „„ Melody → Off / Low / Medium / High The TV power on / off melody sound can be adjusted. NN The Melody does not play - When no sound is output from the TV because the M MUTE button has been pressed. - When no sound is output from the TV because the – (Volume) button has been pressed. - When the TV is turned off by Sleep Timer function. Viewing the Picture in Picture (PIP) You can display a sub picture within the main picture of set programme me or video input. In this way, you can watch the picture of set programme me or video input from any connected equipment while watching the main picture. NN You may notice that the picture in the PIP window becomes slightly unnatural when you use the main screen to view a game or karaoke. TT Press the TOOLS button to display Tools menu. You can also configure PIP related settings by selecting Tools → PIP. General Game Mode : Off BD Wise : Off Energy Saving : Off Menu Transparency : Bright Melody ❑❑ PIP → Off / On You can activate or deactivate the PIP function. E Enter R Return PIP Main picture Sub picture

You can select a size of the sub-picture. NN If main picture is in HDMI mode, Size is not available. PIP : Off Size

Channel : ATV 1 E Enter

R Return „„ Position →

You can select a position of the sub-picture. NN In Double ( , ) mode, Position cannot be selected. „„ Channel You can select a channel of the sub-picture. English - 25 job.indb 25 2009-10-22 3:49:06 Support / Input Supported Program ❑❑ Legal Notice You can view legal notice and general disclaimer regarding third party contents and services. This is full legal notice service regarding the Internet@TV. NN The General Disclaimer may differ depending on the country. NN You can move the previous or next page by pressing the ◄ or ► button. The Product Guide gives you information on the most important features of this TV. NN For more detailed information, select the desired item. ❑❑ Self Diagnosis „„ Picture Test If you think you have a picture problem, perform the picture test. Check the colour pattern on the screen to see if the problem still exists. NN Does the problem still exist with this test photo? appears on the screen. If the test pattern does not appear or there is noise in the test pattern, select Yes. If the test pattern is properly displayed, select No.

• • Yes : There may be a problem with the TV. Contact Samsung’s Call Center for assistance.
• • No : There may be a problem with your external equipment. Please check your connections. If the problem still persists, refer to the external device’s user manual. „„ Sound Test If you think you have a sound problem, please perform the sound test. You can check the sound by playing a built-in melody sound through the TV. NN Does the problem still exist with this sound test? appears on the screen. If during the sound test you can hear sound only from one speaker or not at all, select Yes.If you can hear sound from the speakers, select No.
• • Yes : There may be a problem with the TV. Contact Samsung’s Call Center for assistance.
• • No : There may be a problem with your external equipment. Please check your connections. If the problem still persists, refer to the external device’s user manual. NN If you hear no sound from the TV’s speakers, before performing the sound test, make sure Speaker Select is set to TV speaker in the Sound menu. NN The melody will be heard during the test even if Speaker Select is set to External Speaker or the sound is muted by pressing the MMUTE button. „„ Signal Information (Digital channels only) You can adjust your antenna to improve the reception of available digital channels. NN If the signal strength meter indicates that the signal is weak, physically adjust your antenna to increase the signal strength. Continue to adjust the antenna until you find the best position with the strongest signal. Continued... English - 26 job.indb 26 2009-10-22 3:49:06 ❑ Software Upgrade To keep your product up-to-date with new Digital Television features then software upgrades are periodically broadcast as part of the normal Television signal. It will automatically detect these signals and display the software upgrade banner. You are given the option to install the upgrade.

By USB Insert a USB drive containing the firmware upgrade into TV. Please be careful to not disconnect the power or remove the USB drive while upgrades are being applied. The TV will turn off and turn on automatically after completing the firmware upgrade. Please check the firmware version after the upgrades are complete. When software is upgraded, video and audio settings you have made will return to their default (factory) settings. TV Rear Panel USB Drive

By Channel Upgrades the software using the broadcasting signal. N If the function is selected during the software transmission period, this function searches for available software and downloads the software. N The time required to download the software is determined by the signal status.

Standby Mode Upgrade To continue software upgrade with master power on, Select On by pressing the ▲ or ▼ button. 45 minutes after entering standby mode, a manual upgrade is automatically conducted. Since the power of the unit is turned on internally, the screen may be on slightly for the product. This phenomenon may continue for more than 1 hour until the software upgrade is completed.

Alternative Software Show the previous version that would be replaced. N If software was changed, existing software is displayed. N You can change current software to alternative software by Alternative Software. ❑ HD Connection Guide The brief instruction on how to get the best performance from your new HDTV is displayed. We offer the connection method for HD devices. N You can move the previous or next page by pressing the ◄ or ► button. ❑ Contact Samsung You can know the Samsung Call center, website and information for product. Source List / Edit Name ❑ Source List

Input Use to select TV or other external input sources such as DVD players or Cable Box / Satellite receivers (Set-Top Box) connected to the TV. Use to select the input source of your choice. Source List Edit Name TV, Ext., AV, Component, PC, HDMI1/DVI, HDMI2, HDMI3, HDMI4, USB. N You can choose only those external devices that are connected to the TV. In the Source List, connected inputs will be highlighted and sorted to the top. Inputs that are not connected will be sorted to the bottom. N Using the Colour buttons on the remote with the Source list - Red (Refresh): Refreshes the connecting external devices. - T TOOLS (Tools): Displays the Edit Name and Information menus. O Press the SOURCE button on the remote control to view an external signal source. ❑ Edit Name You can name the device connected to the input jacks to make your input source selection easier.

VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI / DVI PC / TV / IPTV / Blu-ray / HD DVD / DMA N When a PC with a resolution of 1920 x 1080@60Hz is connected to the HDMI IN 1 (DVI) port, you should set the HDMI1/DVI mode to PC in the Edit Name of the Input mode. English - 27 job.indb 27 2009-10-22 3:49:06 Network Network Connection Network Connection is for DLNA, Contents Library-Internet download, Internet@TV and Home Network Centre. ❑❑ Network Connection - Cable „„ LAN Connection for a DHCP Environment The procedures to set up the network using Dynamic Host Configuration Protocol (DHCP) are described below. Since an IP address, subnet mask, gateway, and DNS are automatically allocated when DHCP is selected, you do not have to enter them manually. TV Rear Panel The Modem Port on the Wall External Modem (ADSL/VDSL/Cable TV) 1 LAN Cable 2 Modem Cable

Connect the LAN port on the rear panel of the TV and the external modem with a LAN Cable. Connect the LAN port on the wall and the external modem with a Modem Cable. You can connect the LAN via a Sharer (Router). IP Sharer The Modem Port on the Wall External Modem (ADSL/VDSL/ Cable TV) TV Rear Panel LAN Cable Modem Cable LAN Cable You can connect the LAN port and the TV directly depending on your network status. TV Rear Panel The LAN Port on the Wall Modem Cable NN The terminals (the position of the port and the type) of the external device may differ depending on the manufacturer. NN If the IP address allocation by the DHCP server has failed, turn the external modem off, turn it on again after at least 10 seconds and then try again. NN For the connections between the external modem and the Sharer (Router), refer to the owner’s manual of the corresponding product. NN You can connect the TV to the LAN directly without connecting it through a Sharer (Router). NN You cannot use a manual-connection-type ADSL modem because it does not support DHCP. You have to use an automaticconnection-type ADSL modem. Continued... English - 28 job.indb 28 2009-10-22 3:49:07 „„ LAN Connection for Static IP Environment The procedures to set up the network using a static IP address are described below. You have to manually enter the IP address, subnet mask, gateway, and DNS that are provided by your Internet Service Provider (ISP). TV Rear Panel The LAN Port on the Wall 1 LAN Cable

Connect the LAN port on the rear panel of the TV and the LAN port on the wall using the LAN cable. You can connect the LAN via a Sharer (Router). The LAN Port on the Wall IP Sharer LAN Cable TV Rear Panel LAN Cable NN The terminals (the position of the port and the type) of the external device may differ depending on the manufacturer. NN If you are using a static IP address, your ISP will inform you of the IP address, subnet mask, gateway, and DNS.

You must enter these values to complete the network settings. If you do not know the values, ask your network administrator. For the information on how to configure and connect a Sharer (Router), refer to the owner’s manual for the corresponding product. You can connect the TV to the LAN directly without connecting it through a Sharer (Router). If you use an IP Sharer (IP Router) that supports DHCP, you can set up the device as either DHCP or static IP. For the procedures to use a static IP address, ask your Internet Service Provider. ❑❑ Network Connection - Wireless You can connect to the network wirelessly through a wireless IP sharer. TV Rear Panel Samsung Wireless LAN Adapter The LAN Port on the Wall Wireless IP sharer LAN Cable

Connect the ‘Samsung Wireless LAN Adapter’ into the USB 1 (HDD) or USB 2 terminal of the TV. NN You must use the ‘Samsung Wireless LAN Adapter to use a wireless network. NN Samsung’s Wireless LAN adapter is sold separately. The WIS09ABGN Wireless LAN adapter is offered by select retailers, Ecommerce sites and Samsungparts.com. NN To use a wireless network, your TV must be connected to a wireless IP sharer. NN If the wireless IP sharer supports DHCP, your TV can use a DHCP or static IP address to connect to the wireless network. NN Samsung’s Wireless LAN adapter supports IEEE 802.11A, IEEE 802.11B, IEEE 802.11G, IEEE 802.11N. When you play DLNA video over IEEE 802.11B/G connection, the video may not be played smoothly. NN If the wireless IP sharer allows you to turn the Ping connection function on/off, turn it on. NN Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer is currently being used by another device nearby, this will result in interference and communications may fail. Continued... English - 29 job.indb 29 2009-10-22 3:49:09 NN If you apply a security system other than the systems listed below, it will not work with the TV. -- When applying the security key for the AP (wireless IP sharer), only the following is supported.

1) Authentication Mode : OPEN, SHARED, WPAPSK, WPA2PSK

2) Encryption Type : WEP, TKIP, AES

-- When applying the security key for the Ad-hoc mode, only the following is supported.

1) Authentication Mode : SHARED, WPANONE

2) Encryption Type : WEP, TKIP, AES

NN If your AP supports WPS(Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration) or PIN (Personal Indentification Number). WPS will automatically configure the SSID and WPA key in either mode. NN If the device isn’t certified, it may not connect to the TV via the ‘Samsung Wireless LAN Adapter’. Network Setup ❑❑ Network Type Broadcast Setup Select Cable or Wireless as the method to connect to the network. NN The menu is activated only if the ‘Samsung Wireless LAN Adapter’ is connected.

• • Cable: Connect to network using a cable.
• • Wireless: Connect to network wirelessly. Security Network

General ❑❑ Network Setup „„ Cable Network Setup (when Network Type is set to Cable) NN Please check if the LAN cable is connected.

• • Internet Protocol Setup → Auto / Manual
• • Network Test: You can test or confirm the network connection status after setting up the network. NN When unable to connect to a wired network If your Internet service provider has registered the MAC address of the device used to connect to the Internet for the first time and authenticates the MAC address each time you connect to the Internet, your TV may not be able to connect to the Internet as the MAC address differs from that of the device (PC). In this case, ask your Internet service provider about the procedures to connect devices other than your PC (such as your TV) to the Internet. If your Internet service provider requires an ID or password to connect to the Internet (network), your TV may not be able to connect to the Internet. In this case, you have to enter your ID or password when connecting to the Internet using an Internet Sharer (Router). The internet connection may failure to a firewall problem. In this case, contact your Internet service provider. If you cannot connect to the Internet even if you have followed the procedures of your Internet service provider, please contact a Samsung Electronics. „„ Cable Network Setup-Auto If you connect the LAN cable and it supports DHCP, the Internet Protocol (IP) Settings are automatically configured.

1. Set Network Type to Cable.

2. Select Cable Network Setup.

3. Set Internet Protocol Setup to Auto.

NN The Internet Protocol is set automatically.

4. Select Network Test to check the network connectivity.

To connect the TV to the LAN using a static IP address, you must set up the Internet Protocol (IP). NN Please check if the LAN cable is connected. (See page 28)

Set Network Type to Cable. Select Cable Network Setup. Set Internet Protocol Setup to Manual. Set up IP Address, Subnet Mask, Gateway and DNS Server. NN Press the number buttons on the remote control when you set the Network manually.

5. Select Network Test to check the network connectivity.

English - 30 job.indb 30 2009-10-22 3:49:09 „„ Wireless Network Setup (when Network Type is set to Wireless) NN The menu is activated only if the ‘Samsung Wireless LAN Adapter is connected. (See page 29)

• • Internet Protocol Setup → Auto / Manual
• • Network Test: You can test or confirm the network connection status after setting up the network. NN When unable to connect to an AP Your TV may fail to locate an AP that is configured as a private SSID type. In this case, please change the AP settings and try again. If your Internet service provider has registered the MAC address of the device used to connect to the Internet for the first time and authenticates the MAC address each time you connect to the Internet, your TV may not be able to connect to the Internet as the MAC address differs from that of the device (PC). In this case, ask your Internet service provider about the procedures to connect devices other than your PC (such as your TV) to the Internet. If you cannot connect to the Internet even if you have followed the procedures of your Internet service provider, please contact a Samsung Electronics at 1-800-SAMSUNG.
• • Select a network -- Access Point: You can select the IP sharer to use when using a wireless network. Wireless Network Setup NN If a wireless network is not in the Select a network list, press the Red button. NN When the connection is made, you will be returned to the screen automatically. NN If you have selected an Access Point with a security authentication: The Security Key input screen appears. Enter the security key and press the Blue button on the remote control. NN If security encryption type is WEP, 0~9, A~F will be available when you input security key. Button Moves the selection up/down/left/right. ENTER Enters (Inputs) the selected character. Red button Switch between Upper- and Lower-Case Letters Blue button

Number Lowercase Delete Done Number E Enter R Return Operations

• Key You can delete an already entered character. Press this button to finish entering the security key. ❑❑ Connecting WPS (Wi-Fi Protected Setup) Wireless* Network Setup „„ If Security Key is already set: In access point list, select WPS. NN You can select PBC, PIN, Security Key. Select* a* network

Ad-hoc 3/9 AP_1 AP_2 AP_3 AP_4 PBC PIN Security Key

n Move E Enter R Return

• • Connecting by using PBC: Select a PBC (Push Button Configuration). Press the PBC button on the AP (access point) within 2minutes, and wait for connection. Press the PBC button on the access point.
• : AP_3 Access Point Name Cancel

• • Connecting by using PIN: Select a PIN (Personal Identification Number). NN The message showing the PIN Code is displayed. Input the PIN Code at AP device within 2minutes. Select OK and wait for connection. NN Try again if connecting operation doesn’t work NN When the connection is not established although tried again, reset the access point. Please refer to a manual of each access point.
• • Connecting by using Security Key: When selecting Security Key, the input window is displayed. Input the security key and press Blue button. NN Try again if connecting operation doesn’t work. Press OK After input TV’s Pincode in the access point’s setup. Access Point Name : AP_3 PIN Code : 12345678 Cancel

Wireless* Network*Setup Security

Number Lowercase Delete Done Number E Enter R Return Continued... English - 31 job.indb 31 2009-10-22 3:49:10 „„ If Security Key is not set: When the security setting of AP that supports WPS Wireless* Network Setup is NONE, you can select PBC, PIN, None Security. None Security is capable of Select* a* network 3/9 connecting to AP directly without using WPS function. AP_1 PBC NN Process of PBC, PIN is same as above. Refer to if Security Key is already set. AP_2 PIN

• Search AP_3 NN Try again if connecting operation doesn’t work. Security Key AP_4
• Ad-hoc „„ Ad-hoc: You can connect to a mobile device without an access point through the ‘Samsung Wireless LAN Adapter’ by using a peer to peer network. n Move E Enter R Return
• • How to connect to new Ad-hoc

1. Choose Select a network, then a device list is displayed.

2. While in the device list, press the Blue button on the remote or select Ad-hoc.

NN The message The existing network system may have limited functionality. Do you want to change the network connection? is displayed.

3. Input the generated Network Name(SSID) and Security Key into the device you want to connect.

• • How to connect an existing Ad-hoc device The existing network system may have limited

1. Choose Select a network, the device list is displayed.

functionality. Do you want to change the network connection?

2. Select the device you want in the Device list.

3. If security key was applied, input the security key again.

Yes NN If network doesn’t operate normally, please check the Network Name(SSID) and Security Key again. If the Security Key is incorrect, it may be the reason for the malfunction. „„ Wireless Network Setup - Auto If you want to connect AP, AP should support DHCP. Only devices which support Ad-hoc mode can be connected without DHCP.

1. Set Network Type to Wireless.

2. Select Wireless Network Setup.

3. Set Internet Protocol Setup to Auto.

NN The Internet Protocol is set automatically.

4. Select a network through Select a network.

5. Select Network Test to check the network connectivity.

„„ Wireless Network Setup - Manual To connect the network wirelessly using a static IP address, you must set up the Internet Protocol (IP). (See page 29) NN For more detailed information of static IP address, refer to the user manual of your wireless IP sharer.

Set Network Type to Wireless. Select Wireless Network Setup. Set Internet Protocol Setup to Manual. Set up IP Address, Subnet Mask, Gateway and DNS Server. NN Press the number buttons on the remote control when you set the Network manually.

5. Select a network through Select a network.

6. Select Network Test to check the network connectivity.

Continued... English - 32 job.indb 32 2009-10-22 3:49:10 Media Play Connecting a USB Device

Press the POWER button to turn the TV on. TV Rear Panel Connect a USB device containing photo, music and movie files to the USB jack on the side of the TV. USB Drive USB 1 (HDD) jack is also used as the HDD jack. HDD (Hard disk drive) is device which stores digitally encoded data. Media Play only supports USB Mass Storage Class devices (MSC). MSC is a Mass Storage Class Bulk-Only Transport device. Examples of MSC are Thumb drives, Flash Card Readers and USB HDD (USB HUB are not supported.) MTP (Media Transfer Protocol) is not supported. The file system only supports FAT16/32 (The NTFS file system is not supported). Connect a USB HDD to the dedicated port, USB1 (HDD) port. However, if the connected device requires high power, the USB1 (HDD) may fail to support the device.) Certain types of USB Digital camera and audio devices may not be compatible with this TV. Please connect directly to the USB port of your TV. If you are using a separate cable connection, there may be a USB compatibility problem. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. Do not disconnect the USB device while it is loading. MSC supports MP3 and JPEG files, while a PTP device supports JPEG files only. The sequential JPEG format is supported. The higher the resolution of the image, the longer it takes to display on the screen. The maximum supported JPEG resolution is 15360X8640 pixels. For unsupported or corrupted files, the Not Supported File Format message is displayed. If the number of photo files exceeds 4000 (or the number of music files exceeds 3000), any files exceeding the 4000 limit may not be displayed in the Photo List (or Music List). MP3 files with DRM that have been downloaded from a non-free site cannot be played. DRM(Digital Rights Management) prevents illegal uses of digital media for copyright protection. When moving to a photo, loading may take a few seconds. ❑ Using the Remote Control Button in Media Play Menu Button Operations

Move the cursor and select an item. ENTERE Select the currently selected item. Play or pause the files while playing the Slide Sow, Music, or Movie files. Play or pause the Slide Show, Music, or Movie file. RETURN TOOLS Return to the previous menu. Run various functions from the Photo, Music and Movie menus. Stop the current Slide Show, Music or Movie file. Jump to previous group/Jump to next group. INFO MEDIA.P Show file information. Enter or Exit Media Play mode. DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. English - 33 job.indb 33 2009-10-22 3:49:11 Using the Media Play Function This function enables you to view and listen to photo, music and movie files saved on a USB Mass Storage Class (MSC) device. It might not work properly with unlicensed multimedia files. ❑❑ Entering the Media Play Menu

1. Press the MENU button. Press the ▲ or ▼ button to select Application, then

press the ENTERE button.

2. Press the ▲ or ▼ button to select Media Play (USB & DLNA), then press the

ENTERE button. OO Press the MEDIA.P button on the remote control to display the Media Play menu. OO Press the SOURCE button on the remote control repeatedly to select USB or DLNA, then press the ENTERE button.

3. Press the Red button, then press the ▲ or ▼ button to select the corresponding

USB Memory Device (i.e. if connected through a hub). Press the ENTERE button. NN This function differs depending on the USB Memory Device/ DLNA device connected to TV. NN The selected USB device name appears at the bottom left of the screen. Media Play

4. Press the ◄ or ► button to select an icon (Photo, Music, Movie, Setup), then

press the ENTERE button. NN To exit Media Play mode, press the MEDIA.P button on the remote control. NN In this mode, you can enjoy movie clips contained on a Game, but you cannot play the Game itself. Photo Folder Preference Basic View

You can remove the device safely from the TV.

1. Press the TOOLS button in the Media Play file list screen, or while a Slide Show,

music, or movie file is being played.

2. Press the ▲ or ▼ button to select Remove Safely, then press the ENTERE

3. Remove the USB device from the TV.

❑❑ Removing a USB Memory Device Safely Timeline Colour

4/6 Slide Show Play Current Group Information Remove Safely Folder 1 Preference Basic View Timeline

Device Tools R Upper Folder Nov

Folder Apr Jun Mar.01.2009 IMG_03496 IMG_03496 .JPG

.JPG Device IMG_0335.JPG

IMG_0343 .JPG IMG_03496 .JPG 1File(s) Selected Select

Current Sort Standard: This field shows the current standard for sorting files. View Groups: The sorting group including the currently selected photo is highlighted. Currently selected file: The currently selected file is highlighted. Item Selection Information: Shows the number of photos that are selected by pressing the Yellow button. Current Device: Shows the currently selected device name. NN Red (Device) button: Selects a connected device.

6. Help Items

• • Green (Favourites Setting) button: Changes the Favourites Setting for the selected file. Press this button repeatedly until the desired value appears.
• • Yellow (Select) button: Selects file from the file list. Selected files are marked with a symbol c. Press the yellow button again to cancel a file selection. (Tools) button: Displays the option menus. (The Tools menu changes according to the current status.) TOOLS

• • R RETURN (Return) button: Return to previous menu. English - 34 job.indb 34 2009-10-22 3:49:15 Sorting the Photo / Music / Movie List Photo Preference Basic View Timeline Mar

Mar.01.2009 1/67 IMG_03496 IMG_03496 .JPG .JPG „„ Folder Sorts the files by folder. If there are many folders in USB, the photos files are shown in order in each folder. The file in the Root folder is shown first and the others are shown in alphabetical order by name. , ★★★ , ★★★ , ★★★ Sorts the files by preference (Favourites). NN Changing the Favourites Settings Select the desired photo in the file list, then press the Green button repeatedly until the desired setting appears. NN The stars are for grouping purposes only. For example, the 3 star setting does not have any priority over the one star setting. USB Device Favorites Setting Select T Tools R Return Music Preference Folder

3/4 Carol kidd Mr A-Z

„„ Timeline (Photo / Movie) IMG_03496 .JPG IMG_0343 .JPG IMG_0335.JPG

Pop NPKI usermanual Heaven When I Dream Sorts and displays the music or movie titles in symbol/number/alphabet/special order.

„„ Preference → Folder Jun

Shows the folders on the USB memory device. If you select a folder and press the ENTERE button, corresponding files (Photo / Music / Movie) contained in the selected folder are displayed. NN When sorted according to the Basic View, you cannot set Favourites files.

„„ Basic View Apr.27.2009 1/5 ❑❑ Photo

Sorts the music titles in symbol/number/alphabet/special order, and shows the music file.

Select T Tools R Upper Folder „„ Colour → Red / Yellow / Green / Blue / Magenta / Black / Gray / Unclassified Sorts photos by colour. You can change the photo colour information. NN You should set the Use Colour View to on in the Setup menu before sorting photos by colour. Sorts the music file by artist in symbol/number/alphabet/special order. „„ Mood → Energetic / Rhythmical / Sad / Exciting / Calm / Unclassified Sorts music files by the mood. You can change the music mood information. „„ Genre Sorts music files by the genre. Continued... English - 35 job.indb 35 2009-10-22 3:49:19 Photo / Music / Movie List Option Menu Photo Colour Timeline Basic View

Press the MEDIA.P button. Press the ◄ or ► button to select Photo, Music or Movie then press the ENTERE button. Press the ◄ or ► button to select the desired file.

Folder 4/6 Slide Show Play Current Group NN Selecting Multiple Files

Change Group -- Press the ◄ or ► button to select the desired file. Then press the Yellow button. -- Repeat the above operation to select multiple files. -- The mark c appears to the selected file. Press the TOOLS button. Folder 1 Information Remove Safely Select T Tools R Upper Folder Music NN The option menu changes according to the current status. Preference Folder Basic View

„„ Play Current Group Title 3/4 Using this menu, you can play a SlideShow using only the photo files in the currently selected sorting group. Pop NPKI USB Sky Heaven When I Dream Select Device Select

Tools Tools R Upper Folder R Upper Folder Movie Preference Basic View Timeline Tiltle Folder Apr

„„ Information Remove Safely

You can deselect all files. NN The c mark indicating the corresponding file is selected is hidden. Information Mr A-Z usermanual „„ Deselect All (When at least one file is selected) Play Current Group Carol kidd NPKI Artist

The photo/ music/ movie file information is displayed. You can view the information of files during a SlideShow using the same procedures. OO Press the INFO button to viewing the information. Apr.27.2009 1/5 „„ Remove Safely .avi You can remove the device safely from the TV. Play Current Group USB Device MOVIE_004 .avi Select T Tools R Upper Folder ❑❑ Photo „„ Slide Show Using this menu, you can play a SlideShow using the photo files on the USB memory device. „„ Change Group (When the Sort key is the Colour) You can change a selected photo file’s (or group of files) colour information in order to move it from one colour group to another. NN This does not change the actual colour of the photo. NN The group information of the current file is updated and the photos are moved to the new colour group. NN To change the information of multiple files, select the files you want by pressing the Yellow button. ❑❑ Music „„ Change Group (When the Sort key is Mood) You can change the mood information of music files. The group information of the current file is updated and the file is moved to the new group. To change the information of multiple files, select files by pressing the Yellow button. Continued... English - 36 job.indb 36 2009-10-22 3:49:23 During a slide show (or when viewing a photo) or playing a music or movie, press the TOOLS button to set the option. Press the ▲ or ▼ button to select the desired option, then press the ENTERE button. „„ Picture Setting / Sound Setting You can select the picture and sound settings. „„ Information Tools Stop Slide Show Slide Show Speed Slide Show Effect Rotate Zoom Background Music Picture Setting Sound Setting Information Tools Normal

U Move The file information is displayed. „„ Remove Safely E Enter e Exit Tools You can remove the device safely from the TV. Repeat Mode Picture Setting Sound Setting Information Remove Safely „„ Stop Slide Show / Start Slide Show You can start or stop a SlideShow. U Move

e Exit „„ Slide Show Speed → Slow / Normal / Fast You can select the slide show speed. NN This function is available only during a slide show. Tools NN You can also change the speed of the Slide Show by pressing the π (REW) or μ (FF) button during the Slide Show. „„ Slide Show Effect You can select the screen transition effect used in the slideshow.

• • None / Fade1 / Fade2 / Blind / Spiral / Checker / Linear / Stairs / Wipe / Random NN This function is available only during a slide show. Picture Setting Sound Setting Picture Size Caption Setting Information Remove Safely

U Move Fit Enter e Exit „„ Rotate You can rotate photos saved on a USB memory device. NN Whenever you press the ◄ button, it rotates by 270˚, 180˚, 90˚, and 0˚. NN Whenever you press the ► button, it rotates by 90˚, 180˚, 270˚, and 0˚. NN The rotated file is not saved. „„ Zoom You can magnify photos saved on a USB memory device. (x1 → x2 → x4) NN To move the enlarged photo image, press the ENTERE button, then press the ▲/▼/◄/► buttons. Note that when the enlarged picture is smaller than the original screen size, the location change function doesn’t work. NN The enlarged file is not saved. „„ Background Music You can select background music when watching a Slide Show. NN To use this feature, there must be music and photo files stored on the USB device. NN Loading music files is needed to change BGM mode. Play music files in music category to load. You can play music files repeatedly. Play video at the screen size or original size. You can set the captions for the movie. English - 37 job.indb 37 2009-10-22 3:49:23 Viewing a Photo or Slide Show Photo ❑❑ Viewing a Slide Show Colour Timeline Basic View

NN All files in the File List Section will be used for the Slide Show. NN During the slide show, files are displayed in order from the currently shown file. Folder 4/6 Slide Show NN The Slide Show progresses in the order sorted in the File List Section. NN Music files can be automatically played during the Slide Show if the Background Music is set to On. NN While a photo list is displayed, press the ∂(Play)/ENTERE button on the remote control to start slide show. NN SlideShow Control Buttons ENTERE Preference

Play Current Group Change Group Folder 1 Information Remove Safely Select T Tools R Upper Folder 3648x2432 2009/3/15 1/4 Play/Pause the Slide Show. Play the Slide Show. Pause the Slide Show. Exit Slide Show and return to the photo list.

T TOOLS Change the SlideShow playing speed. Run various functions from the Photo menus. E Pause lr Previous/Next USB

Tools R Return ❑❑ Playing current group Movie Preference Basic View Tiltle Folder Apr Apr.27.2009 1/5

1. Select a Sort key and then in the File List Section, select the photos contained in

the desired group. NN To move to the previous/next group, press the π (REW) or µ (FF) button. Timeline

Press the ▲ button to move to the Sort key Section. Press the ◄ or ► button to select a sorting standard. Press the ▼ button to move to the Group List Section. Select a group using the ◄ and ► buttons. Press the ∂ (Play) button. A slideshow begins with the files of the selected group.

USB Device MOVIE_001.avi Favorites Settings MOVIE_003 .avi MOVIE_004 .avi Select T Tools R Upper Folder

2. Press the TOOLS button.

3. Press the ▲ or ▼ button to select Play Current Group, then press the ENTERE button.

NN Only the photos in the sorting group including the selected files will be used for the Slide Show. ❑❑ To perform a Slide Show with only the selected files

Press the ▼ button to select the File List Section. Press the ◄ or ► button to select the desired photo in the File List Section. Press the Yellow button. Repeat the above operation to select multiple photos. NN The c mark appears to the left of the selected photo. NN If you select one file, the Slide Show will not be performed. NN To deselect all selected files, press the TOOLS button and select Deselect All.

5. Press the ∂ (Play)/ENTERE button.

NN The selected files will be used for the Slide Show. „„ Alternatively

1. In the File List Section, press the Yellow buttons to select the desired photos.

2. Press the TOOLS button.

3. Press the ▲ or ▼ button to select Slide Show, then press the ENTERE button.

NN The selected files will be used for the Slide Show. English - 38 job.indb 38 2009-10-22 3:49:27 Playing Music ❑❑ Playing a music file

1. Press the ▼ button to select the File List Section.

2. Press the ◄ or ► button to select a music file to be played.

3. Press the ∂ (Play)/ENTERE button.

NN This menu only shows files with the MP3 file extension. Files with other file extensions are not displayed, even if they are saved on the same USB device. NN The selected file is displayed at the top with its playing time. E Pause lr Previous/Next T Tools R Return USB NN To adjust the music volume, press the volume button on the remote control. To mute the sound, press the M MUTE button on the remote control. NN If the sound is odd when playing MP3 files, adjust the Equalizer and SRS TruSurround HD in the Sound menu. (An overmodulated MP3 file may cause a sound problem.) NN The playing duration of a music file may be displayed as ‘00:00:00’ if its playing time information is not found at the start of the file. NN π (REW) or μ (FF) buttons do not function during play.

Geek In The Pink Heaven Play/Pauses the music file. Play the music file Pause the music file Exit play mode and return to the music list. T TOOLS Run various functions from the Music menus. When all music files in the folder (or the selected file) are repeated. Repeat Mode is On. When all music files in the folder (or the selected file) are played once. Repeat Mode is Off. ❑❑ Playing the music group

Press the ▲ button to move to the Sort key Section. Press the ◄ or ► button to select a sorting standard. Press the ▼ or ENTERE button to move to the Group List Section. Press the ∂ (Play) button. The files of the selected group will start playing. „„ Alternatively

1. Select a sort key and then in the File List Section, select the files contained in the desired group.

NN To move to the previous/next group, press the π (REW) or µ (FF) button.

2. Press the TOOLS button.

3. Press the ▲ or ▼ button to select Play Current Group, then press the ENTERE button.

NN The music files in the sorting group including the selected file are played. ❑❑ Playing the selected music files

Press the ▼ button to select the File List Section. Press the ◄ or ► button to select the desired music file. Press the Yellow button. Repeat the above operation to select multiple music files. NN The c appears to the left of the selected music file. NN To deselect all selected files, press the TOOLS button and select Deselect All.

5. Press the ∂ (Play)/ENTERE button.

NN The selected files will be played. English - 39 job.indb 39 2009-10-22 3:49:27 Playing a Movie File

1. Press the ▼ button to select the File List Section.

2. Pressing the ◄ or ► button to select a movie file to be played.

3. Press the ∂ (Play)/ENTERE button.

NN The selected file is played. NN The selected file is displayed at the top with its playing time. NN The playing duration of a movie file may be displayed as ‘00:00:00’ if its USB playing time information is not found at the start of the file. NN You can watch exciting gaming multimedia files, but the gaming function is not supported.

❑❑ Playing a movie file 1/3 MOVIE_000.avi E Pause lr Jump T Tools R Return NN Supported caption formats Name MPEG-4 time-based text SAMI SubRip SubViewer Micro DVD Programming Language XML HTML string-based string-based string-based NN Supported Video Formats File extension Container *.avi AVI *.mkv MKV *.asf ASF *.wmv (VC1) ASF *.mp4 MP4 (SMP4) *.3gp 3GPP *.vro VRO VOB *.mpg *.mpeg

Resolution 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 Play/Pauses the movie file Play the movie file Pause the movie file Exit play mode and return to the movie list. T TOOLS Run various functions from the movie menus.

Skip forwards or backwards through the movie file.

Move to the first/last of the file. English - 40 job.indb 40 2009-10-22 3:49:28 ❑❑ Playing the movie group

Press the ▲ button to move to the Sort key Section. Press the ◄ or ► button to select a sorting standard. Press the ▼ or ENTERE button to move to the Group List Section. Press the ∂ (Play) button. Only the files of the selected group will start playing. „„ Alternatively

1. Select a Sort key and then in the File List Section, select the files contained in the desired group.

NN To move to the previous/next group, press the π (REW) or µ (FF) button.

2. Press the TOOLS button.

3. Press the ▲ or ▼ button to select Play Current Group, then press the ENTERE button.

NN The movie files in the sorting group including the selected file are played. ❑❑ Playing the selected movie files

1. Press the ▼ button to select the File List Section.

2. Press the ◄ or ► button to select the desired music file.

3. Press the Yellow button.

NN The c mark appears to the left of the selected movie file. NN To deselect all selected files, press the TOOLS button and select Deselect All.

4. Repeat the above operation to select multiple movie files.

5. Press the ∂ (Play)/ENTERE button.

NN Only the selected file is played. ❑❑ Playing movie continuously (Resume Play) If you exit the playing movie function, the movie can be played later from the point where it was stopped. 1. Select the movie file you want to play continuously by pressing the ◄ or ► button to select it from the File List Section.

2. Press the ∂ (Play)/ENTERE button.

3. Select Play Continuously (Resume Play) by pressing the Blue button.

NN The Movie will begin to play from where it was stopped. NN If Cont. Movie Play Help function is set On in the Setup menu, a pop-up message will appear when you resume play a movie file. Press the MEDIA.P button on the remote control to display the Media Play menu. Press the ◄ or ► button to select Setup, then press the ENTERE button. Press the ▲ or ▼ button to select the desired option. Press the ◄ or ► button to select the option. USB : USB NN To exit Media Play mode, press the MEDIA.P button on the remote control. Photo Select to view the color information in the Photo menu. NN If this is set to ON, the loading time increases for collecting the color information. „„ Music Repeat Mode → On / Off Select to repeatedly play music files. „„ Cont. movie play help → On / Off Select to display the help pop-up message for continuous movie playback. „„ Get the DivX® VOD registration code USB Music Movie Setup Device e Exit Setup Use Color View Off Music Repeat Mode Cont. movie play help Get the DivX® VOD registration code Get the DivX® VOD deactivation code Screen Saver Run Time 10 min Information Remove Safely

Shows the registration code authorized for the TV. If you connect to the DivX web Move Adjust USB Device site and register the registration code with a personal account, you can download VOD registration file. If you play the VOD registration using Media Play, the registration is completed. For more information on DivX® VOD, visit www.DivX.com. Return „„ Get the DivX® VOD deactivation code When DivX® VOD is not registered, the registration deactivation code is displayed. If you execute this function when DivX® VOD is registered, the current DivX® VOD registration is deactivated. Select to set the waiting time before the screen saver appears. „„ Information Select to viewing the information of the connected device. „„ Remove Safely You can remove the device safely from the TV. job.indb 41 English - 41 2009-10-22 3:49:28 Media Play-DLNA Setting the DLNA Network DLNA allows you to watch pictures, musics and videos saved on your PC or on your TV through a network connection in Media Play mode. This removes the need to copy them to a USB storage device and then connect the device to your TV. To use DLNA, the TV must be connected to the network and the DLNA application must be installed on your PC. ❑❑ Network Connection Diagram-Cable

LAN LAN External Modem (ADSL/VDSL/Cable TV) ❑❑ Network Connection Diagram-Wireless TV Side Panel

LAN Samsung Wireless or LAN Adapter

For more information on how to configure your network, refer to ‘Setting the Network’. NN You are recommended to locate both TV and PC in same subnet. The first 3 parts of the subnet address of the TV and the PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**)

Connect the PC to which the Samsung PC Share Manager program will be installed and the external modem using a LAN cable. NN You can connect the TV to the PC directly without connecting it through a Sharer (Router). Installing the DLNA Application To play content on the PC on the TV, you have to first install the application. To use the DLNA function smoothly, use the program in the CD-ROM supplied with the TV or use the Samsung PC Share Manager program corresponding to the TV model that can be downloaded from the Samsung web site. Continued... English - 42 job.indb 42 2009-10-22 3:49:29 „„ System Requirements

1. Insert the Programme CD supplied with this TV into your PC.

2. 30MB of free hard disk space is needed for the programme installation.

NN If you share files, up to 30MB of hard disk drive space is required for each 100 files. NN If you cancel file sharing, the hard disk drive space used for the thumbnail information is also freed. „„ Supported Formats

• • Image: JPEG/ Audio: MP3/ Video: AVI, MKV, ASF, MP4, 3GPP, PS, TS container. For detailed supported video formats, refer to the ‘Playing a Movie File’ instructions. „„ Install the application

1. Run the Setup.exe file on the Programme CD supplied with the product.

NN Alternatively, you can download the file from www.samsung.com.

2. Install the SAMSUNG PC Share Manager as shown in the figures.

3. When the installation is complete, the PC Share Manager icon appears on your Desktop.

NN Double-click the icon to run the programme. Using the DLNA Application Programme Screen Display

1. Menus: The following application menus are

provided : File, Share, Server, and Help.

2. Click to share the selected PC server folder.

3. Click to cancel sharing.

4. Click to refresh the PC folder and files.

5. Click to synchronize the share status.

6. The folders and files of the PC to be shared

7. Folders shared by the user are listed.

8. PC server name shown on the device list of

the Media Play. Continued... English - 43 job.indb 43 2009-10-22 3:49:30 ❑❑ Share „„ Sharing a Folder You can share a folder from your PC to the TV. „„ Cancelling a Shared Folder You can cancel a shared folder on your PC. Select a folder from the Shared Folder pane and select Unshare Folder. „„ Applying the Current Settings Perform this when synchronization is necessary due to a new shared folder or cancelling a shared folder. The Set Changed State menu applies changes to shared folders to the data saved with the PC share programme. Since applying changes to the internal data is a time-consuming process, this function enables users to apply changes to the data only when required. Until the Set Changed State menu is selected, the changed state of the shared folder is not applied to the server. Changes to the shared folders are not applied to your PC until you select the Set Changed State menu. „„ Setting the Access Permission To enable the TV to find your PC, the TV must be set to Set Device Policy in the Access Permission Settings window. In addition, the PC server and the TV must be on the same subnet.

• • Method: Select the Share menu and select Set Device Policy. Rejected items are represented in gray. You can change the access permissions by using the Allow Accept / Deny button. To delete an item, select the item and select Delete Item. You can run or stop using your PC as a server. You can determine whether to start the PC server automatically when Windows starts. You can rename the PC server DLNA (Digital Living Network Alliance) enables content saved on a DLNA server (usually your PC) connected to your TV or over a network to be played. Media Play enables playing content saved on a USB memory device connected to the TV, while DLNA enables playing content saved on a DLNA server (your PC) connected to your TV or over the network. The procedures to use the content are the same as those for Media Play (USB & DLNA).

Media Play Press the MEDIA.P button on the remote control to display the DLNA menu. Press the ◄ or ► button to select an icon (Photo, Music, Movie, Setup), then press the ENTERE button. USB : USB NN To exit DLNA mode, press the MEDIA.P button on the remote control. NN DLNA does not support the following functions. -- The Background Music and Background Music Setting functions. -- Sorting files by preference in the Photo, Music, and Movie folders. -- The Change Group function. -- The Copy / Delete function. -- The Remove Safely function. -- The REW/FF (π/µ) key functions while a movie is playing. -- Playing Movie Continuously (Resume Play) function. NN The Skip function may not work with some container such as asf and mkv. NN The Divx DRM, Multi-audio, embedded caption does not supported. NN Samsung PC Share manager should be permitted by the firewall program on your PC. NN The Skip (◄/► keys) or Pause function may not work while a movie is playing for the DLNA of other manufacturers, depending on the corresponding content information. NN The playing time may not be displayed while a movie is playing. Continued... English - 44 job.indb 44 2009-10-22 3:49:30 About Anynet+ Connecting Anynet+ Devices Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it. ❑ To connect to a TV Anynet+ Device 4 HDMI 1.3 Cable

Anynet+ Device 3 HDMI 1.3 Cable Anynet+ Device 2 HDMI 1.3 Cable Anynet+ Device 1 HDMI 1.3 Cable Connect the HDMI IN (1(DVI), 2, 3 or 4) jack on the TV and the HDMI OUT jack of the corresponding Anynet+ device using an HDMI cable. ❑ To connect to Home Theater Anynet+ Device 4 HDMI 1.3 Cable HDMI 1.3 Cable Home Theatre HDMI 1.3 Cable

Anynet+ Device 3 Anynet+ Device 2 HDMI 1.3 Cable Anynet+ Device 1 HDMI 1.3 Cable Connect the HDMI IN (1(DVI), 2, 3 or 4) jack on the TV and the HDMI OUT jack of the corresponding Anynet+ device using an HDMI cable. Connect the HDMI IN jack of the home theater and the HDMI OUT jack of the corresponding Anynet+ device using an HDMI cable. N Connect the Optical cable between the DIGITAL AUDIO OUT (OPTICAL) jack on your TV and the Digital Audio Input on the Home Theater. N When following the connection above, the Optical jack only outputs 2 channel audio. You will only hear sound from the Home

Theater’s Front Left and Right speakers and the subwoofer. If you want to hear 5.1 channel audio, connect the DIGITAL AUDIO OUT (OPTICAL) jack on the DVD player or Cable/Satellite Box (ie Anynet Device 1 or 2) directly to the Amplifier or Home Theater, not the TV. Connect only one Home Theater. You can connect an Anynet+ device using the HDMI 1.3 cable. Some HDMI cables may not support Anynet+ functions. Anynet+ works when the AV device supporting Anynet+ is in the Standby or On status. Anynet+ supports up to 12 AV devices in total. Note that you can connect up to 3 devices of the same type. English - 45 job.indb 45 2009-10-22 3:49:31 Setting Up Anynet+ ❑❑ Anynet+(HDMI-CEC) Setup You can also display Anynet+ menu by selecting Tools → Anynet+(HDMI-CEC). Application Media Play (USB & DLNA) Home Network Centre To use the Anynet+ Function, Anynet+ (HDMI-CEC) must be set to On. NN When the Anynet+ (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated. „„ Auto Turn Off → No / Yes Setting an Anynet+ Device to turn Off Automatically when the TV is Turned Off NN The active source on the TV remote must be set to TV to use the Anynet+ function. NN If you set Auto Turn Off to Yes, connected external devices are also turned off when the TV is turned off. If an external device is still recording, it may or may not turn off. Anynet+(HDMI-CEC) : On Auto Turn Off : Yes U Move

E Enter R Return Switching between Anynet+ Devices

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-CEC). Press the ▲ or ▼ button to select Device List, then press the ENTERE button. NN Anynet+ devices connected to the TV are listed. If you cannot find a device you want, press the red button to scan for devices. NN Only when you set Anynet+ (HDMI-CEC) to On in the Setup menu, the Device List

menu appears. Press the ▲ or ▼ button to select to a particular device and press the ENTERE button. It is switched to the selected device. View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR : On U Move E Enter R Return NN Switching to the selected devices may take up to 2 minutes. You cannot cancel the operation during the switching operation. NN The time required to scan for devices is determined by the number of connected devices. NN If you have selected external input mode by pressing the SOURCE button, you cannot use the Anynet+ function. Make sure to switch to an Anynet+ device by using the TOOLS button. The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+ Menu Description View TV Anynet+ mode changes to TV broadcast mode. Device List Shows the Anynet+ device list. (device_name) MENU Shows the connected device menus. E.g. If a DVD recorder is connected, the disc menu of the DVD recorder will appear. (device_name) INFO Shows the play menu of the connected device. E.g. If a DVD recorder is connected, the play menu of the DVD recorder will appear. Recording: (*recorder) Starts recording immediately using the recorder. (This is only available for devices that support the recording function.) (*recorder) Reserve Recording Enables reserving a recording for the recorder. (This is only available for devices that support the recording reservation function.) Stop Recording: (*recorder) Stops recording. Receiver Sound is played through the receiver. Continued... English - 46 job.indb 46 2009-10-22 3:49:31 ❑❑ TV Remote Control Buttons Available in Anynet+ Mode Device Type Anynet+ Device Operating Status After switching to the device, when the menu of the corresponding device is displayed on the screen. After switching to the device, while playing a file (Backward search) / (Play) / (Pause) Device with built in Tuner After switching to the device, when you are watching a TV programme

Audio Device When Receiver is activated

button MMUTE button The Anynet+ function only works when the active source on the TV remote control is set to TV. The button works only while in the recordable state. You cannot control Anynet+ devices using the buttons on the TV. You can control Anynet+ devices only using the TV remote control. The TV remote control may not work under certain conditions. In this case, reselect the Anynet+ device. The Anynet+ functions do not operate with other manufacturers’ products. The operations may differ depending on the device. If more than one recording device is connected, they are displayed as (*recorder) and if only one recording device is connected, it will be represented as (*device_name). Recording You can make a recording of a TV programme using a Samsung recorder.

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-CEC). Press the ▲ or ▼ button to select Recording(recorder): then press the ENTERE button. Recording begins. NN When there is more than one recording device View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR When multiple recording devices are connected, the recording devices are listed. : On Press the ▲ or ▼ button to select a recording device and press the ENTERE button. Recording begins. U Move E Enter R Return NN When the recording device is not displayed Select Device List and press the red button to search devices. NN Pressing the button will record whatever you are currently watching. If you are watching video from another device, the video from the device is recorded. NN Before recording, check whether the antenna jack is properly connected to the recording device. To properly connect an antenna to a recording device, refer to the recording device’s users manual. Listening through a Receiver You can listen to sound through a receiver instead of the TV speaker.

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-CEC). Press the ▲ or ▼ button to select Receiver. Press the ◄ or ► button to select On or Off. NN If your receiver supports audio only, it may not appear in the device list. NN The receiver will work when you have properly connected the Optical IN jack of the receiver to the Optical Out jack of the TV. NN When the receiver (home theater) is set to On, you can hear sound output from the View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR : On U Move E Enter R Return TV’s Optical jack. When the TV is displaying a DTV(air) signal, the TV will send out 5.1 channel sound to the Home theater receiver. When the source is a digital component such as a DVD and is connected to the TV via HDMI, only 2 channel sound will be heard from the Home Theater receiver. NN When using the Media Play feature, sound may not output properly through the receiver. NN When listening through the receiver, there are restrictions for using the audio-related (MTS, Preferred language) menus. NN If there is a power interruption to the TV when the Receiver is set to On (by disconnecting the power cord or a power failure), the Speaker Select may be set to External Speaker when you turn the TV on again. (see page 21) English - 47 job.indb 47 2009-10-22 3:49:32 Troubleshooting for Anynet+ Symptom Anynet+ does not work. I want to start Anynet+. Solution

Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only. Connect only one receiver (home theater). Check if the Anynet+ device power cord is properly connected. Check the Anynet+ device’s Video/Audio/HDMI 1.3 cable connections. Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu. Check whether the TV remote control is in TV mode. Check whether it is Anynet+ exclusive remote control. Anynet+ doesn’t work in certain situations. (Searching channels, Plug & Play, etc.) When connecting or removing the HDMI 1.3 cable, please make sure to search devices again or turn your TV off and on again. Check if the Anynet+ Function of Anynet+ device is set on. Check if the Anynet+ device is properly connected to the TV and check if the Anynet+ (HDMI-CEC) is set to On in the Anynet+ Setup menu. Press the TV button on the TV remote control to switch to TV. Then press the TOOLS button to show the Anynet+ menu and select a menu you want. Select View TV in the Anynet+ menu. Press the SOURCE button on the TV remote control and select a device other than Anynet+ devices. (Note that the channel button operates only when a tuner-embedded Anynet+ device is not connected.) You cannot use the remote control when you are configuring Anynet+ or switching to a view mode. Use the remote control when the Anynet+ setting or switching to view mode is complete. You cannot use the play function when Plug & Play is in progress. I want to exit Anynet+.

The message Connecting to Anynet+ device... appears on the screen. The Anynet+ device does not play.

The connected device is not displayed. Check whether or not the device supports Anynet+ functions. Check whether or not the HDMI 1.3 cable is properly connected. Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu. Search Anynet+ devices again. You can connect an Anynet+ device using the HDMI 1.3 cable only. Some HDMI cables may not support Anynet+ functions.

• • If it is terminated by an abnormal situation such as disconnecting the HDMI cable or power cord or a power failure, please repeat the device scan.
• • Check whether the antenna jack on the recording device is properly connected. The TV programme cannot be recorded. The TV sound is not output through the receiver.

• • Connect the optical cable between TV and the receiver. English - 48 job.indb 48 2009-10-22 3:49:32 Content Library Activating the Content Library

Press the MENU button. Press the ▲ or ▼ button to select Application, then press the ENTERE button. Press the ▲ or ▼ button to select Content Library, then press the ENTERE button. The Content Library main menu is displayed. The Content Library enables you to view or play the built-in contents on the TV or stored on your USB device. Content Library Internet@TV Home Network Centre OO Press the CONTENT button on the remote control to display the Content Library main menu.

Press the ◄ or ► button to select an icon (Gallery, Cooking, Children, Wellness, Others, Content Management), then press the ENTERE button. Content Library NN The selected item will be run. Gallery

Gallery Cooking Children Wellness Others Return

Exit ❑❑ Using the Remote Control Button in Content Library Menu Button Operations

Move the cursor and select an item. ENTERE Select the currently selected item. RETURN Return to the previous menu. EXIT Stop the current function and return to the Content Library main menu. Colour Button Button that provide functions are described on the corresponding page. You can control the volume of the played content. CONTENT Enter or Exit Content Library mode. NN If you press the Volume or MMUTE button, no OSD is displayed, but the function operates accordingly. NN To return to TV mode, press the P button on the remote control. NN CONTENTS LIBRARY CONTAINS TEXT, GRAPHICS, IMAGES, MULTIMEDIA, AND OTHER MATERIALS FOR INFORMATIONAL AND PROMOTIONAL PURPOSES ONLY. MATERIALS IN CONTENTS LIBRARY HAS BEEN MODIFIED AND KEEPS BEING REVISED AND UPDATED. THE MATERIALS IN THE CONTENTS LIBRARY MAY NOT BE SUITABLE FOR ALL AUDIENCES. NN INFORMATION IN THE CONTENTS LIBRARY IS PROVIDED “AS IS.” ALTHOUGH THE INFORMATION PROVIDED TO YOU IN THE CONTENTS LIBRARY IS OBTAINED OR COMPLIED FROM SOURCES WE BELIEVE TO BE RELIABLE, SAMSUNG CANNOT AND DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS OR COMPLETENESS OF ANY INFORMATION OR DATA MADE AVAILABLE TO YOU FOR ANY PARTICULAR PURPOSE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE HELD LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES WHATSOEVER ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR THE USE OF, THE CONTENTS LIBRARY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. English - 49 job.indb 49 2009-10-22 3:49:33 Using the Content Library ❑❑ Gallery This function plays a Slide Show with high resolution images and background music and pro­duces various atmospheres. Using the Gallery function of the TV, you can change your home at­mosphere. NN Press INFO button to see the credit and detail information in English for the imagery (currently, the credit supports English only). NN You can pause the slide show by pressing the ENTERE button during a slide show. NN The copyrights of the Gallery contents and all issues related to them are reserved by Timespace / JoongAng M&B, Inc. ❑❑ Cooking You can view various recipes that you can then easily follow step by step. Enjoy these contents which give you great ideas for meals. NN The recipes introduced in the Cooking contents on the Samsung TV are based on recipes published by Anness Publishing. NN The copyrights of the Cooking contents and all issues related to them are reserved by Practical Pictures. ❑❑ Children This is educational and interactive content that children can watch repeatedly. Enjoy existing stories, songs and plays with the Boowa and Kwala characters. NN The copyrights of the Children contents and issues related to them are reserved by UpToTen. ❑❑ Wellness This is beneficial health management content that provides stretching and massage exercises that can be enjoyed by the whole family. ❑❑ Content Management „„ My contents The use of contents is the same as in using the TV memory contents. Also, you can delete and play the each contents. „„ USB You can download the contents onto a USB memory device and play them on your TV. The contents on the external USB device are played directly. NN Content Library only supports USB Mass Storage Class devices (MSC). MSC is a Mass Storage Class Bulk-Only Transport device. Examples of MSC are Thumb drives, Flash Card Readers and USB HDD (USB HUB are not supported.) NN Playing a game using an external USB memory device will allow you to save your game (depending on the game). Take care as removing the USB memory device while saving data to the USB memory device may cause the data to be lost. NN Downloading New Contents New content other than the built-in contents will be provided via the Samsung.com websitefree of charge. When you download the paid contents, you need UDN number to download contents. Check the UDN number before downloading a new content item.

1. Visit the www.samsung.com website.

2. Select a content item in the Contents Download page.

3. Download the contents onto the USB memory device.

4. Go to Content Library main menu by pressing CONTENT button or choosing Content Library

(Menu → Application → Content Library)

5. Plug the USB memory into USB port on the side of the TV.

6. You can see the content sub item which you downloaded.

7. Select a content item and press the enter button.

8. You can play the selected content item.

• • Screen Saver Run Time → 10 min. / 20 min. / 40 min. / 1 hour Select to set the waiting time before the screen saver appears.
• • Save UDN (Unique Device Number) The 18-digit number on the screen is the product code. You can save the UDN to your USB memory. NN An NTFS format USB storage device does not support saving UDN.We recommend using a FAT format USB storage device. English - 50 job.indb 50 2009-10-22 3:49:33 Internet@TV You can use various internet services containing useful information and entertaining content. If you have some problems while using a widget service, please contact to content provider. In the widget, press the green button and get information of contact or refer to help website for widget provider information. NN English may be only supported in widget service depending on region. NN This function may not be supported depending on your country. Getting Started with Internet@TV Internet@TV provides an integrated Internet and television experience powered by the Yahoo!® Widget Engine. You can monitor financial stocks, share photos with friends and family, and track news and weather all through the Internet@TV service on your television. NN If Network condition is unstable, this function may not work. Then, TV would be turned off automatically. Otherwise turn off the TV using power button. NN You may experience slow operation or hesitation when using this function due to network conditions. When running Internet@TV for the first time, the basic settings will proceed automatically. NN The first step is to set up your network. For more information on how to configure your network, refer to ‘Network Setup’. NN After your network is operational, the Internet@TV software guides you through a step-by-step setup wizard. All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or ther intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY, OF QUIET ENJOYMENT, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF THE DEVICE, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time, without notice, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any change, interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability. Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

1. Press the MENU button. Press the ▲ or ▼ button to select Application, then press the ENTERE button.

2. Press the ▲ or ▼ button to select Internet@TV, then press the ENTERE button.

NN INTERNET@TV starts. OO Press the INTERNET@ button on the remote control to display the Internet@TV menu.

3. The General Disclaimer is displayed on the screen. Select I accept or I do not

accept. NN For more information on the General Disclaimer, refer to the ‘Legal Notice’.

4. The ‘welcome screen’ is the starting point of the Internet@TV guided setup.

NN If you select Exit Setup, this step is resumed when you press the INTERNET@ button. NN Select Let’s get started!

5. Choosing your location allows TV Widgets to use localized content.

NN Select your country from the list provided.

6. Accepting the Yahoo!® TV Widget Engine Privacy Policy is required to use

Internet@TV. NN Select OK, I Accept. English - 51 job.indb 51 2009-10-22 3:49:33

7. Accepting the Yahoo!® TV Widget System Terms of Service is required to use Internet@TV.

NN Select OK, I Accept.

8. Enter your name to setup your profile. Each profile has its own list of widgets.

You can create a profile for each person who uses Internet@TV. NN Enter your name and select Save this name. NN For more information, refer to page ‘Using the Profile Widget'.

9. Internet@TV tests the network connection.

NN If the test fails, configure your network again. NN For more information, refer to page ‘Network Setup’.

10. The guided setup is complete. A tutorial on how to use Internet@TV is next.

NN Select Continue to view the tutorial. NN Select Exit setup to start using Internet@TV now. NN To run the tutorial again, select Profile Widget → System Setting → Repeat Tutorial.

11. Press the INTERNET@ button on the remote control to display the Internet@TV user interface.

1 A welcome banner is shown with your profile name in the top right corner. NN This banner disappears after a short delay. 2 The banner highlights two remote control shortcuts. NN If you press the blue button (Viewport) on your remote control, the display is toggled between ‘Viewport mode’ and ‘Overlay mode’. In Viewport mode, the TV or video plays in a scaled-down area with graphics outside. In overlay mode, the graphics are displayed on top of the TV or video. NN If you press the yellow button (Edit Snippet) on your remote control, a help window is displayed and the snippet with focus can be edited. 3 Press the INTERNET@ button on the remote control to begin. NN The horizontal list at the bottom of your TV screen is called ‘the dock’. NN The items in the list are called ‘snippets’. NN A snippet is a shortcut which launches a TV Widget. NN A TV Widget is an Internet application designed to run on your TV. NN Move between snippets by pressing the ◄ or ► buttons on the remote control. NN Focus is located in the left most region (highlighted in blue). NN The dock slides snippets under that focal point. NN Launch a TV Widget by pressing the ENTERE button on the remote control when its snippet is in focus. NN When you add snippets, they form a stack which you can navigate by pressing the ▲ or ▼ buttons. NN Two special TV Widgets appear in the dock: the Profile Widget and the Gallery Widget. These cannot be deleted. NN The dock will slide off screen after a timeout period. „„ Sidebar mode 1 Focus on a snippet and press the ENTERE button to launch the TV Widget sidebar. The TV Widget logo and Home ( ) are at the top of the sidebar. 2 Current menu is displayed under the TV Widget logo. NN To return to a previous screen, select it and press the ENTERE button. NN You can also press the RETURN button on the remote control. 3 Current selection is always highlighted in blue. The highlighted button has focus and is activated when you press the ENTERE button. 4 When there is a lot of data, a page control is used. NN Current page and total pages are displayed. NN Move between pages by pressing ◄ or ► buttons. 5 The bottom toolbar includes Colour buttons that correspond to the red, green, yellow and blue buttons on the remote control.

• • Red button: Close the widget.
• • Green button: Change the widget’s setting.
• • Yellow button: Manage your snippets.
• • Blue button: Size video to fit, or make it full screen. NN Some buttons may not be available depending on widget. Continued... English - 52 job.indb 52 2009-10-22 3:49:34 Editing Snippets in the Dock

Edit a snippet by focusing on it in the dock and pressing the yellow button. The snippet moves to the Second position and its tile slides up to show the following help text:

• • Delete (red button): Remove this TV Widget. NN Deleted widgets can be re-installed using the Widget Gallery.
• • Move (blue button): Re-order the snippet. Press the ◄ or ► button to scroll. Press the yellow button to drop into the new position.
• • Done (yellow button): Exit the Edit Snippet menu. Using the Profile Widget The Profile Widget configures your user profile.You can set up multiple profiles, and each profile maintains its own list of widgets. The Switch Profile menu allows you to switch to a different user profile. NN At least two profiles must be registered. If you want to add a profile, refer to ‘Administrative Controls’. The Profile Settings menu allows you to customize and protect your profile.
• • User profiles can be customized with a unique Name and an Avatar (a picture used to represent your profile).
• • Your profile’s Name and Avatar are displayed in the profile snippet in the dock.
• • Profiles can be protected by Create Profile PIN. NN When setting the PIN for the first time, you can set a Security Question. The Profile Settings menu can limit to widgets.
• • If you forget your Profile PIN you can answer a Security Question that is associated with your profile.
• • A profile that has the Limit Profile indicator turned on will not allow new widgets to be installed. NN The Owner PIN must be set to use this function. To set the Owner PIN, refer to ‘Administrative Controls’. The System Settings menu allows you to:
• • Change your Location and set your Zip Code (US only) to tailor the content to your region.
• • Repeat the Tutorial that was shown during guided setup.
• • Restore Factory Settings to delete all widget configurations and information. In the Administrative Controls menu you can:

Set the Screen Saver timeout to avoid screen burn in. Create Owner PIN and set a Security Question to control other profiles. Create a new Profile which can be configured with a different set of widgets. Delete an existing profile. From the Profile Widget you can Sign in to Yahoo!® using your Yahoo! ID.

If you have a Yahoo! ID, you can access your personalized content using the Yahoo! TV Widgets. All Yahoo! TV Widgets that are installed are automatically signed-in with your profile’s Yahoo! ID. If you have no Yahoo! account, visit www.yahoo.com and create an account. You may fail to log in with an ID created on the Yahoo website in a country that does not support Internet@TV. ❑❑ About Profile widget Press the green button. You can view a brief description of the Profile Widget, Copyright Policy, Terms of Service, and Privacy Policy. English - 53 job.indb 53 2009-10-22 3:49:35 Using the Yahoo!® Widget Gallery Use the Yahoo!® Widget Gallery to add more widgets to your TV. View available TV Widgets in the following categories: Latest Widgets: Displays recently updated widgets. Yahoo!® Widgets: Displays widgets provided by Yahoo!®. Samsung Widgets: Displays widgets provided by Samsung. More Categories: Displays all widgets by category. NN To install a widget, navigate to the detail screen and select Add Widget to My Profile and press the ENTERE button. The widget is installed and becomes available in the dock.

❑❑ Widget Gallery Settings Press the green button. You can view brief information for the Widget Gallery, Copyright Policy, Terms of Service, and Privacy Policy. In the Developer Settings menu You can make your own widget. For more information on creating your own widget, visit our developer site at http://connectedtv. yahoo.com/ Using the Yahoo!® Weather Widget The Yahoo!® Weather Widget provides updates on your local and favorite weather locations. This content dynamically changes with weather conditions.

• • Press the green button on the remote control to display the Yahoo!® Weather Widget Settings menu.
• • From the Settings menu you can add or remove a city for which you want to view weather information. From the Settings menu:
• • Add New City by entering the name of the city. Once the search results are displayed, select the city you want and press the ENTERE button.
• • Delete City by selecting the city you want to delete from the city list. Press the ENTERE button and confirm the deletion.
• • Changing the Temperature Indication Mode You can change the temperature indication mode to Imperial or Metric. For example, Imperial will show temperatures in Fahrenheit and Metric in Celsius. ❑❑ Create a snippet for a favorite city
• • Select the city from the Yahoo!® Weather Widget’s home page and view the detailed weather information.
• • Press the yellow button.
• • Select the Add Snippet menu and press ENTERE to add the city as a snippet. ❑❑ Delete a snippet for a city
• • Launch the snippet.
• • Press the yellow button.
• • Select the Delete Snippet menu and press ENTERE to remove the snippet. Continued... English - 54 job.indb 54 2009-10-22 3:49:35 Using the Yahoo!® News Widget The Yahoo!® News Widget provides the latest headline news for business, entertainment, politics, sports, top stories, and many other categories. Select a category, select a headline within the category, and view a dynamically updated news summary. Using the Yahoo!® Flickr Widget The Flickr Widget can provide you access to your favorite photos from friends and family while watching TV. Share your photos with your family on your big screen TV through a slideshow.
• • Personalize the Flickr Widget by logging in with your Yahoo! ID.
• • For detailed procedures on log in, refer to the ‘Using the Profile Widget’ instructions.
• • For more information on Flickr, visit http://www.flickr.com. NN Your Photos shows photos you have registered with Flickr website. „„ To view Flickr photos in a slideshow:

• • Select a thumbnail of a photo and press the ENTERE button to view the photo’s details.
• • Select Start Slideshow and press the ENTERE button. „„ To control the slideshow display:

• • Press the ENTERE button during a slideshow.
• • The thumbnails of photos are displayed on the bottom of the screen. NN When the slideshow control is displayed, you can Pause, Play and Stop the slideshow. NN If you select the menu and press ENTERE, you can view information for the selected photo.

The Your Sets menu allows you to view photos you have classified in Flickr. The Explore menu allows you to explore photos featured by the Flickr website. You can view the photos updated daily. The Mark as Favorite or Remove From Favorite menu moves photos to your Favorite Photos set or removes photos from it. The Favorite Photos menu allows you to see the photos you have classified as favorites. The Your Contacts menu allows you to see updates from family and friends. The Your Groups menu allows you to select your favorite groups from the Flickr website to share and enjoy photos with the Flickr community of users. To configure the Yahoo!® Flickr Widget Settings press the green button on the remote control.

• • The Time Per Slide menu controls the speed of the slideshow.
• • The Repeat menu will restart the slideshow at the beginning after the last photo is shown. English - 55 job.indb 55 2009-10-22 3:49:35 Using the Yahoo!® Finance Widget View stock information and the latest stock news with the Yahoo!® Finance Widget. Press the green button to set up your stocks. Use the Add New Symbol menu to enter the name of a new stock.
• • Select the stock you want to add from the search results and select the Add Symbol menu and press the ENTERE button. NN The selected stock is added to the My Stocks list.
• • Use the Import Symbols From Yahoo!® menu to retrieve your Yahoo!® Finance portfolio. -- The Merge Symbols menu merges the symbols in the Yahoo!® Finance Widget with the symbols from your portfolio. -- The Replace Symbols menu deletes the symbols in the Yahoo!® Finance Widget and replaces them with the symbols from your portfolio.
• • Use the Display Format menu to change the stock-price fluctuation transition to Value or Percentage.
• • Create a snippet for a favorite stock. -- Select the stock symbol from the Yahoo!® Finance Widget’s home page and view the detailed finance information. -- Press the yellow button. -- Select the Add Snippet menu and press ENTERE to add the stock as a snippet.
• • Delete a snippet -- Launch the snippet from the dock -- Press the yellow button. -- Select the Delete Snippet menu and press ENTERE to remove the snippet. Troubleshooting for internet@TV Problem Possible Solution Some widget services do not •• Check with that service provider. work.
• • In the widget, press the green button and get contact information or refer to help website for widget service provider information.
• • Refer to Help website page. Some widget contents only have English. How can I change the language?

• • Widget content language may be different from widget user interface language. It depends on service provider. After factory reset, Yahoo Widget service doesn’t work and warning message is displayed.

• • After factory reset, turn off and on your TV. Then restart Internet@TV. At the Flickr widget, I logged in my account. But, I can’t view my picture.

• • Visit Yahoo Web site, and activate your Flickr account at your Yahoo! ID. At the Profile widget, I did change location, but the previous setting still remains.

• • Turn off and on your TV. Then restart Internet@TV.
• • Now, you can enjoy widget services supported in changed location. English - 56 job.indb 56 2009-10-22 3:49:36 Help Website Country Austria Belgium www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey NN Approaching step may be changed later on. NN It can be different links for special countrie . English - 57 job.indb 57 2009-10-22 3:49:36 Internet@TV NN This function may not be supported depending on your country. NN If you have some problems while using a widget service, please contact to service provider. In the widget, press the green button and get contact information or refer to help website for service provider information. NN English may be only supported in widget service depending on region. Getting Started with Internet@TV Internet@TV provides SAMSUNG’s widget services through a network connection. Internet@TV contents can be changed depending on contents provider. You can access various information such as YouTube, through the Internet@TV service. NN If a certain content's font provided by contents provider is not supported on TV, It may not be viewed normally. NN The configuration of Widgets and their provided services may differ according to the selected country. After changing country, turn off and on the TV. Then you can use widget service supported changed country. If Country is set to Others, TV can’t recognize your country. In this case, please select directly from the service country list. NN For more information on how how to configure your country, refer to the ‘Plug & Play Feature’ instructions. NN You may experience slow operation or hesitation when using this function due to network conditions. NN Before using Internet@TV, set up the network first. For more information on how to configure your network, refer to ‘Network Setup’. When running Internet@TV for the first time, the basic settings proceed automatically. It may take few minutes to update.

OO Press the INTERNET@ button on the remote control to display the Internet@

TV menu. The User Agreement is displayed. Select Agree to accept the agreement. The Statistics & Analysis is displayed. Select Agree to accept the agreement. Setting up Internet@TV You can check and use the menus regarding Single Sign On (SSO), system management and properties. Press the ▲ or ▼ button to select Setup, then press the ENTERE button. ❑❑ Single Sign On You can use this menu when creating, deleting the account. Using the Single Sign On, you can control your account including contents site’s account information. You don’t need additional log in. NN Account is only for internet@TV. „„ Create Account You can create account and be linked with desired service site. NN Account will be made less than 10. NN Character of Account should be limited to 10. NN If there is no service that needs log in, you can not create account. „„ Account Management

• • Service Site: You can register log in information of service site (such as YouTube).
• • Change Password: Change the password of your account.
• • Delete: Delete the account. NN If you forget the password of account, press the remote control buttons in the following sequence, which resets the Internet@TV: POWER (off) → MMUTE → 9 → 4 → 8 → POWER (On). If you use this function, all accounts will be deleted. Continued... English - 58 job.indb 58 2009-10-22 3:49:36 ❑❑ System Setup NN Ticker Autorun, Ticker Duration may not be supported depending on country. „„ Change the Service Lock password NN The default password number of a new TV set is ‘0-0-0-0’. NN If you forget the password, press the remote control buttons in the following sequence, which resets the password to ‘0-0-0-0’: POWER (Off) → MMUTE → 9 → 4 → 8 → POWER (On). „„ Service Duration Select to set the service duration time before the screen saver appears. Select to set ticker to run automatically or not when turning on the TV. „„ Ticker Duration Select to set the service duration time before the screen saver appears. ❑❑ Properties Display information of Internet@TV. You can measure the speed of your Internet TV service using Measuring the speed of the Internet TV service. Using the Internet@TV service In a widget that provides multiple category menus, you can view the contents of the category menus using the ◄ and ► buttons. „„ Account Login

Press the Red button. Select desired User account, then press the ENTERE button. Input the password. NN When login succeeds, User account will be displayed on the screen. NN Before login, at least one and more account should be registered. If you want to create account, refer to ‘Setting up Internet@ TV’. „„ Using the Widget Gallery You can use Run Service, Lock, Install Service at the existing widget and you can see description of the widget service that isn’t installed. On the Internet@TV, you can add and use various widgets provided by service provider. It may vary according to contents provider.

• • Run Service: Runs the widget service.
• • Lock: Set the service lock
• • Install Service (or Delete Service): Install or delete widget service. You can watch the movie provided by YouTube. If you have the account in YouTube, Register account information using Account management. Then, you can use My Favourites category. NN The menu can be changed by web service. NN There may be inappropriate contents for child. In this case, use Lock function in Widget Gallery. _zol„ U Move E OK R Return English - 59 job.indb 59 2009-10-22 3:49:36 Troubleshooting for internet@TV Problem Possible Solution Some widget services do not work. Check with that service provider. In the widget, press the green button and get contact information or refer to help website for widget service provider information. Refer to Help website page. What is the advantage of single sign on? If you create account and register your login information of desired service, you can access personalized content without additional login. When a network error occurred, I can’t use other menus except setting menu. If network connection doesn’t work, your service might be limited. Because all widgets except setting widget(Profile widget, Widget Gallery) need to connect Internet. Is there any possibility to show adult movies on YouTube? Basically, at the list on the menu it is filtered out. But by using search function, It can be shown. In this case, using the Widget Gallery lock the widget service. Help Website Country Austria Belgium www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey NN Approaching step may be changed later on. NN It can be different links for special countries. English - 60 job.indb 60 2009-10-22 3:49:36 Home Network Centre Home Network Centre About the Home Network Centre The Home Network Centre connects the TV and mobile phones through a network. You can view call arrivals, text message contents, and schedules set on the mobile phone on the TV using the Home Network Centre. In addition, you can play the media contents saved on the mobile phones such as videos, photos and music by controlling them onto the TV via the network. NN If the device supports DLNA DMC (Digital Media Controller) function, Home Network Centre function is available. NN This function is for compatibility with Samsung mobile phone which will be released later on. For more information, visit www. samsung.com or contact Samsung call center. Other models will be added in the future. The mobile device may need additional software installation. For details, refer to each user’s guide. ❑❑ Connecting to the Home Network Centre For more information about the network settings, refer to ‘Network Setup’. „„ Connecting to a Wi-Fi Ad-hoc network TV Rear Panel Mobile phone Samsung Wireless LAN Adapter

1. Connect the ‘Samsung Wireless LAN Adapter’ to the USB 1 (HDD) or USB 2 port of the TV.

2. For more information on how to configure Ad-hoc network, refer to ‘Network Setup’.

NN For information on configuring the mobile phone’s network settings, refer to the mobile phone manual. 3. Set up the IP address, SSID and password for the mobile phone in the Ad-hoc Settings of the mobile phone using the Network Name (SSID) and Security Key (password) displayed on the TV. „„ Connecting through a wire / wireless IP sharer 1. Connect the LAN port of the TV and the Wire/Wireless IP sharer using the LAN cable or connect the USB 1 (HDD) or USB 2 port of the TV and the ‘Samsung Wireless LAN Adapter’. NN For the procedures to set up the wire/wireless sharer and the mobile phone, refer to the manual of the corresponding device. TV Rear Panel Wire/Wireless IP sharer Mobile phone Samsung Wireless LAN Adapter LAN Cable Wire/Wireless IP sharer TV Rear Panel Mobile phone Samsung Wireless LAN Adapter LAN Cable English - 61 job.indb 61 2009-10-22 3:49:39 Setting Up the Home Network Centre ❑❑ Message / Media Shows a list of mobile phones which have been set up with this TV to use the Message or Media function. Home Network Centre NN Media function is available in other mobile devices which support DLNA DMC. „„ Allowed Allows the mobile phone. Message 111-1234-5671 : Allowed Media 111-1234-5672 : Allowed Setup 111-1234-5673 : Denied 111-1234-5674 : Denied „„ Denied Blocks the mobile phone. Return „„ Delete Exit Deletes the mobile phone from the list. NN This function just deletes the name from the list. If the deleted mobile device turns on or tries to connect to the TV, it may be shown on the list. You can determine whether to use the message function (the call arrivals, text message contents, and schedules set on the mobile phone). Home Network Centre „„ Media → On / Off You can select whether to use the Media function that plays the contents (videos, photos, music) from the mobile phone. Message Message : On Media Media : On Setup TV name : TV „„ TV name You can set the TV name so as to find it easily on the mobile device. NN If you selects User Input, you can type the TV name by OSK(On Screen Return Exit Keyboard). Using the Message Function Using this function, you can view the call arrivals, text message contents and schedules set on the mobile phone through the alarm window while watching TV. NN To disable this Message alarm window, set Message to Off in Setup of the Home

husband SMS New message received Network Centre. Doyou want to view The alarm window appears for 20 seconds. If no key is pressed or if Cancel is the details? selected, it appears up to three times at 5 minute intervals. If OK is selected, or if OK is not selected while the message is displayed three times, the message will be deleted. The message is not deleted from the mobile phone. The simple alarm window can be displayed, while using some applications such as Cancel Media Play, Contents Library, etc. In this case, to view the contents of the message, switch to TV viewing mode. When the message of an unknown mobile phone is displayed, select the mobile phone in the Message item of the Home Network Centre and select Denied to block the phone. If a new text message (SMS) arrives while you are watching TV, the alarm window appears. If you click the OK button, the contents of the message are displayed. NN You can configure the viewing settings for the text message (SMS) contents on the mobile phone. For the procedures, refer to the mobile phone manual. NN Some special characters may be displayed as blank or broken characters. ❑❑ Call Arrival Alarm If a call arrives while you are watching TV, the alarm window appears. ❑❑ Schedule Alarm While you are watching TV, the alarm window appears to display the registered schedule. NN You can configure the viewing settings for the schedule contents on the mobile phone. For the procedures, refer to the mobile phone manual. NN Some special characters may be displayed as blank or broken characters. English - 62 job.indb 62 2009-10-22 3:49:41 Using the Media Function An alarm window appears informing the user that the media contents (videos, photos, music) sent from the mobile phone will be displayed on the TV. The contents are played automatically 3 seconds after the alarm window appears. If you press the RETURN or EXIT button when the alarm window appears, the Media Contents are not played. Media will be played from “Unknown Device 13” NN To turn off the media contents transmission from the mobile phone, set Media to Off in Setup of the Home Network Centre. NN The contents may not be played on the TV depending on their resolution and format. ❑❑ Media play control buttons Button ENTER RETURN TOOLS Operations

Move the cursor and select an item. While playing a movie file: Skip forwards or backwards through the movie file. Pressing the ENTERE button during play pauses the play. Pressing the ENTERE button during pause resumes the play. Return to the previous menu. Run various functions from the Photo, Music and Movie menus. INFO Show file information. EXIT Stop Media Play mode and Returns to TV mode. NN The ENTERE and ◄/► buttons may not work depending on the type of media content. NN Using the mobile device, you can control playing media. For details, refer to each user’s guide. English - 63 job.indb 63 2009-10-22 3:49:42 Recommendations for Use Teletext Feature Most television stations provide written information services via Teletext. The index page of the teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons. NN For teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed. 1 : (exit) Exit from the teletext display. 2 6 (index) Used to display the index (contents) page at any time while you are viewing teletext. 3 5 (reveal) Used to display the hidden text (answers to quiz games, for example). To display normal screen, press it again.

4 4 (size) Press to display the double-size letters in the upper half of the screen. For lower half of the screen, press it again. To display normal screen, press it once again. 5 0 (mode) Press to select the teletext mode (LIST/FLOF). If you press it in the LIST mode, it switches into the List save mode. In the List save mode, you can save teletext page into list using the 8(store) button.

6 / (teletext on/mix) Press to activate teletext mode after selecting the channel providing the teletext service. Press it twice to overlap the teletext with the current broadcasting screen. 7 8 (store) Used to store the teletext pages.

9 9 (hold) Used to hold the display on a given page if the selected page is linked with several secondary pages which follow on automatically. To resume, press it again. 0 7 (cancel) Used to display the broadcast when searching for a page.

! Colour buttons (red/green/yellow/blue) If the FASTEXT system is used by a broadcasting company, the different topics covered on a teletext page are colour-coded and can be selected by pressing the colour buttons. Press one of them corresponding to the required. The page is displayed with other coloured information that can be selected in the same way. To display the previous or next page, press the corresponding coloured button. @ 2 (page up) Used to display the next teletext page. # 3 (page down) Used to display the previous teletext page. NN You can change teletext pages by pressing the numeric buttons on the remote control. Continued... English - 64 job.indb 64 2009-10-22 3:49:42 The teletext pages are organized according to six categories: Part Contents

Selected page number.

Broadcasting channel identity.

Current page number or search indications.

Status information. FASTEXT information. NN Teletext information is often divided between several pages displayed in sequence, which can be accessed by: -- Entering the page number -- Selecting a title in a list -- Selecting a coloured heading (FASTEXT system) OO Press the TV button to exit from the teletext display. Wall Mount Kit Specifications (VESA) Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please contact your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury. Product Family LCD-TV PDP-TV VESA Spec. (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Standard Screw Quantity

We provided the standard dimensions for wall mount kits as shown in the table above. When purchasing our wall mount kit, a detailed installation manual and all parts necessary for assembly are provided. Do not use screws longer than the standard dimension, as they may cause damage to the inside of the TV set. For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on their specifications. Do not use screws that do not comply with the VESA standard screw specifications. Do not use fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. Our 57” and 63” models do not comply with VESA Specifications. Therefore, you should use our dedicated wall mount kit for this model. Do not exceed 15 degrees tilt when mounting this TV. Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to electric shock. English - 65 job.indb 65 2009-10-22 3:49:43 Preparing before installing Wall- Mount Case A. Installing SAMSUNG Wall-Mount Case B. Installing other company’s Wall-Mount

Install Wall Mount with the torque range of 15kgf·cm or less. Make sure that parts can be damaged if the torque is out of the specified range.

2. Accessory Kit containsHolder–Ring [2] for installing other company’s Wall-Mount on Samsung TV. (Case B)

NN Screw down the hole [1] when installing wall-mount on the wall.

Securing the TV to the Wall Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided on the included Safety Flyer. For added stability, install the anti-fall device for safety

purposes, as follows. Wall Wall ❑❑ To avoid the TV from falling

Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the screws have been firmly installed onto the wall. NN You may need additional material such as an anchor depending on the type of wall. NN Since the necessary clamps, screws, and string are not supplied, please purchase these additionally.

Remove the screws from the center back of the TV, put the screws into the clamps, and then fasten the screws onto the TV again. NN Screws may not be supplied with the product.

Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong string and then tie the string tightly. NN Install the TV near to the wall so that it does not fall backwards. NN It is safe to connect the string so that the clamps fixed on the wall are equal to or lower than the clamps fixed on the TV. NN Untie the string before moving the TV.

Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have any doubt about the security of your connections,contact a professional installer. English - 66 job.indb 66 2009-10-22 3:49:43

Assembling the Cables Enclose the cables in the Holder-Wire Cable so that the cables are not visible through the transparent stand.

NN The product colour and shape may vary depending on the model.

English - 67 job.indb 67 2009-10-22 3:49:46 Securing the Installation Space Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation. Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product. Install the product so the required distances shown in the figure are kept. NN When using a stand or wall-mount, use parts provided by Samsung Electronics only. -- If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling. -- If you use parts provided by another manufacturer, it may result in a problem with the product or fire due to an increase in the internal temperature of the product due to poor ventilation. NN The appearance may differ depending on the product. „„ When installing the product with a stand 10 cm 10 cm „„ When installing the product with a wall-mount 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm How to assemble the Stand-Base (depending on the model) Using the 5 screws for securing the stand base and the TV, firmly attach the TV to the stand base. (The exterior of the set may be different than the picture.) Method 1 In case of installing your TV on the wall, close the cover (1) on the stand-base connection part using two screws for hiding. Warning Firmly secure the stand to the TV before moving it, as the stand may fall and could cause serious injury. NN Two or more people should carry the TV. Never lay the TV on the floor because of possible damage to the screen. Always store the TV upright. Method 2 Assemble the stand-base to the TV set as shown in the illustration, then tighten down all the screws. NN Lay down the TV set on a shelf prior to insert screws. NN The screen could be damaged when laid down by hitting the shelf-edges. We recommend you to lay the set on a soft fabric to protect the front part from damages. NN The product Colour and shape may vary depending on the model. English - 68 job.indb 68 2009-10-22 3:49:48 Troubleshooting If you have any questions of TV, first refer to this list. If none of these troubleshooting tips apply, please visit ‘www.samsung.com’ site, then click on Support or contact Call Center on list of last page. NN Firmware Upgrade can be as first possible solution. Problem Possible Solution Picture Quality First of all, please perform the Picture Test to confirm that your TV is properly displaying test image.

• Go to Menu → Support → Self Diagnosis → Picture test If the test image is properly displayed, the poor picture may caused by the source or signal. TV image does not look as good as it did in the store.

• • If you have an analog Cable/Set top box, upgrade to an Box. Use HDMI or Component cables to deliver HD picture quality.
• • Cable/Satellite subscriber : Try HD (High Definition) stations from channel line up.
• • Antenna connection: Try HD stations after performing Auto program NN Many HD channels are upscaled from SD (Standard Definition) contents.
• • Adjust Cable/Set top video output resolution to 1080i or 720p. Picture is distorted: macroblock,small block, dots,pixelization.

• • Compression of video contents may cause picture distortion especially on fast moving pictures such as sports and action movies.
• • Low signal level or bad quality can cause picture distortion. This is not a TV issue. Wrong or missing Colour with Component connection.

• • Make sure the Component cables are connected to the correct jacks. Incorrect or loose connections may cause Colour problems or the screen will be blank. Poor Colour or brightness.

• • Adjust Picture options in the TV menu (Picture Mode, Colour, Brightness, Sharpness).
• • Adjust Energy Saving option in Setup menu.
• • Try picture reset to view the default picture setting. (Go to Menu → Picture → Picture Reset) Dotted line on the edge of screen.

• • If picture size is set to Just scan, change to 16:9.
• • Change cable/Set top box resolution. Picture is black and white with AV (Composite) input only.

• • Connect video cable (Yellow) to Green jack of component input 1 of the TV. Picture freezes or is distorted when changing channels or picture is delayed.

• • If connected with cable box, please try to reset cable box. (reconnect AC cord and wait until cable box reboots. It may take up to 20 minutes)
• • Set output resolution of cable box to 1080i or 720p Sound Quality First of all, please perform the Sound Test to confirm that your TV audio is properly operating.
• Go to Menu → Support → Self Diagnosis → Sound Test If the audio is OK, the sound problem may caused by the source or signal. No sound or sound is too low at maximum volume.

• • Please check the volume of device (Cable/Sat Box, DVD, Blu-ray etc) connected to your TV. Then, adjust the TV volume accordingly. Picture is good but no sound.

• • Set the Speaker Select option to TV speaker in the sound menu.
• • Make sure audio cables from an external device are connected to correct audio input jacks on the TV.
• • Check connected device's audio output option. Ex) You may need to change your cable box' audio option to HDMI when you have HDMI connected to your TV.
• • If you are using a DVI to HDMI cable, a separate audio cable is required.
• • Deactivate SRS function if you are setting the volume over 30 value.
• • Remove plug from headphone jack (if available on your TV). Noise from speaker.

• • Check cable connections. Make sure a video cable is not connected to an audio input.
• • For Antenna/Cable connection, check signal strength. Low signal level may cause sound distortion. Continued... English - 69 job.indb 69 2009-10-22 3:49:49 Problem Possible Solution No Picture, No Video TV won't turn on. TV turns off automatically. No picture/Video.

• • Make sure the AC power cord is plugged in securely to the wall outlet and the TV.
• • Make sure the wall outlet is working.
• • Try pressing the Power button on the TV to make sure the remote is working properly. If the TV turns on, it may be caused by Remote Control. To fix the Remote problem, refer to "Remote control does not work" below.

Check if the Sleep Timer is set to On in the Setup menu. If connected the TV to your PC, check your PC power settings. Make sure the AC power cord is plugged in securely to the wall outlet and the TV. If there is no signal for about 10 ~ 15 minutes with Antenna/Cable connection, the TV will turn off.

• • Check cable connections. (remove and reconnect all cables of TV and external devices)
• • Set your external device's (Cable/Set top Box, DVD, Blu-ray etc) video output to match the connections to the TV input. For example, external device's output : HDMI , TV's input : HDMI.
• • Make sure your connected device is powered on.
• • Make sure to select the TV's correct source by pressing the SOURCE button on the remote control.
• • Reboot the connected device by reconnecting the device’s power cable. RF (Cable/Antenna) Connection Cannot receive all channels.

• • Make sure Antenna cable is connected securely.
• • Please try Plug & Play to add available channels to the channel list. Go to Menu → Setup → Plug & Play and wait for all avaiable channels are stored.
• • Verify Antenna is positioned correctly. Picture is distorted : macroblock,small block,dots,pixelization.

• • Compression of video contents may cause picture distortion especially on fast moving pictures such as sports and action movies.
• • Low signal level can cause picture distortion. This is not a TV issue. PC Connection “Not Supported Mode” message.

• • Set your PC's output resolution and frequency so it matches the resolutions supported by the TV. PC is always shown on source list even if not connected.

• • This is normal; PC is always shown on the source list even though a PC is not connected. Video is OK but there is no audio with HDMI connection.

• • Check the audio output setting on your PC. Network Connection Wireless network connection failure.

• • Samsung Wireless USB dongle is required to use wireless network.
• • Make sure Network Type is set to Wireless.
• • TV must be connected to a wireless IP sharer (Router). Others Picture is not shown in full screen. Remote control does not work.

• • Black bars on each side will be shown on HD channels when displaying upscaled SD (4:3) contents.
• • Black bars on Top & Bottom will be shown on movies that have aspect ratios different from your TV.
• • Adjust picture size option on your external device or TV to full screen.
• • Replace the remote control batteries with correct polarity (+ -).
• • Clean the transmission window located on the top of the remote.
• • Try pointing the remote directly at the TV from 5~6 feet away. Continued... English - 70 job.indb 70 2009-10-22 3:49:49 Problem Possible Solution Plasma TV is making humming noise.

• • Plasma TVs typically make a soft humming sound. This is normal. It’s caused by the electrical charges that are used to create the images on the screen.
• • If the humming sound is loud, you may have set the brightness on the TV too high. Try setting the brightness lower.
• • You can also have loud humming if the back of your Plasma TV is too close to a wall or other hard surface. Also try rerouting your connection cables.
• • Improper installation of wall mount can create excessive noise. Image Retention (Burn In) Issue.

• • To minimize the possibility of screen burn, this unit is equipped with screen burn reduction technology. Pixel Shift technology enables you to set picture movement up/ down (Vertical Line) and side to side (Horizontal Dot). Can not control TV power or volume with Cable/Set top box remote control.

• • Program the Cable/Set top remote control to operate the TV. Refer to Cable/Sat user manual for SAMSUNG TV code. “Not Supported Mode” message.

• • Check the supported resolution of the TV and adjust the external device's output resolution accordingly. Refer to resolution settings in this manual. Plastic smell from TV.

• • This smell is normal and will dissipate over time. TV Signal Strength is unavailable in the Self Diagnostic Test menu.

• • This function is only available with digital channels with an Antenna (RF/Coax) connection. TV is tilted to right or left side.

• • Remove the stand base from TV and reassemble. Can not assemble stand base.

• • Make sure TV is placed on flat surface. If can not remove screws from TV, please use magnetized screw driver. Channel menu is grey out (unavailable).

• • Channel menu is only available when TV source is selected. Your settings are lost after 30 minutes or every time TV is turned off.

• • If TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. Please change from Store Demo mode to Home Use mode in the Plug & Play procedure. Press the SOURCE button to select TV mode, go to Menu → Setup → Plug & Play
• Enter Intermittent loss of audio or video.

• • Check cable connections and reconnect.
• • Can be caused by using overly rigid or thick cables. Make sure the cables are flexible enough for long term use. If wall mounting, we recommend using cables with 90 degree connectors. You may see small particles if you look closely at the edge of the bezel surrounding the TV screen.

• • This is part of the product’s design and is not a defect. PIP menu is not available.

• • PIP functionality is only available when you are watching an HDMI, PC or components source. ‘Scramble signal’ or ‘No signal/Weak signal’ with CAM CARD(CI/CI+)

• • Check that CAM has CI(CI+) Card installed into the common interface slot.
• • It is normal, the TV operate OTA(Over The Air) function itself to upgrade firmware downloaded during watching. Recurrent picture/sound issue

• • Check and change signal/source. NN Some of above pictures and functions are available at specific models only. English - 71 job.indb 71 2009-10-22 3:49:49 Specifications The descriptions and characteristics in this booklet are given for information purposes only and are subject to modification without notice. Model Name PS50B850 PS58B850 50 inch 58 inch 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 10 W x 2 15 W x 2 Body 1238 x 751.9 x 29.5 mm 1423.6 x 853.8 x 36.8 mm With stand 1238 x 813.2 x 277.2 mm 1423.6 x 920 x 337.2 mm Body

26.1 kg

36.9 kg

32.5 kg

45.6 kg

Screen Size (Diagonal) PC Resolution (Optimum) Sound (Output) Dimension (W x H x D) Weight Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity NN This device is a Class B digital apparatus. NN Design and specifications are subject to change without prior notice. NN For the power supply and Power Consumption, refer to the label attached to the product. English - 72 job.indb 72 2009-10-22 3:49:49 Software License This product uses parts of the software from the Independent JPEG Group. This product uses parts of the software owned by the Freetype Project (www.freetype.org). This product uses some software programs which are distributed under the GPL/LGPL license. Accordingly, the following GPL and LGPL software source codes that have been used in this product can be provided after asking to vdswmanager@samsung.com. GPL software: Linux Kernel, Busybox, Binutils LGPL software: Glibc, ffmpeg, smpeg, libgphoto, libusb, SDL

❑❑ GNU GENERAL PUBLIC LICENSE

GNU GENERAL PUBLIC LICENSE

Version 3, 2 9 June 2007 Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The GNU General Public License is a free, copyleft license for software and other kinds of works. The licenses for most software and other practical works are designed to take away your freedom to share and change the works. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change all versions of a program--to make sure it remains free software for all its users. We, the Free Software Foundation, use the GNU General Public License for most of our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things. To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the rights. Therefore, you have certain responsibilities if you distribute copies of the software, or if you modify it: responsibilities to respect the freedom of others. For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the recipients the same freedoms that you received. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and (2) offer you this License giving you legal permission to copy, distribute and/or modify it. For the developers’ and authors’ protection, the GPL clearly explains that there is no warranty for this free software. For both users’ and authors’ sake, the GPL requires that modified versions be marked as changed, so that their problems will not be attributed erroneously to authors of previous versions. Some devices are designed to deny users access to install or run modified versions of the software inside them, although the manufacturer can do so. This is fundamentally incompatible with the aim of protecting users’ freedom to change the software. The systematic pattern of such abuse occurs in the area of products for individuals to use, which is precisely where it is most unacceptable. Therefore, we have designed this version of the GPL to prohibit the practice for those products. If such problems arise substantially in other domains, we stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the freedom of users. Finally, every program is threatened constantly by software patents. States should not allow patents to restrict development and use of software on generalpurpose computers, but in those that do, we wish to avoid the special danger that patents applied to a free program could make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non-free. The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS

Definitions. “This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees” and “ recipients” may be individuals or organizations. To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright permission, other than the making of an exact copy. The resulting work is called a “modified version” of the earlier work or a work “based on” the earlier work. A “covered work” means either the unmodified Program or a work based on the Program. To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation includes copying, distribution (with or without modification), making available to the public, and in some countries other activities as well. To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere interaction with a user through a computer network, with no transfer of a copy, is not conveying. An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and prominently visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that there is no warranty for the work (except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list meets this criterion. Source Code. The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any nonsource form of a work. A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language. The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is included in the normal form of packaging a Major Component, but which is not part of that Major Component, and (b) serves only to enable use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to the public in source code form. A “Major Component”, in this context, means a major essential component (kernel, window system, and so on) of the English - 73 job.indb 73 2009-10-22 3:49:49 specific operating system (if any) on which the executable work runs, or a compiler used to produce the work, or an object code interpreter used to run it. The “Corresponding Source” for a work in object code form means all the source code needed to generate, install, and (for an executable work) run the object code and to modify the work, including scripts to control those activities. However, it does not include the work’s System Libraries, or general-purpose tools or generally available free programs which are used unmodified in performing those activities but which are not part of the work. For example, Corresponding Source includes interface definition files associated with source files for the work, and the source code for shared libraries and dynamically linked subprograms that the work is specifically designed to require, such as by intimate data communication or control flow between those subprograms and other parts of the work. The Corresponding Source need not include anything that users can regenerate automatically from other parts of the Corresponding Source. The Corresponding Source for a work in source code form is that same work.

2. Basic Permissions.

All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work. This License acknowledges your rights of fair use or other equivalent, as provided by copyright law. You may make, run and propagate covered works that you do not convey, without conditions so long as your license otherwise remains in force. You may convey covered works to others for the sole purpose of having them make modifications exclusively for you, or provide you with facilities for running those works, provided that you comply with the terms of this License in conveying all material for which you do not control copyright. Those thus making or running the covered works for you must do so exclusively on your behalf, under your direction and control, on terms that prohibit them from making any copies of your copyrighted material outside their relationship with you. Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed; section 10 makes it unnecessary.

3. Protecting Users’ Legal Rights From Anti-Circumvention Law.

No covered work shall be deemed part of an effective technological measure under any applicable law fulfilling obligations under article 11 of the WIPO copyright treaty adopted on 20 December 1996, or similar laws prohibiting or restricting circumvention of such measures. When you convey a covered work, you waive any legal power to forbid circumvention of technological measures to the extent such circumvention is effected by exercising rights under this License with respect to the covered work, and you disclaim any intention to limit operation or modification of the work as a means of enforcing, against the work’s users, your or third parties’ legal rights to forbid circumvention of technological measures.

4. Conveying Verbatim Copies.

You may convey verbatim copies of the Program’s source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this License and any nonpermissive terms added in accord with section 7 apply to the code; keep intact all notices of the absence of any warranty; and give all recipients a copy of this License along with the Program. You may charge any price or no price for each copy that you convey, and you may offer support or warranty protection for a fee.

5. Conveying Modified Source Versions.

You may convey a work based on the Program, or the modifications to produce it from the Program, in the form of source code under the terms of section 4, provided that you also meet all of these conditions:

a) The work must carry prominent notices stating that you modified it, and giving a relevant date. b) The work must carry prominent notices stating that it is released under this License and any conditions added under section 7. This requirement modifies the requirement in section 4 to “keep intact all notices”. c) You must license the entire work, as a whole, under this License to anyone who comes into possession of a copy. This License will therefore apply, along with any applicable section 7 additional terms, to the whole of the work, and all its parts, regardless of how they are packaged. This License gives no permission to license the work in any other way, but it does not invalidate such permission if you have separately received it. d) If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the Program has interactive interfaces that do not display Appropriate Legal Notices, your work need not make them do so. A compilation of a covered work with other separate and independent works, which are not by their nature extensions of the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or legal rights of the compilation’s users beyond what the individual works permit. Inclusion of a covered work in an aggregate does not cause this License to apply to the other parts of the aggregate. Conveying Non-Source Forms. You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the machinereadable Corresponding Source under the terms of this License, in one of these ways: a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by the Corresponding Source fixed on a durable physical medium customarily used for software interchange. b) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by a written offer, valid for at least three years and valid for as long as you offer spare parts or customer support for that product model, to give anyone who possesses the object code either (1) a copy of the Corresponding Source for all the software in the product that is covered by this License, on a durable physical medium customarily used for software interchange, for a price no more than your reasonable cost of physically performing this conveying of source, or (2) access to copy the Corresponding Source from a network server at no charge. c) Convey individual copies of the object code with a copy of the written offer to provide the Corresponding Source. This alternative is allowed only occasionally and noncommercially, and only if you received the object code with such an offer, in accord with subsection 6b. English - 74 job.indb 74 2009-10-22 3:49:49

d) Convey the object code by offering access from a designated place (gratis or for a charge), and offer equivalent access to the Corresponding Source in the same way through the same place at no further charge. You need not require recipients to copy the Corresponding Source along with the object code. If the place to copy the object code is a network server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding Source. Regardless of what server hosts the Corresponding Source, you remain obligated to ensure that it is available for as long as needed to satisfy these requirements. e) Convey the object code using peer-to-peer transmission, provided you inform other peers where the object code and Corresponding Source of the work are being offered to the general public at no charge under subsection 6d. A separable portion of the object code, whose source code is excluded from the Corresponding Source as a System Library, need not be included in conveying the object code work. A “User Product” is either (1) a “consumer product”, which means any tangible personal property which is normally used for personal, family, or household purposes, or (2) anything designed or sold for incorporation into a dwelling. In determining whether a product is a consumer product, doubtful cases shall be resolved in favor of coverage. For a particular product received by a particular user, “normally used” refers to a typical or common use of that class of product, regardless of the status of the particular user or of the way in which the particular user actually uses, or expects or is expected to use, the product. A product is a consumer product regardless of whether the product has substantial commercial, industrial or non-consumer uses, unless such uses represent the only significant mode of use of the product. “Installation Information” for a User Product means any methods, procedures, authorization keys, or other information required to install and execute modified versions of a covered work in that User Product from a modified version of its Corresponding Source. The information must suffice to ensure that the continued functioning of the modified object code is in no case prevented or interfered with solely because modification has been made. If you convey an object code work under this section in, or with, or specifically for use in, a User Product, and the conveying occurs as part of a transaction in which the right of possession and use of the User Product is transferred to the recipient in perpetuity or for a fixed term (regardless of how the transaction is characterized), the Corresponding Source conveyed under this section must be accompanied by the Installation Information. But this requirement does not apply if neither you nor any third party retains the ability to install modified object code on the User Product (for example, the work has been installed in ROM). The requirement to provide Installation Information does not include a requirement to continue to provide support service, warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the operation of the network or violates the rules and protocols for communication across the network. Corresponding Source conveyed, and Installation Information provided, in accord with this section must be in a format that is publicly documented (and with an implementation available to the public in source code form), and must require no special password or key for unpacking, reading or copying. Additional Terms. “Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in this License, to the extent that they are valid under applicable law. If additional permissions apply only to part of the Program, that part may be used separately under those permissions, but the entire Program remains governed by this License without regard to the additional permissions. When you convey a copy of a covered work, you may at your option remove any additional permissions from that copy, or from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give appropriate copyright permission. Notwithstanding any other provision of this License, for material you add to a covered work, you may (if authorized by the copyright holders of that material) supplement the terms of this License with terms: a) Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or b) Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate Legal Notices displayed by works containing it; or c) Prohibiting misrepresentation of the origin of that material, or requiring that modified versions of such material be marked in reasonable ways as different from the original version; or d) Limiting the use for publicity purposes of names of licensors or authors of the material; or e) Declining to grant rights under trademark law for use of some trade names, trademarks, or service marks; or f) Requiring indemnification of licensors and authors of that material by anyone who conveys the material (or modified versions of it) with contractual assumptions of liability to the recipient, for any liability that these contractual assumptions directly impose on those licensors and authors. All other non-permissive additional terms are considered “further restrictions” within the meaning of section 10. If the Program as you received it, or any part of it, contains a notice stating that it is governed by this License along with a term that is a further restriction, you may remove that term. If a license document contains a further restriction but permits relicensing or conveying under this License, you may add to a covered work material governed by the terms of that license document, provided that the further restriction does not survive such relicensing or conveying. If you add terms to a covered work in accord with this section, you must place, in the relevant source files, a statement of theadditional terms that apply to those files, or a notice indicating where to find the applicable terms. Additional terms, permissive or non-permissive, may be stated in the form of a separately written license, or stated as exceptions; the above requirements apply either way. Termination. You may not propagate or modify a covered work except as expressly provided under this License. Any attempt otherwise to propagate or modify it is void, and will automatically terminate your rights under this License (including any patent licenses granted under the third paragraph of section 11). However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a) provisionally, unless and until the copyright holder explicitly and finally terminates your license, and (b) permanently, if the copyright holder fails to notify you of the violation by some reasonable means prior to 60 days after the cessation. Moreover, your license from a particular English - 75 job.indb 75 2009-10-22 3:49:50 copyright holder is reinstated permanently if the copyright holder notifies you of the violation by some reasonable means, this is the first time you have received notice of violation of this License (for any work) from that copyright holder, and you cure the violation prior to 30 days after your receipt of the notice. Termination of your rights under this section does not terminate the licenses of parties who have received copies or rights from you under this License. If your rights have been terminated and not permanently reinstated, you do not qualify to receive new licenses for the same material under section 10.

9. Acceptance Not Required for Having Copies.

You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require acceptance. However, nothing other than this License grants you permission to propagate or modify any covered work. These actions infringe copyright if you do not accept this License. Therefore, by modifying or propagating a covered work, you indicate your acceptance of this License to do so.

10. Automatic Licensing of Downstream Recipients.

Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this License. An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party to that transaction who receives a copy of the work also receives whatever licenses to the work the party’s predecessor in interest had or could give under the previous paragraph, plus a right to possession of the You may not impose any further restrictions on the exercise of the rights granted or affirmed under this License. For example, you may not impose a license fee, royalty, or other charge for exercise of rights granted under this License, and you may not initiate litigation (including a cross-claim or counterclaim in a lawsuit) alleging that any patent claim is infringed by making, using, selling, offering for sale, or importing the Program or any portion of it.

11. Patents.

A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is based. The work thus licensed is called the contributor’s “contributor version”. A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its contributor version, but do not include claims that would be infringed only as a consequence of further modification of the contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner consistent with the requirements of this License. Each contributor grants you a non-exclusive, worldwide, royalty-free patent license under the contributor’s essential patent claims, to make, use, sell, offer for sale, import and otherwise run, modify and propagate the contents of its contributor version. In the following three paragraphs, a “patent license” is any express agreement or commitment, however denominated, not to enforce a patent (such as an express permission to practice a patent or covenant not to sue for patent infringement). To “grant” such a patent license to a party means to make such an agreement or commitment not to enforce a patent against the party. If you convey a covered work, knowingly relying on a patent license, and the Corresponding Source of the work is not available for anyone to copy, free of charge and under the terms of this License, through a publicly available network server or other readily accessible means, then you must either (1) cause the Corresponding Source to be so available, or (2) arrange to deprive yourself of the benefit of the patent license for this particular work, or (3) arrange, in a manner consistent with the requirements of this License, to extend the patent license to downstream recipients. “Knowingly relying” means you have actual knowledge that, but for the patent license, your conveying the covered work in a country, or your recipient’s use of the covered work in a country, would infringe one or more identifiable patents in that country that you have reason to believe are valid. If, pursuant to or in connection with a single transaction or arrangement, you convey, or propagate by procuring conveyance of, a covered work, and grant a patent license to some of the parties receiving the covered work authorizing them to use, propagate, modify or convey a specific copy of the covered work, then the patent license you grant is automatically extended to all recipients of the covered work and works based on it. A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software, under which you make payment to the third party based on the extent of your activity of conveying the work, and under which the third party grants, to any of the parties who would receive the covered work from you, a discriminatory patent license (a) in connection with copies of the covered work conveyed by you (or copies made from those copies), or (b) primarily for and in connection with specific products or compilations that contain the covered work, unless you entered into that arrangement, or that patent license was granted, prior to 28 March 2007. Nothing in this License shall be construed as excluding or limiting any implied license or other defenses to infringement that may otherwise be available to you under applicable patent law.

12. No Surrender of Others’ Freedom.

If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not convey it at all. For example, if you agree to terms that obligate you to collect a royalty for further conveying from those to whom you convey the Program, the only way you could satisfy both those terms and this License would be to refrain entirely from conveying the Program.

13. Use with the GNU Affero General Public License.

Notwithstanding any other provision of this License, you have permission to link or combine any covered work with a work licensed under version 3 of the GNU Affero General Public License into a single combined work, and to convey the resulting work. The terms of this License will continue to apply to the part which is the covered work, but the special requirements of the GNU Affero General Public License, section 13, concerning interaction through a network will apply to the combination as such. English - 76 job.indb 76 2009-10-22 3:49:50

14. Revised Versions of this License.

The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number. If the Program specifies that a certain numbered version of the GNU General Public License “or any later version” applies to it, you have the option of following the terms and conditions either of that numbered version or of any later version published by the Free Software Foundation. If the Program does not specify a version number of the GNU General Public License, you may choose any version ever published by the Free Software Foundation. If the Program specifies that a proxy can decide which future versions of the GNU General Public License can be used, that proxy’s public statement of acceptance of a version permanently authorizes you to choose that version for the Program. Later license versions may give you additional or different permissions. However, no additional obligations are imposed on any author or copyright holder as a result of your choosing to follow a later version.

15. Disclaimer of Warranty.

THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “ AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16. Limitation of Liability.

IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MODIFIES AND/OR CONVEYS THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

17. Interpretation of Sections 15 and 16.

If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms, reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee. How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms. To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively state theexclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is found. <one line to give the program’s name and a brief idea of what it does.> Copyright (C) <year> <name of author> This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version. This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details. You should have received a copy of the GNU General Public License along with this program. If not, see <http://www.gnu. org/licenses/>. Also add information on how to contact you by electronic and paper mail. If the program does terminal interaction, make it output a short notice like this when it starts in an interactive mode: <program> Copyright (C) <year> <name of author> This program comes with ABSOLUTELY NO WARRANTY; for details type `show w’. This is free software, and you are welcome to redistribute it under certain conditions; type `show c’ for details. The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the General Public License. Of course, your program’s commands might be different; for a GUI interface, you would use an “about box”. You should also get your employer (if you work as a programmer) or school, if any, to sign a “copyright disclaimer” for the program, if necessary. For more information on this, and how to apply and follow the GNU GPL, see <http://www.gnu.org/licenses/>.The GNU General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Lesser General Public License instead of this License. But first, please read <http://www.gnu.org/philosophy/why-not-lgpl.html>. English - 77 job.indb 77 2009-10-22 3:49:50 ❑❑ GNU Lesser General Public License (LGPL)

GNU GENERAL PUBLIC LICENSE

Version 3, 29 June 2007 Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The GNU General Public License is a free, copyleft license for software and other kinds of works. The licenses for most software and other practical works are designed to take away your freedom to share and change the works. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change all versions of a program--to make sure it remains free software for all its users. We, the Free Software Foundation, use the GNU General Public License for most of our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things. To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the rights. Therefore, you have certain responsibilities if you distribute copies of the software, or if you modify it: responsibilities to respect the freedom of others. For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the recipients the same freedoms that you received. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and (2) offer you this License giving you legal permission to copy, distribute and/or modify it. For the developers’ and authors’ protection, the GPL clearly explains that there is no warranty for this free software. For both users’ and authors’ sake, the GPL requires that modified versions be marked as changed, so that their problems will not be attributed erroneously to authors of previous versions. Some devices are designed to deny users access to install or run modified versions of the software inside them, although the manufacturer can do so. This is fundamentally incompatible with the aim of protecting users’ freedom to change the software. The systematic pattern of such abuse occurs in the area of products for individuals to use, which is precisely where it is most unacceptable. Therefore, we have designed this version of the GPL to prohibit the practice for those products. If such problems arise substantially in other domains, we stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the freedom of users. Finally, every program is threatened constantly by software patents. States should not allow patents to restrict development and use of software on general-purpose computers, but in those that do, we wish to avoid the special danger that patents applied to a free program could make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non-free. The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS

Definitions. “This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees” and “ recipients” may be individuals or organizations. To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright permission, other than the making of an exact copy. The resulting work is called a “modified version” of the earlier work or a work “based on” the earlier work. A “covered work” means either the unmodified Program or a work based on the Program. To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation includes copying, distribution (with or without modification), making available to the public, and in some countries other activities as well. To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere interaction with a user through a computer network, with no transfer of a copy, is not conveying. An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and prominently visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that there is no warranty for the work (except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list meets this criterion. Source Code. The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any nonsource form of a work. A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language. The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is included in the normal form of packaging a Major Component, but which is not part of that Major Component, and (b) serves only to enable use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to the public in source code form. A “Major Component”, in this context, means a major essential component (kernel, window system, and so on) of the specific operating system (if any) on which the executable work runs, or a compiler used to produce the work, or an object code interpreter used to run it. The “Corresponding Source” for a work in object code form means all the source code needed to generate, install, and (for an executable work) run the object code and to modify the work, including scripts to control those activities. However, it does not include the work’s System Libraries, or general-purpose tools or generally available free programs which are used unmodified in performing those activities but which are not part of the work. For example, Corresponding Source includes interface definition files associated with source files for the work, and the source code for shared libraries and dynamically linked English - 78 job.indb 78 2009-10-22 3:49:50

subprograms that the work is specifically designed to require, such as by intimate data communication or control flow between those subprograms and other parts of the work. The Corresponding Source need not include anything that users can regenerate automatically from other parts of the Corresponding Source. The Corresponding Source for a work in source code form is that same work. Basic Permissions. All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work. This License acknowledges your rights of fair use or other equivalent, as provided by copyright law. You may make, run and propagate covered works that you do not convey, without conditions so long as your license otherwise remains in force. You may convey covered works to others for the sole purpose of having them make modifications exclusively for you, or provide you with facilities for running those works, provided that you comply with the terms of this License in conveying all material for which you do not control copyright. Those thus making or running the covered works for you must do so exclusively on your behalf, under your direction and control, on terms that prohibit them from making any copies of your copyrighted material outside their relationship with you. Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed; section 10 makes it unnecessary. Protecting Users’ Legal Rights From Anti-Circumvention Law. No covered work shall be deemed part of an effective technological measure under any applicable law fulfilling obligations under article 11 of the WIPO copyright treaty adopted on 20 December 1996, or similar laws prohibiting or restricting circumvention of such measures. When you convey a covered work, you waive any legal power to forbid circumvention of technological measures to the extent such circumvention is effected by exercising rights under this License with respect to the covered work, and you disclaim any intention to limit operation or modification of the work as a means of enforcing, against the work’s users, your or third parties’ legal rights to forbid circumvention of technological measures. Conveying Verbatim Copies. You may convey verbatim copies of the Program’s source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this License and any nonpermissive terms added in accord with section 7 apply to the code; keep intact all notices of the absence of any warranty; and give all recipients a copy of this License along with the Program. You may charge any price or no price for each copy that you convey, and you may offer support or warranty protection for a fee. Conveying Modified Source Versions. You may convey a work based on the Program, or the modifications to produce it from the Program, in the form of source code under the terms of section 4, provided that you also meet all of these conditions: a) The work must carry prominent notices stating that you modified it, and giving a relevant date. b) The work must carry prominent notices stating that it is released under this License and any conditions added under section 7. This requirement modifies the requirement in section 4 to “keep intact all notices”. c) You must license the entire work, as a whole, under this License to anyone who comes into possession of a copy. This License will therefore apply, along with any applicable section 7 additional terms, to the whole of the work, and all its parts, regardless of how they are packaged. This License gives no permission to license the work in any other way, but it does not invalidate such permission if you have separately received it. d) If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the Program has interactive interfaces that do not display Appropriate Legal Notices, your work need not make them do so. A compilation of a covered work with other separate and independent works, which are not by their nature extensions of the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or legal rights of the compilation’s users beyond what the individual works permit. Inclusion of a covered work in an aggregate does not cause this License to apply to the other parts of the aggregate. Conveying Non-Source Forms. You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the machinereadable Corresponding Source under the terms of this License, in one of these ways: a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by the Corresponding Source fixed on a durable physical medium customarily used for software interchange. b) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by a written offer, valid for at least three years and valid for as long as you offer spare parts or customer support for that product model, to give anyone who possesses the object code either (1) a copy of the Corresponding Source for all the software in the product that is covered by this License, on a durable physical medium customarily used for software interchange, for a price no more than your reasonable cost of physically performing this conveying of source, or (2) access to copy the Corresponding Source from a network server at no charge. c) Convey individual copies of the object code with a copy of the written offer to provide the Corresponding Source. This alternative is allowed only occasionally and noncommercially, and only if you received the object code with such an offer, in accord with subsection 6b. d) Convey the object code by offering access from a designated place (gratis or for a charge), and offer equivalent access to the Corresponding Source in the same way through the same place at no further charge. You need not require recipients to copy the Corresponding Source along with the object code. If the place to copy the object code is a network server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding Source. Regardless of what server hosts the Corresponding Source, you remain obligated to ensure that it is available for as long as needed to satisfy these requirements. English - 79 job.indb 79 2009-10-22 3:49:50

e) Convey the object code using peer-to-peer transmission, provided you inform other peers where the object code and Corresponding Source of the work are being offered to the general public at no charge under subsection 6d. A separable portion of the object code, whose source code is excluded from the Corresponding Source as a System Library, need not be included in conveying the object code work. A “User Product” is either (1) a “consumer product”, which means any tangible personal property which is normally used for personal, family, or household purposes, or (2) anything designed or sold for incorporation into a dwelling. In determining whether a product is a consumer product, doubtful cases shall be resolved in favor of coverage. For a particular product received by a particular user, “normally used” refers to a typical or common use of that class of product, regardless of the status of the particular user or of the way in which the particular user actually uses, or expects or is expected to use, the product. A product is a consumer product regardless of whether the product has substantial commercial, industrial or non-consumer uses, unless such uses represent the only significant mode of use of the product. “Installation Information” for a User Product means any methods, procedures, authorization keys, or other information required to install and execute modified versions of a covered work in that User Product from a modified version of its Corresponding Source. The information must suffice to ensure that the continued functioning of the modified object code is in no case prevented or interfered with solely because modification has been made. If you convey an object code work under this section in, or with, or specifically for use in, a User Product, and the conveying occurs as part of a transaction in which the right of possession and use of the User Product is transferred to the recipient in perpetuity or for a fixed term (regardless of how the transaction is characterized), the Corresponding Source conveyed under this section must be accompanied by the Installation Information. But this requirement does not apply if neither you nor any third party retains the ability to install modified object code on the User Product (for example, the work has been installed in ROM). The requirement to provide Installation Information does not include a requirement to continue to provide support service, warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the operation of the network or violates the rules and protocols for communication across the network. Corresponding Source conveyed, and Installation Information provided, in accord with this section must be in a format that is publicly documented (and with an implementation available to the public in source code form), and must require no special password or key for unpacking, reading or copying. Additional Terms. “Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in this License, to the extent that they are valid under applicable law. If additional permissions apply only to part of the Program, that part may be used separately under those permissions, but the entire Program remains governed by this License without regard to the additional permissions. When you convey a copy of a covered work, you may at your option remove any additional permissions from that copy, or from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give appropriate copyright permission. Notwithstanding any other provision of this License, for material you add to a covered work, you may (if authorized by the copyright holders of that material) supplement the terms of this License with terms: a) Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or b) Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate Legal Notices displayed by works containing it; or c) Prohibiting misrepresentation of the origin of that material, or requiring that modified versions of such material be marked in reasonable ways as different from the original version; or d) Limiting the use for publicity purposes of names of licensors or authors of the material; or e) Declining to grant rights under trademark law for use of some trade names, trademarks, or service marks; or f) Requiring indemnification of licensors and authors of that material by anyone who conveys the material (or modified versions of it) with contractual assumptions of liability to the recipient, for any liability that these contractual assumptions directly impose on those licensors and authors. All other non-permissive additional terms are considered “further restrictions” within the meaning of section 10. If the Program as you received it, or any part of it, contains a notice stating that it is governed by this License along with a term that is a further restriction, you may remove that term. If a license document contains a further restriction but permits relicensing or conveying under this License, you may add to a covered work material governed by the terms of that license document, provided that the further restriction does not survive such relicensing or conveying. If you add terms to a covered work in accord with this section, you must place, in the relevant source files, a statement of the additional terms that apply to those files, or a notice indicating where to find the applicable terms. Additional terms, permissive or non-permissive, may be stated in the form of a separately written license, or stated as exceptions; the above requirements apply either way. Termination. You may not propagate or modify a covered work except as expressly provided under this License. Any attempt otherwise to propagate or modify it is void, and will automatically terminate your rights under this License (including any patent licenses granted under the third paragraph of section 11). However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a) provisionally, unless and until the copyright holder explicitly and finally terminates your license, and (b) permanently, if the copyright holder fails to notify you of the violation by some reasonable means prior to 60 days after the cessation. Moreover, your license from a particular copyright holder is reinstated permanently if the copyright holder notifies you of the violation by some reasonable means, this is the first time you have received notice of violation of this License (for any work) from that copyright holder, and you cure the violation prior to 30 days after your receipt of the notice. Termination of your rights under this section does not terminate the licenses of parties who have received copies or rights from you under this License. If your rights have been terminated and not permanently reinstated, you do not qualify to receive new licenses for the same material under

section 10.

English - 80 job.indb 80 2009-10-22 3:49:50

Acceptance Not Required for Having Copies. You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require acceptance. However, nothing other than this License grants you permission to propagate or modify any covered work. These actions infringe copyright if you do not accept this License. Therefore, by modifying or propagating a covered work, you indicate your acceptance of this License to do so. Automatic Licensing of Downstream Recipients. Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this License. An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party to that transaction who receives a copy of the work also receives whatever licenses to the work the party’s predecessor in interest had or could give under the previous paragraph, plus a right to possession of the Corresponding Source of the work from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts. You may not impose any further restrictions on the exercise of the rights granted or affirmed under this License. For example, you may not impose a license fee, royalty, or other charge for exercise of rights granted under this License, and you may not initiate litigation (including a cross-claim or counterclaim in a lawsuit) alleging that any patent claim is infringed by making, using, selling, offering for sale, or importing the Program or any portion of it. Patents. A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is based. The work thus licensed is called the contributor’s “contributor version”. A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its contributor version, but do not include claims that would be infringed only as a consequence of further modification of the contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner consistent with the requirements of this License. Each contributor grants you a non-exclusive, worldwide, royalty-free patent license under the contributor’s essential patent claims, to make, use, sell, offer for sale, import and otherwise run, modify and propagate the contents of its contributor version. In the following three paragraphs, a “patent license” is any express agreement or commitment, however denominated, not to enforce a patent (such as an express permission to practice a patent or covenant not to sue for patent infringement). To “grant” such a patent license to a party means to make such an agreement or commitment not to enforce a patent against the party. If you convey a covered work, knowingly relying on a patent license, and the Corresponding Source of the work is not available for anyone to copy, free of charge and under the terms of this License, through a publicly available network server or other readily accessible means, then you must either (1) cause the Corresponding Source to be so available, or (2) arrange to deprive yourself of the benefit of the patent license for this particular work, or (3) arrange, in a manner consistent with the requirements of this License, to extend the patent license to downstream recipients. “Knowingly relying” means you have actual knowledge that, but for the patent license, your conveying the covered work in a country, or your recipient’s use of the covered work in a country, would infringe one or more identifiable patents in that country that you have reason to believe are valid. If, pursuant to or in connection with a single transaction or arrangement, you convey, or propagate by procuring conveyance of, a covered work, and grant a patent license to some of the parties receiving the covered work authorizing them to use, propagate, modify or convey a specific copy of the covered work, then the patent license you grant is automatically extended to all recipients of the covered work and works based on it. A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software, under which you make payment to the third party based on the extent of your activity of conveying the work, and under which the third party grants, to any of the parties who would receive the covered work from you, a discriminatory patent license (a) in connection with copies of the covered work conveyed by you (or copies made from those copies), or (b) primarily for and in connection with specific products or compilations that contain the covered work, unless you entered into that arrangement, or that patent license was granted, prior to 28 March 2007. Nothing in this License shall be construed as excluding or limiting any implied license or other defenses to infringement that may otherwise be available to you under applicable patent law. No Surrender of Others’ Freedom. If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not convey it at all. For example, if you agree to terms that obligate you to collect a royalty for further conveying from those to whom you convey the Program, the only way you could satisfy both those terms and this License would be to refrain entirely from conveying the Program. Use with the GNU Affero General Public License. Notwithstanding any other provision of this License, you have permission to link or combine any covered work with a work licensed under version 3 of the GNU Affero General Public License into a single combined work, and to convey the resulting work. The terms of this License will continue to apply to the part which is the covered work, but the special requirements of the GNU Affero General Public License, section 13, concerning interaction through a network will apply to the combination as such. Revised Versions of this License. The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number. If the Program specifies that a certain numbered version of the GNU General Public License “or any later version” applies to it, you have the option of following the terms and conditions either of that numbered version or of any later version published by the Free Software Foundation. If the Program does not specify a version number of the GNU General Public License, you may choose any version ever published by the Free Software Foundation. If the Program specifies that a proxy can decide which future versions of the GNU General Public License can be used, that proxy’s public statement of acceptance of a version permanently authorizes you to choose that version for the Program. Later license versions may give you additional or different permissions. However, no additional obligations are imposed on any author or copyright holder as a result of your choosing to follow a later version. English - 81 job.indb 81 2009-10-22 3:49:50

15. Disclaimer of Warranty.

THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “ AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16. Limitation of Liability.

IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MODIFIES AND/OR CONVEYS THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

17. Interpretation of Sections 15 and 16.

If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms, reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee.

❑❑ END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms. To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively state the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is found. <one line to give the program’s name and a brief idea of what it does.> Copyright (C) <year> <name of author> This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version. This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details. You should have received a copy of the GNU General Public License along with this program. If not, see <http://www.gnu.org/ licenses/>. Also add information on how to contact you by electronic and paper mail. If the program does terminal interaction, make it output a short notice like this when it starts in an interactive mode: <program> Copyright (C) <year> <name of author> This program comes with ABSOLUTELY NO WARRANTY; for details type `show w’. This is free software, and you are welcome to redistribute it under certain conditions; type `show c’ for details. The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the General Public License. Of course, your program’s commands might be different; for a GUI interface, you would use an “about box”. You should also get your employer (if you work as a programmer) or school, if any, to sign a “copyright disclaimer” for the program, if necessary. For more information on this, and how to apply and follow the GNU GPL, see <http://www.gnu.org/licenses/>. The GNU General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Lesser General Public License instead of this License. But first, please read <http://www.gnu.org/philosophy/why-not-lgpl.html>. The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org. OpenSSL License Copyright (c) 1998-2007 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. All advertising materials mentioning features or use of this software must display the following acknowledgment: “This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)” The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used to endorse or promote products derived from this software without prior written permission. For written permission, please contact openssl-core@openssl.org. Products derived from this software may not be called “OpenSSL nor may “OpenSSL” appear in their names without prior written permission of the OpenSSL Project. Redistributions of any form whatsoever must retain the following acknowledgment: “This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)” English - 82 job.indb 82 2009-10-22 3:49:50 THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS’’ AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). Original SSLeay License Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com). Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. All advertising materials mentioning features or use of this software must display the following acknowledgement: “This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)” The word ‘cryptographic’ can be left out if the rouines from the library being used are not cryptographic related :-). If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement: “This product includes software written by Tim Hudson (tjh@cryptsoft.com)” THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS’’ AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.] English - 83 job.indb 83 2009-10-22 3:49:50 Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Select the OSD Language. Language Nederlands

DTV Cable 900 f tn Freshmen On Campus Street Hypnosis Booze Britain Regarder Information Page Guide complet Quitter UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style Infos modif. Quincy, M.E Annuler progr. The Equalizer Information McMillan & Wife Sélectionner tout VESA DMT / DTV CEA VESA GTF

Français - 19 BN68-02334A-FRA.indb 19 10/21/2009 9:05:38 AM NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) Port modem mural Port modem mural DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Français - 33 BN68-02334A-FRA.indb 33 10/21/2009 9:05:53 AM Carol kidd Mr A-Z

Diaporama Lire gp act. ❑❑ Photo „„ Diaporama Tools Normal Fondu1

U Dépl. Diaporama Lire gp act. Changer gp Folder 1 Geek In The Pink Heaven Nom MPEG-4 time-based text SAMI SubRip SubViewer Micro DVD „„ Aide lecture continue → Mar. / Arr. Media Play (USB & DLNA) Bouton VOL Bouton M MUTE

www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italie www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquie ❑❑ Single Sign On U Move E OK R Return Français - 59 BN68-02334A-FRA.indb 59 10/21/2009 9:06:54 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italie www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquie TELEVISEUR ECRAN A PLASMA Caract. VESA (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Standard Vis Quantité

❑❑ Type montage rural

Français - 67 BN68-02334A-FRA.indb 67 10/21/2009 9:07:13 AM Home-Network-Center Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Alle Sendertyp UKTV Gold UKTV style Sendertyp McMillan & Wife Alle wählen VESA DMT / DTV CEA VESA GTF Deutsch - 19 BN68-02334A-GER.indb 19 10/21/2009 8:38:31 AM ❑❑ Software-Update „„ Alternative Software „„ VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI / DVI PC / TV / IPTV / DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Deutsch - 33 BN68-02334A-GER.indb 33 10/21/2009 8:38:46 AM Media Play Photo Photo USB Music Movie Setup Gerät R Zurück Photo Ordner Benutzerdef. Basisansicht

Apr Jun Mrz.01.2009 1/67

IMG_03496 IMG_03496 .JPG .JPG

USB Gerät Ordner IMG_0335.JPG

IMG_0343 .JPG IMG_03496 .JPG 1Datei(en) gew. Wählen

Pop NPKI usermanual Heaven When I Dream ../ Ordnername/ USB Gerät „„ Preference → Photo

❑❑ Photo „„ Diashow Geek In The Pink Heaven *.ts *.tp *.trp Audio-Codec Media Play (USB & DLNA) Home-Network-Center Content Library Internet@TV Home-Network-Center www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey ❑❑ Single Sign On U Move E OK R Return Deutsch - 59 BN68-02334A-GER.indb 59 10/21/2009 8:39:49 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey Home-Network-Center Message 111-1234-5671 : Autor. Medien 111-1234-5672 : Autor. Setup 111-1234-5673 : Vrboten 111-1234-5674 : Vrboten „„ Verboten Home-Network-Center Message Message : Ein Medien Medien : Ein Setup TV-Name : TV „„ TV-Name Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Select the OSD Language. Language Nederlands

U Move E Enter UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style

A 3 A 4 A 5 A 6 A 7 A 8 C -C -C -C -C -C -C --

VESA DMT / DTV CEA VESA GTF

Nederlands - 19 BN68-02334A-00DUT.indb 19 10/21/2009 8:25:24 AM Tweetalig of DUAL-I/II Dual I Dual II Stereo Stereo NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) ❑❑ Software-upgrade „„ Upgrade stand-bymodus Wireless IP sharer LAN-kabel

DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Nederlands - 33 BN68-02334A-00DUT.indb 33 10/21/2009 8:25:35 AM Carol kidd Mr A-Z

Pop NPKI usermanual Heaven When I Dream ../ mapnaam/ USB Apparaat Keuze

„„ Preference → Alg. weergave

❑❑ Photo „„ Diashow Geek In The Pink Heaven resolutie 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 Media Play (USB & DLNA) (*recorder) Opname reserveren www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italië ❑❑ Single Sign On „„ Create Account ❑❑ System Setup „„ Change the Service Lock password „„ Service Duration „„ Ticker Duration U Move E OK R Return Nederlands - 59 BN68-02334A-00DUT.indb 59 10/21/2009 8:26:11 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italië Nucleo in ferrite (4ea) NN Nucleo in ferrite Negozio Teletext Pagina secondaria Teletext Mantieni Teletext Annulla Teletext b P

Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cavo 900 f tn Freshmen On Campus 2:00 - 2:30 Dettagli non disponibili. Oggi 2:00 - 3:00 f tn Freshmen O.. Street Hypn.. ITV Play Mint Extra Kerrang! Loaded Kiss Fresh 40 with Dynamite MC oneword The Distillery Smash Hits! Smash Hits! Sunday Guarda Informazioni 2:10 Mar 1 Jún 2:00 2:30 ▼ 5:00 Guarda A locked channel.

Programma prenotato UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style McMillan & Wife Seleziona tutto „„ xvYCC → Off / On Frequenza pixel clock (MHz)) VESA DMT / DTV CEA VESA GTF Italiano - 19 BN68-02334A-ITA.indb 19 10/21/2009 8:54:09 AM ❑❑ SRS TruSurround HD → Off / On ❑❑ Volume auto → Off / On NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) „„ Lingua Teletext ❑❑ PIP → Off / On E Conf. R Ritorno PIP „„ VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI / DVI PC / TV / IPTV / Samsung Wireless LAN Adapter Router IP wireless Cavo LAN

❑❑ Collegamento mediante WPS (Wi-Fi Protected Setup) „„ Imp rete wireless - Auto DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Italiano - 33 BN68-02334A-ITA.indb 33 10/21/2009 8:54:24 AM Media Play PHOTO Photo USB Music Movie Setup Dispositivo R Ritorno Apr Jun Mar.01.2009 1/67

IMG_03496 IMG_03496 .JPG .JPG

USB Dispositivo Cartella IMG_0335.JPG

Impostazioni pref IMG_0343 .JPG

IMG_03496 .JPG 1File selez SelezioneT T Strumenti R Ritorno

Ordinamento Photo / Music / Movie List Photo Mar Colore

.JPG „„ Orario (Photo / Movie) Photo / Music / Movie List Option Menu Photo Colore Orario Visual base

Geek In The Pink Heaven Nom MPEG-4 time-based text SAMI SubRip SubViewer Micro DVD Lingua programmazione XML HTML string-based string-based string-based Samsung Wireless o LAN Adapter

Media Play (USB & DLNA) www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey ❑❑ Single Sign On U Move E OK R Return Italiano - 59 BN68-02334A-ITA.indb 59 10/21/2009 8:55:23 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italy www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turkey Router IP wirelessr Telefono cellulare Samsung Wireless LAN Adapter Cavo LAN Router IP wirelessr Telefono cellulare „„ Media → On / Off Spec. VESA (A * B) Quantità 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Viti Quantità

• 150MHz ADC INTER SWITCH Arsenal Audio DAC WM8521

SCART CVBS OUT

SCART CVBS IN

SCART LR SCART RGB (SCART1 LR OUT) DVI Audio

PC Audio Component AV In S-VHS EXT T-NIM (COFDM/CVBS) Buffer

SIF_I2S

SPDIF HD VIDEO SD VIDEO

CLS CVBS OUT

IIC Interrupt I2S1_RF WM8593 S/W, A/D

D/A*2, AMP

SPDIF LVDS PCI BUS USB 2.0 *2 DEBUG Hotel/Wall UART Local BUS

I2S0_MONITOR

I2S0_SPK/HP

• ATSC/OpenCable (S-Card/M-Card IF)

• IIC * 4 Chelsea 400MHz

DDR2 I/F

IR/Key For DCM Display Panel 1080P RTL8100 UART SP3232 STB MICOM WT61P6

9 PC IN / PC/DVI AUDIO IN

ella. ! service Conector para servicio. @ DIGITAL AUDIO OUT (OPTICAL) 5 ANT IN Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 Información no detallada. Hoy 2:00 - 3:00 f tn Freshmen O.. Street Hypn.. ITV Play Mint Extra Kerrang! Loaded Kiss Fresh 40 with Dynamite MC oneword The Distillery Smash Hits! Smash Hits! Sunday Ver Información 2:10 Tue 1 Jun 2:00 2:30 ▼ 5:00 Ver UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style McMillan & Wife Seleccionar todos „„ xvYCC → Des. / Act. „„ Real 100Hz Demo → Des. / Act. VESA DMT / DTV CEA VESA GTF Spanish - 19 BN68-02334A-Spa.indb 19 10/21/2009 8:45:28 AM ❑❑ SRS TruSurround HD → Des./Act. „„ BD Wise → Des. / Act. ❑❑ PIP → Des. / Act. DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Spanish - 33 BN68-02334A-Spa.indb 33 10/21/2009 8:45:40 AM R Carpeta superior 1/67

USB Music Dispositivo Nov IMG_03496 IMG_03496 .JPG

PHOTO USB Carpeta Apr Jun Mar.01.2009

R Carpeta superior Movie Preferencia „„ Información Rep.gr. act. Carol kidd Vista básica Cronología Título Carpeta

Apr MOVIE_001.avi Conf. fav Geek In The Pink Heaven *.ts *.tp *.trp Media Play (USB & DLNA) www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italia www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquía „„ Create Account U Move E OK R Return Spanish - 59 BN68-02334A-Spa.indb 59 10/21/2009 8:46:26 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italia www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquía Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Mini guia Guia predef. ❑❑ Guia predef. Guia completo DTV Cabo 900 f tn Freshmen On Campus 2:00 - 2:30 Informação não detalhada. Hoje 2:00 - 3:00 f tn Freshmen O.. Street Hypn.. ITV Play Mint Extra Kerrang! Loaded Kiss Fresh 40 with Dynamite MC oneword The Distillery Smash Hits! Smash Hits! Sunday Ver Informação Página 2:10 Ter 1 Jun DTV Cabo 900 f tn Freshmen On Campus Street Hypnosis Booze Britain Ver Informação Page Guia completo Sair 2:00 2:30 ▼ 5:00 Mini guia Canal UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style McMillan & Wife Selec. Todos VESA DMT / DTV CEA VESA GTF

Português - 19 BN68-02334A-00POR.indb 19 10/21/2009 9:00:45 AM Mono (Normal use) NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) „„ Idioma do teletexto n Mover E Enter R Voltar n Mover E Enter R Voltar DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Português - 33 BN68-02334A-00POR.indb 33 10/21/2009 9:01:03 AM Apr Jun Mar.01.2009 1/67

IMG_03496 IMG_03496 .JPG .JPG

USB Dispos. IMG_0335.JPG

IMG_0343 .JPG IMG_03496 .JPG 1Fic. sel. T Ferramentas R Voltar

Pop NPKI usermanual Heaven When I Dream ../ No. pasta/ Dispos. USB Selec. T Ferramentas R Voltar

../ No. pasta / Select USB Dispos.

Tools R Upper Folder U Mover E Enter e Sair Geek In The Pink Heaven Sistema home theatre Cabo HDMI 1.3

Dispositivo Anynet+ 3 Dispositivo Anynet+ 2 Cabo HDMI 1.3 Dispositivo Anynet+ 1 Cabo HDMI 1.3 Media Play (USB & DLNA) Content Library Activar a Content Library

All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or ther intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY, OF QUIET ENJOYMENT, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF THE DEVICE, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time, without notice, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any change, interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability. Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

1. Carregue no botão MENU. Carregue no botão ▲ ou ▼ para seleccionar Application e, em seguida, carregue no botão

2. Carregue no botão ▲ ou ▼ para seleccionar Internet@TV e, em seguida, carregue no botão ENTERE.

OO A aplicação INTERNET@TV é iniciada. OO Carregue no botão Internet@ do telecomando para visualizar o menu Internet@TV.

3. O texto General Disclaimer é apresentado no ecrã. Seleccione I accept ou I do

not accept. NN Para obter mais informações sobre o texto General Disclaimer, consulte ‘Legal Notice’.

4. O “ecrã de boas-vindas” é o ponto de partida da configuração guiada da aplicação

Internet@TV. NN Se seleccionar Exit Setup, este passo é retomado quando carregar no botão INTERNET@. NN Seleccione Let’s get started!

5. A escolha da sua localização permite aos Widgets TV utilizar conteúdos no seu

idioma. NN Seleccione o país a partir da lista fornecida.

6. É necessário aceitar a Yahoo!® TV Widget Engine Política de privacidade de forma a poder utilizar a Internet@TV.

NN Seleccione OK, I Accept. Português - 51 BN68-02334A-00POR.indb 51 10/21/2009 9:02:00 AM ❑❑ O widget Profile www.samsung.com → Products → Television → medi@2.0 → Internet@TV Itália www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquia ❑❑ Single Sign On „„ Create Account ❑❑ System Setup „„ Change the Service Lock password „„ Service Duration „„ Ticker Duration U Move E OK R Return Português - 59 BN68-02334A-00POR.indb 59 10/21/2009 9:02:08 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Itália www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turquia 50 °F to 104 °F (10 °C to 40 °C) -4 °F to 113 °F (-20 °C to 45 °C) ! service Spojnik za servis. @ DIGITAL AUDIO OUT (OPTICAL) Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Tools Anynet+ (HDMI-CEC) Picture Size Picture Mode Sound Mode Sleep Timer

SRS TS HD

Energy Saving Dual l ll Add to Favourite U Move

Auto Wide Standard Custom Off Off Off Mono E Enter e Exit Prikažejo se kratka navodila How to get the best performance from your new HDTV. Pritisnite gumb ENTERE . Time Broadcast Security Network General Channel List Channel Mode : Added Ch. Fine Tune DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information Today 2:00 - 3:00 f tn Freshmen O.. Street Hypn.. ITV Play Mint Extra Kerrang! Loaded Kiss Fresh 40 with Dynamite MC oneword The Distillery Smash Hits! Smash Hits! Sunday Watch Information 2:10 Tue 1 Jun 2:00 2:30 ▼ 5:00 DTV Cable 900 f tn Freshmen On Campus Street Hypnosis Booze Britain Watch Information Page Full Guide Exit ❑❑ Channel Mode Mini Guide Channel UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Channel List Channel Mode

Default Guide All Channel Type Zoom Select Page Tools „„ Add / Delete

All Channels nastavite tudi z izbiro možnosti Tools → Add to Favorite (ali Delete from Favourite) C -- Delete

A 3 A 4 A 5 A 6 A 7 A 8 C -C -C -C -C -C -C -- Add to Favourite

„„ Add to Favourite / Delete from Favourite All UKTV Gold UKTV style Lock Timer Viewing Edit Channel Name Sort

Channel Type Zoom Select Page Tools „„ Deselect All / Select All Zoom Select Change Quincy, Info M.E Cancel Schedules The Equalizer Information McMillan & Wife Select All ❑❑ Cell Light / Contrast / Brightness / Sharpness / Colour / Tint (G/R) Mode : Standard Cell Light

Contrast : 95 Brightness : 45 Sharpness : 50 Colour : 50 Tint (G/R) : G50/R50

Advanced Settings ❑❑ Advanced Settings Picture „„ Dynamic Contrast → Off / Low / Medium / High „„ Colour Space „„ White Balance „„ xvYCC → Off / On „„ Colour Tone → Cool / Normal / Warm1 / Warm2 / Warm3 „„ Digital NR → Off / Low / Medium / High / Auto „„ Blue Only Mode → Off / On Advanced Settings Picture Options slikovne načine. Picture Picture ❑❑ Auto Adjustment Brightness : 45 Sharpness : 50 Auto Adjustment

Screen Advanced Settings Picture Options Picture Reset „„ Vhod D-Sub in HDMI/DVI Način IBM MAC VESA CVT Ločljivost VESA DMT / DTV CEA VESA GTF Slovenščina - 19 BN68-02334A-SLN.indb 19 10/21/2009 8:32:49 AM Equalizer SRS TruSurround HD : Off Audio Language

Audio Description ❑❑ Equalizer

Auto Volume : Off Speaker Select : TV Speaker ❑❑ SRS TruSurround HD → Off / On „„ Audio Description → Off / On ❑❑ Auto Volume → Off / On ❑❑ Speaker Select → External Speaker / TV Speaker ❑❑ Sound Select Broadcast Security Network „„ Clock Mode General : Inactivated U Move E Enter

R Return NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) „„ Teletext Language „„ Child Lock → Off / On „„ Parental Lock ❑❑ General „„ Game Mode → Off / On „„ Energy Saving → Off / Low / Medium / High / Picture Off „„ Melody → Off / Low / Medium / High General Game Mode : Off BD Wise : Off Energy Saving : Off Menu Transparency : Bright Melody ❑❑ PIP → Off / On ❑❑ Self Diagnosis „„ Picture Test ❑❑ Software Upgrade „„ Alternative Software Source List Edit Name „„ VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI / DVI PC / TV / IPTV / Number Lowercase Delete Done Number E Enter R Return Delovanje

Wireless* Network Setup Select* a* network 3/9 PBC PIN Security Key

n Move E Enter R Return Press the PBC button on the access point.

• : AP_3 Access Point Name Cancel Press OK After input TV’s Pincode in the access point’s setup. Access Point Name : AP_3 PIN Code : 12345678

Cancel Wireless* Network*Setup Security

Number Lowercase Delete Done Number E Enter R Return Wireless* Network Setup DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Slovenščina - 33 BN68-02334A-SLN.indb 33 10/21/2009 8:33:03 AM ❑❑ Screen Display Preference Basic View Timeline

4/6 Slide Show Play Current Group Information Remove Safely Folder 1 Preference Basic View

Mar.01.2009 1/67 .JPG USB Device IMG_03496 .JPG IMG_0343 .JPG IMG_0335.JPG Favorites Setting Select T Tools R Return Music Preference Folder Basic View

„„ Preference → Photo

„„ Timeline (Photo / Movie) USB Select T Tools R Upper Folder „„ Mood → Energetic / Rhythmical / Sad / Exciting / Calm / Unclassified Slide Show Play Current Group Information Remove Safely Select T Tools R Upper Folder Music Preference Folder Basic View

When I Dream Select Device Select

Tools Tools R Upper Folder R Upper Folder Movie Preference Basic View Timeline Tiltle Folder Apr

„„ Information Remove Safely

Play Current Group Carol kidd NPKI Artist

„„ Remove Safely .avi Play Current Group USB Device MOVIE_004 .avi Select T Tools R Upper Folder ❑❑ Photo „„ Slide Show „„ Picture Setting / Sound Setting Tools Stop Slide Show Slide Show Speed Slide Show Effect Rotate Zoom Background Music Picture Setting Sound Setting Information Tools Normal

U Move „„ Remove Safely E Enter e Exit Tools Repeat Mode Picture Setting Sound Setting Information Remove Safely „„ Stop Slide Show / Start Slide Show „„ Slide Show Speed → Slow / Normal / Fast gumba π (REW) ali μ (FF). „„ Slide Show Effect Tools Picture Setting Sound Setting Picture Size Caption Setting Information Remove Safely

U Move Fit Enter e Exit „„ Rotate Slide Show Play Current Group Change Group Folder 1 Information Remove Safely Select T Tools R Upper Folder 3648x2432 2009/3/15 1/4 E Pause lr Previous/Next USB

Apr.27.2009 1/5 Select T Tools R Upper Folder Geek In The Pink Heaven E Pause lr Jump T Tools R Return „„ Get the DivX® VOD registration code Music Movie Setup Device e Exit Setup Use Color View Off Music Repeat Mode Cont. movie play help Get the DivX® VOD registration code Get the DivX® VOD deactivation code Screen Saver Run Time 10 min Information Remove Safely

„„ Get the DivX® VOD deactivation code „„ Remove Safely Media Play (USB & DLNA) Home Network Centre „„ Auto Turn Off → No / Yes View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR : On U Move E Enter R Return Gumb VOL Gumb M MUTE (ustavi) /

View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR View TV Device List Recording DVDR MENU DVDR INFO Receiver Setup : DVDR : On Content Library Internet@TV Home Network Centre S pritiskanjem gumba ◄ ali ► izberite ikono (Gallery, Cooking, Children, Wellness, Others, Content Management) in nato pritisnite gumb ENTERE. Content Library ❑❑ Content Management „„ My contents NN Prvi korak je nastavitev omrežja. Za dodatne informacije o konfiguriranju omrežja si oglejte razdelek ‘Nastavitev omrežja’. NN Ko omrežje deluje, vas programska oprema Internet@TV vodi po čarovniku za namestitev po korakih. All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or ther intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY, OF QUIET ENJOYMENT, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF THE DEVICE, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time, without notice, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any change, interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability. Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

1. Pritisnite gumb MENU. S pritiskanjem gumba ▲ ali ▼ izberite Application, nato pritisnite gumb ENTERE.

2. S pritiskanjem gumba ▲ ali ▼ izberite Internet@TV, nato pritisnite gumb ENTERE.

NN Zažene se INTERNET@TV. www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italija ❑❑ Single Sign On „„ Create Account ❑❑ System Setup „„ Change the Service Lock password „„ Service Duration „„ Ticker Duration U Move E OK R Return Slovenščina - 59 BN68-02334A-SLN.indb 59 10/21/2009 8:33:47 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV Italija www.samsung.com → Products → Television → medi@2.0 → Internet@TV Turčija NN Media function is available in other mobile devices which support DLNA DMC. „„ Allowed Home Network Centre Message 111-1234-5671 : Allowed Media 111-1234-5672 : Allowed Setup 111-1234-5673 : Denied 111-1234-5674 : Denied „„ Denied „„ Media → On / Off Home Network Centre Message Message : On Media Media : On Setup TV name : TV „„ TV name New message received Doyou want to view Media will be played from “Unknown Device 13” Spec. VESA (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 Standardni vijak Količina

• • Preverite in spremenite signal/vir. 50 °F to 104 °F (10 °C to 40 °C) Delovna vlažnost -4 °F to 113 °F (-20 °C to 45 °C) Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cable 900 f tn Freshmen On Campus Street Hypnosis Booze Britain Sayfa İzle Bilgi Tam Kılavuz Çıkış UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A UKTV Gold UKTV style McMillan & Wife Tümünü Seç VESA DMT / DTV CEA VESA GTF Türkçe - 19 BN68-02334A-Tur.indb 19 10/21/2009 8:11:17 AM ❑❑ SRS TruSurround HD → Kpalı / Açık Regular + NICAM Mono NICAM Mono (Normal) NICAM-Stereo NICAM Stereo Mono (Normal) Stereo Mono (Normal) NICAM ÇİFT I/II) „„ Genel Feragatname Samsung Wireless LAN Adapter Numara Küçük Harf Sil Tamam Numara Küçük Harf Sil Tamam DivX® Certified to play DivX® video, including premium content. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Türkçe - 33 BN68-02334A-Tur.indb 33 10/21/2009 8:11:31 AM Carol kidd Mr A-Z

Pop NPKI usermanual Heaven When I Dream Geek In The Pink Heaven Max Resolution Sti 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 720x576 1920x1080 1920x1080 1920x1080 800x600 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 Media Play (USB & DLNA) Content Library’yi Kullanma ❑❑ Galeri NN İlk adım ağınızı kurmaktır. Ağınızı yapılandırma hakkında daha fazla bilgi için ‘Ağ Kurulumu’na bakın. NN Ağınız çalışmaya başladıktan sonra, Internet@TV yazılımı adım adım kurulum sihirbazı ile size rehberlik edecektir. All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY, OF QUIET ENJOYMENT, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF THE DEVICE, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time, without notice, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any change, interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung may impose limits on the use of or access to certain services or content, in any case and without notice or liability. Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

1. MENU düğmesine basın. Application seçeneğini seçmek için ▲ veya ▼ düğmesine, ardından da ENTERE düğmesine basın.

2. Internet@TV seçeneğinin üzerine gelmek için ▲ veya ▼ düğmesine, ardından ENTERE düğmesine basın.

NN INTERNET@TV starts. OO INTERNET@TV menüsünü görüntülemek için uzaktan kumandadaki Internet@ düğmesine basın.

3. Ekranda General Disclaimer görüntülenir. I accept veya I do not accept

seçeneğini seçin. NN General Disclaimer hakkında daha fazla bilgi için, ‘Legal Notice’ konusuna bakın.

4. Internet@TV’nin rehberlik ettiği kurulumun başlangıç noktası ‘hoş geldiniz

ekranı’dır. NN Exit Setup seçeneğini seçerseniz, bu adım INTERNET@ düğmesine bastığınızda devam eder. NN Let’s get started! öğesini seçin

5. Konumunuzu seçmeniz yerelleştirilmiş içeriği kullanmanız için TV Pencere Öğeleri sağlar.

NN Sunulan listeden ülkenizi seçin. 6. Internet@TV’yi kullanmak için Yahoo!® TV Widget Engine Privacy Policy’yi (Yahoo!® TV Pencere Öğesi Motoru Gizlilik İlkesi) kabul etmeniz gerekir. NN OK, I Accept seçeneğini seçin. Türkçe - 51 BN68-02334A-Tur.indb 51 Devam ediyor... 10/21/2009 8:12:14 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV İtalya www.samsung.com → Products → Television → medi@2.0 → Internet@TV Türkiye ❑❑ Single Sign On „„ Create Account „„ Ticker Duration U Move E OK R Return Türkçe - 59 BN68-02334A-Tur.indb 59 10/21/2009 8:12:20 AM www.samsung.com → Products → Television → medi@2.0 → Internet@TV İtalya www.samsung.com → Products → Television → medi@2.0 → Internet@TV Türkiye 416 Maetan-3 Dong, Yeongtong-Gu, Suwon-City Gyeonggi-Do, Korea, 443-742 Tel. : +82-2-2255-0114 Fax: +82-2-2255-0117 Model Code LVD EMC KTL(Korea Testing Laboratory) CTK CO., LTD.

PS50B850Y1PXXC

KTL(Korea Testing Laboratory) KTL(Korea Testing Laboratory) 222-13, Guro-3dong, Guro-gu, Seoul, 152-718, Korea Tel: +82-2-860-1114 Fax: +82-2-838-2675 Tel: +82-31-339-9970 Fax: +82-31-339-9855 Suwon EMC Test Laboratory416 Maetan-3 Dong, Yeongtong-Ku, Suwon City, Gyeonggi-Do, Korea, 443-742 Tel: +82-31-200-2185 Fax: +82-31-200-2189 10/22/2009 8:13:40 AM
