Bineuse

Extent of delivery	8
Declaration of conformity	8
Description of device / Spare parts	8
Operating times	8
Symbols machine	8
Symbols used in the original instructions	9
Proper use	9
Residual risks	9
Safety instructions	9
Assembly	11
Start-up	11
Working instructions	12
Working with the tiller	12
Maintenance and cleaning	12
Transport	13
Storage	13
Possible faults	13
Technical data	14
Guarantee	14

Extent of delivery

After unpacking, check the contents of the box

That it is complete
Check for possible transport damage

1 Pre-assembled device
1 Lower handle hoop
1 Upper handle hoop
- 1 Screw bag
1 Original instructions
1Assembly and operating instruction sheet

Report any damage or missing items to your dealer, supplier or the manufacturer immediately.

EC Declaration of Conformity

according to EC directive: 2006/42/EC

We,

ATIKA GmbH & Co. KG

Schinkelstraße 97

59227 Ahlen - Germany

herewith declare under our sole responsibility that the product

Bodenhacke (Tiller) type BH 700 and BH 800

Serial number: see last page

is conform with the above mentioned EC directive as well as with the provisions of the guidelines below:

2004/108/EC, 2000/14/EC.

Following harmonized standards have been applied:

EN 60335-1:2002+A1+A11+A12+A2+A13;

EN 60335-1:2002/FprAF:2009; EN 62233:2008;

EN 55014-1:2006; EN 55014-2:1997+A1; EN 61000-3-2:2006;

EN 61000-3-3:1995+A1+A2; EN 709:1997+A2:2009

Conformity assessment procedure: 2000/14/EC - Appendix V.

	BH 700	BH 800
Measured level of the acoustic output LWA	92,3 dB (A)	92,7 dB (A)
Guaranteed level of the acoustic output LWA	93 dB (A)	93 dB (A)

Keeping of technical documents at:

ATIKA GmbH & Co. KG - Technical department - Schinkelstr. 97 59227 Ahlen - Germany

Ahlen, 17.05.2010

A. Pollmeier, management

Description of device / Spare parts

Pos.	Denomination	Order-no.
		BH 700	BH 800
1	Handle	381594
2	Switch handle
3	Safety knob
4	Switch-plug unit	381503
5	Cable strain relief	381595
6	Cable holder	381526
7	Upper handle hoop left	381593
8	Upper handle hoop right	381592
9	Lower handle hoop	381591
10	Body cover	381580
11	Screw M6x45	390143
12	Washer A6.4	391634
13	Star grip M6	385028
14	Safety label	381579
15	Connecting rod	381590
16	Blade protection
17	Blade drum	381586	381587

Operating times

Before initiating the device please observe the provisions pertaining to corresponding laws (regional provisions) for the noise control.

Symbols machine

Carefully read original instructions before handling the machine.

Shut off engine and remove power cord before performing cleaning, maintenance or repair work.

Danger - objects may be thrown out at high speed when motor is running. Keep people, pets and domestic animals out of the danger area.	Keep the mains cable free from the tines or blades. Tines or blades may damage the cables and cause contact with live parts. When connecting cable is damaged or cut through immediately pull out the power plug.
Beware of rotating blades or tines. Do not keep hands and feet near or under rotating parts while the machine is running. Caution! Blades run after!
Wear eye and ear protection.	Protect against moisture.
Electrical devices do not go into the domestic rubbish. Give devices, accessories and packaging to an ecofriendly recycling. According to the European Directive 2002/96/EC on electrical and electronic scrap, electrical devices that are no longer serviceable must be separately collected and brought to a facility for an environmentally compatible recycling.

Symbols Original instructions

Threatened hazard or hazardous situation. Not observing this instruction can lead to injuries or cause damage to property.

Important information on proper handling. Not observing this instruction can lead to faults in the machine.

User information. This information helps you to use all the functions optimally.

Assembly, operation and servicing. Here you are explained exactly what to do.

Please refer to the attached assembly and operating instruction sheet for references to figure numbers in the text.

Proper use

• This device is suited for dig over and mix up of ground areas on private house and hobby gardens.

• The device is not allowed to be used in public gardens, parks, sports centres or at roadsides as well as in agriculture and forestry. The device is not allowed to be used in public gardens, parks, sports centres or at roadsides as well as in agriculture and forestry.
  The device may not be used: on plastered or gravelled areas Risk of injuries existing!

• The intended usage also includes compliance with the operating, servicing and repair conditions prescribed by the manufacturer and following the safety instructions included in the instructions.

• The relevant accident prevention regulations for the operation as well as the other generally acknowledged occupational medicine and safety rules must be complied with.
• Any other use is deemed not to be use as prescribed. The manufacturer is not liable for any type of damage resulting from this: the user bears the sole risk.
• Arbitrary modifications on the scarifier exclude a liability of the manufacturer for damages of all kinds resulting from it.
• Only persons who are familiarised with the device and informed about possible risks are allowed to prepare, operate and service this device. Repair works may only be carried out by us or by a customer service agent nominated by us.
• Shut off engine and remove power cord before performing cleaning, maintenance or repair work.
• The machine may not be used in a potentially explosive environment or be exposed to the rain.

Residual risks

Even if used properly, residual risks can exist even if the relevant safety regulations are complied with due to the design determined by the intended purpose.

Residual risks can be minimised if the "Safety information" and the "Intended usage" as well as the whole of the original instructions are observed.

Observing these instructions, and taking proper care, will reduce the risk of personal injury or damage to the equipment.

• Risk injury of hands and feet if they come close to or under the rotating parts.
• Risk of injury of fingers and hands during assembly and cleaning activities on the blade drum.
• Stones and soil may be thrown off.
• Danger resulting from electric current, if improper connecting wires are used.
• Touching live parts of opened electrical components.
• Impairment of hearing when working on the machine for longer periods of time without ear protection.

In addition, in spite of all the precautionary measures taken, non-obvious residual risks can still exist.

Safety instructions

The device can be dangerous when used improperly. The use of electrical tools requires the observation of basic safety precautions to eliminate risk of fire, electrical shock and personal injuries.

Before commissioning this product, read and keep to the following advice. Also observe the preventive regulations of your professional association and the safety provisions applicable in the respective country, in order to protect yourself and others from possible injury.

Pass the safety instructions on to all persons who work

with the machine.

① Keep these safety instructions in a safe place.
- Make yourself familiar with the equipment before using it, by reading and understanding the original instructions.
- Be attentive. Be careful what you do. Behave sensibly when working. Do not use the device when you are tired or under the influence of drugs, alcohol or medicaments. One moment of carelessness when using the device can result in serious injuries.
- Do not use the device for purposes it is not intended for (see "Intended use").
- Familiarize yourself with your environment and pay attention to possible dangers which you may not be able to hear because of the motor noise.
- Within his area of work the operator is responsible for third parties.
- Children and young persons under 16 years of age as well as persons who have not read the instruction manual are not allowed to operate this product.
- Physically, sensorially or mentally handicapped persons or persons who have no relevant experience and/or knowledge are not allowed to operate the device, unless a person responsible for their safety supervises them or instruct them on how to use the device.
- Children must be supervised to make sure that they do not play with the device.
- Keep bystanders and animals away from your working area. Do not allow other persons, especially children, to touch the tool or cable.
- Switch off the machine if persons, in particular children or pets, are close to you or if you change your working area.
- Never leave the device unattended.
- Wear protective clothing:

• safety goggles

• ear protection (Sound intensity level at workplace can exceed 85 dB (A))

• Wear suitable work clothes:

• do not wear loose-fitting clothes or jewellery; they can catch in moving parts.
  Solid shoes or boots with a nonskid sole

• Trousers to protect the legs

• Do not work with the device barfooted or only with thongs on your feet.
  Take into consideration environmental influences:

• Do not use the device in moist or wet ambience.

• Do not expose the device to rain.
• Do not work directly near swimming pools or garden ponds
• Do only work with sufficient visibility conditions. Provide for good illumination.

• Do not operate the device when the ground is wet, if possible.

• Before trimming, remove all foreign objects (e.g. stones, branches, wires, etc.). While working watch out for further foreign objects.
  If you come across to foreign objects, power off the device, disconnect the mains plug and remove those foreign objects. However before you restart the device, check it for possible damages and have it repaired if necessary.

• Do not overload the device! You work better and safer in the given performance range.

• Only operate the machine with complete and correctly attached safety equipment (e.g. blade guard) and do not alter anything on the machine that could impair the safety.
• Do not modify the device or parts of the device respectively.
• Before turning on the motor, make sure that your feet are at a safe distance from the cutting tools.
• Never keep hands or feet close to or under rotating parts. Keep away from the ejection slot.
• Pay attention to sure footing especially when working on slopes or on wet ground and keep your balance at all times. Guide the device only a walking speed.
• Do not work on steep slopes.
• When working on slopes, always work perpendicular to the slope and never up and down.
• Be especially careful when changing the operating direction on a slope.

• Observe the safety distance given by the handle bar.
  Always push the device forward while it is operating. Do not pull it to yourself or behind you.
  While the motor is running, do not

• lift or carry the device about

• Caution! The tool runs after. Do not try to slow down the tool by hand.

Pay attention that the blade guard is attached.

• Turn off the device and wait until the drum has stopped when - tilting the device

crossing hard ground
- transporting the device to and from the work area

• Switch the machine off and remove the mains plug from the socket when

• carrying out repair works

• maintenance and cleaning
• removing malfunctions and blockages
• transport and storage
• leaving unattended (even during short interruptions)
• when the device begins to exhibit unusual vibrations

• when you have hit an obstacle with the device.

• Do not wash down device with water. (origin of danger electric current).

• Store unused equipment in a dry, locked place out of the reach of children.

• Check the machine for possible damage:

• Before continuing to use the machine, the protective devices must be inspected to ensure that they work perfectly and with their intended function.

• Check whether movable parts function perfectly and do not stick or whether parts are damaged. All parts must be correctly installed and fulfil all conditions to ensure perfect operation.
• Damaged guards and parts must be properly repaired or exchanged by a recognized, specialist workshop; insofar as nothing else is stated in the instructions for use.

• Damaged or illegible safety warning labels should be replaced immediately.

• Maintain your device with care:

• Ensure that all nuts, bolts and screws are tight.

• Make sure that the ventilation apertures are free.

• Keep handles free of oils and grease.
  Follow the maintenance instructions.

Electrical safety

• Design of the connection cable according to IEC 60245 (H 07 RN-F) with a core cross-profile section of at least - 1.5 ~mm^2 for cable lengths up to 25 ~m - 2.5 ~mm^2 for cable lengths over 25 ~m
• Long and thin connection lines result in a potential drop. The motor does not reach any longer its maximal power; the function of the device is reduced.
• Plugs and coupler outlets on connection cables must be made of rubber, non-rigid PVC or other thermoplastic material of same mechanical stability or be covered with this material.
• The connector of the connection cable must be splash-proof.
• When running the connection line observe that it does not interfere, is not squeezed, bended and the plug connection does not get wet.
• Wind off completely the cable when using a cable drum.
• Do not drive the device across the extension cable. Make sure that it is behind you in a secure position. Place the cable on a path or area that has already been worked.
• Do not use the cable for purposes for which it is not meant. Protect the cable against heat, oil and sharp edges. Do not use the cable to pull the plug from the socket.
• Protect yourself against electric shocks. Avoid touching earthed parts with your body (e.g. pipes, heating apparatus, cookers, fridges etc.).
• This device generates an electromagnetic field during operation. Such a field may affect active or passive medical implants under certain circumstances. To reduce the risk of serious injuries we recommend persons who carry medical implants to consult their doctor and the manufacturer of the medical implant before operating this device.
• Regularly check the extension cables and replace them if they are damaged.
• Do never connect a damaged cable to the mains. Do not touch a damaged cable before it is disconnected from the mains. A damaged cable may cause contact with live parts.
• Do not use any defective connection cables.
• When working outdoors, only use extension cables especially approved and appropriately labelled for outdoor use.
• Do not set up any provisional electrical connections.
• Never bypass protective devices or deactivate them.
• Only hook up the machine by means of a fault-current circuit breaker (30 mA).

The electrical connection or repairs to electrical parts of the machine must be carried out by a certified electrician or one of our customer service points. Local regulations - especially regarding protective measures - must be observed.
Damaged mains leads must be replaced by the manufacturer or one of their service workshops or a similar qualified person to prevent dangers.
Repairs to other parts of the machine must be carried out by the manufacturer or one of his customer service points.

Use only original spare parts, accessories and special accessory parts. Accidents can arise for the user through the use of other spare parts. The manufacturer is not liable for any damage or injury resulting from such action.

Assembly

Handle hoop

Plug the lower handle hoop (9) on the connection rod (15) of the motor body. Use the supplied fasteners (2x star grip (13), 2x washer (12), 2x screw M6x45 (11).
B Fasten the upper handle hoop (7,8). You can choose from two handle positions. Use the supplied fasteners (4x star grip (13), 4x washer (11), 4x screw M6x45 (11).
Fix the cable on the handle hoop using the cable holders (6). Make sure that the cable has enough free motion.

Start-up

Mains connection

Compare the voltage given on the machine model plate e.g. 230 V with the mains voltage and connect the machine to the relevant and properly earthed plug.

Connect the machine via a circuit breaker switch (residual-current-operated circuit switch) 30mA .

• Use connecting or extension cables up to a length of 1.5m featuring a core cross section of at least 25mm^2

Mounting of the extension cable

Plug the female connector of the extension cable on the male connector of the switch-connector combination (4). Thread the extension cable through the strain relief (5) as a loop and hang it up.
Make sure that the extension cable has enough free motion.

Switching on / off

Do not use any device where the switch can not be switched on and off. Damaged switches must be repaired or replaced immediately by the customer service.

The device is equipped with a safety circuitry preventing inadvertent switching on.

Only start the machine when it is placed on a flat ground area without obstacles.

Switching on

E Tilt the device slightly towards you.
F Push the safety button (3) and keep it depressed. Next, pull the switch lever (2) toward the handle (1). The device starts and the blade drum can rotate freely.
Now release the safety button (3).

Switching off

When you release the switch lever (2) it returns automatically to its original position.

Motor protection

The motor is equipped with a protective circuit breaker and switches off automatically in case of overloading. After a cooling-down break (approx. 15 min), the motor may be restarted.

Release the switch lever (2) because the device will otherwise restart immediately after it has cooled down. Risk of injury!

Working instructions

Before commencing work, ensure the following:

• You may not start to operate the machine until you have read these original instructions, observed all the instructions given and installed the machine as described!

• Provide for a safe and cleaned workplace. Remove from the working area objects which might be thrown off.
  Before starting your work make sure that:

• the tools and bolts are not worn or damaged. To avoid any unbalance worn or damaged tools and bolts must only be replaced as a whole set.
  drum and blades are in proper condition

• all screw connections are tight
• no other persons or animals stay within the working area,
  you can always step back without any barriers,
  you have always a secure standing position.

Always keep your hands and feet at a safe distance to the rotating tool.

Vibration

If persons who have blood circulation problems are too often exposed to vibrations damages to the nervous system or to blood vessels may occur.

You can reduce vibrations

by thick and warm working gloves,
shorter working time (have longer breaks).

See a doctor if your fingers swell, you don't feel well or your fingers become numb.

Working with the tiller

The device can be used for digging over and for mixing up of ground areas.

Risk of injury by flying around objects. Make sure that the blade guard is attached.

• Place the device at the edge of the ground near the receptacle.
• Move the cable after each turn to the opposite already worked side.
  Make sure not to place excessive strain on the device. ① In case of excessive strain, the motor speed drops and the motor noise changes. Stop and release the switch lever (2)

Wait until the blade drum stands still

• Move the device at an appropriate uniform speed in straight lines across the ground.
• When working on slopes, always position yourself perpendicular to the incline and ensure safe footing. Do not scarify on steep slopes.

In any case, adhere to all safety notes (see "Safe working").

Maintenance and cleaning

Before each maintenance and cleaning work:

• switch off device
• wait until the drum is stationary
• pull out main plug

Maintenance and cleaning activities beyond those described in this chapter may only be performed by customer service.

For maintaining and cleaning, removed security devices must unconditionally be mounted properly and proved again.

Use only original parts. Other parts can result in unexpected damages and injuries.

To make sure that the device is in a safe condition regularly check the device for apparent defects such as

• loose fastening elements (nuts, bolts, screws),
• worn or damaged components.

Maintenance

Blade drum

Risk of injury! Wear protective gloves when working on the blade drum.

Worn blades reduce the performance of the device and put excessive strain on the motor. Therefore check the condition of the blades before each use. If required, have the blade drum replaced by a new one by your authorized service personnel.

Cleaning

Clean the device carefully after each use to ensure faultless function to be maintained.

Risk of injury! Wear protective gloves when working on the blade drum.

• Remove the dirt with a cloth or brush.
  Clean the device immediately after finishing the work.
  Clean the bottom of the device and the blade drum.
• Clean the housing, especially the vent slots, from dirt stuck to it.
• Do not clean the machine with running water or high-pressure cleaners.
• Do not use solvents for the synthetic parts (petrol, alcohol, etc.) as these can damage the synthetic parts.

Transport

Pull the mains plug prior to transport.

The drum can be damaged during transport, e.g. on hard ground, even when the motor is switched off. Therefore carry the device.

Storage

Pull out main plug.

• Store unused equipment in a dry, locked place out of the reach of children.
• In case of extended storage (e.g. during winter) ensure that the device is protected against frost and corrosion.

• Before extended storage, please observe the following to increase the service life of the device and to ensure smooth operation:

• thoroughly clean the device

• Treat metal parts after each use against corrosion using an environmentally friendly biologically degradable spray oil.

Never use any grease!

Possible faults

Before each fault clearance

• switch off device
• wait until the drum is stationary
• pull out main plug

After each fault clearance, put into operation and recheck all security installations.

Fault	Possible cause	Remedy
Device doesn't start	no power	Check power supply, power socket and fuse protection
	Extension cable defect	Check extension cable, exchange defect cable immediately
	Main plug, motor or switch defect	Have main plug, motor or switch checked by an approved electrician or replaced by original spare parts
	Protective motor switch has tripped	1. Drum blocked remove the blockage 2. Allow the motor to cool down approx. 15 minutes before continuing to work
The device operates with interruptions	Extension cable defect	Check extension cable, exchange defect cable immediately
	Internal fault.	Please contact the after sales service.
	ON/OFF button defective.	Please contact the after sales service.
Unusual sounds	Drum is blocked	Remove the blockage
	Loose screws, nuts or other fasteners	Tighten all parts; contact customer service if the noises continue to occur.
Unusual vibrations	Cutting blade damaged or dull	Please contact the after sales service.
Unsatisfactory result	Dull blades	Please contact the after sales service.

Technical data

Type		BH 700	BH 800
Model		BH 700	BH 800
Motorating P1		700 W	750 W
Mains voltage / Mains frequency		230 V~/50 Hz
Mains fuse		10 A inert
No-load speed n0		340 min-1
Working width		370 mm	450 mm
Work depth		180 mm
Number of blades		16	24
Hand-arm vibration according to EN 786		2,10 m/s2	2,04 m/s2
Sound levels at the work-place LPA (according to 2000/14/EC)		72,3 dB (A)	72,7 dB (A)
Sound levels LWA (according to 2000/14/EC) measured sound power level		92,3 dB (A)	92,7 dB (A)
guaranteed sound power level		93 dB (A)	93 d B(A)
Dimensions (length x bright x height) approx.		1275 x 480 x 205 mm	1335 x 480 x 205 mm
Weight approx.		8,5 kg	10,5 kg
Protection class		II (protective insulated)
Degree of protection		IPX4

Guarantee

Please observe the enclosed terms of guarantee.

Sommaire

2004/108/CE, 2000/14/CE.

Proceded evaluation of the conformity: 2000/14 CE - Annexe V

BkJIIOUBaHe / N3KJIIOUBaHe

He n3non3baIte ypeI, npi KoiTo npeBknIOUbaTeIaT He MoKeJa 6bJe BkIOUbaH u 3KIOUbaH. NOBpeHn PpeKbcBaunCneBa Da 6bDat nonpaBeHOn CTepBn3HaTa CnyX6a Hnn Da6bDaT 3aMeHEn C HOBn.

YpeIbT mHa 3aunTeH npeKbcBaU, KOITo npedOTBpaTBA HeKeIaTeHOTO BKNIOUcBaHe.

I Iynche Te ypea, eDba cnei kato cTe ro noctabnBbpxy paBHa nOBbpxHOCT 6e3 npenrTCTBn.

BkIIOUBaHe

E IeKO HAKJOHeTe YpeDa KbM c6e cn.
F Hatnchete 3aunTHOTO KONue (3) n ro 3aDpBXTe HATnCHato. CneI TOBa IpbHHeTe DpbXkata-npeKbCBaY (2) KbM dpBxKata (1). YpeDbT TpBrBa N BaJRAkT Ha HOxa MOKe Da Ce BbPTN CBO6oNDHO.

2004/108/EG, 2000/14/EG.

2004/108/EK, 2000/14/EK.

2004/108/CE, 2000/14/CE.

A. Pollmeier, management

2004/108/WE i 2000/14/WE.

conform directive: 2006/42/UE

Prin prezenta, noi

ATIKA GmbH & Co. KG

Schinkelstraße 97

59227 Ahlen - Germany

declarçampepropireraspundereca produsul

Bodenhacke (prasitoare) tip BH 700 s i BH 800

2004/108/UE, 2000/14/UE.

Conformity assessment procedure 2000/14/UE – Appendix V

2004/108/ES, 2000/14/ES.

Uporabljeni so bili naslednjih harmonizirani standardi:

EN 60335-1:2002+A1+A11+A12+A2+A13;

EN 60335-1:2002/FprAF:2009; EN 62233:2008;

EN 55014-1:2006; EN 55014-2:1997+A1; EN 61000-3-2:2006;

EN 61000-3-3:1995+A1+A2; EN 709:1997+A2:2009

Postopek za ugotavljanje skladnosti: 2000/14/ES - Dodatek V.

	BH 700	BH 800
Izmerjen nivo zvočne jakosti LWA	92,3 dB (A)	92,7 dB (A)
Garantirani nivo zvočne jakosti LWA	93 dB (A)	93 dB (A)

Shranjevanje tehniche dokumentaciye:
