USER MANUAL Thermosense 340 Clear CECOTEC

THERMOSENSE 340 CLEAR

Hervidor de agua / Electric kettle

Safety instructions 7

1. Parts and components 43

2. Before use 43

3. Operation 43

4. Cleaning and maintenance 45

5. Troubleshooting 46

6. Technical specifications 46

7. Disposal of old electrical and electronic appliances 46

8. Technical support and warranty 47

9. Copyright 47

SOMMAIRE

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users.

• This appliance can be used by children aged 8 years old and above if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Cleaning and user maintenance should not be carried out by children unless they are over 8 years old and are under supervision. Keep this appliance and its power cord out of reach of children under the age of 8.
• This appliance can be used by people with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or appropriate instruction concerning the use of the appliance in a safe way and understand the hazards involved.
• The appliance must not be used by children. Keep the appliance and its power cable out of the reach of children.
• This symbol means “Caution: hot surface”. The accessible surfaces of the appliance may reach high temperatures during operation. Be careful not to burn yourself.
• WARNING: do not remove the cover while water is boiling.

• CAUTION: place the cover in such a way as not to direct steam at the handle.

• The kettle must exclusively be used with the supplied base.

• CAUTION: make sure the appliance is switched off before removing it from the base.
• This appliance is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.
• If the kettle is overfilled, boiling water may be spilled.
• Avoid touching the hot surfaces when in operation, and let it cool down for a few minutes after use. Grab it by the handle. The kettle surfaces are likely to be hot during use.
• To prevent possible injury caused by steam, do not face the spout when operating the kettle.
• Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the wall outlet is earthed.
• Do not immerse the cable, plug, or any other non-removable part of the appliance in water or any other liquid. Do not expose the electrical connections to water. Make sure your hands are dry before handling the plug or switching on the device.
• Never immerse the appliance in water. Do not touch the water!
• Check the power cable regularly for visible damage. If the cable is damaged, it must be repaired by the official Cecotec Technical Support Service to avoid any type of danger.
• Do not carry or pull the appliance from the power cable. Do not use the power cable as handle. Do not push the cable against corners or sharp edges. Do not crush the power cable with the full weight of the appliance. Keep the cable away from hot surfaces.

• Do not operate the appliance if its cable, plug, or body show visible damage, do not operate properly, or have been dropped.

• Do not use the appliance in confined spaces with explosive or flammable vapours.

• Do not leave the appliance unattended while in use.
• Unplug it from the power supply when you finish using it and before leaving the room.
• Avoid spillage on the conductor cable.
• The surface of the heating element is subject to residual heat after use.
• In case of misuse, personal injury and/or material damage may occur.
• Do not try to repair the appliance by yourself. Contact the official Cecotec Technical Support Service.
• Always turn off and unplug the appliance when not in use, before moving it to a new location, and before assembling or disassembling it. To avoid tripping hazards, wind the cable safely.
• To ensure the correct operation of the appliance, cleaning and maintenance tasks must be carried out according to this instruction manual. Always turn off and unplug the appliance before cleaning.
• Boiling water may overflow from the kettle.
• Use the appliance only for its intended purpose.
• Fill up the kettle with cold water only.
• The water level must be between the MAX. and MIN. marks.
• Always ensure that the cover is tightly closed.
• The kettle body must fit correctly with the kettle base.
• Remove and refit the cover carefully when hot.
• Take extreme precaution when moving the kettle containing hot water. Never lift the kettle by its cover. Always use the handle.
• Never switch on your kettle when empty.
• Do not use the base unit for other purposes.

- To avoid scalding, do not open the cover during the boiling process or immediately after.

INSTRUCTIONS DE SÉCURITÉ

1. Cover
2. Handle
3. Lever
4. Base
5. Base decorative ring
6. Bottom cover
7. Decorative ring
8. Light
9. Glass container

NOTE:

The graphics in this manual are schematic representations and may not exactly match the device.

2. BEFORE USE

• This appliance is packaged in a way as to protect it during transport. Take the appliance out of its box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place to prevent damage to the device if you need to transport it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.

Box content

• Kettle and base
• Instruction manual

3. OPERATION

Basic instructions for using the kettle

• The refilled water level must be between the "MIN" and "MAX" marks.
• Switch the kettle off before removing it from the base.
• Close the cover and make sure it is securely closed.
• The base and exterior of the kettle must not get wet.

ENGLISH

• The body of the appliance must fit the base.
• Do not open the cover when pouring.
• Be careful when opening the cover to avoid splashing the condensed water that is already on the cover.

Before using the kettle for the first time

Before using the kettle for the first time, it is recommended that you clean it.

1. To do this, fill it as full as possible with water and bring it to the boil.
2. When the water is boiling, discard it.
3. Repeat this process 2 or 3 times if necessary.

Use

1. To fill the kettle, remove it from the base and open the cover, fill the kettle with the desired amount of water.

NOTE:

Always fill the kettle between the minimum (0.5 l) and maximum (1.7 l) marks. If the water level does not exceed the "MIN" mark, the kettle will switch off before the water boils.

Do not fill the kettle above the "MAX" mark, as water may spill out of the spout while boiling.

Make sure the cover is well placed before plugging the appliance into the mains.

1. Put the cover on.
2. Place the kettle on the base making sure that the kettle makes contact with the base.
3. Connect the power cable to a plug socket.
4. Move the lever to the "I" position, the indicator light on the lever will switch on. The water will then start to boil. The kettle and the indicator light will automatically switch off when the water has boiled. You can switch off the kettle any time by pressing the lever.

NOTE: make sure that the lever is free of obstructions and that the cover is properly closed. The kettle will not switch off if the lever is blocked or if the cover remains open.

1. Lift the kettle from the base and pour out the water.

NOTE: be careful when pouring water, as you may burn yourself. Do not open the kettle cover while the water is hot.

1. The kettle will not boil again until the lever is lifted. Allow to cool for 15\~20 seconds before reopening to boil the water. You can leave the kettle on the base when not in use.

NOTE: make sure the kettle is unplugged when not in use.

Dry boiling protection

If you accidentally let the kettle operate without water, the dry boiling protection will automatically switch off the appliance.

If this happens, allow the kettle to cool down before filling it with cold water for reuse.

4. CLEANING AND MAINTENANCE

1. Unplug the appliance and allow it to cool down before cleaning.
2. To avoid risk of electric shock, do not clean the base with water or immerse it in it.
3. A slightly damp, clean cloth can be used for cleaning.
4. Do not use abrasive detergents or corrosive cleaning products.

Descaling

• Depending on the quality of the water in your area, limescale deposits may form inside the appliance, so it is advisable to remove them regularly.
• Any warranty claims will be void if the appliance malfunctions due to insufficient descaling.

To perform a correct descaling, follow the steps below:

1. A mixture of 0.5 litres of water and 40 ml of vinegar is suitable for descaling.
2. Pour in the descaling solution.
3. Switch on the appliance until the solution reaches boiling temperature.
4. Leave it on for a short period of time.
5. To clean the main body after descaling, rinse it thoroughly with clean water.

NOTE

• During descaling, make sure that there is sufficient ventilation and do not inhale vinegar fumes.
• Do not pour descaling products into enamelled sinks.

Cleaning the kettle housing

Use a soft, damp brush to clean the housing of the appliance.

WARNING: do not use chemicals, steel wool or abrasive detergents to clean the kettle body, as these may damage its glossy finish.

Cleaning the filter

If necessary, clean the filter with a soft, damp brush.

Storage

When the kettle is not in use, store the power cable in the compartment under the base.

5. TROUBLESHOOTING

Problem	Solutions
The kettle does not switch on	Check that it is correctly connected to the mains.Make sure that the plug works.Make sure the lever was pressed down.
The kettle does not boil water	Make sure that the water is between the minimum and maximum level.Check that it is correctly connected to the mains.Check that the water is not already hot.
The kettle does not switch off automatically	Check that the cover is correctly fitted.

6. TECHNICAL SPECIFICATIONS

Product reference: 00170

Product: ThermoSense 340 Clear

Power: 1850-2200 W

Voltage: 220-240 V

Frequency: 50/60 Hz

Maximum capacity: 1.7 L

Technical specifications may change without prior notification to improve product quality.

Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

8. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions, and deadlines established by the applicable regulations.

It is recommended that repairs be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.
