Product Type	Iron
Brand	Cecotec
Model	Ironhero H 3000 X Treme
Power	2400 W
Water Tank Capacity	300 ml
Soleplate Type	Ceramic Soleplate
Steam Function	Yes, vertical steam
Anti-Drip Function	Yes
Self-Cleaning Function	Yes
Auto Shut-Off Function	Yes
Variable Temperature	Yes
Cable Length	1.8 m
Weight	1.2 kg
Dimensions (LxWxH)	28 x 12 x 16 cm
Color	White and Purple
Maintenance	Clean with a damp cloth, descale regularly
Spare Parts	Water tank, soleplate
Repairability Index	7.2/10
Warranty	2 years

Frequently Asked Questions - Ironhero H 3000 X Treme CECOTEC

How to descale my Cecotec Ironhero H 3000 X Treme iron?

Use the self-cleaning function: fill the tank, set max temperature, then press the self-cleaning button. Repeat if necessary.

Can I use tap water?

Yes, but to prevent limescale, we recommend a mixture of 50% tap water and 50% demineralized water.

How to activate vertical steam?

Fill the tank, select a high temperature, then hold the iron vertically and press the steam trigger.

What to do if the iron stops heating?

Check that the power indicator is on. If the auto shut-off has been triggered, shake the iron to reactivate it. Make sure the temperature dial is set to a hot position.

How to clean the ceramic soleplate?

Let the iron cool down, then gently rub with a damp, non-abrasive cloth. Avoid chemical products.

What is the water tank capacity?

The tank has a capacity of 300 ml, enough for several minutes of continuous ironing.

Can the iron be used for dry ironing?

Yes, set the temperature according to the fabric without pressing the steam trigger. The anti-drip function prevents water leaks.

How to store the iron after use?

Empty the tank, let it cool down, then wrap the cable around the heel and store it in a dry place.

What to do if the iron drips during ironing?

Check that the anti-drip function is activated (it normally is). If the problem persists, reduce steam or wait for the soleplate to get hotter.

What is the warranty period?

This iron is covered by a 2-year warranty against manufacturing defects. Keep the receipt for any claims.

USER MANUAL Ironhero H 3000 X Treme CECOTEC

IronHero H-3000 X-Treme

Plancha horizontal / Horizontal plates

SAFETY INSTRUCTIONS....5

ESPAÑOL....50

ENGLISH....56

FRANÇAIS....62

DEUTSCH....68

ITALIANO....75

PORTUGUÊS....81

NEDERLANDS....87

POLSKI....93

ČEŠTINA....99

MAGYAR....105

ΕΛΛΗΝΙΚΑ 111

TÜRKÇE....117

العربية....123

CATALÀ....128

FIGURES....134

NOTA

EU01_122549 IronHero H-3000 X-Treme

EN • The coding in this manual is generic and applies to all code variants of the appliance.

Please read these instructions carefully before using the appliance. Keep this instruction manual for future reference or new users.

• This appliance is intended for domestic use only and is not suitable for use in commercial establishments such as bars, restaurants, farms, hotels, motels, and offices.
• This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children must not play with the appliance. Cleaning and maintenance should not be carried out by children without supervision.
• Keep the iron and its cord out of reach of children

under 8 years of age when the appliance is plugged into a mains socket or when it is cooling down.

• Do not leave the appliance unattended while it is hot, plugged into an outlet, or on the ironing board.
• Unplug the appliance from the mains before filling or emptying the water tank.
• Do not use the iron for anything other than its original purpose.
• The filling opening must not be open during use.
• Place and use the appliance on a flat, stable, dry, and heat-resistant surface. Make sure the surface is stable.
• Children must be supervised to make sure they do not play with the appliance.
• Do not operate the appliance if it has been dropped, shows visible damage, or is leaking.

- This symbol means: "Caution, hot surface". The accessible surfaces of the appliance may reach high temperatures during operation. Be careful not to burn yourself. Do not touch hot surfaces during operation or immediately after.

- Do not allow appliances to be plugged in unnecessarily. Unplug when not in use.

- Do not touch the appliance with wet or damp hands.

- Check the power cable regularly for visible damage. If the power cord is damaged, it must be replaced by the Cecotec's official Technical Support Service or similarly qualified personnel to avoid hazards.

- Ensure that the mains voltage matches the voltage stated on the product's rating label and that the socket is properly earthed.

- Do not twist, bend, pull, or damage the power cord. Protect it from sharp edges and heat sources. Never let the power cord come into contact with hot surfaces. Do not let the cord hang over the edge of the working surface or worktop.

- Do not immerse the cord, plug, or any other non-removable part of the appliance in water or any other liquid or expose electrical connections to water. Make sure your hands are completely dry before handling the plug or switching on the appliance.

- Avoid contact with the hot parts of the iron, water or steam generated by the appliance. Steam temperature is very high and can cause burns and other damage. Hot water may flow if the iron is placed upside down.

- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

- To avoid personal injury and damage to the appliance, only add water to the water tank. Never add cleaning solutions, perfumes, oils or other chemical additives.

- Switch off and unplug the appliance when not in use and before cleaning it. To unplug the appliance, pull the plug, not the cord.

- Keeping the iron at maximum temperature for too long may cause discolouration, which will not affect the performance of the appliance.

• Do not try to repair the appliance by yourself. Contact Cecotec's Official Technical Support Service for any query or repair.
• Ensure that the appliance is switched off, unplugged, and completely cool before filling or cleaning it.
• Cecotec takes no responsibility for any damage caused by misuse of the machine. Any misuse or non-compliance with these instructions voids the warranty and Cecotec's liability.

https://cecotec.es/es/information/declaration-of-conformity

ENGLISH

1. Parts and components

Fig. 1

1. Non-stick soleplate
2. Water spray nozzle
3. Water tank lid
4. Steam selection knob
5. Steam shot button
6. Swivel cable
7. Water spray button
8. Temperature control knob
9. Handle adjustment ring
10. Water tank

Note:

The graphics in this manual are schematic representations and may not exactly match the product.

2. Before use

• This appliance comes in a packaging designed to protect it during transport. Remove the appliance from its box. You can keep the original box and other packaging materials in a safe place to prevent damage to the appliance if you need to transport it in the future. If you wish to dispose of the original packaging, make sure all items are recycled properly.
• Check that all parts and components are included and in good condition. If any of them are missing or damaged, please contact Cecotec's Official Technical Support Service immediately.

Box content:

• Steam iron
• Instruction manual

- Do not remove the product's serial number in order to keep proper traceability if technical assistance is required.

3. Operation

Before first use

When using the iron for the first time, test it on an old piece of fabric to ensure that the soleplate and water tank are completely clean.

It is normal for it to emit a slight odour or smoke during the first use. This is normal and is due to the initial heating of the materials. It will disappear quickly.

When not ironing, ensure that the steam selection knob is in the closed position.

Anti-scale function

The tank incorporates a special resin filter that softens water and prevents limescale build-up on the soleplate. This filter is permanent and requires no replacement. It is recommended to use tap water only. The use of distilled or demineralised water may alter the anti-scale system properties, rendering it ineffective.

Avoid adding chemicals, aromatic essences, or descaling agents. Cecotec accepts no responsibility for non-compliance with these instructions.

Anti-drip function

The anti-drip system allows precise ironing of delicate fabrics.

It prevents water dripping from the soleplate during ironing, avoiding stains when the temperature is too low to generate steam.

Warning: Always check the garment care label before ironing. In the absence of a label, verify the fabric type to ensure proper ironing.

Care label	Type of fabric	Temperature setting
	Synthetic-Nylon	· Low
	Silk-Wool	·· Medium
	Cotton-Linen	··· High
	Do not iron

To save time during heating, it is recommended to iron fabrics requiring lower temperature settings first. This also reduces the risk of burning the fabric.

Using the steam iron

1. Place the steam iron in an upright position and insert the plug into the power socket.
2. Select the desired temperature on the temperature control knob.
3. The indicator light will turn on and, once the selected temperature is reached, it will turn off and you can start ironing.
4. The indicator light will illuminate while the iron is heating up. Once the temperature is reached, it will turn off. It will turn on and off occasionally while ironing, as the thermostat automatically keeps the soleplate at the same temperature.
5. Another important feature of your steam iron is the 180° swivel cord, which prevents tangles and allows for easy use by both right- and left-handed users.

ENGLISH

1. The iron features an automatic shut-off function. If the user does not perform any operation within 30 seconds, the iron will automatically turn off and the LED light will flash once per second when it is off. When the iron shuts off automatically, if the user wishes to continue ironing, the user must shake the iron to reactivate it and continue ironing.

Choosing the right water

This steam iron can be used with normal tap water. However, if the water in your region is particularly hard, it is recommended to use distilled water to prolong the life of the iron. Do not use water that has been desalinated by chemical exchange.

Dry ironing

1. Insert the plug into the mains socket.
2. Ensure that the steam selection knob is in the closed position, dry ironing mode.

Fig. 2

1. Cleaning
2. Dry ironing
3. Energy-saving steam
4. Intense steam

5. Steam shot

6. Select the desired temperature on the temperature control knob.

7. Press the water spray button to spray a fine mist onto the clothes and moisten them.
8. After the indicator light goes out, you can start ironing.

Steam ironing

Steam ironing is effective at high temperatures, as indicated on the temperature control knob.

1. Ensure there is enough water in the tank.
2. Place the iron in an upright position.
3. Plug the power cord into the power supply.
4. Turn the temperature control knob to the desired position within the appropriate range for steam.
5. Wait until the indicator light to turns off.
6. Set the steam selection knob to the desired level. Now you can start steam ironing. Steam will be evenly distributed through the soleplate holes.
7. There are three steam levels: small, intense and reinforced. Adjust according to your needs by turning the knob to the desired level.
8. Press the steam shot button to release a strong jet.

Temperature settings

1. Place the iron in an upright position.
2. Plug the hair straightener into a power socket.
3. Set the temperature control knob to the correct ironing temperature as indicated

ENGLISH

on the label or in the temperature setting chart.

Tips for good ironing

• For fabrics with special treatments (such as decorative pieces, embroidery, etc.), use low temperature ironing.
• For blended fabrics (such as 40% cotton + 60% synthetics), adjust the temperature as needed and iron at low temperature.
• If you do not know the fabric composition, test on a hidden part of the garment to determine the appropriate ironing temperature.
• Start with a low temperature and gradually increase until the desired temperature is reached.
• Do not iron surfaces with sweat or other stains, as the heat from the soleplate will set the stains, and they cannot be removed. Dry ironing at medium temperature will maintain the size of the garment, while overheating can burn the garment and cause yellow stains.
• To prevent silk, wool or synthetic fabrics from becoming shiny when ironed, iron them inside out.
• To prevent the velvet from becoming shiny, iron it inside out and in the same direction (along the grain).
• The more clothes you put in the washer at one time, the more they will wrinkle. The more the drum rotates, the more likely it is to wrinkle.
• Many fabrics are easier to iron before they are completely dry. Silk, for example, should be ironed damp.

4. Cleaning and maintenance

Before cleaning the iron, always ensure that it is unplugged from the power socket and completely cool.

Soleplate

• Residues on the soleplate can be cleaned with a cloth soaked in a vinegar and water solution.
• Do not use scouring pads, abrasives or chemical cleaning solvents as they may damage the finish.
• Once the tank is full of water, turn the knob to the wash position to begin cleaning the soleplate and removing limescale. When the water in the tank runs out, the dial button returns to dry ironing mode, plug in and turn on the power, evaporate residual water stains on the bottom plate, turn off the power and wipe off the water.

Housing

• The housing can be cleaned with a damp cloth and then dried.
• Other than the recommended cleaning, no further maintenance by the user should be necessary. If for any reason your steam iron needs repairs, do not attempt to repair it yourself. Send it to Cecotec's Official Technical Support

Service.

Storage

• Disconnect the plug from the mains socket.
• Turn the iron upside down and shake gently to drain water.
• Allow the iron to cool completely.
  ● Wind the power cord loosely around the iron.

• Store the iron in an upright position.

• Troubleshooting

Problem	Possible cause	Possible solution
The appliance does not heat up	Not connected correctly	Check the connection and plug
No steam is released	Empty water tank	Filling the water tank
Stains on clothing	Residues on the soleplate	Clean the soleplate with water and vinegar
Weak steam output	Steam knob in low position	Adjust to a higher steam level
Water dripping	The set temperature is too low	Raise the temperature before using steam

6. Technical specifications

Product: IronHero H-3000 X-Treme

Product reference: EU01_122549

Voltage: 220-240 V\~

Frequency: 50-60 Hz

Rated power: 3050 W

Technical specifications may change without prior notice to improve product quality.

Made in China | Designed in Spain

7. Recycling of electrical and electronic equipment

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its service life, you must remove the batteries/accumulators and take it to a collection point designated by local authorities.

For detailed information on how to properly dispose of electrical and electronic equipment and/or the corresponding batteries, consumers should contact their local authorities.

Information regarding national packaging recycling systems and their marking can be found on our website.

Compliance with the above guidelines will help protect the environment.

8. Technical support and warranty

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of product delivery under the terms, conditions and deadlines established by applicable regulations.

Repairs should be carried out by qualified personnel.

If you detect any problem with the product or have any queries, please contact Cecotec's

Official Technical Support Service at [phone].

9. Copyright

The intellectual property rights over the texts in this manual belong to CECOTEC

INNOVACIONES, S.L. All rights reserved. The content of this publication may not, either in part or in its entirety, be reproduced, stored in a retrieval system, transmitted or distributed by any means (electronic, mechanical, photocopying, recording or similar) without prior authorisation from CECOTEC INNOVACIONES, S.L.

10. Simplified EU Declaration of Conformity

Cecotec Innovaciones hereby declares that this appliance complies with the

essential requirements and other relevant provisions of the regulations applicable in the European Union. This appliance has been designed, manufactured and tested in compliance with required safety and quality standards. The full text of the EU Declaration of

Conformity can be found on the following website:

https://cecotec.es/es/information/declaration-of-conformity
