CU-VD50EX - DVD player JVC - Free user manual and instructions

Product Type	External DVD reader and writer
Brand	JVC
Model	CU-VD50EX
Dimensions (W x H x D)	152 x 42 x 195 mm
Weight	Approx. 920 g (without power adapter or cables)
Power Supply	AC adapter AP-V50U: input AC 110-240 V, 50/60 Hz; output DC 5.3 V, 3.5 A
Supported disc formats	Read and write: DVD-R, DVD-RW, DVD-R DL; Read only: CD-ROM, CD-R, CD-RW
Main functions	Copy videos from Everio camera (USB) to DVD; create AVCHD, data or DVD-video discs; connect to a PC for data burning; play AVCHD, DVD-video and data discs
Connectivity	USB 2.0 (mini-A to mini-B); HDMI output (HDCP); composite video output; component video output (Y/Cb/Cr); audio output (2 channels)
HDMI video output	1080p, 1080i, 720p, 576p, 576i; compatible with x.v.Color and Deep Color
Remote control	RM-V55U, CR2025 battery, range approx. 5 m
Supplied accessories	AC adapter, power cord, USB cable, audio/video cable, stand, remote control, 1 blank DVD-R, 1 software CD-ROM (CyberLink Power2Go 5.5 Lite)
Maintenance and cleaning	Clean the exterior with a dry cloth; clean discs with a soft wipe; for the lens, use a compressed air duster; do not use liquid cleaners
Safety	Class 1 laser product; do not open; unplug in case of smoke or odor; use only the supplied adapter
Spare parts and repairability	Contact an authorized JVC dealer for any repairs; CR2025 battery replaceable (Panasonic, Sanyo, Sony or Maxell)
General information	Operating temperature: 0 °C to 35 °C; humidity not specified; PC compatibility: Windows XP/Vista (32-bit); not Mac compatible

Frequently Asked Questions - CU-VD50EX JVC

What types of discs can I use with the JVC CU-VD50EX?

Use DVD-R, DVD-RW or DVD-R DL discs from recommended brands (JVC, TDK, Verbatim, SONY). Do not use DVD+R, DVD+RW or DVD-RAM. DVD-R DL discs are only compatible with an Everio high-definition camcorder.

How do I connect the burner to a TV?

Connect via HDMI, component video or composite video. Use a Category 2 HDMI cable for best quality. Make sure the TV is on and set to the appropriate input.

Can I copy videos from my Everio camera to a DVD without a computer?

Yes, connect the Everio camera to the burner using the supplied USB cable. Turn on the camera in the appropriate mode, insert a blank disc, then follow the on-screen instructions on the camera to create an AVCHD, data or DVD-video disc.

What should I do if the remote control does not work?

First, check that the disc tray is closed. If the problem persists, remove the CR2025 battery and reinsert it. Replace the battery if it is weak. Make sure to point the remote at the burner's sensor within 5 meters.

How do I clean the burner and discs?

For the exterior, use a soft dry cloth. For discs, gently wipe from the center outward with a cleaning wipe. Do not touch the laser lens; use a compressed air duster if necessary.

The power indicator is blinking red slowly, what should I do?

This indicates a drop in internal temperature. Wait until the indicator stops blinking before using the burner. If the problem persists, turn off the unit and let it cool down for a few moments.

Why doesn't my computer recognize the burner?

Make sure the USB cable is properly connected and the burner is on. If you are using a USB hub, plug it directly into a USB 2.0 port on the computer. Check that the Power2Go software is installed.

Can I play commercial DVD videos on this player?

Yes, the burner can play commercial DVD videos, but playback is not guaranteed. The region code must be '2' (Europe) or 'ALL' to work.

How do I force eject a stuck disc?

Turn off the burner. Insert a thin rod (like an unfolded paper clip) into the forced ejection hole located next to the eject button. The tray will then open manually.

The burner does not create an AVCHD disc correctly, why?

Make sure you are using a compatible disc (DVD-R or DVD-R DL) and that the Everio camera is in the appropriate mode. Finalize the disc after copying. If the problem persists, check that the USB cable is properly connected and that the camera is supported.

USER MANUAL CU-VD50EX JVC

La lecture commence!

PRODUIT LASER DE CLASSE 1

REPRODUCTION DES ÉTIQUETTES

ÉTIQUETTE D'AVERTISSEMENT A L'INTEREUR DE L'APPAREL

CAUTION CLASS 38 VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, AVOID EXPOSURE TO THE BEAM.

ATTENTION RADIATIONS LASER VISIBLEES ET INVISIBLES DE CLASSES 38 OUANO UVERTÉ VITEZ TOUT EXPERTON DU FAISCEAU.

ADVARSEK LASSE 328 SYNGL OG USYNGL LASERSTRAADING VED ABNING, UNOGU UDSSETTLEMENTE FOR STRAADING.

AVATTAESSA OLET ALTIINA NAKYVALLE JA

VARDI: NAKYMATTGMALELUOKAN 3B LASERSATEXYL ALA KATSOS SATESEEN.

WARNING Klass 3BSYNCHOCSYNGLERSTRALSTERNING NAR DENNA DEL APROPAD.NOVIK ATT UTSATTA DFIG FOR STRALEN.

BE GEFORDEN FABEOCKING IS SICHBARTE UND UNSICHTBART ELLIANTEN. 1985. RESEARCH AND BUSINESS. 2nd ed. VARIENHAN, NOTCH EM LASERSTRAH, AUSSEZTEN!

PRECAUCTION CUANDO SE ABRE HAY RADIATION LASER DE CLASSES 38 VISIBLE INVISIBLE, EVITE LA EXPOSION A LOS RAVOS LASEN.

Adaptatour CA (AP-V50U)

CLASS 33 VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, A/OID EXPOSURE TO THE BEAM.

ATTENTION

RADIATIONS LASER VISIBLES ET INVISIBLES DE CLASSES 38
QUIO UOVERT. EVITEZ TOUT EXPERTUON AU FAISCEAU

ADMARSEL KLASSE 38 SYNILG OG USYNLG LASERSTRAUING VED ABNING. UNGA UDS/SETTLEF FOR STRALING.

VAATEAESTA QET ALTTTA NAKVJALI VA
VARO! NAKTAYA KANAN 38 LASERSTABLEA LA KATO SDATSEESEN.

VARNING KCLASS 3B SYNLIG OCH OSYNLIG LASERSTRALNING NAR DENNA

DEL AR OPPNAD. UNDVIK ATT UTSATTA DIG FOR STRALEN.

BE GEOFFNETER ABDECKUNG IST SICHTBARE UND UNSICHTBARE
