| Brand | PANASONIC |
| Model | SC-UX100E |
| Product type | Stereo system with CD player and Bluetooth speaker |
| RMS output power | 150 W per channel (4 Ω, 1 kHz, 30% THD), 300 W total |
| Power supply | AC 220-240 V, 50 Hz |
| Power consumption | 49 W (operation), 0.5 W (standby) |
| Bluetooth version | 2.1 + EDR, Class 2 |
| Bluetooth range | 10 m (line of sight) |
| Supported Bluetooth profiles | A2DP, AVRCP, SPP |
| Supported audio formats | CD-DA, MP3 (CD, CD-R/RW, USB) |
| FM radio | 87.50 MHz to 108.00 MHz, 30 presets |
| DAB+ radio | Band III (5A to 13F), 20 presets (SC-UX102 model only) |
| Auxiliary input (AUX) | Pin jack (adjustable input level: Normal or High) |
| USB port | USB 2.0 full speed, up to 32 GB, FAT12/16/32 |
| Supplied accessories | Remote control, battery, power cord, indoor FM antenna |
| Maintenance | Soft dry cloth; do not use alcohol, thinner or benzene |
| Safety | Auto standby after inactivity (20 min), thermal protection, Bluetooth standby |
| Repairability | Do not disassemble yourself; consult a qualified technician |
| Remote control code | Switchable between REMOTE 1 and REMOTE 2 |
| Laser class | CLASS 1 LASER PRODUCT |
Frequently Asked Questions - SC-UX100E PANASONIC
How do I pair a Bluetooth device with the system?
Make sure the system is in Bluetooth mode. Press [3] to select Bluetooth input. If "PAIRING" is not displayed, press [PLAY MENU] and select "PAIRING". On your Bluetooth device, search for "SC-UX100" in the list and connect. If a code is requested, enter "0000".
Why is the sound distorted or absent?
First check the volume of the system and the source device. If the sound is distorted, reduce the volume or turn off the device, then turn it back on after letting it cool down. Ensure that the speakers are properly connected and the polarity is not reversed. If using the AUX input, set the input level to "NORMAL" via the menu [PLAY MENU] > "INPUT LEVEL".
How do I set the clock?
Press [SETUP] and select "CLOCK". Use the [ , ] keys to set the time, then press [OK] to confirm. The clock runs on a 24-hour cycle. You can also enable automatic setting via DAB+ (SC-UX102) in the menu [PLAY MENU] > "AUTO CLOCK ADJ".
The remote control does not work, what should I do?
First check the battery: install it correctly respecting polarity (+/-). Replace it if necessary. Make sure no obstacles block the sensor and that you are within 7 m with an angle of 20° vertical and 30° horizontal. If the display shows "REMOTE 1" or "REMOTE 2", the remote code may need to be changed. Follow the procedure in the manual.
What does the message "F61" on the screen mean?
The "F61" code indicates a speaker connection problem. Check that the speaker cables are correctly connected to the corresponding color terminals and that they are not short-circuited. If the problem persists, disconnect any USB device and restart the system.
How do I use the play timer?
First set the clock. Press [SETUP] and select "TIMER ADJ". Set the start and end time, then choose the source (CD, USB or radio). Then activate the timer in [SETUP] > "TIMER SET" > "PLAY ON". The device must be on standby for the timer to work. A "⊙" symbol will be displayed.
Can I connect a USB device?
Yes, plug in a USB device (up to 32 GB formatted in FAT12/16/32) into the front USB port. Press [USB/CD] to select "USB". The system plays MP3 files. Note: do not use a USB extension cable, as it may not be recognized.
How do I safely clean the device?
Use a soft dry cloth to wipe the device. Never use alcohol, paint thinner or benzene. If using a chemically impregnated cloth, read the accompanying instructions carefully. Avoid touching the speaker cones.
How do I reset the system to factory settings?
Unplug the power cord. Keep pressing the [/] key on the main unit while reconnecting the cord. Continue pressing until dashes appear on the display, then release. All settings will return to default values.
How do I change the remote control code to avoid interference with other Panasonic devices?
If other Panasonic devices respond to your remote, change the code. To switch to REMOTE 2, hold down [USB/CD] on the main unit and [USB/CD] on the remote until "REMOTE 2" appears, then hold [OK] and [USB/CD] on the remote for 4 seconds. For REMOTE 1, use [3] instead of [USB/CD].
User questions about SC-UX100E PANASONIC
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Bluetooth speaker in PDF format for free! Find your manual SC-UX100E - PANASONIC and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. SC-UX100E by PANASONIC.
USER MANUAL SC-UX100E PANASONIC
Section tuner, bornes
Dimensions (L x H x P)
181 mm x 308 mm x 165 mm
Poids
2 kg
Données générales
Alimentation
Dimensions (L x H x P)
250mm× 132mm× 227mm
Poids (SA-UX102)
1,7 kg
Poids (SA-UX100)
1,7 kg
Kadoma, Osaka, Japan
Importer for Europe:
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
