Product Type	Portable radio with DAB+/FM and Bluetooth
Brand	Panasonic
Model	RF-D20BTEG
Weight (without batteries)	0.6 kg
Weight of AC adapter	0.1 kg
Power supply	AC adapter 220-240 V, 50/60 Hz, output 5 V 1.5 A; batteries: 3 x R6/LR6 (4.5 V)
Power consumption	2 W (operation), 0.8 W (standby)
Radio receiver	FM (87.5-108 MHz), DAB/DAB+ (Band III)
Station memory	5 FM presets + 5 DAB
Bluetooth	Version 2.1+EDR, Class 2, A2DP/AVRCP profiles, range 10 m
Speaker	5 cm full-range speaker (1 way)
Output power	3 W per channel (4 Ω, 1 kHz, 10% THD)
Protection rating	IPX3 (splash-proof)
Functions	Alarm, sleep timer, equalizer (Heavy, Soft, Clear, Vocal, Flat), display dimmer
Display	LCD screen with adjustable backlight
Battery life (approximate)	FM/DAB: approx. 2 h (manganese) / 8 h (alkaline); Bluetooth: approx. 2.5 h / 12 h
Temperature range	0 °C to +40 °C
Humidity range	20% to 80% RH (no condensation)
Maintenance	Wipe with a soft, dry cloth. Do not use alcohol, thinner, or benzene.
Safety	Double insulation (Class II), splash protection
Supplied accessories	AC adapter, power cord
Repairability	Do not disassemble. Contact a qualified technician.

Frequently Asked Questions - RF-D20BTEG PANASONIC

How to turn on the Panasonic RF-D20BTEG radio?

Press the [I/O] switch on the top of the device to power on. The first startup automatically starts a DAB scan.

How to set the alarm?

Press [MENU], select "Alarms" with [V TUNE/SELECT ∧] then [ENTER]. Choose "Alarm on", set the time, source (Buzzer, DAB or FM) and volume. The alarm only works on mains power.

How to connect a device via Bluetooth?

Make sure the Bluetooth source is selected (press [SOURCE]). Press and hold the [8] button until "Pairing" appears. On your device, search for "RF-D20BT" in the Bluetooth list. If a code is required, enter 0000 or 1234.

How to preset an FM station?

Listen to the desired station, then press and hold one of the direct preset keys [1] to [5]. Press [ENTER] to confirm.

The radio does not receive any DAB station, what to do?

Fully extend the antenna. Perform a full scan: press [MENU], select "Full scan" and confirm with [ENTER]. Check that you are in a DAB coverage area.

How to reset the device to factory settings?

Press [MENU], navigate to "Reset" with [V TUNE/SELECT ∧], press [ENTER], then select "Yes" and confirm.

Is the device waterproof?

Yes, it has an IPX3 protection rating: resists water splashes from rain up to a 60° angle. Make sure to close the cover of the DC IN terminal and battery compartment properly.

What is the battery life?

With LR6 alkaline batteries: approx. 8 hours in FM/DAB and 12 hours in Bluetooth. With R6 manganese batteries: approx. 2 hours in FM/DAB and 2.5 hours in Bluetooth.

How to change the display language?

Press [MENU], select "Language" with [V TUNE/SELECT ∧], then [ENTER]. Choose from French, English, German, or Italian.

The sound is distorted or absent, what to check?

Check the volume. Adjust the antenna. Move the device away from interference sources (phones, computers, fluorescent lamps). Perform a new full station scan.

USER MANUAL RF-D20BTEG PANASONIC

(Da 174,928 MHz a 239,200 MHz)

Dimensioni (L x A x P)

90 mm x 140 mm x 100 mm

Peso

Con batterie 0,7 kg

Dimensions (L x H x P)

90 mm x 140 mm x 100 mm

Poids

Avec piles 0,7 kg

Sans piles 0,6 kg

87.55MHz Scanning...

3 W per kanaal (4 Ω), 1 kHz, THD 10%

Tuner

Voorkeurgeheugen 5 FM-zenders

Frequenti modulatie (FM)

Frequentiebereik

87,50 MHz tot 108,00 MHz

(stap van 50 kHz)

DAB

Testing Centre, Winsberging 15,

Manuel indstilling at stationer

87.55MHz Scanning...

"Pairing" (Parring) vises.

For at annullere, vaelg "No" (Nej).

For at navigere rundt i menuen

"No DAB station" (Ingen DAB-station)

87.55MHz Scanning...

"No DAB station" (Brak staci DAB)

(174,928 MHz do 239,200 MHz)

Czulośc *BER 4x10-4

Manuell stationsinstalling

87.55MHz Scanning...

"No DAB station" (Ingen DAB-station)

87.55MHz
Scanning9...

Apparatet stanser innstillingen nár den finner en stasjon. Trykk [AUTO TUNE] en gang til for à innstille dennestaste stajsjonen.

Manuell instilling

Fuktighetsomrade for drift

20% til 80% RH (ingen kondensering)

Sprutsikkerhet IPX3ller ekvivalent

Importer for Europe:

Panasonic Corporation

Kadoma, Osaka, Japan

Panasonic Marketing Europe GmbH

Panasonic Testing Centre

Winsberging 15, 22525 Hamburg,

Germany

EU
