Type d'appareil	Téléviseur LCD
Alimentation	Alimentation secteur
Connexions avant et arrière	Oui
Connexion SCART	Oui
Connexion S-Video	Oui
Connexion VGA	Oui
Connexion HDMI	Oui
Télécommande	Incluse
Modes de télécommande	TV, TELETEXTE, DVD
Installation initiale	Guidée
Options vidéo	Personnalisables
Options audio	Personnalisables
Options de menu de configuration	Oui
Options de minuterie	Oui
Accessoires inclus	Non précisé
Précautions de sécurité	Incluses dans la notice

FOIRE AUX QUESTIONS - TV022 SWEEX

Comment connecter le SWEEX TV022 à ma télévision ?

Pour connecter le SWEEX TV022 à votre télévision, utilisez un câble HDMI. Branchez une extrémité dans le port HDMI du SWEEX TV022 et l'autre extrémité dans un port HDMI disponible de votre télévision. Ensuite, sélectionnez le bon canal HDMI sur votre télévision.

Le SWEEX TV022 ne s'allume pas, que faire ?

Vérifiez que l'appareil est correctement branché à une prise électrique fonctionnelle. Assurez-vous que le câble d'alimentation est bien connecté. Si l'appareil ne s'allume toujours pas, essayez de remplacer le câble d'alimentation.

Comment réinitialiser le SWEEX TV022 aux paramètres d'usine ?

Pour réinitialiser le SWEEX TV022, localisez le bouton de réinitialisation sur l'appareil. Appuyez et maintenez ce bouton pendant environ 10 secondes jusqu'à ce que l'appareil redémarre. Cela rétablira les paramètres d'usine.

Pourquoi je ne reçois pas de signal sur ma télévision ?

Assurez-vous que le SWEEX TV022 est allumé et correctement connecté à la télévision. Vérifiez que la source HDMI sélectionnée sur votre télévision correspond au port utilisé. Si le problème persiste, essayez d'utiliser un autre câble HDMI.

Comment mettre à jour le logiciel du SWEEX TV022 ?

Pour mettre à jour le logiciel, connectez le SWEEX TV022 à Internet. Allez dans le menu des paramètres, sélectionnez 'Mise à jour du logiciel' et suivez les instructions à l'écran pour installer la dernière version.

Le son ne fonctionne pas, que faire ?

Vérifiez que le volume de votre télévision est activé et ajusté correctement. Assurez-vous également que le SWEEX TV022 est configuré pour utiliser la sortie audio correcte. Si le problème persiste, essayez de redémarrer l'appareil.

Comment utiliser les fonctionnalités de streaming du SWEEX TV022 ?

Pour utiliser les fonctionnalités de streaming, assurez-vous que le SWEEX TV022 est connecté à Internet. Accédez à l'interface de l'appareil et sélectionnez l'application de streaming de votre choix. Connectez-vous avec vos identifiants si nécessaire.

Le signal Wi-Fi est faible, que faire ?

Essayez de rapprocher le SWEEX TV022 de votre routeur Wi-Fi. Évitez les obstacles comme les murs et les appareils électroniques qui pourraient interférer avec le signal. Vous pouvez également envisager d'utiliser un amplificateur de signal Wi-Fi.

Comment configurer les applications ?

Pour configurer les applications, accédez au menu principal du SWEEX TV022, sélectionnez 'Applications' puis 'Installer'. Choisissez les applications que vous souhaitez ajouter et suivez les instructions à l'écran pour les installer.

MODE D'EMPLOI TV022 SWEEX

Contents

1 PREFACE 3
2 SAFETY PRECAUTIONS 3
3 IN THE CARTON 5
FRONT&BACK 6 CONNECTIONS OF LCD
5 INSTALLATION DRAWINGS Power Cord Connection 7 Antennas Connection 7 SCART Connection 8 YPbPr Connection 8 S-Video Connection 9 VGA Connection 9 HDMI Connection 10
Remote control instructions in TV mode 11 Remote control instructions in TELETEXT mode 12 Remote control instructions in DVD mode 13 Remote control setup 14
7 ACCESSORIES 14
8 TV OPERATION

9

DVD OPERATION

Basic operation 24

MP3/JPEGPlayback 24

Function Settings 25

DVD Function General setup 25

System Setup 25

Language Setup 28

Audio Setup 29

Digital Setup 30

10

TROUBLESHOOTING AND ADVICE

31

1. PREFACE

Thank you for buying this TV! Please read this manual thoroughly before operating the TV.

Make sure the TV was not damaged in transit. Should the TV is damaged, do no install your dealer. Check that you have all the accessories according to the model.

it and contact

2. SAFETY PRECAUTIONS

Put the TV on a stable surface.

Do not place any material on the TV.

Do not use the with fixtures other than those provided or suggested by the manufacturer.

Do not block or cover the ventilation openings on the TV. If you have a wall mount, check that it is steady.

Power cord and cables must be properly routed and protected to prevent people from stepping on them and causing the TV to fall.

Keep the TV dry and away from humidity.

Keep the TV away from heat sources.

Unplug the before cleaning it. Do not use solvent or liquid TV to clean the TV. Only clean the TV with a soft and dry cloth.

In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer. Using inadequate spare parts can lead to electric shocks, short-circuits fire or other incidents.

Unplug the TV during lightening storms or when unused for long periods of time.

3. IN THE CARTON

LCD TV SET

Remote Control

User Manual

AAA Batteries

4. FRONT&BACK CONNECTIONS OF LCD

Front View

1. Press "SOURCE" to select the input source;
2. Press P + or P - to scan through channels;
3. Press "V+ or "V- to increase or decrease the sound level;
4. Press "MENU" to bring up the main menu on the screen;
5. Press "POWER" button to turn standby mode on or off;
6. POWER INDICATOR: show red in standby mode, show green when your TV is switched on;
7. REMOTE SENSOR: infrared sensor for the remote control.
8. OPEN/CLOSE in DVD mode;
   9.▶PLAY/PAUSE in DVD mode;
9. STOP in DVD mode;

Back View and Control Connections

1. HDMI: Connect the HDMI output jack of DVD.
2. VGA: Connect the PC-RGB output jack of PC.
3. SCART: Connect the SCART jack of VCR or DVD.
4. S-VIDEO: Connect the S-VIDEO output jack of DVD or VCR.
5. YPbPr: Connect the YPbPr output jack of DVD or VCR.
6. PCAUDIO: Connect the Audio output jack of PC;
7. YPbPr S-VIDEOAUDIO: Connect the Audio input jack of DVD or VCR for YPbPr S-VIDEO
8. RF: Connect the antenna.

5. INSTALLATION DRAWINGS

Power Cord Connection

1. Connect the power cord correctly as shown.
2. Press the POWER switch of your LCD V to switch on the LCD TV. The power indicator on the front panel lights up in Green

Antennas Connection

To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as Shown above can be sourced from TV equipment shops, which will provide service for correct installation and connection. After installation, insert the 75-ohmantenna plug into the antenna jack as shown above.

SCART Connection

Connect the SCART connector on the external video device to the SCART connector on the set using a SCART cable.

YPbPr Connection

Connect the YPbPr output of the DVD or VCR to the YPbPr input on the set. The picture quality is improved; compared to connecting a regular VCR to the video input. Connect the Audio output of the DVD or VCR to the Audio input jacks on the set using the RCA cable.

S-Video Connection

Connect the S-VIDEO output of the DVD or VCR to the S-VIDEO input on the set. The picture quality is improved compared to connecting a regular VCR to the video input.

Connect the Audio output of the DVD or VCR to the Audio input jacks on the set using the RCA cable.

Select S-VIDEO input source with using the SOURCE button on the remote control.

VGA Connection

Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output of the PC to the PC AUDIO jack on the set. Select the VGA input source with using SOURCE button on the remote control.

TV Back

HDMI Connection

Connect HDMI output of the DVD to the HDMI input jack on the set. Select the HDMI input source with SOURCE button on the remote control.

6. REMOTE CONTROL

Remote control instructions in TV mode

POWER

Turn the LCD TV ON or OFF.

MUTE

Press to mute the sound. Press again or press V + to un-mute the TV.

SOURCE

Press to cycle through the input source in following:

PMODE

Press repeatedly to cycle through the available video picture modes.

SMODE

Press to cycle through the different sound settings.

AUDIO(I/II)

Press to search the NICAM modes.

SLEEP

Lets you select amount of time before your TV turn itself off automatically.

NUMBER BUTTONS

Press 0-9 to select a TV channel directly when you are watching TV. The channel change after 2 seconds.

--

Press this button to enter a program number for multiple program channel such as 2-1,etc.

Return to the previous channel viewed.

DISPLAY

Press to display the source and channel's information.

THUMBSTICK (▲/▼/▲/▶/OK ENTER)

Allows you to navigate the on-screen menus and adjust the system settings to your preference.

TV MENU

Brings up the main TV menu to the screen.

EXIT

Exit the main TV menu to the screen.

V+/V-

Press to increase / decrease the sound level.

P+/P-

Press to scan through channels.

SIZE

Change the picture format.

FAV+/FAV/FAV-

Press to increase decrease your favourite program in TV mode.

Remote control instructions in TELETEXT mode

NUMBER BUTTONS

Press 0-9 to select a teletext page.

TEXT

Press to switch between TV and Teletext mode.

P+/P-

Page up and Page down.

COLOR BUTTONS

Select 4 Preferred TELETEXT page.

SUBTITLE

To display subtitle.

HOLD

Freeze the current page.

SIZE

Change the picture size.

REVEAL

Reveal or hide the hidden words.

MIX

TV and TXT pictures are mixed together in transparent background.

INDEX

Request index page when index link is valid.

SUBPAGE

TELETEXT Subpage.

Remote control instructions in DVD mode

AUDIO(I/II)

AUDIO selection buttons in DVD mode.

NUMBER BUTTONS

Numerical buttons for various data.

PROGRAM

Program a disc playing in a desired sequence.

GOTO

It is possible to get access to any point on the directly using the "GOTO" menu.

Press GOTO to access the "GOTO" menu.

THUMBSTICK ( / / /) OK ENTER

Allows you to navigate the on-screen menus and adjust the system settings to your preference.

DVD SETUP

Used for selecting programs. It may also be used to execute commands.

A-B

This button enables you to repeat a selected section from the disc.

ANGLE

Selects various camera angles for certain scenes or passages on the DVD during playback.

REPEAT

Press REPEAT to cycle through the repeat play options.

SUBTITLE

Select a different subtitle language(dVD disc must have the subtitle you selected.

#

PLAY/PAUSE in DVD mode.

D.DIS

Press to display the DVD information of DVD mode.

SIZE

Change the picture format.

D.MENU

DVD disc menu Access to menu.

ZOOM

In play state, press ZOOM, the player will zoom in the picture one time.

#

Jump to previous and next track.

#

DVD STOP

#

Fast backward and forward key.

#

To eject the disc.

Remote control setup

1. Open the cover;
2. AAA size batteries, When inserting the batteries, make sure correct polarities as per "+" and "-" marks on the batteries and within the battery compartment;
3. Replace the battery cover.

To prevent battery leakage which may result in bodily injury or damage to the remote:

1. Install all batteries correctly as marked on the remote control.
2. Do not mix batteries: (OLD and NEW or CARBON and ALKALINE, etc) Remove batteries when the remote is not used for a long time.

7. ACCESSORIES

1. One Remote Control;
2. Two Batteries 1.5V;
3. One User Manual.

8. TV Operation

In this manual, the OSD ( On Screen Display) may be different from your TV's, because this is just an example for the TV operation.

First Time Installation

If this is the first time you open the TV and there is no programs in the TV memory, the First Time Installation menu will appear in the picture.

Country

Press / button and then use / to select the country.

Language

Press / button and then use to select the OSD language.

Delete Analog Program

Press / button and then use / to select whether to delete all the analog programs.

Analog Program Search

Press / button and then use / to select whether to start searching analog programs.

Delete Digital Program

Press / button and then use / to select whether to delete all the digital programs.

Digital Program Search

Press / button and then use / to select whether to start searching digital programs

After setting the items, select OK to finish the first time installation, or select Cancel to exit this menu.

If you cancelled the first time installation, it will remind you whether to set the first time installation next time.

TV Information

Program Information

Press DISPLAY or NICAM button to display the program information.

1	25 TV Label		4
2	Auto	Auto	5
3	No Signal	▼	6

1. The number of current program.
2. The colour system of current program, could be selected in Manual Tuning menu(an option of SETUP menu).
3. The name of current program.
4. The label of current program, you can label it in Manual Tuning menu(an option of SETUP menu).
5. The sound system of current program, could be selected in Manual Tuning menu (an option of SETUP menu).
6. The NICAM mode of current program.

If the icon of NICAM mode is red, it means the current program supplies multi NICAM signals, and you can select it by pressing NICAM button.

The NICAM modes and relative icons:

Mono

Stereo

Duel I

Duel II

VIDEO menu options

Press MENU button on the front panel or TV MENU on the remote control to display the main menu.

1. Press button to select PICTURE in the main menu.
2. Press / A button to select the option that you want to adjust in the PICTURE menu.
3. Press button to adjust.
4. When you are satisfied with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

Picture Mode

Select Picture Mode in PICTURE menu. (Available picture mode: Standard, Personal, Movie, Sport, Mild, Game.) If you change the value of Contrast, Brightness, Colour, Tint, Sharpness or Colour temperature on the picture menu, the picture mode will be changed to "Personal" automatically. You may select the picture mode directly by pressing PMODE button.

TIPS: You can press PMODE button on the remote control to select the Picture Mode directly.

Contrast

Press / button and then use / to adjust the contrast of the picture.

After adjust the value you want, press TV MENU button to return to the preview MENU.

Brightness

Press / button and then use / to adjust the brightness of the picture.

Colour

Press / button and then use / to adjust the colour saturation.

NOTE: This option is invalid in PC mode, and it will be shown in gray.

Tint

Press / button and then use / to adjust the tone of colour when your system is in NTSC.

Sharpness

Press to select the sharpness mode of your TV. (Available Sharpness Mode: Normal, Sharp, Sharpest, Softest, Soft.)

Colour temperature

Select an optimum colour temperature mode to suit your eyes for viewing among Normal, Warm and Cold.

NOTE: This option is available only in PC mode.

DNR (Digital Noise Reduction)

If the broadcast signal received is weak, you can select the DNR option to reduce the video noise level between Off, Low, Mid and High.

AUDIO menu options

Press MENU button on the front panel or TV MENU on the remote control to display the main menu.

1. Press the / button to select in SOUND the main menu.
2. Press the / button to select the option that you want to adjust in the SOUND menu.
3. Press the / button to adjust.
4. When you are satisfied with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

Volume

Press / button and then use to adjust the sound level.

After adjust the value you want, press TV MENU button to return to the preview MENU.

Sound Mode

Select Sound Mode in SOUND menu. (Available sound mode: Personal, Voice, Music, Theatre.)

If you change the value of Bass and Treble on the Sound menu, the sound mode will be changed to "Personal" automatically.

You may select the sound mode directly by pressing SMODE button.

TIPS: You can press SMODE button on the remote control to select the Sound Mode directly.

Bass

Press / button and then use / to increase or decrease the level of the lower-pitched sounds.

Treble

Press / button and then use / to increase or decrease the level of the higher-pitched sounds.

Balance

Press / button and then use / to adjust the audio output between / speakers.

Setup menu options

1. Press the / button to select SETUP in the main menu.
2. Press the / button to select your option what you want to adjust in the SETUP menu.
3. Press the button to adjust.
4. When you are satisfied with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

Country

This option allows you to select the country.

Auto tuning

This option allows you to tune the channels that can be received automatically.

Note: Before you perform Auto Tuning, you must choose the country where you are by selecting COUNTRY option.

Press ENTER key to start.

You can press TV MENU button to stop auto tuning and close the OSD menu.

Manual Tuning

This option allows you to perform Manual Tuning.

Note: Before you perform Manual Tuning, you must choose the country where you are by selecting Country option in the FUNCTION menu.

1. Press to select Manual tuning in SETUP menu.
2. Press / to perform your selection, the menu of Manual tuning will display on the screen.

Program

The current program number. Press / to select the upper or lower program.

Sound System

Press / to select a corresponding sound system, such as DK, L/L', BG, I.

Colour System

Press to select a corresponding colour system, such as Auto, PAL, SECAM.

ProgramLabel

This option allows you to label a channel, you can also relabel the programs have been labeled.

1. Select a channel you want to labeled.
2. Press / select Program Label in SETUP menu.
3. Press / to perform your selection. The menu of program label will display as below:

1. Press the numeric buttons to input the numbers directly or press / to select the letters.
2. Press / to move the cursor.
3. Press ENTER, TV MENU or EXIT button to confirm and return to previous menu.

AFT (Auto Fine Tune)

Due to weak signals or a wrong antenna configuration, some of the channels may not be tuned to the best reception condition. AFT function allows you to fine tune channel selected( the frequency of channel is around the value in Manual Search option.

Manual Search

This option has two functions:

1. Set the frequency of channel for AFT option.
2. Press button for 3+ seconds and it will start auto tuning from this frequency.

Program Edit

This function allows you to sort the TV programs according to your preferences, as following:

1. Press / to select Program Edit in SETUP menu.
2. Press / to enter into the sub menu, a channel list will display.
3. Press / to select the channel in the list which you would like to sort.
4. Press to perform your selection.
5. Press / to select the location you would like to place the channel.
6. Press to perform you selection.
7. Press TV MENU to return to the previous menu or press EXIT to exit.

SETUP menu of VGA input (for setting the PC picture position):

SETUP menu of HDMI input (for setting the HDMI picture position):

SETUP menu of YPbPr input (for setting the YPbPr picture position):

Timer menu options

Press MENU button on the front panel or TV MENU on the remote control to display the main menu.

1. Press the / button to select TIMER in the main menu.
2. Press the button to select your option what you want to adjust in the TIMER menu.
3. Press the / button to adjust.
4. When you are satisfied with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

Sleep Timer

Select the sleep time to put automatically the TV in standby mode. Timer can be selected as 0min, 15min, 30min, 45min, 60min, 75min, 90min, 105min, 120min. Also you can select the sleep time by pressing SLEEP button repeatedly.

OSD Timer

You can select the time when the OSD display on the screen such as: 5Sec,10Sec,15Sec, 20Sec, 25Sec, 30Sec.

Function menu options

Press MENU button on the front panel or TV MENU on the remote control to display the main menu.

1. Press the / button to select FUNCTION in the main menu.
2. Press the / button to select your option what you want to adjust in the FUNCTION menu.
3. Press the button to adjust.
4. When you are satisfied with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

Language

Press to select the OSD language.

Video Size

This option allows you to select the screen display mode which best corresponds to your viewing requirements.

Note: The available aspect mode may be different in different input signal.

Blue screen

This option allows you to select the blue background on or off. If on, the screen background will turn blue at very weak or no signal condition.

Child Lock

Press ENTER or button to set the child lock.

PIN Code:

Delete 0~9 Input ENTER Enter

You need to enter the PIN code if the Child lock is set "on", and the default PIN code is empty, you can press ENTER button directly to enter.

TIPS: The superuser's (administrator's) password 8329.

Child Lock

Press ENTER or button to set the child lock.

Key Lock

Press ENTER or button to set the key lock.

Change PIN Code

Press button to enter Change PIN Code menu.

Old PIN Code

Press 0~9 buttons to enter the correct old PIN code, you can not change the PIN code if you entered a wrong PIN code.

New PIN Code

Press 0~9 buttons to enter the new PIN code you want

Change PIN Code

Press 0~9 buttons to enter the PIN code you entered in the New PIN Code menu again to confirm the new PIN code.

First Time Installation

Press button to open the first time installation menu, and the operation of this menu is in page 3.

Reset

Press ENTER or button to reset the TV to the factory default.

9. DVD Operation

Basic operation

1. Turn ON and OFF the function DVD

• Turn on the LCD TV and then press SOURCE button to select DVD mode.

2. Playback

Insert DVD discs, if PBC is "ON" status, press button will enter the disc menu.

Press button to start in sequence. For others, while stopped, press the button to start in sequence.

3. Program playback

Using Program playback, you can select max. 16 chapters from the disc to playback in programmed order.
- OSD for program playback as below.

MP3/JPEG Playback

After loading and scanning the MP3 / JPEGCD&DVD, it will initially display the MP3 contents automatically and start to play the first file (highlighted file). Screen as follow:

Press the or button select the icons to select your file type. Music, Picture and Video.

Press the button in the opposite direction to select the file type, then press ENTER on the remote control. Now you can choose from the list of files to play.

• Using the navigation buttons enables you to check you favorite folder and playback the first file or move to the your favorite folders.

NOTE:

• Press buttons to move the highlighted files to folders, documents or mode selection.
• Press numeric buttons to select the contents directly. For number over 10, press +10 button first. (e.g. File number 15, press +10 then 5.)
• When playing MP3 files, there is no picture display, only audio output.
• Playing JPEG discs: Press the PROGRAM button to select slide effects. There are 12 slide modes, press the PROGRAM button to toggle between different modes in sequence. (Start from top, Start from bottom, Start from left, Start from right, Start from upper left corner, Start from upper right corner, Merge from left / right, Horizontal blades, Vertical blades, Merge form 4 corners, Random, Playback Slide effect OFF).

• When playing or pauseing images, you may use navigation buttons to flip / rotate the picture.

• button to flip horizontally.

• button to flip vertically.
• button to rotate left 90^

• button to rotate right 90^

• When playing or pausing images, you may use the D MENU button to enter preview mode to display 12 pictures. Press button to select next / previous page or press numeric buttons to view the corresponding pictures.
  The maximum JPEG image size that can be displayed is 1280 × 1024 .

Function Settings

DVD Function General setup

• Press DVD SETUP the button to activate the DVD player OSD menu;
• Press buttons to move and highlight between different sub-menus. Press ENTER button to enter the highlighted sub-menu.
• Press DVD SETUP button to exit the OSD menu.

System Setup

TV SYSTEM

• Press button to enter the TV SYSTEM, and then press / to select one from below:

AUTO(Default setting)

This format can be used if your DVD is capable of both PAL and NTSC formats.

PAL

This is the format used in UK for example.

NTSC

This format is used by some other countries, e.g. USA

SCREENSAVER

If the screen saver option is on, when your DVD player is in Stop, Open, or No Disc state, or there is a frame frozen for more than 60sec, the screen saver will be displayed. This feature can protect the screen from damage.

ON: Choose this setting to activate the screen saver.

OFF: Choose this setting to cancel the screen saver

TV TYPE

DVD's are produced in a variety of screen aspect ratios. This menu enables you to select one of the three aspect ratios:

4:3 PS (Normal)
4:3 LB (Normal)
16:9 (Wide)
- Select the most appropriate aspect ratio for the JPG being viewed.

NOTE:

• Playback screen size may vary according to the disc contents.
  For media with 4:3 contents, using any mode would only display a 4:3 screen
• Screen ratio selection should be according to the connected TV / Display aspect ratio.

password

• The default setting is locked. No Rating selection or change password could be done. To edit the Rating setting, please enter default password "0000" using the numeric buttons, then press ENTER button to confirm.
  To change password, input any 4 digit number when the lock is unlocked. Once the 4 digit number is entered, that will be your new password.

RATING

You can select the rating setting according to your preference. Rating restriction is divided into eight different category from KID SAFE to ADULT.

NOTE: Only editable when password is unlocked.

POWERRESUME

ON: Choose this setting to activat the power resume.

OFF: Choose this setting to cancel the power resume.

DEFAULT SETTING

• Press ENTER button to restore factory default.

Language Setup

Press DVD SETUP button to enter the DVD OSD menu.

OSD Language

Use navigation buttons to select the OSD LANGUAGE setup icon, press ENTER button to confirm. There are 7 languages for your selection, press

\& buttons to toggle between different languages, Press ENTER button to confirm.

AUDIO LANGUAGE

Use navigation buttons to select the AUDIO LANG setup icon, press ENTER button to confirm. There are 7 languages for your selection. Press & buttons to toggle between different languages. Press ENTER button to confirm.

SUBTITLE LANGUAGE

Use navigation buttons to select the SUBTITLE LANG setup icon, press ENTER button to confirm. There are 7 languages for your selection Press & buttons to toggle between different languages. Press ENTER button to confirm.

MENULANGUAGE

Use navigation buttons to select the MENU LANG setup icon, press ENTER button to confirm. There are 7 languages for you selection, press & buttons to toggle between different Languages. Press ENTER button to confirm.

Audio Setup

AUDIO setup

The audio setup options are illustrated below:

KEY

• Use the Up and Down arrow button to move the scroll and adjust the KEY.

Digital Setup

DYNAMIC RANGE

Switch the compress mode to "Audio output" to adjust the compress ratio for different effects. When selected FULL, the peak signal value is smallest. When selected OFF, the peak signal value is largest.

DUAL MONO

You can select four different audio output, STEREO, MONO L, MONO R, MIX MONO. The audio out description of these Selections is shown in the table below.

MODE	LEFT SPEAKER	RIGHT SPEAKER
STEREO	STEREO-L	STEREO-R
L-MONO	L-MONO	L-MONO
R-MONO	R-MONO	R-MONO
MIX-MONO	L-MONO+R-MONO	L-MONO+R-MONO

10. TROUBLESHOOTING AND ADVICE

Please check if you can solve the troubleshooting by yourself.

Troubleshooting	Control
No signal	Please check that all cables are correctly plugged in.
No color shades	Adjust the contrast, the color and the brightness.
Stain show on the screen.	Maybe result from a lighting signal from car, motor, neon light and other electrical devices or appliances.
Double or multiple display image	Maybe the result of an electrical wave disturb from other TV, Computer and Game machine or Radio.
Snow on the screen	The cables of the antenna are not correctly plugged in.
The remote control does not work	Please check the batteries order and alignment. Check that the IR of the remote control is not hidden by something.
"Zip" made noise on TV cover	Even if the display image is correct, the noise may come from an unsteady fixation of the panel.
No sound	Make sure that you have not press the MUTE button of the panel or of the remote control.
No DVD	Make sure if the TV Set have been switched to DVD mode.
DVD player not working properly	Ensure disc is correctly inserted into the player. Ensure the disc does not damaged and with correct format. Please wait patiently as some discs need longer time to play.
