SM1000 - Food processor Concept - Free user manual and instructions

Brand	Concept
Model	SM1000
Product type	Multifunction food processor
Power supply	220-240 V ~ 50/60 Hz
Power	1500 W
Acoustic power level	Up to 90 dB(A)
Bowl capacity	Approximately 1.5 L (glass bowl)
Materials	Glass bowl, plastic lid with seal
Net weight	Approximately 5 kg
Dimensions (L x W x H)	Approximately 30 x 20 x 30 cm
Main functions	Blending, cooking, heating, pulse, ice crushing
Preset programs	4 programs: Creamy soup/purée, Soup, Compote, Sauce
Manual mode	Temperature adjustment (low, medium, high) and time
Safety	Built-in safety fuse, stops if bowl or lid is incorrectly positioned
Maintenance and cleaning	Clean with soapy water, do not immerse the heating bowl
Included accessories	Measuring cup, glass bowl, lid with seal
Repairability	Repairs by authorized service center only
Warranty	24 months from the date of purchase

Frequently Asked Questions - SM1000 Concept

How to use the preset programs?

Select the desired program (creamy soup, soup, compote or sauce). The display shows the default duration, which you can adjust using the +/- buttons, then press the start/stop button to begin. A beep sounds at the end of the program.

Can I add ingredients during cooking?

It is not recommended to add ingredients during hot programs due to the risk of burns. Wait until the end of the program if necessary.

How to clean the food processor?

Unplug the appliance and fill half the bowl with soapy water. Close the lid and press the Ice/Pulse button 3 to 5 times. Let it sit for 15 minutes, then empty and rinse. Dry thoroughly before reassembling. Never immerse the heating bowl in water.

What if the appliance does not start?

Check that the bowl and lid are correctly locked. The appliance is equipped with a safety fuse that prevents operation if the accessories are not properly positioned. Also ensure the power outlet is working.

What is the recommended ingredient size?

Ingredients should be cut into pieces of approximately 2 x 2 x 2 cm for optimal blending.

Can I blend hot liquids?

Yes, the food processor can blend hot liquids thanks to its cooking programs. Be careful when opening the lid to avoid burns.

How to make crushed ice?

Use the Ice/Pulse button. Place ice cubes in the bowl, close the lid and press the button several times until you get the desired texture.

Is the appliance noisy?

The maximum acoustic power level is 90 dB(A), which is comparable to a standard blender.

What to do in case of breakdown?

Do not attempt to repair the appliance yourself. Contact an authorized service center. The list of centers is on the packaging or on the website www.my-concept.com.

What is the warranty period?

The warranty is 24 months from the date of purchase. It does not cover normal wear and tear, damage caused by misuse or unauthorized interventions.

USER MANUAL SM1000 Concept

Black and white photo of a modern kitchen blender with digital display and control buttons (no visible text or symbols)

SM1000

CZ

HU LV DE FRENSK PL

IT ES

RO

concept

CZ

Poděkování

NÁVOD K OBSLUZE

UPOZORNÉNÍ

Obr.1

NÁVOD NA OBSLUHU

UPOZORNENIE

obr.1

INSTRUKCJA OBSŁUGI

PRZESTROGA

WSTĘPNIE USTAWIONE PROGRAMY

HASZNÁLATI ÚTMUTATÓ

FIGYELMEZTETÉS

LIETOŠANAS INSTRUKCIJA

BRĪDINĀJUMS

1.att

1. Pievienojiet ierici elektrotiklam.
2. Izvėlieties standarta programmu (skat. blendėšanas programmas) vai vienmėrīgu sajauksanu.
3. Nonemiet trauku no motora pamatnes tikai tad, kad motors nedarbojas.

Piez.: lerice ir aprikota ar drośibas mehänismu. Tā nedarbosies bez pareizi novietota trauka un vāka.

BRÍDINAJUMS

Thank you for purchasing a Concept product. We wish you much joy with your new appliance every day you use it. Please read the instruction manual carefully before initial use. To refer to this manual any time you need to, we recommend you to keep it in a safe place. And please pass it to any future owner of the appliance.

Technical specifications
Voltage 220-240 V, 50/60 Hz
Input 1500 W
Sound performance level max. 90 dB (A)

IMPORTANT SAFETY PRECAUTIONS

• Do not use the appliance in any other way than as described in this manual.
• Remove all the covering and marketing materials from the appliance before the first use.
• Make sure the mains voltage corresponds to the values on the rating plate of the appliance.
• Do not leave the appliance unattended when it is switched on or connected to the mains.
• Place the appliance on a stable, level surface, do not place it on any other appliance.
• Do not place the appliance near flammable substances, fire, heating elements or hot oven.
• Do not cover the appliance, there is a risk of overheating.
• Do not place anything on the appliance during operation.
• Do not carry the appliance when it is switched on.
• Keep the appliance clean, do not allow foreign objects to into the grid openings. It could cause short circuit, damage to the appliance or cause fire.
• When disconnecting the unit from the wall outlet, never pull the power cord, grasp the plug end and disconnect it by removing it from the receptacle.
• Do not allow children or unauthorized people to handle the appliance, use it out of their reach.

EN

concept

concept

EN

• Persons with reduced mobility, reduced sensory perception, mental disadvantage or persons not familiar with the operation must use the appliance only under the supervision of responsible person, who is familiar with the instructions.
• Pay extra attention if the appliance is used near children.
• Do not use the appliance as a toy.
• Do not allow the power cord to hang freely over the edge of the worktop where children might reach it.
• Do not use the appliance outdoors or on a wet surface, there is a risk of electric shock.
• Do not use any accessories other than those recommended by the manufacturer.
• Do not use the appliance with a damaged cord or plug and have it repaired immediately by an authorized service centre.
• Do not use the power cord to move or handle the appliance.
• Keep the appliance away from heat sources such as radiators, ovens, etc. Protect it from direct sunlight and humidity.
• Do not touch the appliance with wet hands.
• When installing accessories, cleaning and maintenance or in the event of a malfunction, switch off the appliance and disconnect the plug from the electrical outlet.
• Do not touch moving parts while the appliance is in operation. Wait until it stops completely.
• The appliance is only suitable for home use and is not intended for commercial use.
• Do not immerse the power cord, plug or appliance in water or any other liquid.
• Check the appliance and the power cord for damage regularly. Never switch on a damaged appliance.
• Do not let hair and clothing hang loose near openings and moving parts of the appliance.
• Before connecting or disconnecting the appliance from the mains socket, make sure that the switch is in the off position.
• Always exercise caution when handling blades and cutting discs. They are very sharp and can cause injury.
• Before cleaning and after use of the appliance, switch the appliance off, disconnect it from the mains and allow it to cool down.

• The appliance contains sharp parts. Exercise caution when cleaning.
- Do not allow the power cord to hang freely over the edge of the worktop. Do not allow the power cord to touch hot surfaces.
- Do not allow the appliance to hang on the power cord.
- Do not use the appliance without properly fitted accessories.
- Do not let the appliance run idle.
- Do not repair the appliance yourself. Contact an authorized service centre.
- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Cleaning and maintenance performed by the user must not be carried out by children unless they are 8 years old and under supervision. Children aged under 8 years of age must be kept away from the appliance and its power cord. Do not let children play with the appliance.
- Do not touch the hot surface. Use the container handle.
- Never pour cold water into a hot heating container.

Damages from failure to follow the manufacturer's instructions are not covered by the warranty.

EN

concept

concept

EN

PRODUCT DESCRIPTION

1. Measuring cup
2. Container lid
3. Lid seal
4. Glass container
5. Base
6. Pre-set programs
7. Start/Stop button
8. Performance speeds
9. Pulse/ice crushing button
10. Buttons for setting the heating time/level
11. Timer Indicator
12. Heating level indicator

OPERATING INSTRUCTIONS

NOTICE

Before putting a new appliance into operation, you should wipe it thoroughly from the outside with a damp cloth and wash all removable parts in warm water for hygienic reasons.

The appliance has a built-in safety fuse. The appliance motor can only be switched on if the accessories are properly fitted. Do not bypass the safety mechanism!

Never leave the appliance unattended while in operation or switched off, but plugged in! Immediately after switching off the motor and unplugging the power cord, some parts may be still moving for a while. Wait until the accessory has completely stopped before opening the lid.

USE

1. Place the container on the blender base. Before putting the appliance into operation, check that the container is correctly seated in the base.
2. Place the food in the container and place the lid on the blender container (the recommended size of inserted food is 2 x 2 x 2 cm). Rotate the lid until it snaps into the grooves of the blender container (Fig. 1).

Fig. 1

1. Connect the appliance to the mains.
2. Select a preset program (see mixing programs) or continuous mixing.
3. Remove the container from the motor base only if the motor is not running.

Note: The appliance is equipped with a safety fuse. It will not work without properly fitted container and lid.

NOTICE

In case of pre-set hot programs, we do not recommend adding food during the program. There is a danger of scalding.

46

SM1000SM1000

EN

concept

concept

EN

PRESET PROGRAMS

Cream soup / purée (25 min.) - e.g. broccoli cream

Soup (25 min.) - e.g. chicken soup

Compote (20 min.) - e.g. apple compote

Sauce (25 min.) - e.g. tomato sauce

Select a program, the display will show the duration of the program. You can adjust the cooking time using the +/- symbols. Confirm your selection with the Start/Stop button, a beep sounds once. During cooking, depending on the selected program, mixing is automatically started. At the end of the program, a beep sounds 3 times.

Manual

Select the program, select the cooking level from the three possible intensities using the +/- symbols, confirm with the Start/Stop button. Select the cooking time using the +/- symbols and confirm with the Start/Stop button.

Low temperature level ⚡ - the program can be used as KEEP WARM to maintain the temperature of already cooked dishes and to mix e.g. butter creams for desserts.

Medium temperature level ⬆ - moderate cooking of small amounts of content, e.g. baby food.

High temperature level 🔒 - the content will quickly boil.

Note: The continuous operating time in the "Manual" program is 1 min, then allow to cool for 3 min.

CLEANING AND MAINTENANCE

1. Unplug the power cord from a wall outlet before cleaning.
2. Never immerse the container with the heating unit in water!
3. Do not use any sharp or abrasive cleaners.
4. Clean only the outside of the blender and use only a damp cloth.
5. Fill up to half of the container with soapy water, close the container with a complete lid, press the Ice/Pulse button 3-5 times. Leave the soapy water in the container for approx. 15 min. Then pour out the contents and rinse the container with clean water.
6. Before reassembling, let all the parts dry thoroughly.

SERVICE CENTRE

Extensive maintenance or repair, which requires access to internal parts of the product, has to be performed by a qualified specialist or the service centre.

ENVIRONMENTAL CONCERNS

• Packaging materials and old appliances should be recycled.
• Packaging materials may be disposed of as sorted waste.
• Dispose the plastic bags made of polyethylene (PE) of as sorted waste.

Recycling of the appliance at the end of its lifespan:

This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The disposal of such material has to be done according to the recycling regulations. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the appliance.

The product meets all the necessary requirements of the EU directives applicable to the specific product.

Changes in text, design, and technical specifications are subject to change without prior notice and we reserve the right to change them.

48

concept concept

DE

Danksagung

MODE D'EMPLOI

MISE EN GARDE

MANUALE D'USO

AVVERTIMENTO

Fig. 1

MANUAL DE USO

ADVERTENCIA

Fig. 1

MANUAL DE UTILIZARE

ATENTIONARE

Fig. 1

The manufacturer (or Importer) is responsible for ensuring the product complies with the requirements of applicable legal regulations as well as those of the relevant technical standards. Moreover, they are responsible for ensuring the product has the properties the manufacturer described in documents related to the goods or those reasonably expected by the customer with regard to the nature of the goods or based on advertising produced by the manufacturer, and further they are responsible for ensuring the product is fit for the purpose proposed by the manufacturer or that a product of the same type is normally used for.

The quality warranty term is 24 months from product takeover by the customer.

The warranty does not apply to wear and tear caused by regular use. The customer shall not be entitled to any warranty claims if, prior to taking the product over, they knew the product contained a defect or if the defect is attributable to the customer.

The warranty specifically does not apply:

• if the product installation, operation and service conditions stipulated in the product operating manual have not been adhered to,
  • to malfunctions caused due to mechanical, heat or chemical damage, short circuit, over voltage or incorrect installation.
  • to malfunctions caused by an inexpert third-party intervention,
  • to malfunctions caused by natural disaster,
  • to malfunctions caused by insufficient or inappropriate maintenance in violation of the operating manual, including malfunctions caused by water and other sediments,
  • to changes in colour of the heating surface or to scratching of the surface caused as a result of using the products in an unusual manner,
  • to appearance and functional changes caused by exposure to sunlight, thermal radiation of water and other sediments,
• if the service life of certain product parts expires, e.g. for accumulators, bulbs, etc.

The warranty does not apply to any products and services provided along with the product (gifts, promotional articles, etc.).

Filing a complaint

A complaint against a product defect must be filed as soon as identified, yet no later than before the end of the warranty term.

The customer must file a product complaint with the dealer from which they have purchased the product, or with any authorised service centre, a list of which is included in the product package, or available at www.my-concept.com.

While filing a product complaint, the product must be duly cleaned and securely packed so as to prevent any damage during its transport to an authorised service centre, where relevant, unless the product is delivered in person.

The customer must submit proof of having concluded a purchase contract for the product by producing the receipt.

While filing their complaint, the customer must indicate the noted defect and identify the preferred complaint application method.

Complaints processing

As long as the noted defect may be removed, the user has the right to have the defect duly removed free of charge on a timely basis.

Where such a procedure is not reasonable with regard to the nature of the defect, the user may require to be supplied a new defect-free product (replacement), or, where the defect applies to a part of the product only, replacement of the part concerned. However, if replacement of the product or any part thereof is not proportionate with regard to the nature of the defect, especially if the defect can be removed without undue delay, the customer has the right to have the defect removed free of charge.

If the noted defect is not removable, or if the customer becomes entitled to replacement of the product or a part thereof, yet the replacement is not possible, for example due to the product having been sold out, the customer has the right to return the product (withdrawal from the contract).

The customer shall have the right to a new product (replacement) or to replacement of a part of the product even if the defect can be removed, provided they cannot properly use the product due to repeated occurrence of the defect or due to a high number of such defects. In such a case, the customer also has the right to return the product (by withdrawing from the contract).

If the product is not returned (the customer does not withdraw from the contract), or if the customer does not apply the right to a new defect-free product (replacement), to replacement of a part thereof or to repair of the product, they may request a reasonable discount. The customer also has a right to a reasonable discount if a new defect-free product cannot be supplied to them, or if a product part cannot be replaced or the product repaired unless the situation is remedied within a reasonable time limit, or if remedying the situation would create major discomfort on the part of the customer.

The seller, authorised service centre or a staff member authorised by them must decide about each complaint immediately or within three business days in complicated cases. This term does not include a reasonable period of time, depending on the type of product concerned,

required for the defect to be assessed by an expert. A complaint, including defect removal, must be dealt with without any undue delay, yet no later than within 30 calendar days of the complaint filing date, unless the seller and the customer agree on a later deadline.

On returning the product (withdrawing from the contract) the customer must return any accessories and documents supplied along with the product.

The customer does not have the right to keep the defective parts and components of the product replaced as part of a repair of the product.

This shall be without prejudice to any other rights the customer may have in relation to the purchase of the product.

Remark: Complaints against products damaged in transport are governed by the carrier's complaints procedure.

Manufacturer

Jindrich Valenta - Concept

Vysokomýtská 1800, 565 01 Choceň

Czech Republic

tel.: [phone]

fax [phone]

Company ID No. 13216660

email: [e-mail]

www: www.my-concept.com

Product data

Model:
Production number:
Date of purchase: Seal and signature of vendor:
