Product Type	Shiatsu Neck Massage Cushion
Brand	SilverCrest
Model	SSMN 2 B3
Intended Use	Massage of neck and shoulders for personal domestic use
Power Supply	Mains adapter: Input 100-240 V ~ 50/60 Hz, Output 12 V ⎓ 1 A
Appliance Power Input	12 V ⎓ 1 A
Adapter Model	YJS010A-1201000G
Massage Functions	Shiatsu massage with rotating heads (slow and fast speed)
Heat Function	Yes, built-in warmth (2 massage heads illuminate and warm up)
Auto Shut-off	After 15 minutes
Massage Heads	4 rotating heads
Control Buttons	On/Off, Massage (speed), Warmth
Cover Material	70% nylon, 30% polyester
Cover Removal	Removable via zipper for machine washing
Cover Washing	Machine wash at max 30°C, delicate cycle; do not bleach, tumble dry, iron, or dry clean
Appliance Cleaning	Wipe with damp cloth and mild detergent; do not immerse in water
Safety Warnings	Do not use on infants, children under 8, or persons insensitive to heat; not for medical use; avoid use on injured or inflamed skin; do not cover appliance during use; keep away from water and flammable materials
Warranty	3 years from date of purchase
Included Accessories	Mains adapter, operating instructions
Dimensions	Not specified in manual
Weight	Not specified in manual

Frequently Asked Questions - SSMN 2 B3 SILVERCREST

How do I use the Shiatsu Neck Massage Cushion?

Place the cushion around your neck so the massage heads lie on the sides of your neck. Use the hand loops to adjust. Connect the adapter and press the On/Off button to start slow massage. Press Massage to increase speed, and Warmth to activate heat. The device switches off automatically after 15 minutes.

Can I wash the removable cover?

Yes, the cover can be removed via zipper and washed in a machine at max 30°C on a delicate cycle. Do not bleach, tumble dry, iron, or dry clean. The material is 70% nylon and 30% polyester.

How long can I use the massager continuously?

Do not use for more than 15 minutes at a time, as longer massage may cause overstimulation of muscles. The appliance has an automatic shut-off after 15 minutes.

Is the massager safe for people with neck injuries or pain?

No. Do not use if you have injuries or pain in the neck or cervical spine. Stop immediately if you feel discomfort or pain. Consult a doctor before using if you have any medical conditions.

Does the massager have a heating function?

Yes, press the Warmth button to activate heat. Two of the massage heads will illuminate and warm up. Note: if you stop the massage heads, the warmth also turns off and must be reactivated.

What is Shiatsu massage?

Shiatsu is a Japanese massage technique that uses finger pressure. This device mimics that with rotating massage heads to provide a relaxing and powerful massage for the neck and shoulders.

How do I clean the appliance?

Always unplug the adapter before cleaning. Wipe the appliance and adapter with a damp cloth, using mild detergent if needed. Do not immerse in water. Do not open the zipper on the appliance (it is for production only).

Can I use the massager while lying down?

Yes, it is recommended to lie back during the massage for relaxation. Ensure the device is properly positioned around your neck and the hand loops are used for alignment.

What is the warranty period and how do I claim?

The warranty is 3 years from purchase date. To claim, contact the service hotline (UK: 0871 5000 720) or email [e-mail] with the receipt and description of the defect. Return the product to the service address provided.

Is the massager suitable for children?

The appliance may be used by children aged 8 and over only with supervision. Do not massage infants, young children, or helpless persons. Children must not play with the device.

USER MANUAL SSMN 2 B3 SILVERCREST

Gray massage gleeve with mesh mesh grille and control buttons (no text or symbols visible)

SHIATSU NECK MASSAGE CUSHION SSMN 2 B3

GB

SHIATSU NECK MASSAGE CUSHION

Operating instructions

SI

SHIATSU MASAŽNA BLAZINA ZA ZATILJE

Navodila za uporabo

SK

ŠIJOVÝ MASÁŽNY VANKÚŠ SHIATSU

Návod na obsluhu

HU

SHIATSU NYAKMASSZÍROZÓ KÉSZÜLÉK

Használati utasítás

CZ

MASÁŽNÍ LÍMEC

Návod k obsluze

DE AT CH

SHIATSU-NACKENMASSAGE-HÖRNCHEN

Bedienungsanleitung

GB

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

HU

Disposal of the packaging 3

Appliance description 4

Technical data 4

Safety instructions 5

What is Shiatsu massage? 7

Operation 7

Connection 7

Fitting 8

In use 8

After the massage 9

Cleaning 9

Cleaning the removable cover 9

Cleaning the appliance 10

Storage 10

Troubleshooting 11

Disposal of the appliance .... 1 1

Disposal of the mains adapter .... 1 1

Kompernass Handels GmbH warranty 12

Service 13

Importer 13

Introduction

Congratulations on the purchase of your new appliance.

You have clearly decided in favour of a quality product. These operating instructions are a part of this product. They contain important information in regard to safety, use and disposal. Before using the product, familiarise yourself with all of these operating and safety instructions. Use the product only as described and only for the specified areas of application. Retain these instructions for future reference. In addition, pass these documents on, together with the product, to any future owner.

Copyright

This documentation is copyright protected.

Any copying or reproduction of it, including as extracts, as well as the reproduction of images, also in an altered state, is only permitted with the written authorisation of the manufacturer.

Intended use

This appliance is intended for massaging the neck and shoulders of people. This appliance is intended solely for personal use in the domestic sector, it is not to be used for medical or commercial applications and may not substitute for medical treatment. The appliance is designed for use in dry indoor rooms. It is not intended for use in the medical/therapeutic or commercial fields.

WARNING

Risks from unintended use!

Risks can be engendered if this appliance is used for purposes not intended for it and/or for other types of use.

▶ Use the appliance exclusively for its intended purposes.

▶ Pay heed to the procedures described in these operating instructions.

NOTICE

Risks can be engendered if this appliance is used for purposes not intended for it and/or for other types of use. Use the appliance exclusively for its intended purposes. Observe the procedures described in these operating instructions. Claims of any kind for damage resulting from unintended use, incompetent repairs, unauthorised modification or the use of unauthorised spare parts will not be accepted. The operator alone bears liability.

Items supplied

The appliance is delivered with the following components as standard:

• Shiatsu Neck Massage Cushion
- Mains adapter
- Operating Instructions

1) Remove all parts of the appliance and the operating instructions from the carton.
2) Remove all packaging material.
3) Clean all parts of the appliance as described in the section "Cleaning".

NOTICE

▶ Check the contents to ensure that everything is present and for signs of visible damage.
▶ If the delivery is not complete or something is damaged due to defective packaging or through transportation contact the Service Hotline (see chapter Service).

Disposal of the packaging

The packaging protects the appliance from transport damage. The packaging materials are selected from the point of view of their environmental friendliness and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and reduces the amount of waste generated. Dispose of packaging material that is no longer needed as per the regionally established regulations.

NOTICE

▶ If possible, preserve the appliance's original packaging during the warranty period so that, in the event of a warranty claim, you can package the appliance appropriately for its return.

Appliance description

① Massage heads
② Removable cover
③ Hand loops
4 Socket
⑤ "Warmth" button
6 "Massage" button
⑦ "On/Off" button
8 Mains adapter
9 Connection plug

Technical data

Mains adapter 8
Type YJS010A-1201000G
Input voltage 100 - 240 V	~, 50/60 Hz
Current consumption 350 mA
Output voltage 12 V	——
Output current 1000 mA
Protection class	II / ☐
Polarity	⊖—⊖—⊕
Appliance
Input voltage 12 V	——
Current consumption 1 A

Safety instructions

RISK OF ELECTRIC SHOCK

▶ Operate the appliance only with the supplied power adapter YJS010A-1201000G.
- Connect the appliance only to correctly installed and earthed mains power sockets. Ensure that the rating of the local power supply tallies completely with the details given on the rating plate of the appliance.
- Ensure that the power cable cannot become wet or damp while the appliance is in operation. Place it such that it cannot be crushed or damaged.
- Keep the power cable away from hot surfaces.
- Do not perform any repairs on the appliance. All repairs must be performed by our Customer Services or by qualified personnel.
▶ Always remove the plug from the mains power socket before you clean the appliance.
- Do not use the appliance in damp areas, such as in the bathroom.
▶ To avoid risks, arrange for defective plugs and/or cables to be replaced at once by qualified technicians or our Customer Service Department.
▶ Do not insert needles or other sharp objects into the appliance.

⚠ WARNING! RISK OF INJURY!

• Do not use an external timing switch or a separate remote control system to operate the appliance.
  This appliance may be used by children aged 8 over and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use of the appliance safely and are aware of the potential risks. Children must not play with the appliance. Cleaning and user maintenance tasks must not be carried out by children unless they are supervised.
• Do not massage infants, young children, helpless persons or animals with the appliance.
  ▶ NEVER use the appliance if you have injuries or pain in the neck or cervical spine.
• Stop treatment with the appliance IMMEDIATELY if you feel it to be uncomfortable or painful.
  ▶ During use the appliance has a hot surface. Individuals who are insensitive to heat must take care when using the appliance.
  ▶ Do not use the appliance on swollen, burnt, inflamed, diseased or injured regions of the skin and body areas. If in doubt, obtain medical advice before using the appliance.
  ▶ Ensure that your fingers or other body parts do not come between the rotating massage heads. Risk of crush injuries!

⚠ WARNING! RISK OF INJURY!

The appliance may not be used in the face (e.g. eyes), on the throat, feet or other sensitive body parts.
▶ During use do not cover the appliance (with a pillow, blanket, etc.). NEVER use the appliance in the vicinity of petrol or other inflammable materials.

WARNING - PROPERTY DAMAGE!

Use the appliance only indoors.

▶ Operate the appliance only with the supplied power adapter.

What is Shiatsu massage?

Shiatsu (shi = finger, atsu = pressure) is a form of massage developed in Japan, which itself emerged from traditional Chinese medicine. Shiatsu massage consists of a relaxing and powerful massage with fingers, thumbs or palms. This massager mimics the movements of shiatsu massage with the help of rotating massage heads ①.

Operation

Connection

1) Connect the connection plug ⑨ on the mains adapter ⑧ with the socket ④ on the appliance.
2) Connect the mains adapter 8 into a mains power socket.

Fitting

1) Place the appliance around your neck so that the massage heads ① lie on the sides of the neck. You can use the hand loops ③ to align it. The control panel with the buttons must be on your right.

In use

Preferably, lie back for the massage and relax. Provide for a relaxing atmosphere. For example, dim the lights a little.

NOTICE

▶ Ensure that you experience the massage as comfortable and relaxing. If needs be, vary the pressure and/or your position. Stop the massage immediately if it is painful or uncomfortable.

NOTICE

▶ Never use the appliance for more than 15 minutes. A longer massage may lead to tension caused by overstimulation of the muscles.

You can select between 2 functions:

• Shiatsu massage with the massage heads ① (fast and slow)
• Warmth (2 of the massage heads ① illuminate and warm up)

You can combine various massage functions with each other or use them individually:

■ Press the "On / Off" button ⏻ ⑦. The massage heads ① begin with the slow massage.

■ Press the button "Massage" 6 to increase the massage speed. Press the button "Massage" 6 once again to stop the massage heads 1.

■ Press the "Warmth" button ⑤, to switch the warmth on. The "Warmth" button ⑤ and the massage heads ① light up. Press the "Warmth" button ⑤ again to switch the warmth function off. The light on the massage heads ① as well as the button "Warmth" button ⑤ goes out.

NOTICE

Once you have switched the warmth function on and the massage heads ① are rotating and you then stop the massage heads ① by pressing "Massage" ②, the warmth function also turns off at the same time. If you want to use the warmth function again, press the "Warmth" button ③ to reactivate the warmth function.

NOTICE

The appliance switches off automatically after 15 minutes.

If you want to terminate the massage before the end of 15 minutes and wish to switch the appliance off, press the "On/Off" button ⏻⑦.

After the massage

1) Disconnect the connection plug ⑨ from the socket ④.

2) Remove the appliance.

3) Disconnect the mains adapter 8 from the mains power socket.

Cleaning

Cleaning the removable cover

■ Switch off the appliance and then pull the mains adapte 8 out of the socket.

■ Completely open the zip on the removable cover ② to take the removable cover ② off the appliance.

Note the following washing instructions when you wash the removable cover ② in the washing machine:

	max. 30°C in the delicates cycle
	do not bleach
	do not tumble dry
	do not iron
	do not dry clean

The cover material is 70% nylon and 30% polyester.

Cleaning the appliance

RISK OF ELECTRIC SHOCK

Before you clean the appliance, always disconnect the mains adapter 8 from the mains power socket.
▶ UNDER NO CIRCUMSTANCES should you immerse the appliance in water or other liquids during cleaning!

WARNING - PROPERTY DAMAGE!

▶ Do not use any aggressive cleaning liquids or solvents. They could damage the surface.

NOTICE

The zipper on the appliance must not be opened, because it is fitted only for production-technical reasons.

1) Wipe the appliance with a damp cloth. If necessary, add a little mild detergent onto the cloth.
2) Wipe the mains adapter ⑧ off with a damp cloth.
3) Let all parts dry thoroughly before re-use.

Storage

■ Clean the appliance as described in the chapter "Cleaning".
■ Store the appliance at a clean and dry location.

Troubleshooting

Defect Cause Remedy
The appliance does not work.	The mains adapter 8 is not connected into a mains power socket.	Connect the mains adapter 8 with a mains power socket.
	The appliance is not switched on.	Switch the appliance on.
	The appliance is defective.	Contact Customer Services.
	The connection plug 9 is not connected to the socket 4 on the appliance.	Connect the connection plug 9 with the socket 4.

Disposal of the appliance

Do not dispose of the appliance in your normal domestic waste. This product is subject to the provisions of European Directive 2012/19/EU.

Dispose of the appliance through an approved disposal centre or at your community waste facility. Pay heed to the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

Disposal of the mains adapter

Do not dispose of the mains adapter with the normal household waste. This product is subject to the provisions of European Directive 2012/19/EU.

Dispose of the mains adapter at an approved disposal centre or your community waste facility. Please observe applicable regulations. Please contact your waste disposal facility if you are in any doubt.

This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.

Warranty conditions

The validity period of the warranty starts from the date of purchase. Please keep your original receipt in a safe place. This document will be required as proof of purchase.

If any material or production fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you at our discretion. This warranty service is dependent on you presenting the defective appliance and the proof of purchase (receipt) and a short written description of the fault and its time of occurrence.

If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.

Warranty period and statutory claims for defects

The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.

Scope of the warranty

This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.

The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or fragile parts such as switches, batteries, baking moulds or parts made of glass.

The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.

This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications/repairs which have not been carried out by one of our authorised Service centres.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

- Please have the till receipt and the item number (e.g. IAN 12345) available as proof of purchase.

- You will find the item number on the type plate, an engraving on the front page of the instructions (bottom left), or as a sticker on the rear or bottom of the appliance.

- If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

- You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

You can download these instructions along with many other manuals, product videos and software on www.lidl-service.com.

Service

GB Service Great Britain

Tel.: [phone] (£ 0.10/Min.)

E-Mail: [e-mail]

IAN 275419

Importer

Please note that the following address is not the service address. Please use the service address provided in the operating instructions.

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Tartalomjegyzék

Bevezetés....16

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Kazalo

Uvod....30

Avtorske pravice 30

Predvidena uporaba 30

Vsebina kompleta 31

Odlaganje embalaže med odpadke 31

Opis naprave....32

Tehnični podatki 32

Varnostni napotki....3 3

Kaj je masaža shiatsu? 35

Uporaba 35

Priključitev 35

Namestitev 36

Uporaba 36

Po masaži 37

Čiščenje 37

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Pooblaščeni serviser

SI Servis Slovenija

Tel.: [phone]

E-Mail: [e-mail]

IAN 275419

Garancijski list

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Obsah

Úvod....56

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Inhaltsverzeichnis

Einleitung 70

Urheberrecht....70

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

DEUTSCHLAND / GERMANY

www.kompernass.com
