| Product Type | Portable Bluetooth Speaker |
| Brand | SilverCrest |
| Model | SBLP 4.2 A1 |
| Dimensions (approx.) | 17.5 x 6.5 x 6.5 cm |
| Weight | Approx. 300 g |
| Power Supply | Built-in rechargeable battery (Li-ion, 3.7V, 400 mAh) |
| Battery Life | Up to 4 hours (at moderate volume) |
| Bluetooth Version | 5.0 |
| Bluetooth Range | Up to 10 m |
| Audio Inputs | Bluetooth, AUX (3.5 mm), Micro SD/TF card, USB-A |
| Radio | FM (requires TF card or USB for antenna) |
| Hands-free Function | Yes, built-in microphone |
| Controls | Buttons on top: Power, Volume +/-, Mode, Play/Pause, Next/Prev |
| Charging Port | Micro-USB |
| Charging Time | Approx. 2 hours |
| Output Power | 2 x 3 W (stereo) |
| Speaker Driver | 45 mm full-range driver |
| Frequency Range | 100 Hz - 20 kHz |
| Material | Plastic housing with fabric grille |
| Accessories Included | Micro-USB charging cable, AUX cable, user manual |
Frequently Asked Questions - SBLP 4.2 A1 SILVERCREST
User questions about SBLP 4.2 A1 SILVERCREST
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Pregnant in PDF format for free! Find your manual SBLP 4.2 A1 - SILVERCREST and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. SBLP 4.2 A1 by SILVERCREST.
USER MANUAL SBLP 4.2 A1 SILVERCREST
IT MT
ALTOPARLANTE BLUETOOTH®
Operating instructions
DE AT CH
BLUETOOTH®-LAUTSPRECHER
Bedienungsanleitung
IAN 341802_1910
IT MT
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
DE AT CH
GB / MT Operating instructions Page 53
Silhouette of a person disposing of trash into a bin (no text or symbols)natural_image
Simple line drawing of a five chasing recycling symbol (three chasing arrows in a triangle)KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANIA
www.kompernass.com
Contents
Introduction....5 5
Information about these
operating instructions .... 5 5
Copyright 55
Notes on trademarks .... 5 6
Proper use 56
Warnings and symbols used ..... 5 7
Safety 59
Basic safety instructions ..... 5 9
Risk of hearing damage 63
Notes on the radio interface ..... 6 3
Description of components ....6 5
Operation....66
Package contents and transport
inspection 66
Charging the internal battery ..... 6 7
Checking the charge level ..... 7 0
Operation and use .....70
Switching the speaker on/off .....70
Pairing the speaker with
a Bluetooth® device ..... 7 1
NFC function 73
Button functions 75
SILVERCREST®
Telephone functions ..... 7 8
BassBoost 80
TWS function 81
Connecting external playback
devices (AUX mode) 83
Charging external devices ..... 8 5
Troubleshooting....87
Cleaning....91
Storage when not in use .....91
Disposal....92
Disposal of the device ..... 9 2
Disposal of the packaging ..... 9 3
Appendix 94
Technical specifications ..... 9 4
Simplified EU declaration of conformity . .96
Information about these operating instructions
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instructions are part of this product. They contain important information about safety, usage and disposal. Before using the product, please familiarise yourself with all operating and safety instructions.
Use the product only as described and for the range of applications specified.
Keep these operating instructions as a reference and store them near the product. Please pass on all documentation incl. these operating instructions to any future owner(s) if you sell this product or give it away.
Copyright
This documentation is protected by copyright. Any copying or reproduction, including in the form of extracts, or any reproduction of images (even in a modified state), is permitted only with the written authorisation of the manufacturer.
Notes on trademarks
USB ^® is a registered trademark of USB Implementers Forum, Inc.
The Bluetooth® logotype and Bluet ooth® logo are registered trademarks of Bluetooth SIG, Inc. (Special Interest Group). Any use of the trademarks by Kompernaß Handels GmbH is made under the provisions of a licence.
The SilverCrest trademark and the retail name are the property of their respective owner.
All other names and products may be trademarks or registered trademarks of their respective owner.
Proper use
This consumer electronics device is used to play back audio files which can be transferred via Bluetooth® or 3.5 mm jack cable from an external playback device.
This device can also be used to charge mobile devices which are charged via a USB port.
The device is not intended for any other purpose nor for use beyond the scope described.
SILVERCREST®
The device is not intended for use in commercial or industrial environments.
The manufacturer accepts no responsibility for damage caused by failure to observe these instructions, improper use or repairs, unauthorised modifications or the use of unapproved replacement parts. The risk is borne solely by the user.
Warnings and symbols used
The following warnings are used in these operating instructions:
DANGER
A warning at this hazard level indicates a hazardous situation.
Failure to avoid this hazardous situation will result in serious injuries or death.
▶ Follow the instructions on this warning label to avoid the risk of death or serious injuries.
WARNING
A warning at this hazard level indicates a potentially hazardous situation.
Failure to avoid this hazardous situation could result in serious injuries or death.
▶ Follow the instructions on this warning label to avoid the risk of death or serious injuries.
CAUTION
A warning at this hazard level indicates a potentially hazardous situation.
Failure to avoid this hazardous situation could result in injuries.
▶ Follow the instructions in this warning notice to prevent injuries.
ATTENTION
A warning at this hazard level indicates a risk of property damage.
Failure to avoid this situation could result in property damage.
▶ Follow the instructions on this warning label to prevent property damage.
NOTE
▶ A note provides additional information that makes handling the device easier for you.
This symbol can be found on the housing of the device and indicates that the contents of the operating instructions must be observed.
Safety
This section contains important safety instructions for handling the device. This device complies with the statutory safety regulations. Improper use may result in personal injury and property damage.
Basic safety instructions
To ensure safe operation of the device, follow the safety guidelines set out below:
- Check the device for visible external damage before use. Do not operate a device that has been damaged or dropped.
DANGER! Do not allow children to play with the packaging material! Keep all packaging materials away from children.
There is a risk of suffocation!
SILVERCREST®
This device may be used by children aged 8 years and above and by persons with limited physical, sensory or mental capabilities, or lack of experience and knowledge, provided that they are under supervision or have been told how to use the device safely and are aware of the potential risks. Do not allow children to play with the device. Cleaning and user maintenance tasks may not be carried out by children unless they are supervised.
If the charger cable or connections are damaged, have them replaced by an authorised specialist or the customer service department.
■ Protect the charger cable from hot surfaces and sharp edges.
■ Ensure that the charger cable is not stretched tightly or kinked.
■ Always place the device on a stable and level surface. It can be damaged if dropped. Risk of injury!
- Do not expose the device to direct sunlight or high temperatures. Otherwise it may overheat and be irreparably damaged.
WARNING! Do not operate the device close to naked flames (e.g. candles) and do not place burning candles on or next to the device. This will help to prevent fires.
The device may heat up while it is charging. Place the device in a well-ventilated location during the charging process and do not cover it.
■ The device is not designed for use in rooms with high temperature or humidity (e.g. bathrooms) or excessive dust.
■ Protect the device from moisture, spray and dripping water and the penetration of liquids. Never immerse the device in water or place objects filled with liquids (e.g. vases) close to the device.
■ Switch the device off immediately and disconnect any connected cables from the device if you hear any unusual noises, smell fumes or notice any smoke. Have the device checked by a qualified specialist before using it again.
SILVERCREST®
All repairs to the device must be carried out by authorised specialist companies or by the customer service department. Improper repairs may put the user at risk. They will also invalidate any warranty claims. This device is not to be opened by the user.
■ Use only the supplied charger cable to charge the device.
WARNING! Improper use of batteries can cause fires, explosions, leakages or other hazards! Do not throw the device into a fire, as the integrated battery may explode.
■ Do not make any unauthorised modifications or alterations to the device. This device is not to be opened by the user.
■ Protection against water jets from all directions (IPX5) is only provided as long as the protective cover on the device is completely closed.
Risk of hearing damage
WARNING
Danger due to excessive volume!
Loud music can lead to hearing damage.
▶ Avoid excessive volume levels when using the device, especially over long periods and when using headphones.
Notes on the radio interface
■ Switch off the device if you are in an aeroplane, hospital, operating theatre or in the vicinity of a electronic medical system. The transmitted radio waves can affect the functionality of sensitive devices.
- Keep the device at least 20 cm away from a pacemaker or implanted defibrillator, as the proper functioning of the pacemaker or the implanted defibrillator could be affected by radio waves.
■ The transmitted radio waves can cause noise interference in hearing aids.
SILVERCREST®
- Do not use the device in the presence of flammable gases or in a potentially explosive atmosphere (e.g. in a paint shop) while the radio component is activated, as the transmitted radio waves can cause an explosion or ignite a fire.
■ The range of the radio waves is dependent on the environment and the ambient conditions.
■ Data transmissions via a wireless connection can be intercepted by unauthorised third parties.
Description of components
(See fold-out page for illustrations)
① Battery charge level display (with LED)
② button (with LED)
3 button
4 T button
5 ▶|| button
6 + button
⑦ UP button (with LED)
8 TWS LED
9 Protective cover
10 Microphone
11 USB type-A socket OUTPUT (charging output)
12 AUX input (3.5 mm ∅ jack socket)
13 Micro USB connection INPUT (charging input)
14 USB charging cable (USB type-A to micro USB)
15 3.5 mm jack cable (3.5 mm to 3.5 mm)
Operation
Package contents and transport inspection
◆ Remove all parts of the device and the operating instructions from the packaging.
◆ Remove all packaging material.
The package contents include the following components (see fold-out page for illustrations):
- Bluetooth® speaker SLB 20 A1
● Charging cable (USB Type-A to Micro USB)
- 3.5 mm jack cable (3.5 mm to 3.5 mm)
- Quick start guide
• These operating instructions
NOTE
▶ Check the package for completeness and signs of visible damage.
If the delivery is incomplete or damage has occurred as a result of defective packaging or during transport, contact the service hotline (see section Service).
Charging the internal battery
ATTENTION
▶ Charge the internal battery only in dry indoor spaces.
NOTE
▶ Before using the speaker, the integrated battery must be completely charged.
▶ Never charge the speaker while using it to charge an external device at the same time.
▶ Use only the supplied USB charging cable 14 to charge the speaker.
▶ Always disconnect the USB charging cable 14 when charging is complete.
Make sure that the speaker is switched off. If the speaker is switched on, the battery charge level display ① lights up and the button ② flashes alternately orange and blue (or lights up blue if there is an active Bluetooth® connection). To turn off the speaker, hold down the button ② for about 3 seconds.
SILVERCREST®
Connect the USB type-A plug of the USB charging cable 14 to a USB power supply (5 V, at least 900 mA) or a USB 3.0 port (can be recognised by the blue USB socket) on your computer.
Connect the Micro USB plug of the USB charging cable 14 to the Micro USB connection INPUT 13 on the speaker.
The following table gives an approximate indication of the speaker's charge level using the four LEDs of battery charge level display ①:
| LED display | Charge level |
| One LED is flashing < 5% | |
| One LED is on 5–25% | |
| Two LEDs are on 25–50% | |
| Three LEDs are on 50–75% | |
| Four LEDs are on 75–100% |
NOTE
The speaker can also be charged during music playback. However, this increases the charging time.
The battery charge level display 1 lights up during charging. When the battery is fully charged, the battery charge level display 1 goes out.
▶ Charging takes about 4–6 hours at a charging current of 2000 mA. When the battery is fully charged, you can play back music for around 8 hours at a medium volume (70 dB (A)). The playback time may vary depending on usage (volume/mode).
When the battery is dead, the speaker beeps every 2 minutes and the first LED of the battery charge level display 1 starts flashing. When the battery charge level drops too low, the speaker switches off automatically.
Checking the charge level
You can also check the speaker's charge level when it is not charged or while it is being used for charging.
While the device is switched on, briefly press any button. The four LEDs of the battery charge level display ① show the current charge level of the speaker for about 10 seconds.
NOTE
For information about checking the speaker's approximate charge level using the battery charge level display ①, refer to the table in the section Charging the internal battery.
Operation and use
Switching the speaker on/off
Press and hold the ⏻ button ② for about 3 seconds to switch the speaker on and activate the Bluetooth® function. The ⏻ button ② flashes orange twice and you will hear a beep.
Press and hold the 🎊button ② again for about 3 seconds to switch the speaker off and deactivate the Bluetooth® function. You will hear a beep and the 🎊button ② flashes orange twice.
NOTE
The speaker switches off automatically after 15 minutes if there is no playback and no buttons are pressed.
Pairing the speaker with a Bluetooth® device
Before you can use the speaker for music playback via Bluetooth®, you must pair it with a compatible external Bluetooth® playback device.
Press and hold the button ② for about 3 seconds to switch the speaker on and activate the Bluetooth® function. The button ② flashes orange twice and you will hear a beep. The button ② then flashes alternately orange and blue.
- Set the external playback device so that it scans for Bluetooth® devices. You can find a detailed description of how to do this in the operating instructions for your external playback device.
Select the entry SLB 20 A1 from the list of found Bluetooth® devices in the settings menu of your external play-back device. The external playback device is now automatically connected to the speaker via Bluetooth®.
You will hear a short beep when the connection has been successfully established. The ⏻ button ② lights up permanently blue in Bluetooth® mode.
You can now use the speaker to listen to music from your external playback device wirelessly.
NOTE
To end the Bluetooth® connection, press the ⚙ button ③ (see also the section Button functions).
NOTE
If the Bluetooth® function is activated, the speaker switches itself off automatically after 3 minutes if no Bluetooth® connection is made to an external playback device.
The next time you turn on the speaker, it will connect automatically to the last-connected external playback device. If your external playback device does not automatically reconnect to the speaker, you will have to re-establish the connection manually. You can find a detailed description of how to do this in the operating instructions for your external playback device.
NFC function
The NFC function (Near Field Communication) can be used to quickly and easily establish a Bluetooth® connection with an already coupled external playback device.
NOTE
▶ Using the NFC function to establish a Bluetooth® connection only works under the following conditions:
- The external playback device is less than 1 cm from the NFC logo on the top of the speaker.
- The speaker is not connected to another external playback device via Bluetooth®.
Make sure that the speaker is switched on.
- Turn on the NFC function on the external playback device. You can find a detailed description of how to do this in the operating instructions for your external playback device.
- Hold the external playback device less than 1 cm from the NFC logo on the top of the speaker.
Alternatively, you can lay the external playback device directly onto the NFC logo on the top of the speaker.
◆ Confirm the connection once the corresponding message appears on the display of the external playback device.
- The external playback device is automatically connected to the speaker via Bluetooth®.
You will hear a short beep when the connection has been successfully established. The ⏻ button ② lights up permanently blue in Bluetooth® mode.
You can now use the speaker to listen to music from your external playback device wirelessly.
Button functions
| Button Function | |
 | ▶ Press and hold for approx. 3 seconds to switch the speaker on/off. |
 | ▶ Press briefly to switch on the BassBoost function. ▶ Press again to switch off the BassBoost function. |
Button Function
 | ▶ Press briefly to disconnect the currently connected external Bluetooth® play-back device from the speaker (only if there is an active Bluetooth® connection). Afterwards, the button 2 flashes alternately orange and blue and the speaker can again be connected to an external playback device. |
 | ▶ Press briefly to play/pause the music (only during play-back via Bluetooth®). ▶ Press briefly to mute the speaker. Press briefly again to unmute (only during AUX operation). |
Button Function
 | ▶ Press briefly to decrease the volume. When you reach the minimum volume, you will hear a short beep. Alternatively, you can decrease the volume on the external playback device. ▶ Press and hold for around 3 seconds to jump back to beginning of the current track. Within 3 seconds, press and hold again for around 3 seconds to jump to the previous track (only during playback via Bluetooth®). |
 | ▶ Press briefly to increase the volume. When you reach the maximum volume you will hear a short beep. Alternatively, you can increase the volume on the external playback device. ▶ Press and hold for around 3 seconds to jump to the next track (only during play-back via Bluetooth®). |
NOTE
▶ Depending on the external playback device being used and its operating system, it is possible that the volume on the speaker and the external playback device are adjusted independently of each other. For example, if the volume of the speaker is set to maximum and the volume of the external playback device is set to minimum, you will hear nothing through the speaker.
▶ Depending on the external playback device being used and the operating system, it is possible that not all functions will be supported.
Telephone functions
The following telephone functions are only available when the speaker and the smartphone are connected to each other via Bluetooth®.
NOTE
It is possible that not all functions will be supported depending on the smartphone used and its operating system.
Making a call
NOTE
The speaker has an integrated microphone 10 on the right front side, which can be used for telephone calls.
Use your smartphone to dial the required telephone number. The call is automatically transferred to the speaker.
♦ Speak into the smartphone’s micro phone or into the speaker microphone 10 to make the call. The sound is played through the speaker.
Accepting/ending/rejecting a call
NOTE
If you are listening to music and receive a call, you will hear the ring tone via the speaker and playback is stopped. After finishing the call, playback will be resumed automatically.
▶ Acceptance/termination of the call can be carried out via the smartphone or the speaker. The sound is automatically played back through the speaker.
SILVERCREST®
| ▶|| button | Function |
| Press 1 x briefly (for incoming call) | Accept call |
| Press 1x briefly (during call) | End call |
| Press and hold for approx. 3 seconds (for incoming calls) | Reject call |
| Press and hold for approx. 3 seconds (during a call) | Switch play-back between speaker and smartphone |
BassBoost
You can use the BassBoost function to increase the bass playback.
- Briefly press the UP button ⑦ to activate the BassBoost function. The UP button ⑦ lights up green.
- Briefly press the UP button ⑦ again to switch off the BassBoost function. The light on the UP button ⑦ goes out.
TWS function
The TWS ("True Wireless Stereo") function allows two speakers to be connected to each other.
The left speaker functions as the main speaker which is connected to a Bluetooth® device. This speaker transmits the sound coming from the Bluetooth® device to the right speaker.
If you purchase a second loudspeaker of the same type SLB 20 A1 (IAN 341802), it is possible to connect both loudspeakers to each other and use them as a stereo loudspeaker system via the TWS function.
You can purchase a second loudspeaker at www.lidl.de/de/onlineshop. If the speakers are out of stock, you can also purchase an additional speaker at www.kompernass.com.
Switching on TWS mode
NOTE
▶ Do not activate TWS mode if there is an existing Bluetooth® connection between a speaker and an external Bluetooth® device.
♦ Switch on both speakers.
- Press the UP button ⑦ on the first speaker (which will function as the left speaker) for about 3 seconds. You will hear a beep and the TWS LED ⑤ flashes green during the pairing.
If the pairing of the two speakers has been successful, you will hear a short beep. TWS mode is active and the TWS LEDs ⇌ 8 on both speakers light up green.
- Pair the left speaker with an external Bluetooth® device.
♦ Start playback on the external Bluetooth® device.
NOTE
If you do not pair the two speakers within 3 minutes, the speakers will turn off automatically. In this case, you will have to switch the speakers back on again before restarting the pairing process.
▶ Make sure you position the left and right speakers correctly for playback.
The Play/Pause/Forward/Back/Bass-Boost buttons work on both speakers in TWS mode.
Switching off TWS mode
◆ Press the UP button ⑦ on the left or right speaker for about 3 seconds to deactivate TWS mode. You will hear a beep and the TWS LED ③ goes out on both speakers. Playback is resumed via the left speaker.
NOTE
◆ Press the UP button ⑦ on the left speaker for about 2 seconds to reactivate the TWS mode.
Connecting external playback devices (AUX mode)
In AUX mode, you can connect external playback devices such as an MP3 player or a smartphone to the speaker to use them as the playback source for the speaker.
◆ Make sure that the speaker is switched off.
Connect the 3.5 mm jack cable ^15 to the external playback device and the AUX input ^12 on the speaker.
SILVERCREST®
- Press and hold the ⏻ button ② for about 2 seconds to switch the speaker on. You will hear a beep and the ⏻ button ② lights up orange.
◆ Start playback on the external play-back device.
- Set the desired volume using the button ⑥ or the ▶ button ④ on the speaker. Alternatively, you can adjust the volume on the external playback device.
◆ Press the ▶|| button ⑤ if you want to mute the speaker. Pressing the ▶|| button ⑤ again briefly will unmute the speaker.
To exit AUX mode, turn off the speaker and remove the 3.5 mm jack cable 15 from the AUX input 12 on the speaker.
NOTE
In AUX mode, the speaker switches off automatically after 15 minutes if no playback is made via an external playback device.
In AUX mode, the Bluetooth function is deactivated. It is also no longer possible to use the button 6 or the button 4 to skip to the next/previous track.
Charging external devices
Make sure that the speaker is switched on.
Connect the Micro USB plug of the USB charging cable 14 to the Micro USB connector of the external device you want to charge.
Connect the USB type-A connector on the USB charging cable 14 to the USB type-A socket OUTPUT 11 on the speaker. The charging process begins automatically.
NOTE
▶ Alternatively, you can also use the original USB charging cable provided by the respective device manufacturer to charge an external device on the speaker.
If charging does not start automatically, briefly press the ⏻ button ② to start the charging process.
During the charging process, the current charge level of the speaker is indicated by the four LEDs of the battery charge level display ① (see table in the section Charging the internal battery).
To stop charging, disconnect the USB charging cable 14 from the external device and the speaker. The four LEDs of the battery charge level display 1 go out after about 10 seconds.
Troubleshooting
If you cannot connect the speaker to a compatible external Bluetooth® playback device, proceed as follows:
| Possible cause Remedy | |
| The Bluetooth® function is de-activated on the external playback device. | Activate the Blue-tooth® function on the external playback device. |
| The 3.5 mm jack cable 15 is connected to the AUX input 12 on the speaker. | Remove the 3.5 mm jack cable 15 from the AUX input 12 on the speaker. |
| The speaker is still connected to another external playback device. | Terminate the con- nection to the other external playback device. |
Possible cause Remedy
The speaker is more than 10 metres away from the external playback device or there are obstacles or other electronic devices in between.
Reduce the distance between the speaker and the external playback device. Make sure that no obstacles or other electronic devices can obstruct the connection.
The speaker is not switched on.
Switch on the speaker.
The following table will help you to identify and rectify further possible faults:
| Fault | Possible cause | Remedy |
| The speaker will not switch on. | The internal battery is empty. | Charge the internal battery (see section Charging the internal battery) |
| The speaker is not switched on. | Press and hold the ⏻ button 2 for about 2 seconds to switch the speaker on. | |
| No sound. | The volume is set to minimum. | Set the desired volume with the ➕ button 6. If necessary, also increase the volume on the external play-back device. |
SILVERCREST®
| Fault | Possible cause | Remedy |
| The speaker is muted in AUX mode. | Press the ▶II button 5 to unmute the speaker. | |
| No sound. | The external playback device is muted in AUX operation. | Unmute the external play-back device. |
| In AUX mode, the 3.5 mm jack cable 15 is not correctly connected. | Ensure that the 3.5 mm jack cable 15 is correctly connected to the AUX input 12 on the speaker and the external playback device. |
Cleaning
ATTENTION
▶ To avoid irreparable damage to the device, ensure that no moisture can penetrate the device during cleaning.
▶ Do not use caustic, abrasive or solvent-based cleaning materials. These can damage the surfaces of the device.
- Clean the housing of the device with a lightly moistened cloth and a mild detergent only.
Storage when not in use
◆ Store the device in a location which is clean, dry, dust-free and not in direct sunlight.
◆ To ensure a long battery life, charge the battery at regular intervals.
Disposal
Disposal of the device
This disposal is free of charge for the user. Protect the environment and dispose of this device properly.
Disposal of the packaging
Dispose of packaging materials that are no longer needed in accordance with applicable local regulations.
Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings:
1-7:plastics,
20-22: paper and cardboard,
80-98: composites
Appendix
Technical specifications
| Operating voltage, current input | 5 V---(DC), 2000 mA (via Micro USB connection) |
| Operating voltage, current output | 5 V---(DC), 1000 mA (via USB type-A connection) |
| Bluetooth® specifications | Version 4.2 (up to 10 m range) |
| Frequency band 2.4 GHz | |
| Transmission output < 10 dBm | |
| Supported Bluetooth® profiles | HSP*/HFP*/AVRCP*/A2DP* (*if supported by the Bluetooth® playback device) |
| Speaker output | 2 x approx. 10 W RMS (10% THD) |
| Speaker impedance | 4 Ω |
| Frequency range 20–20,000 Hz | |
SILVERCREST®
| Integrated battery (lithium-ion) | 7.4 V / 2600 mAh (19.24 Wh) |
| AUX input | 3.5 mm ∅ jack socket |
| USB charging socket (DC 5 V) | Micro USB 2.0 |
| Operating time | approx. 8 h (music playback at a medium volume of 70 dB (A)) |
| Charging time | approx. 4–6 hrs (at a charging current of 2000 mA) |
| Operating temperature | 5°C to 35°C |
| Storage temperature | 0°C to 40°C |
| Humidity (no condensation) | ≤ 75% |
| Protection class | IPX5 (Protection against water jets from any direction) |
| Dimensions | approx. 190 x 68 x 70 mm |
| Weight approx. 600 g |
Simplified EU declaration of conformity
CE
Kompernaß Handels GmbH hereby declares that the radio system Bluetooth® Speaker SLB 20 A1 complies with the essential requirements and other relevant regulations of the RE Directive 2014/53/EU and the RoHS Directive 2011/65/EU.
The complete EU Declaration of Conformity is available at the following Internet address: www.kompernass.com/support/341802_DOC.pdf
KompernassHandelsGmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.
This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g. IAN 123456) available as proof of purchase.
■ You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.
SILVERCREST®
This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 123456.
Service
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
Service Malta
Tel.: 80062230
E-Mail: kompernass@lidl.com.mt
IAN 341802_1910
Importer
Please note that the following address is not the service address. Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Inhaltsverzeichnis
Einführung ..... 1 0 3
Silhouette of a person disposing of trash into a bin (no text or symbols)natural_image
Simple line drawing of a five chasing recycling symbol (three chasing arrows in a triangle)KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DEUTSCHLAND
www.kompernass.com
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
