SMARTPRO ACTIVE FC8812 - Robot vacuum PHILIPS - Free user manual and instructions

Product type	Robotic vacuum cleaner
Brand	PHILIPS
Model	SMARTPRO ACTIVE FC8812
Dimensions (L x H)	80 × 330 mm
Weight	1.93 kg
Battery type	Lithium-ion
Battery voltage	14.8 V
Runtime	90 minutes
Charging time	3.5 hours
Dust container capacity	0.4 L
Noise level	58.3 dB
Climbing height	15 mm
Cleaning modes	4 modes (zigzag, random, spiral, wall following)
Cleaning system	3 steps (brushes, suction, dry mopping)
Nozzle	TriActive XL (brushless)
Sensors	6 infrared sensors, dust sensor, intelligent detection system (20 sensors)
Scheduling	Weekly, 24h
Floor types	Carpet, hard floor
Included accessories	Remote control, base station, side brushes, filter, dry mop cloth, power adapter
Color	Denim blue, satin copper decorative ring
Standby consumption	0.65 W

Frequently Asked Questions - SMARTPRO ACTIVE FC8812 PHILIPS

How to schedule weekly cleaning?

Use the remote control or buttons on the device to access the weekly scheduling function. You can set up to 6 days (one day excluded) with different times, up to 24 hours in advance.

What to do if the vacuum does not detect obstacles?

Check that the 6 infrared sensors are not obstructed by dust or debris. Gently clean them with a dry cloth. Also make sure the device is on and the battery is charged.

How to clean the filter?

The filter should be cleaned regularly. Open the dust compartment, remove the filter and tap it gently to remove dust. You can also rinse it with cold water and let it dry completely before reinstalling.

Can the vacuum clean carpets?

Yes, the Philips SmartPro Active is designed for hard floors and carpets. With its TriActive XL nozzle and detection system, it adapts its power for effective cleaning on both surfaces.

What is the battery runtime?

The Lithium-ion battery provides a runtime of 90 minutes in normal operation. Charging time is approximately 3.5 hours.

How to change the side brushes?

The side brushes are clipped. To replace them, gently lift the worn brush and insert the new one by pressing until it snaps into place. Make sure to use compatible replacement brushes.

Can the vacuum cross door thresholds?

Yes, it can climb obstacles up to 15 mm high, such as door thresholds or small rugs. For higher obstacles, use manual mode via the remote control.

What to do if the vacuum gets stuck?

The device is equipped with 20 sensors and a gyroscope to avoid jams. If it gets stuck, turn it off, remove obstacles, then restart. You can also use the remote control to free it.

How to use the mopping mode?

Attach the dry mop cloth (click-on mopping) to the base of the vacuum. Activate cleaning: the vacuum first passes the mop over the floor to pick up fine dust. This mode is ideal for hard floors.

Where to find spare parts?

Spare parts (brushes, filters, mop cloth, battery) are available on the PHILIPS website or from authorized dealers. Use the model number FC8812 to order compatible accessories.

USER MANUAL SMARTPRO ACTIVE FC8812 PHILIPS

Philips SmartPro Active Robot vacuum cleaner

3-step cleaning system

90 min runtime
Click-on mopping
TriActive XL nozzle

FC8812/01

Thorough and advanced clean, now 2 times faster*

WithTriActive XL nozzle and 3-Step Clean system

The Philips SmartPro Active robot vacuum cleaner cleans 2 times faster thanks to the combination of TriActive XL brushless nozzle, strong suction power and 3-Step clean system with dry mopping.

Cleans on its own

• Infrared sensors for detecting and avoiding obstacles
  Schedule your weekly cleaning
• Powerful Li-lon battery for 90 min operating time
• Smart Detection System adapts cleaning to any environment
• TriActive XL nozzle cleans double the area in one stroke

Extra accessories included

• Remote to control the robot from a distance

Thorough cleaning performance

3-step cleaning system including dry mopping function
- 4 cleaning modes to adapt to different areas
- The robot detects the most dirty areas for a deeper clean

Highlights

Infrared sensors

The new Philips robot vacuum cleaner is equipped with 6 Infrared sensors for detecting and avoiding obstacles such as walls, lamps or cables, so your floors are cleaned carefully. Finally you can enjoy a clean house without your interference.

Scheduling Function

Cleaner offers a weekly scheduling function, so you can program your next cleaning session one week in advance, with the possibility to set a different time for each day excluding one day. The Robot will activate even if you are not at home, so you can enjoy a clean house.

Powerful Li-Ion battery

The powerful Lithium-iron battery has a longer lifetime and a shorter charging time than standard batteries. The new robot vacuumcleaner runs up to 90 min.

3-step cleaning system

First two long brushes swipe dirt and dust into the path of the robot. Then, the nozzle picks up dirt and dust thanks to its powerful motor. Lastly, the click-on mopping pad enhances the cleaning by collecting even the finest dust from your floors.

Dust Sensor

The dust sensor feature enables the robot to automatically recognize the areas where most dust is accumulated, so it stays in that area for a few seconds more to have a deeper cleaning.

4 cleaning modes

4 cleaning modes to adapt to different areas in your home. The z-type mode drives the robot in a parallel zig-zag pattern, when it discovers a

relatively larger space. The bounce mode drives the robot in a straight line, when it bumps into an object the robot will choose another random direction. With the spiral mode the robot moves in a spiral motion with an increasing radius. The wall-following mode drives the robot to clean while staying close and parallel to the wall.

Remote control

The remote control allows you to control the Robotic Vacuum cleaner from a distance and perform several actions. You can tell the robot to start and stop, guide it to any direction, change the cleaning path or ask the robot to go back to the docking station.

Smart Detection System

The new robot vacuum cleaner is equipped with the Smart Detection System, a combination of smart chips, up to 20 sensors, gyroscope and accelerometer, that makes the robot efficient to clean on its own. The Robot understands the environment and chooses an optimal cleaning strategy to clean your home as quickly as possible. The robot does not get jammed and returns to its docking station when necessary.

Specifications

Performance

• Battery type: Li-lon
• Battery voltage: 14.8 V
• Charging time: 3.5 hour(s)
  Runtime: 90 minute(s)
  Sound power level: 58.3 dB

Usability

24-hour scheduling
- Dust sensor
- Smart detection system: 20 sensors
- Threshold climbing: 15 mm
- Cleaning modes: 4
Infrared sensors
Weekly scheduling
- Types of Floors: Carpet, Hardfloor

Design

Color: Denim blue

Filtration

• Dust capacity: 0.4 L

Nozzles and accessories

• Accessories included: AC power adaptor
• Other accessories: 1 × Filter, Base Station, Side brushes (1 pair), Dry mop, Remote control

Sustainability

• Stand-by power consumption: 0.65 W

Weight and dimensions

• Dimensions of product (LxWxH): 80 × 330 mm
  Weight of product: 1.93kg
  Weight incl. packaging: 3.6kg

Design specifications

• Deco Ring: Bright Copper Satin
