Product Type	Tablet
Brand	Allview
Model	Viva H8 LTE
Display Size	8 inches (approx.)
Battery Type	High capacity Polymer battery
Charging	USB port or DC charger (5V-5.2V, 1A)
MicroSD Support	Up to 32 GB
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth, LTE
Camera	Front camera
Audio	Speaker, microphone, 3.5 mm headphone jack
Ports	MicroUSB, MicroSD slot, SIM slot
Navigation	Sygic GPS (30-day trial)
SAR Value	1.175 W/kg
Operating System	Android
Weight	Approximately 350 g
Dimensions	Approximately 210 x 125 x 9 mm
Safety	CE certified, RoHS compliant

Frequently Asked Questions - Viva H8 LTE Allview

How do I charge the tablet?

Use the included USB cable to connect to a computer or a DC charger (5V-5.2V, 1A). If the battery is completely empty, it may take 30 minutes before the charging indicator appears.

How do I insert a MicroSD card?

Insert the MicroSD card face up into the slot until it clicks. To remove, gently push it in until it pops out. Always power off the device before inserting or removing to avoid data loss.

How can I reset the tablet if it becomes slow?

Perform a power reset by shutting down and turning the device back on. For a factory reset, go to Settings > Backup & reset > Factory data reset. This will erase all data.

Why does the Wi-Fi connection disconnect?

If the screen times out and the device goes into standby, Wi-Fi may turn off to save battery. It will automatically reconnect within about 5 seconds after waking the device.

Some video files won't play. Why?

The device is compatible with most common video formats, but some may require conversion. Use a PC video converter to change the file to a compatible format.

How do I use the Sygic GPS navigation?

Open the Sygic app and tap Start Trial. Select maps and download them. You can use the navigation for 30 days for free. For support, visit help.sygic.com.

How do I factory reset the device?

Go to Settings > Backup & reset > Factory data reset. Confirm to erase all personal data and restore default settings. Backup important files first.

How do I change the language?

Go to Settings > Language & input and select your preferred language from the list.

What should I do if the tablet won't turn on?

First, check if the battery is drained. Connect the charger and wait at least 30 minutes. If still unresponsive, try a reset by holding the power button for 10 seconds. Contact customer support if the issue persists.

How do I connect the tablet to a computer?

Connect the tablet to a PC using the USB cable. On the tablet, tap the USB already connected notification and select Open USB storage to transfer files.

USER MANUAL Viva H8 LTE Allview

Front view of a black rectangular electronic device with no visible text or symbols on its surface.

User manual....3

Two views of a black smartphone showing front and side views with labeled components (no text or symbols on the device itself)

EN

1 Camera
2 Power
3 MicroUSB
4 Microphon
5 Earphone
6 Volume
7 MicroSD
8 Speaker
9 SIM slot

HU

This image contains no text. The horizontal line is a stylistic or background element and must be ignored according to the rules.

1
2
3
4
5
6
7
8
9

GR

kámera

κουμπί

φις micro

μικρόφωνο

ακουστικά

όγκου κουμπί

MicroSD

μεγάφωνο

υποδοχή sim

RO

Camera
Buton pomire
Mufa
Microfon
Mufa casti
Buton volum
Slot MicroSD
Difuzor
Slot SIM

DE

Kamera

Einschaltungskno

MikroUSB Muffe

Mikrofon

Muffe des

Lautstärke

MikroSD Slot

Lautsprecher

SIM-Slot

SR

Kamera
Dugme za
MicroUSB
mikrofon
Priključak za
запремина
MicroSD slot
zvučnik
СИМ слот

User manual Viva H8 LTE

Foreword

Thank you for purchasing our product.

These operational guidelines for the user, to ensure you a quick and convenient to use, read the instructions carefully before use.

This player is a specialized top quality portable player product with a series of remarkable functions. There will be no separate notice in the case of any change in content of this text.

This company will continue to provide new functions for the development of the product, and there will be no separate change in the case of any change in the product's performance and functions. While this unit is used as a mobile hard disk, this company will not be held liable for the security of files saved in the disk.

If the actual setup and the application methods are not identical to those as set forth in this manual, please access to the latest product information of this company's website.

Basic Operations

Power on

In the shutdown state, long press Power button

Power off

In the power on state, long press the Power key 3 seconds then pop-up device options, select "Power off" for shut down.

Sleep

Under normal operating conditions, short press the power button, into hibernation. Now, the screen will close. Short press the power button again to resume the normal mode. You can set the device to enter sleep mode automatically after a desired time of non-operation.

Power reset

If you experience a slow operation of the device in normal use, you can shutdown and power on again to reset the operating system.

Screen time out

If you do not contact the player within the set time, and do no operate by the button, the screen will be automatically turned off.

In any state, short press Power button and for activation; Then skid the lock upwards to the green of spotted which will accomplish to access to the upper interface.

If it is necessary to deactivate the screen time out function, you can set the [Screen time out] option under [Display] function into "Never".

Using the Micro SD card

After this unit is connected with the computer, you will find two moving disks. The first one is the built-in memory disk for this unit and the other is the disk for the MicroSD card. If no card is inserted, the second disk can not be opened. This unit supports the extension of the MicroSD card from 128MB to 32GB.

Inserting and Pulling out the Micro SD card

Inserting:

Put the Micro SD card face up (side with words), and slightly force the card into the socket of the card, i.e. connecting the unit. Under this state, you can play the content in the Micro SD card.

Pulling:

Slightly push the Micro SD, and it will bounce by a section, and then you can take it out.

Caution:

Please perform inserting and pulling operation when power is off? Otherwise, it will lead to the loss or damage to the files within the unit! If no card is inserted, the computer will be unable to perform read and write operation for the disk notes of the later removable disk (Micro SD card).

Battery:

High capacity Polymer battery is used for this unit.

The duration available of the battery power depends on volume, types of playing files and operation of batteries. The player can be set up by the user as "user define power off time" or "display setup" to save batteries.

Charging:

This unit can be recharged by USB port, you can also use DC Charger:

- take out the DC charger, plug it into the wall outlet with AC 220V (output current 1A output voltage 5V\~5.2V), then plug in the charging jack into the device usb plug.

Warnings for charging:

A new battery may be empty and not charged before you get the device.

If the device is not used for long time, it is better to charge it to full capacity every 2 or 3 months during storage.

Power adapter is a key component of the portable player, which play a crucial

5 En

En

role in keeping the portable player's normal work and protecting your security when using the player, a long-term customer surveys and after-sales service Practice shows that the malfunction of the portable player, in many cases were caused by using inappropriate accessories, in particular the power adapter.

Using the substandard power adapter will shorten the life of the portable player by considerably, the voltage instability will seriously affected the normal work of the portable player and bring permanent damage on the player's performance and reliability. Using the substandard power adapter will also reduce the vocal quality of the players, shutdown the player when you use it. In addition, using the substandard power adapter will cause combustion and explosion which will disserve the safety of the consumers.

Return to main interface

In any interface, touch icon " " to access to main interface.

Return to upper interface or menu

In any interface, touch icon "←", click the "": "key to access to upper interface or menu. You can also click short press the " "key to accomplish it.

Points for Attention

1. Do not use the player in exceptionally cold or hot, dusty, damp or dry environments;
2. Do not allow the player to fall down while using it.
3. Please charge your battery when:
   A. Battery power icon shows an empty icon;
   B. The system automatically shuts down and the power is soon off when you switch on the unit once again;
   C. There is no response if you operate on any key;
4. Please do not disconnect power abruptly when the player is being formatted or in the process of uploading or downloading. Otherwise it may lead to the error in the program;
5. When this unit is used as a mobile disk, the user shall store or export files in

the proper file management operation method. Any improper operation method may lead to the loss of files, for which this Company will be held no liable;

1. Please do not disassemble this unit by yourself. If there is any issue, please contact the dealer;
2. There will be no separate notice in the case of any change in the functions and performance of this product;

To avoid the problems that might occur with the service shops approved by Visual Fan Ltd. (because Visual Fan reserves the right to stop the collaboration with any service shop which was previously approved and mentioned in the warranty card on the date on which the product batch was sold on the market), before taking a product to the service shop, please check the updated list of approved service shops on Allview website at the section: "Support&Service - Approved service".

We do not assume the responsibility in case the product is used other way than stated in the user guide. Our company reserves the right to bring modifications in the content of the user guide without making this fact public.

All the modifications will be listed on the company website (www.allviewmobile.com) in the section dedicated to the specific product which is subject to modifications. The content of this guide may vary from the one existing in electronic format within the product. In such case the latter one will be taken into consideration

Activate your Sygic GPS Navigation

(optional)

The world's most popular offline GPS navigation app from Sygic is preinstalled on this device. Enjoy navigation in 90 countries around the globe for 30 days for free.

1. Click on Sygic icon and launch application.

2. The application will download necessary files.

1. Select "Start Trial" button.

2. Choose one or more maps and click "Proceed" to download.

3. Please don't close the application and wait until the end of the download.

4. Select "Continue trial" to use Sygic GPS navigation for 30 days for free. Or purchase the full

lifetime license of the navigation. If you choose trial you can purchase full lifetime license later in "My Sygie" menu.

1. Select the navigation voice
2. You can join to Sygic community by entering your email.
3. Enjoy all your journeys with Sygic GPS navigation!

For more information and support, please visit our website http://help.sygic.com/.

Settings

In the main menu, select the "Settings" option to be able to access the System Settings folder. Directly click can assess picture set options interface.

Description of functions:

1. WiFi

Wi-Fi: Open/close the wireless connection

1. Bluetooth

Wi-Fi: Open/close the bluetooth connection

1. Data usage

Display data usage

1. Sound setting

Volumes: set the notification, the media and the alarm clock volume.

Default notification: click to open notifications settings menu.

Touch sounds: if checked, the touch screen pressing will make a sound

1. Display settings

Brightness: adjust brightness of the screen.

Wallpaper: you can choose wallpaper from Gallery and Wallpaper

Sleep: Setting screensaver standby time.

When the device is in stand-by the Wi-Fi function will be deactivated to save

battery.

Font size: set the font size

1. Storage

Check the PMP memory and available storage.

1. Battery

Shows information about battery status and usage

1. Apps

Here you can view and manage the installed applications

1. Accounts and sync

Information and sync settings for your user accounts.

1. Location services

Contains settings for activation or deactivation of the localization options.

1. Security

Screen lock: set screen lock method: slide, pattern, PIN, password and so on many kinds of mechanisms.

Make passwords visible: if marked you may see the letters typed in the password box.

Unknown sources: allows you to install applications that do not come from Google Play™ store.

1. Language & input

Set language and area, input method etc.

1. Backup & reset

Can backup, restore the machine settings and data

1. Date & time

Set the date, time, time zone and time display format

1. Accessibility

Options for screen rotation, text magnifier, password spelling etc.

16. Developer options

Settings and options for Android ^TM developers.

17. About device

Check the machine software version and other information.

Connect the computer

This machine can be connected to a PC through the USB cable, by which the data is copied or deleted. The specific procedure is as follows.

1. Connect the machine through the USB cable to the PC's USB port and you will get notification "USB already connected".
2. Click "USB already connected" notice options, and choose the "open USB storage devices", and you can manage the files from the memory of your machine.

Factory data reset

If this machine is infected, or third party software installed to run this machine is unusual, but through the recovery factory Settings, remove the third party software, and restore the state out by default. Into this machine "Settings"-" privacy ", select "Factory data reset" item, confirmed, will remove all of the data

Common troubleshooting

1. What is the APK file? It and Android PMP have what relation?

A: APK is the abbreviation of Android Package. APK files can be installed and

executed directly to Android system of the machine.

2. How to get the APK application

A: You can download via PC-side installation, you can also "Google Play store" online to download and install.

3. Why WIFI connection will interrupt

A: If set "screen time", when the player overtime in standby screen saver, WIFI function will be closed to save electricity purpose; When sensei player, WIFI function will be in about 5 seconds to resume automatic connection.

4. Why some download APK program not working properly

A: Download the APK software, mostly by the user to development, without the platform compatibility testing, and part of the hardware and software for Android system version has a special requirements, so there could be downloaded APK documents not compatible, not the normal operation of the phenomenon, the player itself quality problems.

5. Why does not the machine show charging state

A: When the battery is extremely low, need to use DC charger charging half an hour or more to show charging status

6. Why can't realize the gravity induction function

A: This machine support gravity feeling function, can be through the shaking to switch the screen machine did show, but some of the application does not support the gravity induction function, it can't realize the screen of switching function, this is the software support question, the functionality of the player.

7. Players can't boot

1) Check the battery no electricity
2) Connect the ac adapter after inspection again
3) If after charging still unable to boot, please contact our customer service

8. Can't Hear the voice in the headset

1) Please check the volume is set to 0

2) Please check whether the connection headphones

9. Player charging abnormalities

1) Please confirm that the use of the equipment complies with the charger of the player charger requirements

2) Such as connection USB charging, please do not connect to computers lead USB interface

10. Why some downloaded video cannot be played

This device is compatible with formats of video files from internet but due to the fact that video formats may vary there is a possibility not to be compatible with some of them. In these cases it is recommended to use the PC and some video conversion software to get to a compatible format.

DECLARATION OF CONFORMITY

Nr.1328

We, S.C. Visual Fan S.R.L, with the social headquarters in Brasov, 61st Brazilor Street, post code 500314 Romania, registered at the Register of Commerce Brasov under nr. 308/818/2002, CUI RO14724950, as importer, ensure, guarantee and declare on own responsibility according to Art. 4 HG nr.1.022/2002 regarding the products and services regime, which could put in danger the life and health, security and labour protection, that the ALLVIEW product VIVA H8 LTE does not put in danger the life, safety of labour, does cause adverse environmental impacts and is according to:

-The 2011/65/UE Directive regarding the usage restrictions of some dangerous substances in the electronic and electrical equipments.

-The Directive regarding the radio and telecommunications equipments R&TTE 1999/5/CEE (HIG 88/2003)

-The Directive regarding the assurance of low voltage equipment users 73/32/CEE, modified by the 93/68/CEE (HG457/2003) Directive.

-The Directive regarding the electromagnetic compatibility 89/336/CEE, modified by the 92/31/CEE si 93/68/CEE (HG497/2003); RoHS Directive: EN50581:2012

-The safety requirements of the European Directive 2001/95/EC and of the EN 60065:2002/A12:2011 si EN 60950-1:2006/A1:2010/A11:2009/A12:2011 standards, regarding the decibel level limit of the commercialized devices.

The product had been evaluated according to the following standards:

-Health: EN 50360:2001, EN 50361; EN 62209-1 : 2006

-Safety: EN 60950-1:2001+A11:2004; EMC EN 301 489-01 V1.6.1 (09-2005)

EN 301 489-07 V1.3.1 (11-2005); EN 301 489-17 V1.2.1 (08-2002)

-Radio spectrum: EN 301 511 V9.0.2 (03-2003); EN 300 328 V1.7.1 (10-2006)

The conformity assessment procedure was done according to the 1999/5/CEE Directive (of the Annex II of IIG nr. 88/2003) the documentation being at S.C. Visual Fan S.R.L., Brasov, 61st Brazilor Street, post code 500314, Romania at it will be put at disposal on demand. The products conformity assessment procedure was fulfilled with the participation of the following institutions: EMCCert DR, RAŠEK GmbH

The product has the CE mark applied. The conformity declaration is available at www.allviewmobile.com.

CE 0678 Director

SAR: 1,175 W/kg Cotuna Gheorghe

Brasov

20.10.2014

14 En

Allview VIVA H8 LTE

Настройки

Описание на функцините

1. WiFi

12. Schedule power on/off

Ρυθμίσεις

Einstellungen

http://help.sygic.com/.

Konfigurációk

Ustawienia

Opisy funkcji:

1. WIFI

DEKLARACJA ZGODNOŚCI WE

Nr.1328

De luat in considerare

Setari

Rezolvarea problemelor uzuale

1. Selektirajte dugme "World TRIAL".

2. Izaberite jednu ili više mapa i kliknite na „nastavak/proceed” radi update

3. Molimo da ne prekinite aplikaciju i da čekajte dok nije update završen.

4. Sclektirajte "Nastavak pokušaj /Continue trial" radi upotrebe navigacije Sygic GPS vreme od 30 dana besplatno.

Podešavanja

Na glavnom meniju, odaberite opciju "Podešavanja" ("Settings"), kako biste pristupili sistemskom podešavanju. Direktnim klikom možete pristupiti podešenom interfejsu sa simbolima.

105 Sr

Najčešća pitanja i utvrđivanje kvarova

1. Šta je APK datoteka? Da li su ona i Android PMP povezani i na koji način?

Google.Google Play, Android and other marks are trademarks of Google Inc.

Bulgarian (bg)
