Product Type	Electronic Cash Register
Brand	Sharp
Model	ERA771
Dimensions (approx.)	400 x 400 x 300 mm
Weight (approx.)	10 kg
Power Supply	AC mains, 230V/50Hz
Display Type	Digital screen with character display
Keyboard	Alphanumeric with PLU, department, and function keys
Printer	Integrated thermal or impact receipt printer
Clerk Key	Contactless clerk key unit (Models RUNTZ3844RCZZ and RUNTZ3845RCZZ)
Supported Payment Methods	Cash, check, credit, hotel transfer, CID, CH/CG, CA/CHK
Tax Systems	Up to 6 tax rates (TAX1 to TAX6) with VAT
Reporting	X and Z reports, departmental and group reports, PLU reports
Programmable Features	Price shifts, menu types, combos, promotions, condiments, recipes, tare tables
Drawer Compatibility	Optional cash drawer; must be securely fastened to platform
Connectivity	Optional contactless clerk key body; modular design
Safety Compliance	CE marked, complies with 89/336/EEC, 73/23/EEC, 93/68/EEC
Environmental	Built-in battery for backup; dispose of battery at recycling centers
Cleaning Instructions	Wipe with dry cloth; do not use liquids or solvents
Supplied Accessories	Manual, contactless clerk key and key body

Frequently Asked Questions - ERA771 SHARP

How do I perform a daily X report?

In REG mode, press the X key followed by #/ST. The report will print showing sales totals by department and PLU.

How can I reset the daily totals (Z report)?

In PGM mode, press Z followed by #/ST. This prints a Z report and resets the counters. Ensure you collect the report before midnight.

How do I program a new PLU?

Enter PGM2 mode, select PLU programming. Enter PLU number, department, price, and tax status using the numeric keypad. Confirm with ST.

What does the 'GLU' function do?

GLU (Global Look Up) allows you to search and recall previous transactions by entering a transaction number. Press GLU, enter the number, then ST.

Can I use a cash drawer with this model?

Yes, an optional cash drawer can be connected. Ensure it is securely attached to the platform to prevent tipping when open.

How do I change the clerk key assignment?

In PGM2 mode, select Clerk Key programming. Use the contactless key to register it. Follow the manual for binding keys to clerk numbers.

Why is the printer not printing?

Check if the paper roll is correctly loaded and the cover is closed. If the printer is silent, verify power and that the printer ribbon (if thermal) is not depleted.

How to set tax rates?

Enter PGM2 mode, select Tax programming. For each TAX1 to TAX6, enter the rate as a percentage (e.g., 10 for 10%) and press ST.

What does 'CLASS A' mean on the label?

This is a Class A product. In domestic environments, it may cause radio interference. If interference occurs, move the device away from radios or TVs or install shielding.

How to dispose of the battery?

The device contains a backup battery. Do not throw it in fire or household waste. Take it to a local recycling center, dealer, or customer service for safe disposal.

USER MANUAL ERA771 SHARP

CAUTION: Please observe the following when an optional drawer is used.

The drawer units should be securely fitted to the supporting platform to avoid instability when the drawers are open.

CAUTION:

The socket-outlet shall be installed near the equipment and shall be easily accessible.

VORSICHT:

For a complete electrical disconnection pull out the mains plug.

VORSICHT:

This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC.

This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

Warnung

- Helligkeitsregler

CLK#0001 CLERK0001 *0.00 SCM (+) *55.50 SCM TTL *55.50

6

Registrierungen

REG-MODUS

1000	AMT
60	PLU/SUB
	TL

Display

	10:32	0001
1 PL000060		10.00
CASH		10.00

WITH OUT	16	PLU'SUB
WITH	17	PLU'SUB
	11	PLU'SUB
		TL

Display

	12:35	0001
1 PL000011		20.00
PL000014
PL000015
PL000017
CASH		20.00

1001	TRANS OUT
	GLU
	TRANS OUT

Display

D10	6.000 Q
DPT. 10		*49.66
*NT TL3	6.000 Q	*49.66
TRANSACTION
(-) 1	2 Q	-1.56
(-) 2	1 Q	-3.51
(-) 3	1 Q	-1.03
(-) 4	1 Q	-1.16
%1	1 Q	-3.14
%2	1 Q	-3.84
%3	1 Q	-1.00
%4	1 Q	-2.27
NET 1		*147162.15
TAX1 ST		*144280.25
VAT 1		*10066.06
TAX2 ST		*779.56
VAT 2		*22.71
TAX3 ST		*1993.45
VAT 3		*76.67
TAX4 ST		*18.17
VAT 4		*0.87
TAX5 ST		-22.43
VAT 5		-0.44
TAX6 ST		*18.97
VAT 6		*0.19
TTL TAX		*10166.06
NET		*136996.09
VAT SFT		*72.40
TAX DELE		*114.10
SER. CHRG		*1015.79
(-) 5	1 Q	-0.68
(-) 6	2 Q	-2.64
(-) 7	1 Q	-0.86
(-) 8	1 Q	-0.65
%5	2 Q	-1.05
%6	1 Q	-2.09
%7	1 Q	-1.88
%8	1 Q	-0.71
DISCOUNT	0 Q	*0.00
CP PLU	11 Q	-38.33
REFUND	6 Q	*541.31
VD	0 Q	*0.00
VOID	2 Q	*29.31
MGR VD	8 Q	*29.10
SBTL VD	1 Q	*17.43
WASTE TL	95 Q	*666.50
RETURN	2 Q	*9.07
HASH VD	0 Q	*0.00
HASH RF	2 Q	*2.71
HASH RT	2 Q	*5.03
NOTURNVD	0 Q	*0.00
NOTURNRF	1 Q	*1.25
NOTURNRT	1 Q	*4.82

■ Spartenbericht

• X1-Bericht

DRAWER2/DRAWER1/NONE

1 TAX1: MWSt 1
2 TAX2: MWSt 2
3 TAX3: MWSt 3
4 TAX4: MWSt 4
5 TAX5: MWSt 5
6 TAX6: MWSt 6

HINWEIS

SHARP CORPORATION hereby declares that this CONTACTLESS CLERK KEY UNIT (KEY Model: RUNTZ3844RCZZ and BODY Model: RUNTZ3845RCZZ) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

According to article 6 (3) of the directive 99/5/EC this manual contains a declaration of conformity for the "Contactless Clerk Key & Key Body", which is mounted in this POS terminal.

DECLARATION OF CONFORMITY

Declare that the following product(s)

Contact Less Clerk Key Contact Less Clerk Key Body

Model Number(s):

RUNTZ3844RCZZ (Key) RUNTZ3845RCZZ (Key Body)

Conform(s) to the following Directives and Standards:

Council Directive(s)

Richtlinie(n) des Rates 1999/5/EG Directive du Conseil 1993/5/CE

1999/5/EC

Applied Standards:

Angewandte Standards: Normes appliquées:

Radio: EN 300 330-1 V1.3.1 (06-2001)

EN 300 330-2 V1.1.1 (06-2001)

EMC: EN 301 489-1 V1.4.1 (08-2002)

EN 301 489-3 V1.4.1 (08-2002)

Health EN 50371 (2002)

The following Notified Body with ID. No. 0891 was involved: TRL COMPLIANCE SERVICES LTD Solutions Division Warwick Innovation Centre Warwick Technology Park Gallows Hill CV34 6UV United Kingdom

CE Mark affixed on the product: 2003

Director, Human Resources and General Services

Environment Protection

The device is supported by a battery. To dispose the battery safely to protect the environment, please note the following points:

• Take the used battery to your local waste depot, dealer or customer service centre for recycling.
- Do not throw the used battery into fire, into water or into the household waste!
