Product Type	UHF Wireless Receiver
Brand	TOA
Model	WT-5810
Dimensions (without antenna)	206 x 40.6 x 152.7 mm
Weight	590 g
Power Supply	AC adapter or 12 V DC, 130 mA
Receiving Frequency	506 – 867 MHz (depending on region)
Number of Channels	16 selectable channels
Receiving System	Double superheterodyne
Diversity System	Space diversity
Antenna	Two whip antennas adjustable to 45°
Audio Output	Balanced (XLR, 600 Ω) and unbalanced (jack, 600 Ω)
Mix Input	-20 dB, 10 kΩ, unbalanced jack
Receiving Sensitivity	>90 dB (S/N ratio at 20 dBμV)
Signal-to-Noise Ratio	>104 dB (A-weighted, balanced output)
Harmonic Distortion	Less than 1%
Frequency Response	100 Hz – 15 kHz, ±3 dB
Operating Temperature	-10°C to +50°C
Operating Humidity	30 to 85% RH
Cleaning	With a dry cloth; do not use solvents
Safety	Do not expose to rain; use specified voltage; unplug if not used for more than 10 days
Repairability	Contact TOA dealer; do not open the casing

Frequently Asked Questions - WT-5810 TOA

How to set the channel on the WT-5810 receiver?

Press the Set button for about 1 second until the channel number flashes. Use the Next button to select the desired channel, then press Set again for 1 second to save.

How to reduce radio interference?

Use the squelch control to adjust sensitivity. Turn clockwise to reduce range and eliminate interference. You can also use the RF Control button to check for interfering waves and change channel if necessary.

What does the battery alarm indicator mean?

The battery alarm indicator (Battery alarm) lights up when the battery voltage of the corresponding wireless microphone is too low. Replace or recharge the microphone battery.

How to clean the device?

Clean the casing with a dry cloth. Never use gasoline, solvent, or any other volatile liquid.

What are the dimensions of the receiver?

The dimensions of the receiver (without antenna) are 206 mm width, 40.6 mm height, and 152.7 mm depth. Its weight is 590 g.

Can I use other microphones with this receiver?

The receiver is designed to work with compatible TOA wireless microphones. Ensure that the microphone transmits on the same frequency as the receiver. Use the channel detection function to find a free channel.

How to adjust the squelch?

Turn the Squelch control on the front panel. Position '0' provides maximum sensitivity (long range), '6' minimum sensitivity (short range). Adjust to eliminate background noise without losing the microphone signal.

What type of antenna is used?

The receiver is equipped with two whip antennas that should be raised at 45° outward for optimal reception. Remember to fold them for transport.

What to do in case of malfunction?

If you detect smoke, unusual smell, or if the unit has been dropped or damaged, turn it off immediately and disconnect the power. Contact your nearest TOA dealer. Never attempt to open the casing.

Can the receiver be used outdoors?

No, the unit is designed for indoor use only. Do not expose it to rain or moisture, as this could cause electric shock or fire.

USER MANUAL WT-5810 TOA

8. HOW TO CHECK AND DEAL WITH INTERFERENCE

8.1. Order of Actions (Action Flowchart) ..... 6
8.2. Checking Ambient Signal Condition ..... 7
8.3. Reducing Radio Interference by the Squelch Control 7
8.4. Channel Detection 8

9. SPECIFICATIONS 8

Accessory 8

1. SAFETY PRECAUTIONS

• Be sure to read the instructions in this section carefully before use.
• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included.
• We also recommend you keep this instruction manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage which could result from mishandling. Before operating your product, read this manual first and understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

WARNING

Indicates a potentially hazardous situation which, if mishandled, could result in death or serious personal injury.

When Installing the Unit

• Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as doing so may result in fire or electric shock.
• Use the unit only with the voltage specified on the unit. Using a voltage higher than that which is specified may result in fire or electric shock.
• Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using the power cord in close proximity to heaters, and never place heavy objects -- including the unit itself -- on the power cord, as doing so may result in fire or electric shock.
• Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a slanted surface. Doing so may result in the unit falling down and causing personal injury and/or property damage.
• To prevent lightning strikes, install the unit at least five meters away from a lightning rod, and yet within the protective range (angle of 45^ ) of the lightning conductor. Lightning strikes may cause a fire, electric shock or personal injury.
• Since the unit is designed for in-door use, do not install it outdoors. If installed outdoors, the aging of parts causes the unit to fall off, resulting in personal injury. Also, when it gets wet with rain, there is a danger of electric shock.

When the Unit is in Use

- Should the following irregularity be found during use, immediately switch off the power, disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause fire or electric shock.

• If you detect smoke or a strange smell coming from the unit.
  · If water or any metallic object gets into the unit
• If the unit falls, or the unit case breaks
  · If the power supply cord is damaged (exposure of the core, disconnection, etc.)
• If it is malfunctioning (no tone sounds.)

- Do not place cups, bowls, or other containers of liquid or metallic objects on top of the unit. If they accidentally spill into the unit, this may cause a fire or electric shock.

- Do not touch the unit's antennas during thunder and lightning, as this may result in electric shock.

CAUTION

Indicates a potentially hazardous situation which, if mishandled, could result in moderate or minor personal injury, and/or property damage.

When Installing the Unit

• Never plug in nor remove the power supply plug with wet hands, as doing so may cause electric shock.
• When unplugging the power supply cord, be sure to grasp the power supply plug; never pull on the cord itself. Operating the unit with a damaged power supply cord may cause a fire or electric shock.

• When moving the unit, be sure to remove its power supply cord from the wall outlet. Moving the unit with the power cord connected to the outlet may cause damage to the power cord, resulting in fire or electric shock. When removing the power cord, be sure to hold its plug to pull.

• The socket outlet shall be installed near the equipment and shall be easily accessible.

• Avoid installing the unit in humid or dusty locations, in locations exposed to the direct sunlight, near the heaters, or in locations generating sooty smoke or steam as doing otherwise may result in fire or electric shock.

When the Unit is in Use

• Do not place heavy objects on the unit as this may cause it to fall or break which may result in personal injury and/or property damage. In addition, the object itself may fall off and cause injury and/or damage.
• Make sure that the volume control is set to minimum position before power is switched on. Loud noise produced at high volume when power is switched on can impair hearing.
• Never open the unit case as there are high temperature parts inside the unit, which may cause a burn if touched. Refer all servicing to your nearest TOA dealer.
• Use the dedicated AC adapter for the unit. Note that the use of other adapter may cause a fire.
• If dust accumulates on the power supply plug or in the wall AC outlet, a fire may result. Clean it periodically. In addition, insert the plug in the wall outlet securely.
• Switch off the power, and unplug the power supply plug from the AC outlet for safety purposes when cleaning or leaving the unit unused for 10 days or more. A fire or electric shock may result.
• Any modifications made to this device that are not approved by TOA Corporation may void the authority granted to the user to operate this equipment.
• Operation of this device is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

The frequencies between 865 MHz and 867 MHz do not comply with "CE."

2. GENERAL DESCRIPTION

The WT-5810 Wireless Tuner is designed for use on the UHF band, and suitable for vocal or speech reinforcement applications. It features a commander circuit which minimizes the influence of ambient noise.

3. FEATURES

• An optimized PLL-synthesizer minimizes the oscillation frequency drift resulting from the ambient temperature change.
• Compact size and high reliability

4. HANDLING PRECAUTIONS

• When installing, keep the unit as far away as possible from fluorescent lamps, digital equipment, personal computers, and other equipment that generate high frequency noise.
• When cleaning the case, use a dry cloth. Never use benzine, thinner or other volatile liquids.
• When using two or more wireless microphones, keep them at least 50 cm away from each other to avoid malfunctions or noise.
• Keep the wireless microphone at least 3 m away from the receiving antenna. Using the microphone in close proximity to the antenna could result in malfunctions or noise.

5. NOMENCLATURE AND FUNCTIONS

[Front]

1. Power switch

Press this switch to turn the power on, and press it again to turn off the power.

2. Rod antennas

Raise both antennas at 45^ outwards from a vertical line.

When carrying the unit, be sure to fold down both antennas to prevent them from break.

3. Reception lamps

Either lamp of A (left) or B (right) lights yellow when the tuner receives a radio signal.

4. Battery alarm lamp

Lights when the battery voltage in the corresponding wireless microphone becomes low.

5. AF peak lamp

Lights red when the tuner output level reaches the point about 3 dB below the clipping level.

6. Squelch control

Adjusts the squelch level

7. RF check button

Switches off the squelch for monitoring the receiving frequency.

8. Channel number display

Indicates the current channel number in normal state.

In setting mode, the indicated channel number ashes until registered.

9. Channel setting keys (SET and NEXT keys)

Used to select the receiving channel (frequency). (The tuner frequency must be identical to that of the microphone.)

10. Volume control

Adjusts the output level.

[Rear]

11. I/O port

Used for service only.

12. DC input jack

Connect the power cable of the supplied AC adapter or its equivalent to this jack.

13. AF output

Balanced XLR jack, male type (Pin #2: Hot)

14. AF output

Unbalanced phone jack

15. AF mixing input (unbalanced)

Connects to other unit's AF output.

Input level: -20 dB, 10 kΩ (0 dB = 1 V)

6. OPERATION

Step 1. Turn the power on, and the Channel number display lights to indicate the channel number.

Step 2. Set the wireless microphone switch to the ON position.

The reception lamp lights when the tuner receives the same frequency signal.

Step 3. Adjust the volume control.

The output level increases as the volume is turned clockwise, and decreases as turned counterclockwise.

Microphone Sensitivity Adjustment

Although the audio level is preset by the factory, it can be adjusted depending on the user's voice level.

Step 1. Holding the microphone body, rotate the microphone grip counterclockwise to remove it in the case of the hand-held microphone, or slide the battery cover down to open it in the case of the lavaliere microphone.

Step 2. Turn on the power of the tuner and microphone.

Step 3. Adjust the microphone's audio level control using a screwdriver. The sensitivity increases as the control is rotated clockwise, and decreases as rotated counterclockwise.

Step 4. Set the volume control so that its knob points to the 2 o'clock position. If the AF peak lamp remains lit, readjust the microphone's audio level control so that the lamp only flashes when the signal reaches its highest peak.

Step 5. Replace the microphone grip (hand-held type) or the battery cover (lavaliere type).

The tuner's AF peak lamp lights when the tuner output level reaches the point of about 3 dB below the clipping level. The Peak lamp operates in response to the volume control position.

7. CHANNEL NUMBER SETTING

Step 1. Press the Set key for about a second until the displayed channel number blinks.

Step 2. Select the desired channel number with the NEXT key, and press the Set key for about a second until the blinking number turns to steady light.

Tip

Continuous or each depression of the NEXT key permits the display to cycle through the channel numbers.

8. HOW TO CHECK AND DEAL WITH INTERFERENCE

8.1. Order of Actions (Action Flowchart)

8.2. Checking Ambient Signal Condition

8.2.1. What is the "squelch"?

In FM receivers, such as a wireless tuner, big noise is produced at the output when incoming signals are weak or when no signal is present. When the signal received is lower than a certain level of signal strength, by silencing the output, the noise can be suppressed. It is a squelch circuit that achieves this. An RF check button is provided to permit check of a disturbing wave when the unit is interfered with during its use. The key also checks the presence of the disturbing wave in the channel of the new channel numbers when the unit is set for such numbers.

8.2.2. Operation

Hold down the RF check button for a while. As long as this button is pressed, the wireless tuner outputs the condition received in the highest sensitivity, allowing an operator to hear radio interference.

Note

Take care about the volume level since noise or interfering sounds are heard while the key is pressed.

8.3. Reducing Radio Interference by the Squelch Control

The WT-5810 tuner has the squelch function that virtually eliminates ambient noise and unwanted other wireless microphone systems by silencing the output when the signal received is lower than a certain level of signal strength.

This signal strength level can be varied by means of the squelch control. The sensitivity is the highest and radio signals can be received in wide areas when the control is in the "fully counterclockwise" position, while the "fully clockwise" position makes the sensitivity the lowest, permitting the radio signals to be only received in narrow areas.

It is possible to eliminate disturbing waves and only receive the radio signal transmitted from the required microphone by changing the squelch setting to make the radio signal reception area narrow. The wireless microphone's signal transmission distance varies largely depending on its ambient conditions.

The table below provides the guideline on the squelch control vs. transmission distance ratio, supposing that the squelch control is graduated from "0" to "6" as illustrated though not actually so.

Squelch Control Graduation 0	1	2	3	4	5	6
Transmission Distance (%)	10	0	85	70	50	30	20	15

Note: Transmission distance is a relative ratio with respect to 100% at "0" level.

Tips

• Set the control to the "0" position in locations free from interference.
• Set the control to the position that does not cause any reception loss of wireless microphone signals.

8.4. Channel Detection

Step 1. Press the Set key and the Next key at the same time for over a second.

Channel detection begins, and an idle channel number is indicated blinking on the channel number display.

Step 2. Press the Next key to select the channel.

Step 3. To set the channel to the unit, press the Set key for over a second until the blinking number turns to steady light.

9. SPECIFICATIONS

Power Source AC mains	(Supplied AC adapter must be used)
Power Consumption 130	mA (12 V DC)
Receiving Frequency 506	-867 MHz(506 - 538 MHz and 576 - 606 MHz for USA/Canada, 614 - 698 MHz for Brazil, 748.3 - 757.7 MHz and 803.3 - 805.7 MHz for Thailand, 865 - 867 MHz for India)
Channel Selectable 16 channels
Receiving System Double super-heterodyne
Diversity System Space diversity
Mixing Output MIC: -60 dB*	1, 600 Ω, balanced, XLR-3-32 type connectorLINE: -20 dB*600 Ω, unbalanced, phone jack
Mixing Input -20 dB*	1, 10 kΩ, unbalanced, phone jack
Antenna	Whip antenna
Receiving Sensitivity	90 dB or more, Signal to Noise ratio (20 dBμV input, 40 kHz deviation)
Squelch Sensitivity 16 - 40 dBμV variable
Squelch System Using together of noise SQ, carrier SQ and tone SQ
Tone Frequency	32.768 kHz
Indicator	ANT A/B, Audio (peak), Battery alarm, Channel number
Channel Check	Usable frequencies scanning
Signal to Noise Ratio	104 dB or more (A-weight, unbalanced output)
Harmonic Distortion	1% or less (typical)
Frequency Response	100 Hz - 15 kHz, ±3 dB
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Operating Humidity	30 % to 85 %RH
Finish	Resin, black
Dimensions	206 (w) x 40.6 (h) x 152.7 (d) mm (8.11" x 1.6" x 6.01") (excluding antenna)
Weight	590 g (1.3 lb)

^*1 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.

- Accessory

AC adapter ^*2 1

*2 No AC adapter is supplied with the version B02ER or C04ER.

DRAHTLOSEMPFÄNGER

WT-5810

INHALTSVERZEICHNIS

Graduation Squelch	0	1	2	3	4	5	6
Distance transmission (%)	100 85	70 50	30 20	15

ÍNDICE

Line drawing of a portable electronic device with ports and control knobs (no text or symbols)

ÍNDICE

4. PRECAUÇÕES RELATIVAS AO MANUSEIO

Any modification to the unit, unless expressly approved by TOA Electronics, Inc. could void your authority to operate the equipment.

DECLARATION OF CONFORMITY

TOA Electronics, Inc.

1 Harmon Plaza, Suite 602 Secaucus, New Jersey 07094, USA TEL [phone]

declare under our sole responsibility that the product

WIRELESS TUNER WT-5800, WT-5805 WT-5810, WT-S200, WT-4800, WT-4810 and WT-4820 WIRELESS TUNER UNIT WTU-4800

comply with Part 15 of FCC Rules.

Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

TOA

DECLARATION OF CONFORMITY

We: TOA Electronics Europe GmbH

as the authorised representative of the

Manufacturer: TOA Corporation

7-2-1, Minatojima-nakamachi, Chuo-ku, Kobe, Japan 650-0046

declare, under our sole responsibility, that the product

Product Name: WIRELESS TUNER, WIRELESS TUNER UNIT

Model Number: WT-5800, WT-5805, WT-5810, WT-4820, WT-5100, WTU-4800

conforms with following specifications:

RED: EN 301 489-1 V2.2.0 (2017-03)

EN 301 489-9 V2.1.1 (2017-03)

EN 300 422-1 V2.1.2 (2017-01)

EN 62368-1: 2014 + A11: 2017

RoHS: EN 50581: 2012

The product herewith complies with the requirements of the EU directives:

2014/53/EU relating to the radio equipment (RED),

2011/65/EU relating to the restrictions of hazardous substances (RoHS).

Remark:

This Declaration of Conformity replaces all previous ones of the above model(s).

Hamburg, ^th 3June 2017

(place, date)

T. Sakata, Managing Director (authorised signature)

The Technical Construction File (TCF) is kept at the UK office:

TOA Corporation (UK) Ltd; Unit 7 & 8, The Axis Centre, Cleeve Road, Leatherhead, Surrey, KT22

7RD, United Kingdom

Tel.: [phone]; Fax: [phone]; URL: www.toa.co.uk

German Office:

TOA Electronics Europe GmbH, Süderstraße 282, 20537 Hamburg, Germany

Tel: +49 / (0)40 / 25 17 19-0, Fax: +49 / (0)40 / 25 17 19-98 URL: www.toa.eu

COMPLIANCE STATEMENT TO
WT-4820, WTU-4800, WT-5100, WT-5800, WT-5805, WT-5810
URL: www.toa.eu

AT BE CH DE	ÖsterreichBelgienSchweizDeutschland	Hiermit erklärt TOA Electronics Europe GmbH die Übereinstimmung des Empfängers / Empfangsmoduls mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 2014/53/EU.(verantwortlich für die Schweiz: GoWild (Zug); URL: http://www.gowild.ch)
BE CH FR LU	BelgiqueSuisseFranceLuxembourg	Par la présente TOA Electronics Europe GmbH déclare que l'appareil récepteur / module de réception est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2014/53/UE.(CH: GoWild (Zug); URL: http://www.gowild.ch)
BE NL	BelgiëNederland	Hierbij verklaart TOA Electronics Europe GmbH dat deze ontvanger / ontvangstmodule in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 2014/53/EU.
BG	Държава	С настоящото TOA Electronics Europe GmbH, декларира, че този приемник / тунер модул е в съответствие със съществените изисквания и другите приложими разпоредби на Директива 2014/53/EC.
CY	Купроσ	Н TOA Electronics Europe GmbH, δηλώνει ότι ο δέκτης σημάτων/радioфωνικός δέκτης συνάδει με τις βασικές απαιτήσεις και άλλες σχετικές διατάξεις της Οδηγίας 2014/53/EE.
CZ	Česká republika	TOA Electronics Europe GmbH tímto prohlašuje, že tento přijímač / modul tuneru je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 2014/53/EU.
DK	Danmark	Undertegnede TOA Electronics Europe GmbH erklærer herved, at følgende udstyr Modtager / Modtager Modul overholder de væsentlige krav og øvrige relevante krav i direktiv 2014/53/EU.
EE	Eesti	Käesolevaga TOA Electronics Europe GmbH, teatab, et see vastuvõtja / tuuner moodul on vastavus olulistele nõuetele ja teistele asjakohastele sätetele direktiivi 2014/53/EL.
ES	España	TOA Electronics Europe GmbH declara que el receptor / sintonizador inalámbrico cumple con los requisitos esenciales y otras disposiciones aplicables o exigibles en la Directiva 2014/53/UE.
FI	Suomi / Finland	TOA Electronics Europe GmbH vakuuttaa täten että tämä vastaanotin / viritinmoduli on direktiivin 2014/53/EU oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
UK IE	United Kingdom Eire	Hereby, TOA Electronics Europe GmbH, declares that this receiver / tuner module is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
GR	Ελλαδα	Με την παρούσα η εταιρεία TOA Electronics Europe GmbH δηλώνει ότι ο radioφωνικός δέκτης/ μονάδα δέκτη συμμορφώνεται με τις ουσιώδεις απαιτήσεις και τις λοιπές σχετικές διατάξεις της οδηγίας 2014/53/EE.
HR	Hrvatska	Ovime, TOA Electronics Europe Gmbh, izjavljuje, da je ovaj prijemnik/modul prijemnika u skladu s osnovnim zahtijevima i relevantnim odredbama direktive 2014/53/EU.
HU	Magyarország	A TOA Electronics Europe GmbH ezennel kijelenti, hogy ez a vevőkészülék megfelel az 2014/53/EU Irányelv alapvető követelményeinek és egyéb vonatkozó rendelkezéseinek.
ITCH	Italia Svizzera (Italian)	Con la presente TOA Electronics Europe GmbH dichiara che questo Ricevitore / Modulo sintonizzatore è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 2014/53/UE.
LT	Lietuva	Šiuo, Toa Electronics Europe GmbH ", deklaruoja, kad šis imtuvas / imtuvas modulis atitinka esminius reikalavimus ir kitas susijusias nuostatas Direktyvos 2014/53/ES.
LV	Latvija	TOA Electronics Europe GmbH, deklarē, ka šis uztvērējs / raidītāja modulis atbilst būtiskajām prasībām un citiem ar to saistītajiem noteikumiem Direktīvā 2014/53/ES.
MT	Malta	TOA Electronics Europe GmbH tistqarr li r-ričevitur u t-tuner module (il-modulu li jagħżel il-frekwenzi) jissodisfaw l-obbligi necessarji u provvedimenti oħra relevant tad-direttiva 2014/53/UE.
NO	Norway (Norwegian)	TOA Electronics Europe GmbH erklærer herved, at denne mottagermodul / radio er i samsvar med de vesentlige egenskapene og øvrige relevante krav i direktiv 2014/53/EU. (N: Scandec Systemer AS, URL: www.scandecsystemer.no)
PL	Polska	My, TOA Electronics Europe GmbH, niniejszym deklarujemy, iż ten odbiornik/moduł tunera jest zgodny z zasadniczymi wymaganiami oraz innymi stosowanymi postanowieniami Dyrektywy 2014/53/UE.
PT	Portugal	TOA Electronics Europe GmbH declara que este Receptor / Sintonizador está conforme com os requisitos essenciais e outras disposições da Directiva 2014/53/UE.
RO	Romania	Prin aceasta TOA Electronics Europe GmbH declara ca acest modul receptor / tuner este in conformitate cu cerintele esentiale si cu alte prevederi relevante ale Directivei 2014/53/UE.
SE	Sverige (Swedish)	Härmed intygar TOA Electronics Europe GmbH att denna Mottagare / Radio modul står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 2014/53/EU.
SI	Slovenija	S tem, TOA Electronics Europe GmbH, izjavlja, da je ta sprejemnik / tuner modul v skladu z bistvenimi zahtevami in drugimi ustreznimi določbami Direktive 2014/53/EU.
SK	Štát	TOA Electronics Europe GmbH týmto prehlasuje, že tento prijímač/modul tunera je v zhode so základnými požiadavkami a d'alšími príslušnými ustanoveniami smernice 2014/53/EÚ.

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

AT BECH DE	Österreich Schweiz Deutschland	WICHTIGER HINWEIS!	Der Gebrauch dieses Funkempfängers für andere Zwecke als zum Empfang eines Tonsignals von einem passenden Funkmikrofon ist nicht zulässig.Dieses Gerät arbeitet auf in der europäischen Gemeinschaft (EU) nicht harmonisierten Frequenzen. Abhängig vom geografi schen Gebiet dürfen bestimmte Frequenzen legal mit oder ohne Autorisierung / individueller Lizenz entsprechend der beigefügten Frequenztabelle genutzt werden.
BE CH FR LU	Belgique Suisse France Luxembourg	AVIS IMPORTANT!	Ne pas utiliser les récepteurs HF pour une réception du signal audio provenant d' un appareil, autre que les microphones prévus à cet effet.Cet appareil utilise des fréquences d'émission qui ne sont pas harmonisées à travers la Communauté Européenne (EU). En fonction du lieu géographique certaines fréquences peuvent être utilisée de façon légale avec ou sans autorisation / licence individuelle comme décrit dans le tableau des fréquences.
BE NL	België Nederland	BELANGRIJKE AANWIJZING!	Het is niet toegestaan deze ontvanger te gebruiken voor enig ander doel dan het ontvangen van een audiosignaal van de bijbehorende draadloze microfoon.Dit apparaat maakt gebruik van frekwentiebanden welke in de Europesche Gemeenschap (EG) niet algemeen zijn toegestaan. Afhankelijk van de geografi sche ligging kan voor het legaal gebruik van een bepaalde frekwentie een vergunning nodig zijn, zoals is aangegeven in de frekwentietabel.
BG	Държава	ВАЖНО УТОЧНЕНИЕ!	Не е законно използването на този приемник за каквато и да е друга цел, освен приемането на аудио сигнали от предвидения негов безжичен микрофон. Това устройство може да работи в честототен диапазон, нехармонизиран с изискванията на Европейската Общност (EC). В зависимост от конкретното географско място, само определени честоти могат да бъдат използвани легално – със или без оторизация / индивидуална лицензия, както е посочено в таблицата с честотите.

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

LV	Latvija	SVARĪGAPIEZĪME!	Uztvērēju paredzētā izmantošanaIr aizliegts izmantot šo uztvērēju jebkuram citam nolūkam, kā saņemot audio signālu no atbilstoša bezvadu mikrofona.Šī iekārta izmanto frekvenču joslas, kas nav saskaņotas visā Eiropas savienībā (ES).Atkarībā no ğeogrāfiskā regiona tikai noteiktās frekvences var izmantot legāli, ar vai bez atļaujas vai individuālās licences, kā norādīts frekvenču tabulā.
MT	Malta	NOTA MPORTANTI!	Uzu tar-receiversMhux permess l-uzu ta’ dan ir-recievers, hlief biex jittrazmetti sinjal ‘audio’ lil microfonu tieghu. Kwalinkwe uzu ghal skop differenti, huwa llegali.Dan il-microphone jaghmel uzu minn frekwenzi li mhux ..... fl -Unjoni Ewropeja. F’certu zoni jistghu jigu ntuzati biss legalment certu frekwenzi bil- jew bla- awtorizzazzjoni jew licenzji li huma mhabbrin fuq il-‘frequency table’.
NO	Norway	VIKTIG MELDING!	Det er ulovlig å bruke denne mottakeren til noe annet formål enn å motta et lydsignal fra en tilhørende trådløs mikrofon.Denne enheten gjør bruk av frekvensbänd som ikke gjennomført er harmonisert i det Europeiske Fellesskap (EU). Avhengig av det geografi ske område kan noen frekvenser være tillatt brukt med eller uten autorisasjon / individuelle lisenser slik det er beskrevet i frekvenstabellen.
PL	Polska	WAŽNAINFORMACJA!	Używanie odbiornika bezprzewodowego w celu innym, niż odbiór sygnału audio ze sparowanego z nim nadajnika jest niezgodne z prawem.To urządzenie wykorzystuje pasma częstotliwości, które nie są zharmonizowane w obrębie Unii Europejskiej (UE). W zależności od lokalnych regulacji krajowych część częstotliwości może być niemożliwa do wykorzystania, lub też wymagać posiadania licencji, zgodnie z Krajową Tablicą Przeznaczeń Częstotliwości.

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810

PT	Portugal	NOTA IMPORTANTE!	Este Receptor só pode receber sinal de audio do respectivo Microfone Emissor. Este equipamento utiliza bandas de frequência que não estão harmonizadas em toda a Comunidade Europeia (CEE). De acordo com a área geográfi ca, certas frequências podem ser usadas com ou sem autorização / licença individual, conforme está mencionada na lista de frequências.
RO	Romania	NOTA IMPORTANTA!	Este ilegala utilizarea acestui receptor in orice alt scop decat receptionarea unui semnal audio transmis de catre microfonul sau compatibil.Acest dispozitiv utilizeaza benzi de frecventa care nu sunt armonizate in Comunitatea Europeana (EU). In functie de asezarea geografica, numai anumite frecvente pot fi utilizate legal cu sau fara autorizatie/ licenta individuala dupa cum se mentioneaza in tabelul de frecvente.
SE	Sverige	VIKTIG ANMÄRKNING!	Det är illegalt att använda denna mottagare för något annat ändamål än att ta emot en audiosignal från dess tillhörande trådlösa mikrofon.Denna apparat utnyttjar frekvensband som inte överensstämmer med varandra inom hela Eyropeiska Gemenskapen (EG). Beroende på geografi skt område kan vissa frekvenser användas legalt med eller utan tillständ/ individuell licens enligt frekvensplanen.
SI	Slovenija	POMEMBNO!	Prepovedana je vsakršna uporaba sprejemnika v druge namene kot sprejemanje avdio signala pripadajočega brezžičnega mikrofona.Ta naprava omogoča uporabo frekvenčnih pasov, ki niso usklajeni v vsej Evropski skupnosti (EU). Glede na geografsko območje se lahko legalno uporabljajo samo določene frekvence z ali brez dovoljenja, kot je navedeno v frekvenčni tabeli.

INTENDED USE OF WT-4820, WTU-4800, WT-5800, WT-5805, WT-5810
