IAN 43116 - Moulin à poivre/sel SILVERCREST - Free user manual and instructions

Brand	SilverCrest
Model	IAN 43116
Product Type	Electric Salt & Pepper Mill
Power Source	6 x 1.5 V AAA batteries (LR03, included)
Operating Voltage	9 V
Power Consumption	3.5 W
Grind Adjustment	Adjustable screw for fine to coarse grind
Light	Built-in LED (bulb 9), replaceable
Capacity	Fills up to 75% of container for best results
Materials	Plastic, ceramic grinding mechanism
Safety Class	Protection class III (low voltage)
Suitable For	Peppercorns or coarse salt only
Aroma Seal	Removable aroma seal cover on base
Cleaning	Wipe exterior with soft dry cloth; no liquids
Battery Replacement	Remove batteries if not used for long periods
Warranty	3 years from date of purchase
Package Includes	Mill, 6 x AAA batteries, replacement bulb
Dimensions (approx.)	Height: 20 cm, Diameter: 5 cm (estimated)
Weight (with batteries)	Approx. 300 g (estimated)

Frequently Asked Questions - IAN 43116 SILVERCREST

How do I insert batteries in the SilverCrest IAN 43116 pepper mill?

To insert batteries, hold the base firmly and turn the top counter-clockwise to open the bayonet cap. Remove the top and motor, then insert 6 AAA batteries (1.5V) observing correct polarity as shown in the compartment. Reassemble by aligning the motor notch with the base protrusion.

What type of salt or pepper can I use in the mill?

Only use peppercorns or coarse salt. Do not use fine salt or other spices as they may damage the grinding mechanism.

How do I adjust the grind coarseness?

Turn the adjustable screw on the bottom: clockwise for finer grind, anticlockwise for coarser grind. If the mechanism stops, choose a coarser setting or loosen the screw to release stuck pieces.

How do I activate the mill and the light?

Press and hold the switch on top to activate the motor and the built-in light simultaneously. Release to stop.

How do I replace the bulb?

First remove the batteries to avoid accidental activation. Hold the base upwards, carefully pull out the old bulb, and insert a new bulb of the same type (included replacement bulb).

Why is the mill not grinding?

The mill may be choked or blocked. Turn the adjustable screw anticlockwise to a coarser setting and shake the mill to release stuck pieces. If it still stops, unscrew the adjustable screw completely, loosen the grinding mechanism, and reassemble.

How do I clean the salt and pepper mill?

Clean only the exterior with a soft dry cloth. Never use liquids or detergents as they can damage the device.

Is the mill safe for children to use?

Children aged 8 years and above can use the mill under supervision. They must be instructed on safe use and the hazards. Children should not play with the device or perform cleaning without supervision.

How should I dispose of the old batteries?

Do not dispose of batteries in household waste. Return them to a local collection point or recycling facility in accordance with local regulations.

What is the warranty coverage for the SilverCrest IAN 43116?

The device has a 3-year warranty from date of purchase covering material and manufacturing faults. It does not cover normal wear (e.g., batteries) or damage from improper use. Keep the sales receipt as proof of purchase.

USER MANUAL IAN 43116 SILVERCREST

Silver Crest® food processor dispensing sugar into a dessert (no text or symbols visible on the food or background)

ELECTRIC SALT & PEPPER MILL

GB

ELECTRIC SALT & PEPPER MILL

Operation and Safety Notes

HU

ELEKTROMOSSÓ-/BORSÖRLÖ

GB Operation and Safety Notes Page 4

Familiarise yourself with the product before using it for the first time. In addition please refer carefully to the operating

instructions below and the safety advice. Use the product only as described and for the indicated purpose. Keep these instructions in a safe place. If you pass the product on to anyone else, please ensure that you also pass on all the documentation.

- Intended use

This appliance is intended for use as electrical salt or pepper mill. All modifications to this appliance are not intended and may cause considerable risk of accident. The manufacturer assumes no liability for damages caused because of non-intended usage. The product is not intended for commercial use.

- Technical specifications

Batteries: 6 x 1.5 V AAA (tR03), included

Operating voltage: 9V ——

Capacity: 3.5 W

Protection class:

Parts description

1 Top
2 Switch
3 Motor
4 Contact 1
5 Contact 2
6 Base with container
7 Aroma seal cover
8 Adjustable screw
9 Bulb
10 Replacement bulb

Safety Information

WARNING! DANGER TO LIFE

AND ACCIDENT HAZARD FOR TODDLERS AND

SMALL CHILDREN! Never allow children to play unsupervised with the packaging material. There is a danger of suffocation from the packaging material. Children frequently underestimate the dangers. Children should be kept away from the product at all times.

WARNING! DANGER

TOLIFE! Batteries can be swallowed, which may represent a danger to life. If a battery has been swallowed, medical help is required immediately.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

- Do not use the device if it is damaged. Damaged devices represent a danger of death from electric shock!

- Do not expose the device to - extreme temperatures, - strong vibrations, - strong mechanical stresses, - direct sunlight, - moisture.

Otherwise the device may be damaged.

Please note that the guarantee does not cover damage caused by incorrect handling, non-compliance with the operating instructions or interference with the device by unauthorised individuals.

■ Under no circumstances should you take the device apart. Improper repairs may place the user in considerable danger. Repairs should only be carried out by specialist personnel.

- Please keep the product clean. - Please fill the salt and pepper mill only with peppercorns or coarse salt.

FOOD SAFE! This product does not affect the taste and aroma properties of foodstuffs.

Safety Instructions for Batteries

■ Remove the batteries from the device if they are not going to be used for a prolonged period.

CAUTION! DANGER OF EXPLOSION! The

batteries must never be recharged!

- When inserting the batteries, ensure the correct polarity! This is shown in the battery compartments.

If necessary, clean the batteries and device contacts before inserting the batteries.

■ Remove spent batteries immediately from the device. There is an increased danger of leaks!

■ Batteries must not be disposed of in the normal domestic waste!

■ Every consumer is legally obliged to dispose of batteries in the proper manner!

- Keep batteries away from children; do not throw them in the fire, short-circuit them or take them apart.

If the above instructions are not complied with, the batteries may discharge themselves beyond their end voltage. There is then a danger of leaking. If the batteries have leaked inside your

device, you should remove them immediately in order to prevent damage to the device!

- Avoid contact with the skin, eyes and mucous membranes. If you come into contact with corrosive battery fluids, flush the affected area thoroughly with clean water and contact a doctor immediately.

Use

- Insert Batteries / Filling of the salt and pepper mill

Indication: The salt and pepper mill is intended for peppercorns or coarse salt.

Proceed as follows:

1. Hold the base with the container 6 firmly and turn the top 1 counter-clockwise (see Fig. A) until the arrow on the top 1 is aligned with the symbol 🔒 on the base with container 6.
2. Open the bayonet cap by turning and then pulling it. The remove the top part 1 from the base with container 6.
3. Pull the motor 3 carefully off the base with container 6.
4. Insert 6 new batteries type AAA 1.5 V-- (LRO3).

Indication: Pay attention to the right polarity. This is shown in the battery compartment.

1. Fill up the base with container 6 with peppercorns or coarse salt. The best result will be achieved when filling the base with container 6 up to 75%.
2. Putthemotor 3 back on the base with container 6. Be sure to place the notch on the motor marked with a white arrow into the respective protrusion on the base with container (see Fig.B).

Indication: Please make sure that the contacts 4, 5 face each other (see fig. A).

1. Put the top 1 back on the base with container 6.
2. Hold the base with container 6 firmly and turn the top 1 clockwise (see Fig. B) until the arrow on the top 1 aligns with the symbol on the base with container 6.

• Using of the salt and pepper mill

☐ Pull off the aroma seal cover from the bottom of the base with container 6 before use (see fig. B).
Please keep the switch pushed to activate the salt and pepper mill. The bulb 9 on the base of the salt and pepper mill will then be simultaneously activated.

- Adjusting the grinding level

Turn the adjustable screw clockwise to receive a finer grinding level (see fig. C).
Turn the adjustable screw anticlockwise to receive a coarser grinding level (see fig. C).
☐ Turn the top of the device and press the switch 2 to remove residues from the grinding mechanism.

Note: Choose a coarser setting if the grinding mechanism stops rotating when you are using a very fine setting. If the grinding mechanism still refuses to rotate, then it may be choked or blocked. Unscrew the adjustable screw 8 and loosen the grinding mechanism. Release the stuck pieces by shaking the grinding mechanism, then tighten the adjustable screw 8 again.

- Changing the bulb

Remove the batteries before you change the bulb 9. In this way you will ensure that the salt and pepper mill is not turned on by accident while you are changing the bulb 9.

Note: Use only bulbs of the same type as the

bulb supplied. Otherwise the product may be damaged.

Hold the base with container so that it is facing upwards as shown in Figure C.
Remove the broken bulb by pulling it carefully out of the socket.
☐ Insert the new bulb.

● Cleaning and maintenance

■ Under no circumstances should you use liquids or detergents, as these will damage the device.
☐ The device should only be cleaned on the outside with a soft dry cloth.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries must be recycled in accordance with Directive 2006 / 66 / EC. Please return the batteries and / or the device to the available collection points.

Environmental damage through incorrect disposal of the batteries!

Batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules

and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries at a local collection point.

Warranty

The device has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this device is 3 years from the date of purchase. Should this device show any fault in materials or manufacture within three years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the device has been damaged or improperly used or maintained.

The warranty applies to faults in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

CE
