USER MANUAL TCR 36 A1 TRONIC

Model No.: HG11200A/HG11200B

Version: 01/2024

IAN 445679_2307

USB-KFZ-LADEADAPTER / USB CAR CHARGER / CHARGEUR

ALLUME-CIGARE USB TCR35 A1, TCR36 A1

DE AT CH

USB-KFZ- LADEADAPTER

Operation and safety notes

FR BE

CHARGEUR ALLUMECIGARE USB

Operation and safety notes Page 36

FR/BE

List of pictograms used . Page 37

Introduction 39

Intended use . Page 40

Description of parts. Page 41

Technical data. Page 42

Scope of delivery . Page 44

Trademark notices . Page 44

Safety notices . Page 45

Start-up Page 47

Cleaning and care . Page 52

Troubleshooting . Page 53

Disposal. Page 54

Warranty . Page 57

Warranty claim procedure . Page 60

Service . Page 62

List of pictograms used

Direct current / voltage

CAUTION! This symbol with the signal word "CAUTION" indicates a hazard with a low level of risk which, if not avoided, could result in minor or moderate injury.

	ATTENTION! This symbol with the signal word"ATTENTION" indicates a potential property damage, if not avoided, could result in property damage.
CE	CE mark indicates conformity with relevant EU directives applicable for this product.
	Safety Information Instructions for use

USB CAR CHARGER

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you

also pass on all the documentation with it.

Intended use

This USB CAR CHARGER (hereinafter called "product") can be used to charge and power devices that can be charged or powered from a USB port as standard. The product can be used in a normal car socket that provides the specifications given under "Technical data". The product is not intended for commercial use. The manufacturer is not liable for any damages caused by any use other than for the intended purpose.

Description of parts

1 Control lamp
2 USB-A port
3 USB-C port
4 Short manual

Technical data

Input:

$$ 1 2 / 2 4 \mathrm {V} = =, 3. 5 \mathrm {A} $$

Output USB port:

HG11200A

USB-A: 5 V ---, 3 A (15 W)

Two USB-C ports (18 W each)

USB-C PD: 5 V=, 3 A;

9 V--, 2 A;

12 V, 1.5 A,

PPS: 3.3-11 V=1.65 A

Max. output power:

HG11200A: 35 W

HG11200B: 36 W

Operating temperature:

0 - 25 °C

Scope of delivery

1 USB car charger
1 Instructions for use

Trademark notices

USBa registered trademark of USB Implementers Forum, Inc.
The TRONIC trademark and trade name is the property of their respective owners.
Any other names and products are trademarks or registered trademarks of their respective owners.

Safety notices

PLEASE READ THE INSTRUCTIONS PRIOR TO USE! PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE!

Check the product for damage before use. Never use a damaged product.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of

the product in a safe way and understand the hazards involved.

Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision.

Do not expose the product to direct sunlight or moisture.

Only plug the product into car sockets that are easily accessible, so that you can unplug it easily in case of an emergency.

Start-up

ATTENTION! RISK OF

OVERHEATING! Make sure that the connected load has a maximum current consumption of 3.5 A (3500 mA).

ATTENTION! If you use the product under max. loading condition, the product may get hot. This is normal because in this condition, the product uses more power and therefore generates more heat.

Plug the product into a correctly installed car socket that provides the specifications given under "Technical data". The control lamp 1 lights up white to show that the product is receiving current.

Connect your external devices that should be charged with the product by plugging its USB-A plug into the USB port type A 2, and plugging its USB-C plug into the USB port type C 3.

DANGER! RISK OF

SUFFOCATION! Never leave

children unattended with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

The packaging material is not a toy.

DANGER! RISK OF

SUFFOCATION! In the content of delivery, there are small parts that can be swallowed, choking hazard and NOT for children.

IMPORTANT! You can leave the motor on or off when using the product. Be aware that the battery of car might become low because

the product still consumes power when the motor is off. Disconnect the product completely from the power supply if you are not intended to charge your external devices.

ATTENTION: Do not switch

the ignition on or off during the charging process, as this can lead to differences or peaks in the power supply.

Disconnect your charged external device from the product after charging, by unplugging the USB-A plug from the USB port type A 2, and unplugging the USB-C plug from the USB port type C 3.

Disconnect the product from the car charging socket when it is no longer in use.

Cleaning and care

Always unplug the product from the car socket before cleaning!
Use a dry, soft and lint-free cloth for cleaning and care.
Moisture entering the product may result in damage.
Ensure no moisture enters the product during cleaning to prevent damage.

• Do not use abrasive, solvent-based or aggressive cleaners. These can damage the surface of the product.

Troubleshooting

= Problem
= Solution
The product does not work properly.
Try unplug and plug charger properly.
Check external device functionality condition.

Disposal

Packaging:

The packaging is made of environmentally friendly materials, which you be disposed through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98:composite materials.

Product:

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

The adjacent symbol of a crossed out dustbin on wheels indicates this product is subject to directive 2012/19/EU. This directive states at the end of the life this product must not be disposed of through regular household refuse but must be returned to special collection sites, recycling depots or waste management companies.

This disposal is free of charge to you.

Protect the environment and dispose of properly.

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting

information), for better waste treatment. The Triman logo is valid in France only.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase.

Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

To ensure quick processing of your claim, observe the following instructions:

Make sure to have the original sales receipt and the item number (IAN 445679_2307) available as proof of purchase.

You can find the item number on the rating plate, an engraving on the product, on the front page of the instruction manual (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.

Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.

Service

Service Great Britain

Tel.:[phone]

E-Mail: [e-mail]

Service Ireland

Tel.:[phone]

E-Mail: [e-mail]
