Motion sensor

- Introduction

This document is a shorter printed version of the complete instruction manual. Scanning the QR code takes you straight to

the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 481855_2410.

The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Store the short guide in a safe place, and if you give the product to third parties, all documentation should be passed on to them as well.

PDF ONLINE www.lidl-service.com

- Proper use

This product is suitable for dry locations use only.

This product is intended for use in private, domestic environment only and not for commercial purposes. This product is not suitable for security, fire alarm, emergency purpose.

- Delivery scope

1 Motion sensor

2 Dowels

3 Batteries

1 Instructions for use

2 Screws

• Description of parts

1 Batterycompartment cover
2 Screw (for battery compartment cover)
3 Battery compartment 4 Main unit

5 Slideswitch (ALARM/OFF/BELL)
6 Speaker
7 Motion detector
8 Wall mount
9 Wall mount screw
10 Dowel

- Technical data

Battery Type: 3 × 1.5 ~V

AA/LR6--- alkaline battery (included)

prox. 70 dB (at a distance of 1.5 m from the product)

Bell signal volume:

Protection class: III/

Operating temperature: 0 °C to 35 °C

Storage temperature: -10 °C to 45 °C

Operating humidity: 40 to 75 % RH

Safety information

READ THESE INSTRUCTIONS BEFORE USING THE PRODUCT! PLEASE KEEP ALL SAFETY INSTRUCTIONS AND INSTRUCTIONS FOR USE FOR FUTURE REFERENCE!

DANGERWARNING!

DEATH AND ACCIDENTS FOR TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Please keep children away from the product at all times.

This product may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or those lacking experience and/or knowledge provided they are supervised or instructed in the safe use of the product and they understand the associated risks. Do not allow children to play with the product. Cleaning and user maintenance must not be performed by children without supervision.

This product is not a toy and should be kept out of the reach of children. Children are not aware of the dangers associated with handling electrical products.

■ Verify all parts are in good condition. Risk of injury when mounting damaged parts.

- Verify all parts are mounted correctly. Improper product assembly may result in injuries.

CAUTION! RISK OF OVERHEATING! Do

not operate the product inside the packaging.

■ After use, keep the product in the packaging to prevent unwanted damage.
This product does not contain any parts that can be serviced by the user. The bulbs cannot be replaced.
■ The LEDs are not replaceable.
If the LEDs fail at the end of their lives, the entire product must be replaced.
The equipment is only suitable for mounting at heights ≤ 2 m.

Safety instructions for batteries/rechargeable batteries

■ DANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.

■ Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.

Warning symbol image with exclamation mark inside triangle and gray square

DANGER OF EXPLOSION! Never

recharge non-rechargeable batteries.

Do not short-circuit batteries/recharge-

able batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.

Risk of leakage of batteries/rechargeable batteries

Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.

If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES!

Leaked or damaged batteries/re- chargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

In the event of a leakage of batteries/rechargeable batteries, immediately remove them from the product to prevent damage.

Only use the same type of batteries/rechargeable batteries. Do not mix used and new batteries/rechargeable batteries.

■ Remove batteries/rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

Only use the specified type of battery/rechargeable battery!
Insert batteries/rechargeable batteries according to polarity marks (+) and (-) on the battery/rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery/rechargeable battery and in the battery compartment before inserting!
■ Remove exhausted batteries/rechargeable batteries from the product immediately.

- Before first use

Indoor use

When selecting the mounting location, pay attention to the following:

☐ Make sure the motion detector 7 covers the desired area. The motion detector 7 has a maximum coverage range of 8 m, with a coverage angle of about 60° (depending on the mounting height – a height of 1.50 m is ideal) (Fig. D).

Attention:

If you mount the product less than 1 m from the ground, please avoid the false trigger of pet.

To avoid damage to unit; do not aim the sensor towards the strong light.
To avoid nuisance triggering, the sensor should be directed away from heat sources such as air-conditioners, other lighting and flue vents.
To avoid nuisance triggering, keep the product away from the area of strong electromagnetic disturbance.
Do not aim towards reflective surfaces such as smooth white walls, etc.

- Installation

Note: You will need a screwdriver (not included) and a electric drill (not included) to install the product.

Note: Only use the included screws 9 and dowels 10 for installation.

• Installing the product (see Fig. B)

Make sure you will not be drilling into electrical, gas or water lines inside the wall. Use a electric drill to drill the holes into the wall. Always observe all safety instructions for the electric drill in the manual for the electric drill. Death or injury due to electric shock may otherwise result.

☐ Mark the drilling hole onto the desire location, drill a hole ( 6 mm) and insert the dowel ^10 .

Screw the wall mounting screw 9 into dowel 10. Note: Leave a piece of the screw head protruding from the dowel 10 so that you can then hang the wall mount 8 on it.

□ Attach the product to wall mount 8.

- Verify all parts are mounted correctly. Improper product assembly may result in injuries.

- Inserting/replacingbatteries (see Fig. C)

☐ Rotate the screw 2 on battery compartment cover 1 anti-clockwise.

Open the battery compartment cover 1 and insert three batteries type AA (LR6) in the battery compartment 3. Be sure the polarity is correct. This is indicated in the battery compartment 3.

☐ Close the battery compartment cover 1 and lock it by rotating the screw 2 clockwise.

Operation

Alarm: Slide the switch into the ALARM position. Red LED light up at motion detector 7 approx. 10 sec. The motion detector 7 is activated. The alarm sounds from speaker 6 when the motion detector 7 detects some motion in the detection area.

Bell: Slide the switch into the BELL position. Red LED light up at motion detector 7 approx. 10 sec. The motion detector 7 is activated. The BELL sound from speaker 6 when the motion detector 7 detects some motion in the detection area.

- Cleaning

☐ Only clean the outside of the product using a soft, dry cloth.

● Storage during non-use

Store the product in a dry, dust-free location, protected from direct sunlight. Remember take out the batteries from battery compartment 3 before storage or non-use

- Troubleshooting

Note: This product has delicate electronic components. This means that if it is placed near an object that transmits radio signals, it could cause interference. If you notice that the product is malfunctioning, remove any sources of interference from the area of the product.

Note: Electrostatic discharges may cause product to malfunction. In the event of such malfunctions, remove the batteries briefly and reinsert them.

- Disposal

Packaging:

The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

Contact your municipality for information on how to dispose of your worn-out product.

The adjacent symbol of a crossed out dustbin on wheels indicates this product is subject to directive 2012/19/EU. This directive states at the end of the life this product must

not be disposed of through regular household refuse but must be returned to special collection sites, recycling depots or waste management companies.

The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

This disposal is free of charge to you.

Protect the environment and dispose of properly.

Batteries/accumulators:

Environmental damage through incorrect disposal of the batteries/accumulators!

Defective or exhausted batteries/rechargeable batteries must be recycled in accordance with

DIRECTIVE 2023/1542. Return batteries/rechargeable batteries to the appropriate local collection facilities.

The symbol showing the crossed-out bin on batteries or rechargeable batteries means that such batteries must not be disposed of in domestic waste. Remove the batteries/battery pack from the product before disposing of them/it. They may contain toxic heavy metals and are subject to hazardous waste regulations.

The chemical symbols of the heavy metals are: Cd = cadmium, Hg = mercury, Pb = lead.

- Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

- Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 481855_2410) available as proof of purchase.

You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

Service Ireland

Tel.:[phone]

E-Mail: [e-mail]
