ZBSW11WT - Detector NEDIS - Free user manual and instructions

Product type	Zigbee water leak detector
Brand	Nedis
Model	ZBSW11WT
Communication technology	Zigbee (requires Nedis WIFIZBxxx gateway)
Power supply	1 CR123A battery (3 V, not included)
Battery life	Up to 1 year (depending on usage)
Communication range	Up to 30 m (without obstacles)
Detection area	Up to 1 m² (direct water contact)
Intended use	Indoor only, flood and leak detection
Required compatibility	Nedis WIFIZBxxx Zigbee gateway and Nedis SmartLife app (iOS/Android)
Key features	Water detection, push notification to smartphone, alert history
Protection rating	IPX4 (splash-resistant, battery cover and detection points)
Materials	ABS plastic
Color	White
Package contents	Detector, mounting bracket, battery (not included), user manual
Operating temperature	0 °C to 40 °C
Operating humidity	10% to 90% (non-condensing)
Certifications	CE, RED 2014/53/EU
Maintenance and cleaning	Wipe with a clean, dry cloth. Do not use harsh chemicals.
Safety	Do not immerse, do not disassemble, observe battery polarity, keep out of reach of children (packaging)
Waste disposal	Do not dispose of with household waste. Dispose of at a suitable collection point or return to the retailer.

Frequently Asked Questions - ZBSW11WT NEDIS

How to install the Nedis ZBSW11WT water leak detector?

Place the detector in the area to be monitored (under a sink, near a washing machine). Insert a CR123A battery, observing polarity (+/-). Pair it with your Nedis Zigbee gateway via the Nedis SmartLife app. The detector is ready to use.

How to pair the detector with the Zigbee gateway?

Open the Nedis SmartLife app, tap 'Add device', select 'Sensor', then follow the instructions. Put the detector into pairing mode (usually by inserting the battery). The gateway and detector will connect automatically.

How to replace the detector's battery?

Open the battery cover by sliding it off. Remove the old battery and insert a new CR123A battery, respecting polarity. Close the cover. A notification may be sent via the app to confirm operation.

What to do if the detector does not connect to the app?

Check that the battery is correctly inserted and polarity is observed. Ensure the gateway is on and within range (max 30 m without obstacles). Reset the detector by removing and reinserting the battery, then restart pairing.

Is the detector waterproof?

No, it is not fully waterproof. Only the battery cover and water detection points are water-resistant (splash-proof). Do not immerse the product in water or other liquids.

Where to place the detector for optimal detection?

Place it in areas prone to leaks: under the sink, near the water heater, washing machine, or dishwasher. Install it flat on the floor or mount it on the wall using the provided bracket, with the detection points in contact with the surface.

Can I use the detector without a Zigbee gateway?

No, the detector requires a Nedis Zigbee gateway (model WIFIZBxxx) to operate wirelessly. Without a gateway, it will not be able to send notifications via the Nedis SmartLife app.

How to clean the detector?

Wipe the device with a clean, dry cloth. Do not use harsh chemical cleaners, solvents, or detergents, as they may damage the plastic or circuits.

What to do in case of water leak detection?

The Nedis SmartLife app sends a push notification to your smartphone. Shut off the water supply if possible, check the source of the leak, and dry the area. The detector remains active; after resolution, wipe the detection points to prevent false alerts.

How to reset the detector to factory settings?

Remove the battery, wait 10 seconds, then reinsert it. The detector will restart in pairing mode. For a full reset, refer to the detailed manual online at ned.is/zbsw11wt.

USER MANUAL ZBSW11WT NEDIS

Zigbee Water Detection Sensor

Safety instructions

ZBSW11WT

Illustration of a digital device with a hexagonal logo and Wi-Fi signal icon (no text or symbols)

EN Safety instructions 3

Zigbee Water Detection Sensor

For more information see the extended manual online: ned.is/zbsw11wt

Aboutthisdocument

This document is the user manual and contains all the information for correct, efficient, and safe use of the product.

Ensure you have fully read and understood the instructions in this document before you install or use the product. Keep the packaging and this document for future reference.

Symbolsused

WARNING!

Signal word used to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION!

Signal word used to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE

Signal word used to address practices not related to physical injury.

Intendeduse

This product is intended as a water leak sensor to detect flooding or leakage.

This product requires the Nedis Zigbee Gateway WIFIZBxxx to use the product wirelessly.

This product is intended to be used with the Nedis SmartLife app.

This product is intended for indoor use only.

Only use the product as described in this user manual.

Any modification of the product may have consequences for safety, warranty and proper functioning.

This product is intended to be used in household and similar applications such as kitchen areas.

This product is not intended for professional use.

Safetyinstructions

WARNING!

Safetyhazard:

- Do not dismantle, open or shred batteries.

Firehazard:

- Do not use the product if a part is damaged or defective. Replace a damaged or defective product immediately.

Electricalhazard:

• Do not immerse the product in water or other liquids. Only the battery cover and water detection points are water resistant.
• Make sure the batteries are clean and dry before installation.
• Make sure that the battery polarity (+/-) matches the polarity markings inside the battery compartment.
• Do not use any cell or battery that is not designed for use with the product.
• Use only the cell or battery in the application for which it was intended.
• Wipe the cell or battery terminals with a clean dry cloth if they become dirty.
• Battery usage by children should be supervised.

Chokinghazard:

- Do not let children play with the packaging material. Always keep the packaging material out of the reach of children.

NOTICE

Risk of damaging the product:

• Only use the product as described in this manual.
• Do not drop the product and avoid bumping.

• Do not use aggressive chemical cleaning agents when cleaning the product.

• Store the product in a dry place away from sunlight and protect it against excessive dust and dirt.

• Remove the batteries if you do not use the product for an extended period of time.
• Make sure the batteries are clean and dry before installation.

Disposal

The product is designated for separate collection at an appropriate collection point. Do not dispose of the product with household waste.

For more information, contact the retailer or the local authority responsible for the waste management.

DeclarationofConformity

We, Nedis B.V. declare as manufacturer that the product ZBSW11WT from our brand Nedis ^® , produced in China, has been tested according to all relevant CE standards and regulations and that all tests have been passed successfully. This includes, but is not limited to the RED 2014/53/EU regulation.

The complete Declaration of Conformity (and the safety datasheet if applicable) can be found and downloaded via: nedis.com/zbsw11wt#support

Zigbee-Wasserdetek- tionssensor

ZBSW11WT
