USER MANUAL 59510P Vollrath

Mirage® ProInductionRange

ThankyouforpurchasingthisVollrathequipment.Beforeoperatingthe equipment,readandfamiliarizeyourselfwiththefollowingoperating andsafetyinstructions.SAVETHESEINSTRUCTIONSFORFUTURE REFERENCE.Savetheoriginalboxandpackaging.Usethispackaging toshipthequipmentifrepairsareneeded.

SAFETYPRECAUTIONS

Toensuresafeoperation, read the following statements and understand their meaning. This manual contains safety precautions which are explained below. Please read carefully.

WARNING

Warningisusedtoindicate the presenceofahazardthatwillorca causeseverepersonaljuryordeath.

CAUTION

Cautionisusedtoindicate the presence ofahazardthatwillcauseminorormajorpersonal Injuryifthecautionisignored.

NOTICE:Noticeisusedtonoteinformationthatisimportantbutnot hazard-related.

Toreduceriskofinjuryordamageotheequipment:

• Plugonlyintogroundedelectricaloutletsthatmatchthevoltage on theratinglabel.
• Thisequipmentrequiresadedicatedcircuit.
• Donotusextensioncords, powerstripsorsurgeprotectorswith thisequipment.
• Unplugthisequipmentfromthewalloutletwhennotinuse.
• Usethissequipmentonlyinaflat,levelposition.
• Toprotectagainstelectricalshockdonotimmersethecordorplug inwater.Keeprecordawayfromheatedsurface.Donotletthe cordhangovertheedgeoftableorcounter.
• Asaprecaution, persons using pacemakers should standback 12* (30cm) from an operating unit. Studies have shown that the induction element will not disrupt pacemaker.
• Keepallcreditcards, driver licenses and other items with magnetic stripaway from operating unit. The unit's magnetic field will damage the information on thesesstrips.
• Theheatingsurfaceismadeofastrong,non-porousmaterial. However,shoulditcrackorbreak,stopusingandimmediately unplugtheunit.Cleaning solutionsandspillscouldpenetratethe brokencook-topandcreateariskofelectricalshock.
• Donotoperatethisequipmentwithadamagedcordorplugorifitis notfunctioningproperly.
• Donotoperatunattended.Closelysuperviseunitsoperating in publicareasand/oraroundchildren.
• Donotplaceanyobjectsinsidetheairintakeorexiaustpanels.
• Donotattachanyaccessoryobjectstothisequipment.

ModelDescription

59500PCountertopInductionRange,1800watts

59510PCountertopInductionRange,1440watts

FUNCTIONANDPURPOSE

Thisequipmentisintendedtocookfoodincemercialfoodservice operationsonly.Itsnotintendedforhousehold,industrialor laboratoryuse.Itsis intended to be used with induction-ready cookware.

COOKWARE REQUIREMENTS

Compatible

-Flatbase4%to101

(12.1to26cm)indiameter

-Ferrousstainlesssteel,iron, castiron

Incompatible
lessthan4%

-Baseisnotflat
-Baseislessthan43/4"(12.1cm) indiameter
Pottery, glass, aluminum, bronzeorcoppercookware
-Metaldiskonbottomofpan

Note: Cookware with inferior construction material may not perform well. Cookware with larger based diameter can be used, however only the area of the cookware above the induction coil will heat. The more cookware extends past the coil, themorethe overall performance will be reduced.

NOTICE:EquipmentDamageHazard

Not intended for use withaluminumpanswithametaldisk onthebottom. Underhighheat,themetaldiskwillseparate fromthepan.Thesepansmaydamageyouunitandvoid yourwarranty.

FCCSTATEMENT

ThisequipmenthasbeentestedandfoundtocomplywithPart18of FCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceinaresidentialinstallation.Thisequipment generates,usesandcanradiateradiofrequencyenergyand,ifnot installedandusedinaccordancewiththeinstructions,maycause harmfulinterferencetoradiocommunications.However,thereisno guaranteethatinterferencewillnotoccurinaparticlarinstallation.If thisequipmentdoescauseharmfulinterferencetoradioortelevision reception,whichcanbedeterminedbyturningthequipmentoffand on,theuserisencouragedtotrycorrecttheinterferencebyoneor moreofthefollowingmeasures:

-Reorientorrelocatethereceivingantenna
- Increase the separation between the equipment and receiver
Connectthequipmentintoanoutletonacircuitdifferentfromthat towhichthereceiverisconnected
- Consultthedealeroranexperiencedradio/TVtechnicianforhelp Toassurecontinuedcompliance,anychangesormodificationsnot expresslyapprovedbythepartyResponsibleforcompliancecouldvoid theuser'sauthoritytooperatethisequipment.

INSTALLATION

ClearanceandEnvironmentRequirements

NOTICE: This unit is not designed to be enclosed or built into any area. Sufficient airflow must be allowed around the unit. Blocking the air flow could cause the unit to overheat.

Rearotherangetoanysurroundingsurface:4"10cm)
-Bottomoftherangeoansurroundingsurface: 1 / 2^ (2cm）
-Indooruseonly.
- Donotplatzehquipmentnornearheat-producingequipment.

Installation

NOTICE: This equipment requires dedicated circuit.

NOTICE:Usingavoltageotherthanenameplateratedvoltagewill causedamagetotheunit.Incorrectvoltage,modification tothepowercordorelectricalcomponentscandamage unitandwillvoidthewararranty

1.Placetheinductionrange/warmeronaflatstablesurface.
2.Plugthepowercordintoagroundedelectricaloutletsthatmatchthevoltageontheratinglabel.

FEATURESANDCONTROLS

AOn/OffButton.Presstoturnnontherange.
BPower/TempButton.PresstotogglebetweenPowerand Temperaturecontrol,andFahrenheitandCelsius.
CTimerButton.Presstosethetimer.
DDisplayPanel.Displaythepowerlevel,settemperature,ortime dependinguponthesesectedmode.
ETimerLEDLight. Illuminateswhentimerfunctionisoperating.
F ^C LEDLight. Illuminateswhenthetemperatureinbeing displayedindegreesCentigrade.
G°FLEDLight. llluminateswhenthetemperatureinbeing displayedindegreesFahrenheit.
HControlKnob.Rotatetosettemperature,powerlevelortime,

OPERATION

WARNING

ElectricalShockHazard

Keepwaterandotherliquidsfromenteringtheinsideofthe equipment.Liquidinsidethequipmentcouldcausean electricalshock.

CAUTION

BurnHazard

Don't touch hot food, liquidor heating surfaces while equipment is heating or operating.

NOTICE: Donotpreheatemptycookware. Because of the speed and efficiency of the induction range, cookware can very quickly overheat and bedamaged.

NOTICE: Donotdropcookingutensilsorotherobjectsothe cookingsurface. Thestrong, non-poroussurface will break. Thewarrantydoesn'tcoverthistypeofabuse.

NOTICE: Don'tleaveanemptytanoperatingunit.

NOTICE: Dontheatsealedcansorcontainers, theymayexplode.

TurnontheInductionRange

Pressand release.Thedisplay panelwillshowpowerlevel.

Thisindicatestheunitisheating.

AdjustPowerorTemperature

ToSwitchBetweenPowerandTemperatureModes

Pressandrelease.

ToSwitchBetweenFahrenheitandCelsius

Pressandreleasetwo times.

ToAdjustthePowerLevelorTemperature

1.PressandreleasetoselectPowerorTemperaturemode.
2.Rotatethecontrolknobtoincreaseordecreasethepowerortemperature.

CookFood

The displaywindow should remain constant during operation. If the display is flashing or showing an error message, seethe Troubleshooting section in this manual.

Removingcookwarefromthecookingsurfaceformorethanten minuteswillcausetheunittoautomaticallyturnoff.Removing cookwareforlessthantenminuteswillnotinterruptoperation.

UsetheTimer

1.Pressandrelease.ThetimerLEDwillilluminate.
2.Rotatethecontrolknobotosethimerinfull-minuteincrementes.
3. Whenthimercycleiscomplete,therangewillbeephreetimes andthenturnoff.

4.Tocancelthetimer,press.Theangewillreturntopowerortemperaturemode.

OverheatProtection

Thisinductionrangeisequippedwithanover-heatprotectionfeature.If thetemperatureofthecookingsurfacebecomestoohot,theunitwill turnoff.Thedisplaywillflash“F5”or“F6”toindicatetheequipmentis in“over-heatingprotection”mode. Aftertheequipmenthascooled, presstheON/OFFbutton. Ifdisplaydoesnhow“F5”or“F6”, the equipmenthascooledanditisreadytoresumecooking.

CLEANING

Tomaintaintheappearanceand increasetheservice life,clean your inductionrangedaily.

WARNING

ElectricalShockHazard

Keepwaterandotherliquidsfromenteringtheinsideofthe equipment.Liquidinsidethequipmentcouldcauseanelectricalshock.

CAUTION

BurnHazard

Don't touch hot food, liquidor heating surfaces while equipment is heating or operating.

NOTICE: The cookingsurfacer remainshot even when theisequipment is turned off.

NOTICE: Donotuseabrasivematerials, scratchingcleansorsor scouringpadtocleantheequipment. Thesedamage thefinish.

1. Pressandrelease.

2.Unplugthecordfromthewalloutlet.
3.Allowthequipmenttocool.
4.Wipethexteriorwithacleandampcloth.
5.Thoroughlywipeoffanymildsoaporchemicalcleaners. NOTICE:Residuecouldcorrodethesurfaceoftheunit

TROUBLESHOOTING

ProblemMightbeCausedByCourseofAction
Theunitturnedoffafter10minutes.	Thereisnotapot/panontheinductionrange orthepot/panisnotinduction-ready cookware.Theinductionrangeturnedoff.Thisisanormal.	Verifythepot/panisinductionready.SeetheFUNCTIONand PURPOSESectionofthismanual.
Theunitison,butnothesing.	Thecookwaremaybetooosmallormaynot beinduction-ready.	Verifythepot/panisinductionready.SeetheFUNCTIONand PURPOSEofthismanual.
Thedigitaldisplaylightsare flashing.	Theoverheat-protectionfeaturemayhave activated.	Removecookware.Letcookingsurfacecool.
Theunitsuddenlystoppedworking.	Theunitmaybetoooclosetoanexternalheat sourceorthearitakemayberestricted.	Relocatetheunitawayfromanyexternalheatsourc.Clearany obstructionstotheairtake.
ADDPAN	Apot/panhasnotbeendetectedonde the inductionrange.	Placeinduction-readycookwareontheheatingsurface.
BADPAN,F9	Thecookwaremaybetooosmallormaynot beinduction-ready.	Verifythepot/panisinductionready.SeetheFUNCTIONand PURPOSEofthismanual.
TOOHOT,F2	Theoverheat-protectionfeaturemayhave activated.	Removecookware.Letcookingsurfacecool.Clearany obstructionstotheairtake.
BADFLO,F8	Theunitmaybetoooclosetoanexternalheat sourceorthearitakemayberestricted.	Relocatetheunitawayfromanyexternalheatsourc.Clearany obstructionstotheairtake.
HTSNC,F4	Theoverheat-protectionfeaturemayhave activated.	Removecookware.Letcookingsurfacecool.Clearany obstructionstotheairtake.
HTTH,F5	Theoverheat-protectionfeaturemayhave activated.	Removecookware.Letcookingsurfacecool.Clearany obstructionstotheairtake.
HOT	Nodefect.Indicatesthecookingsurfaceis hotafterheatingcyclehascompleted.	Restartwithpanonsurface.Allowtimeforthecookingsurface tocool.

SERVICEANDREPAIR

ServiceablepartsareavailableonVollrath.com.

To avoid serious injury or damage, never attempt to repair the unit or replace a damaged power cord yourself. Do not send units directly to TheVollrathCompanyLLC. Please contact Vollrath Technical Services for instructions.

When contacting Vollrath Technical Services, please be ready with the item number, model number (if applicable), serial number, and proof of purchaseshowingthedatetheunitwaspurchased.

WARRANTYSTATEMENTFORTHEVOLLRATHCO.L.L.C.

This warranty does not apply to products purchased for personal, family or household use, and The Vollrath Company LLC does not offer a written warranty to purchaseersforsuchuses.

The Volrath Company LLC warrants the products it manufactures or distributes against defects in materials and workmanship as specifically described in our full warranty statement. In all cases, the warranty runs from the date of the end user's original purchase date found on the receipt. Any damages from improper use, abuse, modification or damage resulting from improper packaging during return shipment for warranty repair will not be covered under warranty.

Forcompletewarrantyinformation/productregistrationandnewproductannouncement,visitwww.vollrath.com.

www.vollrath.com

TheVollrathCompany,L.L.C.

1236North18thStreet

Sheboygan.WI53081-3201U.S.A.

MainTel:800.624.2051or920.457.4851

MainFax:800.752.5620or920.459.6573

CustomerService:800.628.0830

CanadaCustomerService:800.695.8560

Technical Services

[e-mail]

InductionProducts:800.825.6036

Countertop WarmingProducts:800.354.1970

Toasters:800-309-2250

AllOtherProducts:800.628.0832
