Product Type	Hair dryer
Brand	Sogo
Model	SS-3620
Supply Voltage	220-240 V ~
Frequency	50-60 Hz
Power	1100-1300 W
Dimensions (approx.)	20 x 8 x 25 cm
Weight (approx.)	0.5 kg
Temperature Settings	2 levels: medium and high
Airflow Settings	2 levels: medium and high
Thermal Protection	Automatic shut-off in case of overheating
Included Accessories	Concentrator
Hanging Loop	Yes, hanging loop
Maintenance	Clean the grilles with a damp cloth; no lubrication required
Safety	Do not use near a water source; unplug after use in a bathroom
Spare Parts	No user-replaceable parts; repair by a qualified technician
General Information	Made in China; imported by Sanysan Appliances S.L.; after-sales service: www.sogosat.com

Frequently Asked Questions - SS-3620 Sogo

How to use the temperature and airflow settings?

The sliding switch allows you to choose between 0 (off), 1 (medium temperature and airflow for gentle drying), and 2 (high temperature and airflow for quick drying).

What to do if the hairdryer suddenly stops?

This is likely due to overheating. Unplug the device, wait 10 to 20 minutes for it to cool down, then check that the ventilation grilles are not blocked before turning it on again.

Can I use the hairdryer in a bathroom?

Yes, but with caution. Unplug it after use because proximity to water poses a risk even when off. It is advisable to install a 30 mA residual current device (RCD) in the bathroom circuit.

How to clean the hairdryer?

Unplug the device. Clean the plastic casing with a damp cloth then dry it. Do not use alcohol or abrasive products. Periodically clean the rear grille and the air outlet grille to remove hair and debris.

Is it normal for the concentrator to heat up during use?

Yes, accessories heat up during use. Wait for them to cool down before touching.

Can I use an extension cord with this hairdryer?

It is not recommended to use an extension cord. If necessary, ensure its power rating is at least equal to that of the product (1100-1300 W) and arrange it to avoid any tripping hazard.

What to do if the power cord is damaged?

Do not use the appliance. The cord must be replaced only by the manufacturer, its service agent, or a similarly qualified person to avoid any hazard.

Can I use the hairdryer on wet hair?

Yes, it is designed to dry damp or wet hair. For optimal styling, hair should remain slightly damp. Avoid over-drying to prevent frizz.

Can the hairdryer be used by children?

It can be used by children over 8 years of age under the supervision of a responsible adult, after receiving instructions on safe use. Children must not play with the appliance nor perform cleaning without supervision.

Where can I find after-sales service for this model?

After-sales service is provided by Sogo. You can contact www.sogosat.com or by email at [e-mail], or by phone at 0034 902 222 161.

USER MANUAL SS-3620 Sogo

TRAVEL HAIR DRYER

Caution: please read and preserve these important instructions. This manual can be downloaded from our website, www.sogo.es in the following languages: SPANISH, CATALAN, ENGLISH, FRENCH, PORTUGUESE, GERMAN, ITALIAN AND MORE.

ref. SS-3620

INDEX

1. Important Note P. 11
2. Symbol definitions P. 11
3. Safety instructions for the user P. 11

I. General precautions during the use of electrical equipment P. 11-12 II. Restrictions on use to avoid personal injury P. 12-13 III. Product use restrictions due to poor condition or breakdown P. 13 IV. Restrictions on use when used with children and elders P. 14 V. IMPORTANT WARNING P. 14-15 VI. Instructions to follow when using the device P. 15-16

1. Technical specifications P. 17
2. Parts description P. 17
3. Instructions for use P. 17
4. Cleaning and maintenance P. 18
5. Declaration of conformity P. 54
6. Responsibility for disposal, details of the manufacturer and after-sales service P. 55

INDEX

Always read the instruction book carefully before using. This manual can be downloaded from our web page www.sogo.es. Keep these instructions for future reference.

2. Symbol definitions

1

GENERAL PRECAUTIONS

1- Important information and useful hints on use. 2- Warning against dangerous situations in terms of life and property. 3- Cautions while using electrical and electronic equipment.

3. Safety instructions for the user

1.

GENERAL PRECAUTIONS

General precautions during the use of electrical equipment

• Do not use the appliance for any other purpose than described in this manual.
• Do not use or store the appliance outdoors.
• Misuse or improper handling may cause problems in the appliance and cause injury to the user.
• The unit must be used only for the intended purposes. No liability is accepted for damages arising from improper use or wrong handling.
• Ensure that the voltage indicated on the nameplate matches the mains voltage before

plugging in the appliance.

Always remove the plug from the power socket when the appliance is not in use. Do not leave the appliance unattended when switched on. Close supervision is necessary when any appliance is being used by or near children. Before cleaning or storing your appliance, always unplug the appliance from the power supply. The device is not completely disconnected from the power source, even after it has been turned off. To disconnect it completely, disconnect it from the mains plug.

Restrictions on use to avoid personal injury

Do not let the appliance operate unattended.

Do not place or operate this appliance near water sources.

Do not place or operate the appliance and its power cord on or near hot surfaces (e.g., stove plates) or open flames.

Do not leave the power cord hanging from sharp edges and keep away from hot objects and flames. Do not wind the cord around the appliance and do not bend it.

Never use accessories that are not recommended by the manufacturer.

The use of accessories not recommended or sold by the appliance manufacturer may result in fire, electric shock or injury to persons.

When you want to remove the plug from the wall contact, please do this at the plug itself and not by pulling on the cable or the appliance itself.

To avoid electric shock, make sure your hands are dry before plugging or unplugging. Do not use the device with wet hands, on damp floors or when the atmosphere is humid, there is a risk of electric shock. While using the appliance, make sure that the power cord must not be caught or crushed. Do not let the motor unit, cord or plug get wet to protect against risk of electric shock.

III. ⚠️ Product use restrictions due to poor condition or breakdown

Never immerse the appliance or the plug in water or any other liquid. In the event of the appliance falling in water, disconnect immediately from the mains supply and take it to an authorized service agent for repair before reusing.

Do not use the appliance if it has fallen on the floor, if there are visible signs of damage or if it has a leak.

Do not use the appliance if the cable or plug is damaged. In case of the cord being damaged, it must be replaced only by the manufacturer, its service agent or similarly qualified persons in order to avoid hazard.

In case of appliance malfunction, or if it has been damaged in any manner, return the appliance to the nearest authorized service facility for examination, repair or adjustment.

- In case of hardware problems, do not attempt to repair the product yourself. Repairs should only be carried out by qualified technicians.

IV. Restrictions on use when used with children and elders

• Children should be supervised to ensure that they do not play with the appliance. - Cleaning and user maintenance shall not be made by children without supervision. - Children shall not play with the appliance. - This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Keep the appliance and its cord out of reach of children less than 8 years. - The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.

V. ⚠️ IMPORTANT WARNING

• To avoid a circuit overload when using this product, do not operate another high-wattage product on the same electrical circuit.
• A short power supply cord is provided with this product. An extension cord is not recommended for use with this product, but if one must be used:

- The marked electrical rating of the cord must be at least as great as that of the product.

- Arrange the extension cord so that it does

not hang where it can be tripped over or pulled unintentionally.

VI. ⚠️! Instructions to follow when using the device

• This appliance works with high temperature, therefore during the use always hold it by the handle and use extreme caution.
• Do not use the dryer inside a bathroom, shower, sauna, etc.
• Never use hairspray with the dryer on ionization.
• Keep away the small objects or mini particles away from the dryer, to prevent to be sucked in through the protection grid.
• Do not leave the device exposed to the weather (rain, sun, frost...)
• Do not use while bathing.
• Do not place or store appliance where it can fall or be pulled into a tub or sink.
• Do not place in or drop into water or other liquid.
• If an appliance falls into water, “unplug it” immediately. Do not reach into the water.
• Never block the air openings of the appliance or place it on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep the air openings free of lint, hair, and the like.
• Never use while sleeping.
• Never drop or insert any object into any opening or hose.
• Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.
• Do not direct hot air toward eyes or other heat sensitive areas.
• Attachments may be hot during use. Allow them to cool before handling.
• Do not place appliance on any surface while it is operating.
• While using the appliance, keep your hair away from the air inlets.
• This hair dryer, if it can be fitted on the wall, should be fitted away and out of reach of persons who are taking a bath or washing themselves.
• When the hairdryer is used in a bathroom, unplug it after use since the proximity of water presents a hazard even when the hairdryer is switched off: For additional protection, the installation of a residual current device (RCD) having a rated residual operation current not exceeding 30mA is advisable in the electrical circuit supplying the bathroom. Ask your installer for advice.
• Danger! Risk of electrocution! Make sure that no objects such as hair clips or hair pins are inserted into the appliance. These can cause a short circuit.
• WARNING: Do not use this appliance near water. Do not use this appliance near bathtubs, showers, basins or other vessels containing water.

READ ALL INSTRUCTIONS BEFORE USING

KEEP AWAY FROM WATER

4. TECHNICAL SPECIFICATIONS

Voltage Power Frequency
220-240V~	1100-1300W	50 – 60Hz

5. PARTS DESCRIPTION

A: Hair dryer B: Back cover C: Rear housing D: On / Off and temperature button E. Hanging loop F. Concentrator

6. INSTRUCTIONS FOR USE

INSTRUCTIONS FOR USE:

1. Your washed hair should be normally dried i.e., by a normal hairdryer, but the hair should remain damp and moistened. When the hairs are dry; slightly dampen it with water.
2. Before styling, brush or comb your hair, ensure that it is entangled. Prevent the hair from becoming too dry: this may result in frizzy hair which is hard to style. Depending on your own views and ideas you can style your hair using hair dryer.

Handling: With the handy sliding-switch the heating and fan capacity can be changed to your individual requirements.

The following settings are possible:

0= off

1 = medium temperature / medium airflow for gentle drying/styling of slightly damp hair 2 = higher temperature / strong airflow for quick drying and/or styling.

THERMAL PROTECTION

1. If due to an obstruction in the protection grid or in the air outlet, the dryer overheats, it has an internal protection system (thermal switch), which activates automatically and results in turning off of hair dryer. If this happens, disconnect the dryer from the mains and wait 10 to 20 minutes before reusing it.

7. CLEANING AND MAINTENANCE

1. Please, disconnect the device first.
2. Clean the plastic surface of the housing with a damp cloth and dry it with a dry one. Do not use alcohol or abrasive products.
3. It is recommended to clean the rear protection grid periodically. Remove the hair and other debris deposited on the grid.
4. Some hair may also be deposited on the air outlet grille, clean it if necessary.
5. This hair dryer model is maintenance free.
6. There is not any need of lubrication or any cleaning liquids.
7. Always make sure to keep the appliance clean for proper operation.
8. To avoid overheating make sure to keep the hair intakes unblocked and unclogged.
9. This appliance should be stored in a safe, cool and dry place.
10. Keep it out of reach of children.
11. In case the dryer stops working, for any reason, turn it off and let it cool for a few minutes before turning it on again.

REMEMBER - Never use the dryer with wet hands, or in a bath, shower, sauna, etc. Do not place it on wet surfaces, such as a damp towel.

1. IMPORTANT:

4. TECHNICAL SPECIFICATIONS

4. TECHNICAL SPECIFICATIONS

4. TECHNICAL SPECIFICATIONS

DECLARATION OF CONFORMITY

This device complies with EU Low Voltage Directive 2014/35/EC.

Electromagnetic Compatibility Directive 2014/30/EU. Directive 2015/863/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

Directive 2009/125/EC on the eco-design requirements applicable to energy-related products.

This symbol on the product or on the packaging indicates that this product cannot be disposed of as normal rubbish or household waste. All electrical and electronic equipment and battery-operated units must be recycled in a proper manner and according to local municipal laws. You can recycle them by taking them to government-authorized disposal centers or specialized bins, which you can find in any nearby large supermarkets, electronics or electro-domestic products stores, or malls that have these types of facilities available.

Designed by: SOGO based on European quality standards. Imported by: Sanysan Appliances S.L, NIF: B98753056, C/ Barcas 2, 2, 46002 Valencia, Spain. Product manufactured in CHINA. After-sales service: www.sogosat.com, [e-mail] / 0034 902 222 161
