87771 - USB Docking Station DeLOCK - Free user manual and instructions

Product Type	USB Docking Station
Brand	DeLOCK
Model	87771
Input Interfaces	USB Type-B (with included USB Type-C adapter)
Output Interfaces	2x HDMI, 1x Gigabit Ethernet RJ45, 6x USB (2x USB 3.2 Gen 1, 4x USB 2.0), 1x 3.5mm microphone input, 1x 3.5mm speaker output
Maximum Resolution (Single Display)	Up to 2560 x 1440 @ 50 Hz
Maximum Resolution (Dual Display)	Up to 2048 x 1152 @ 60 Hz
Functions	Mirror or Extended Mode
System Compatibility	Windows 8.1/10, Mac OS 10.15.5+
Power Supply	External Power Adapter 5V/4A (Input 100-240V AC)
Dimensions (Without Stand)	190 x 78 x 38 mm
Color	Black / White
Length of Included USB Cable	Approx. 1 m
Package Contents	Docking Station, USB Type-B to USB Type-A Cable (with Type-C Adapter), Power Supply, Manual
Driver Installation	Required, Driver to Download from DeLOCK Website
Maintenance and Cleaning	Clean with a dry, soft cloth. Avoid contact with water or moisture.
Safety	Protect from moisture and direct sunlight. Do not open the casing.
Warranty	Check the Retailer's Terms (Not Specified by the Manufacturer).

Frequently Asked Questions - 87771 DeLOCK

How to install the docking station drivers?

First, connect the docking station to your computer. Then download the driver from the official product page: www.delock.com/produkte/G_87771/treiber.html. Run the downloaded file and follow the installation instructions. A restart may be required.

Why is the external display not showing?

Check that the driver is properly installed. Make sure the HDMI cable is connected and the display is on. On Windows, right-click on the desktop and select Display settings to detect the display. On Mac, go to System Preferences > Displays.

Can I use the docking station with a Mac?

Yes, it is compatible with Mac OS 10.15.5 or later. After installing the driver, go to System Preferences > Security & Privacy > Privacy and check DisplayLinkUserAgent if necessary.

How to configure display mode (mirror or extended)?

On Windows: right-click on the desktop, choose Display settings then select the desired mode from the dropdown. On Mac: System Preferences > Displays and choose the arrangement. Note: on Windows, only one screen can be mirrored, the second is extended.

Does the docking station charge my laptop?

No, this docking station does not provide charging for the computer. It requires an external power supply of 5V/4A (included) to power its ports. The USB ports can charge peripherals (including one port with BC1.2).

Can I connect USB 3.0 devices?

Yes, the station has 2 USB 3.2 Gen 1 ports (formerly USB 3.0) on the front, supporting USB 3.0 devices. The 4 USB 2.0 ports on the back are limited to 480 Mbps.

How to connect a microphone or speakers?

Connect your microphone to the 3.5 mm jack labeled microphone (input) and your speakers to the stereo speaker jack (output). The audio ports are located on the front of the station.

The Ethernet network is not working, what to do?

Make sure the RJ45 cable is properly connected. Check your computer's network settings. The station supports 10/100/1000 Mbps automatically. If the problem persists, restart the station and the computer.

What is the maximum supported resolution?

With a single display: up to 2560 x 1440 @ 50 Hz. With two displays simultaneously: up to 2048 x 1152 @ 60 Hz. Resolution depends on the system and monitor used.

Where to find the latest drivers or manuals?

Drivers and documentation are available on the official DeLOCK website: www.delock.com/produkte/G_87771/treiber.html. You can also contact support by email: [e-mail].

USER MANUAL 87771 DeLOCK

USB Docking Station Dual HDMI

White DOLOCK 3D printer front panel with visible ports and connectors (no text or symbols on device body)

CEFC|

Product-No:87771

front side:

1	1 x USB 3.2 Gen 1 Type-A female
2	1 x USB 3.2 Gen 1 Type-A female - Battery Charging specification BC1.2
3	1 x speaker 3.5 mm stereo jack
4	1 x microphone 3.5 mm stereo jack

back side:

5	4 x USB 2.0 Type-A female
6	1 x Gigabit LAN 10/100/1000 Mbps RJ45 jack
7	2 x HDMI-A female
8	1 x USB 3.2 Gen 1 Type-B female downstream port
9	1 x DC 5 V power connector

Description

This docking station by Delock can be connected to a computer with a USB-C™ or USB Type-A port and provides a variety of interfaces. Two monitors can be operated simultaneously at the HDMI output ports. Four built-in USB 2.0 ports and two USB 3.2 Gen 1 ports allow the use of peripherals, and connections for microphone and speaker and Gigabit network complete the features.

Full-HD resolution

Full-HD (1080p) resolution is possible when using only one monitor and also when using both HDMI outputs at the same time.

Specification

- Connectors:

front side:

1 x SuperSpeed USB (USB 3.2 Gen 1) Type-A female 1 x SuperSpeed USB (USB 3.2 Gen 1) Type-A female - Battery Charging specification BC1.2

1 x microphone 3.5 mm stereo jack

1 x speaker 3.5 mm stereo jack back side:

1 x SuperSpeed USB (USB 3.2 Gen 1) Type-B female

1 x DC 5 V power connector

2 x HDMI-A female

1 x Gigabit LAN 10/100/1000 Mbps RJ45 jack

4 x USB 2.0 Type-A female

- Maximum resolution (depending on the system and the connected hardware): Single display: up to 2560 x 1440 @ 50 Hz

Dual display: up to 2048 x 1152 @ 60 Hz

• Transmission of audio and video signals

- Functions: Mirrored or Extended (under Windows only one display can be mirrored, the second one is extended)

• Colour: black / white

- Dimensions without stand (LxWxH): ca. 190 x 78 x 38 mm

Power supply specification

• Wall power supply
• Output: 5 V / 4 A
  • Ground outside, plus inside
• Dimensions:
  inside: ca. 1.7 mm
  outside: ca. 4.75 mm
  length: ca. 9.5 mm

- Input: AC 100 \~ 240 V / 50 \~ 60 Hz / 0.8 A

System requirements

• Mac OS 10.15.5 or above
• Windows 8.1/8.1-64/10/10-64
• PC or laptop with a free USB Type-A port or
• PC or laptop with a free USB Type-C™ port

Package content

• USB docking station
• Cable USB Type-B male to USB Type-A male (with adapter to USB Type-C™ male), length ca. 1 m
• Power supply
• User manual

Safety instructions

• Protect the product against moisture
• Protect the product against direct sunlight

Driver Installation

1. Switch on your computer.
2. Connect the docking station to an available USB port of your computer.
3. Download the driver from the product page: https://www.delock.com/produkte/G_87771/treiber.html.
4. Follow the instructions of the driver installation.
5. The driver will now be installed.
6. Click on "Finish".
7. Your computer will ask to reboot. Click "Yes" to restart the computer.
8. After restart you can start using the device immediately.

Configuration

1. Network connection: Supports 10/100/1000 Mbps and can be used immediately.
2. USB ports: You can now connect your devices to these 6 ports.

3. Audio ports: You can connect your headset and your speakers to the audio ports.

4. HDMI ports: You can set the additional displays on mirroring or extended. In order to change the setting, proceed like this:

Windows: Click with the right mouse button on the desktop and click on "display settings".

Afterwards you can change the graphics settings.

Mac: Open the System Preferences > Displays.

It can happen that the security settings need to be changed. Therefore go to System Preferences > Security & Privacy > Privacy and set the hook on "DisplayLinkUserAgent".

Note

Under Windows only one display can be mirrored, the second one is extended.

Support Delock

If you have further questions, please contact our customer support [e-mail]

You can find current product information on our homepage: www.delock.com

Final clause

Information and data contained in this manual are subject to change without notice in advance. Errors and misprints excepted.

Copyright

No part of this user manual may be reproduced, or transmitted for any purpose, regardless in which way or by any means, electronically or mechanically, without explicit written approval of Delock.

Edition: 08/2020

Kurzbeschreibung

Declaration of conformity

Products with a CE symbol fulfill the EMC directive (2014/30/EU), the ErP directive (2009/125/EC), LVD directive (2014/35/EU) and RoHS directive (2011/65/EU+2015/863), which were released by the EU-comission.

The declaration of conformity can be downloaded here:

http://www.delock.de/service/conformity

WEEE-notice

The WEEE (Waste Electrical and Electronic Equipment)-directive, which became effective as European law on February 13th 2003, resulted in an all out change in the disposal of disused electro devices. The primarily purpose of this directive is the avoidance of electrical waste (WEEE) and at the same time the support of recycling and other forms of recycling in order to reduce waste. The WEEE-logo on the device and the package indicates that the device should not be disposed in the normal household garbage. You are responsible for taking the disused electrical and electronical devices to a respective collecting point. A separated collection and reasonable recycling of your electrical waste helps handling the natural resources more economical. Furthermore recycling of electrical waste is a contribution to keep the environment and thus also the health of men. Further information about disposal of electrical and electronical waste, recycling and the collection points are available in local organizations, waste management enterprises, in specialized trade and the producer of the device.
