USER MANUAL RCST-9400D Royal Catering

TECHNISCHES DATENBLATT

Thank you for choosing this quality product by Royal Catering!

CAUTIONS

General safety information for the use of electrical devices:

To avoid injury from fire or electric shock, please ensure compliance with safety instructions when using this device. Please read the instruction carefully and make sure that you have understood it well. Keep the manual near the equipment to be able to read it at any time. Always use current sources connected to the ground and providing the necessary voltage (indicated on the label on the device). If you have any doubt, let an electrician check that your outlet is properly grounded. Never use a damaged power cable. Do not open the unit in damp or wet environment, or if you are wet yourself. Protect the unit of solar radiation. Use the device in a protected location to avoid damaging the equipment or endangering others. Make sure the device is able to cool and avoid placing it too close to other devices that produce heat. Before cleaning, disconnect it. Use a soft damp cloth for cleaning. Avoid using detergent and make sure that no liquid enters the unit. No internal element of this device needs to be maintained by the user. An opening of the device without our approval leads to a loss of warranty.

General safety information for the use of soup kettle:

• The user manual should be kept close to the device and should always be accessible for the users. Instruct your employees how to use the soup kettle properly.
• Make sure the hot air can circulate well and place the device more than 10cm away from walls and other electrical devices. Aerate well the working area.
• Do not place the device close to combustible materials.
• Some parts of the device can get extremely hot. To avoid any injuries, be careful by every contact with the device.
• The food warmed up by the device can get really hot. Do not forget to use adapted protections
• Clean the device regularly to avoid a durable encrustation of dirt.

TECHNICAL DATA

Model RCST-9400 RCST-9400D
Rated voltage 230V 230V
Frequency 50Hz 50 Hz
Rated power 400W 400W
Capacity 10 | 10 |
Temperature range	30°C - 85°C	30°C - 90°C

SCOPE OF DELIVERY

Soup kettle with lid.

Instruction manual.

USAGE PURPOSE

This soup kettle warmer is designed for heating and keeping warm soups, goulashes and sausages only. This soup kettle warmer is not designed to cook soups or sauces, nor is it designed to re-thermalize cold or frozen products. Always keep the hinged lid attached and closed when not serving.

Assembly - RCST-9400

The device is composed of:

I - soup kettle, the outer container;
2-rotating, hinged lid;
3-ladlecut;
4-indicator light;
5 - power control;
6 -inner container;
7-ring.

Assembly - RCST-9400D

The device is composed of:
I - soup kettle, the outer container;
2-rotating, hinged lid;
3-ladlecut;
4 - digital thermostat;
5-inner container;
6-ring.

DIGITAL THERMOSTAT

POWER - power on / off; setting the temperature upward

HEAT - control light is on when the device is in heating mode

KEEP - control light is on when the device keeps the desired temperature

SET - setting a lower temperature

BEFORE FIRST USE

Checking packaging upon consignment

When the goods are received proceed with opening the packaging if there are no signs of damage. If when the goods are delivered there are signs of damage to the packaging, such as agent or courier, and within three days from the date indicated on the documents draw up a detailed list and report of all damage to the goods. Do not turn the packed goods upside down! When transporting the package make sure its four main points are rmly secured (maintain the goods parallel to the ground).

Disposing of packaging

The various items used for packaging (cardboard, plastic straps, polyurethane foam) should be conserved, so that the device can be sent back to the service centre in best conditions in case of problem.

DEVICE INSTALLING

Appliance location

The work surface where the device will be located must be suitable for the size of the appliance, please refer to the measurements. The work surface must be levelled and dry and at a limiting height from the ground to enable a proper use of the device.

The environmental humidity shouldn't be over 85% . The power cord connected with the appliance must be reliable grounding and correspond to the technical details.

OPERATION

• Add 0.6 litres of water to the outer container before placing the inner container insert into the warmer. Never over-ill with water. Under no circumstances should the inner container float, ever when empty. Remove any excess water immediately.

- Put the plug into the power socket.

RCST-9400

• Turn the soup kettle on. The indicator light will glow, showing that the unit is on. Adjust the temperature control dial to the correct setting:

• Settings 8-12 are designed for initial warm-up.
  Normal control settings range from I-8.

• Once the kettle has reached the desired temperature, adjust the temperature control dial to a lower setting. It is recommended that the lowest possible setting that maintains food serving temperatures be used.

RCST-9400D

• Turn the soup kettle on by pressing the POWER button. Display will be on.

• Press SET button for setting the desired temperature. Display will flash, temperature can be set by buttons POWER (increasing the temperature) and SET (reducing the temperature). After setting, do not press any button for about 6 seconds and machine will start working.

• Push POWER button during normal work, display will show "--" and the device will turn off.

• When the device cooled down, clean it. This should be done after each use to keep the device in perfect hygienic condition. To clean the rest of the device, watch up to protect the electric parts from humidity and from direct water contact to avoid electric shocks and short-circuits. An impregnated cloth is easily enough if you regularly clean the device.

• If you don't use the device for a longer time or stock it, check the humidity and temperature conditions: The air has to be dry and the device should be covered to be protected from dust deposits.

REGULAR CONTROL OF THE DEVICE

Control regularly that the device doesn't present any damage. If it should be the case, please contact your customer service to solve the problem.

What to do in case of problem?

Please contact your customer service and join following information:

• Invoice number and serial number (the latest is to be found on the technical plate on the device).
• If relevant, a picture of the damaged, broken or defective part.
• It will be easier for your customer service clerk to determinate the source of the problem if you make a detailed and precise description of the matter. Avoid formulations like "the device doesn't heat", which may mean that it doesn't heat enough or even not at all. Though, those two possibilities have a different causation!
• Still indicate the performance of the lights to facilitate the diagnosis: Is the light of the ON/OFF switch on when the rocker switch is in ON position? Does the control light turn on when the device is working?

The more detailed your information, the quicker the customer service will be able to answer your problem rapidly and efficiently!

INSTRUKCJA OBSLUGI

User Manual | Bedienungsanleitung | Manuale di istuzioni | Manuel d'utilisation | Manual de uso

KOCIOLEK DO PODGRZEWANIA ZUP

RCST-9400
RCST-9400D

expono.de

Competition RCST-9400

Competition RCST-9400D

For the disposal of the device please consider and act according to the national and local rules and regulations.
