305862 - Computer accessory CSL - Free user manual and instructions

Brand	CSL
Model	305862
Product type	HDMI splitter
Category	Computer accessory
HDMI input	1 HDMI port
HDMI output	2 HDMI ports
Maximum resolution	UHD (2160p) @30 Hz
Power supply	Included power supply, input 100-240 V~ 50/60 Hz, output 5 V ⎓ 1 A
Dimensions (H x W x D)	2 cm x 5.5 cm x 6 cm
Weight (device only)	127 g
Ambient temperature	0-3°C to 35-40°C
Main features	Transfers signal from one HDMI source to two displays simultaneously; automatic detection of the lowest resolution
Package contents	2-port HDMI splitter, power supply, user manual
Care and cleaning	Disconnect before cleaning; use a dry, soft cloth; avoid moisture
Safety	Do not open or repair yourself; use in dry indoor environments; avoid water, moisture, thermal shock, and vibration
Spare parts and repairability	No spare parts provided; any repair by a third party voids the warranty
General information	WEEE Directive 2012/19/EU; WEEE registration number: DE 67896761; declaration of conformity available from WD Plus GmbH

Frequently Asked Questions - 305862 CSL

How to connect the HDMI splitter?

Turn off all devices. Connect the power supply to the splitter (Power port). Connect your HDMI source to the input, then both displays to outputs 1 and 2. Plug the power supply into the mains, then turn on the devices.

What is the maximum supported resolution?

The splitter supports a maximum resolution of UHD (2160p) at 30 Hz. It automatically adapts to the lowest resolution of the two connected displays.

Can I use HDMI cables longer than 5 meters?

For UHD resolutions, it is not recommended to exceed a total cable length (input + output) of 5 meters, otherwise image quality may be lost.

How to set the maximum resolution on a specific display?

The maximum resolution is set by the HDMI 2 output. Connect the display with the lower resolution to this output. After disconnection, the splitter uses the settings from output 2.

Does the splitter work with all HDMI devices?

Yes, the splitter is compatible with most HDMI sources (Blu-ray player, console, PC) and displays (TV, monitor, projector). It automatically detects resolutions.

Is it possible to connect a 4K display and a Full HD display at the same time?

Yes, but both displays will show the lowest resolution (Full HD). To enjoy 4K, both displays must support UHD.

Is the power supply mandatory?

Yes, the splitter requires the included power supply (5 V ⎓ 1 A) to operate. Plug it into a properly wired mains outlet.

What to do in case of display problems?

Check that all cables are properly connected and that the power supply is plugged in. Try swapping HDMI cables or connecting the displays one at a time. Restart the devices.

How to clean the splitter?

Disconnect the device before cleaning. Use a dry, soft cloth. Do not use liquid or abrasive products. Avoid moisture entering the device.

How to dispose of this product at end of life?

Do not throw the device in household waste. Take it free of charge to a WEEE collection point, manufacturer, or retailer. Comply with Directive 2012/19/EU (registration number: DE 67896761).

USER MANUAL 305862 CSL

Thank you for choosing a CSL product. Please read the following user manual carefully so that you can enjoy your purchased product. Before using the delivered product, check that it is complete, faultless and undamaged.

1. Scope of delivery

• 2 Port HDMI Splitter
  Power supply
• User manual

2. Technical data

Input 1 x HDMI socket
Output 2 x HDMI socket
Maximal resolution UHD (2160p) @30 Hz
Current supply via enclosed power supply unit
Power supply	• Input: 100-240 V 50-60 Hz AC • Output: 5V 1A DC
Dimensions (H x W x D) 2 cm x 5.5 cm x 6 cm
Weight 127g (device only)
Ambient temperature + 0-3°C to 35-40°C

3. Properties

With this HDMI splitter you can transmit the signal of an HDMI player to two display devices (TV, monitor, projector) simultaneously. The splitter detects the maximum resolutions of the display devices automatically. The HDMI splitter adjusts to the device with the lowest value.

4. Getting started

Take out the HDMI splitter and the power supply from the packaging. Connect the power supply to the corresponding port on the splitter labeled „Power".

Turn off all devices you want to connect and link them to the splitter by using a suitable HDMI cable. The various HDMI ports of the splitter are explained in the table below:

Input Port of the HDMI player

Output 1 Port of the first HDMI display device

Output 2 Port of the second HDMI display device

Now plug the power supply of the HDMI splitter into a properly installed grounded socket and turn on the devices connected by the HDMI cable. The splitter is now ready for use.

Note: Please note that the maximum resolution is determined at HDMI output 2. To do this, connect the device with the lower resolution to output 2.

After disconnecting the power, the splitter takes over the maximum settings of the HDMI output 2. To ensure correct performance, we recommend to connect the device with the lower configuration options (resolution) to the HDMI output 2.

Note: Please note that for UHD resolutions a maximum cable length of 5m should not be exceeded, otherwise the image quality may be affected (HDMI input + HDMI output = total length).

5. Safety instructions and liability disclaimer

Never try to open the device to carry out repairs or conversions. Avoid contact with mains voltages. Do not short-circuit the product. The device is not certified for use in the open air; only use it in dry conditions. Protect it from high humidity, water and snow. Keep it away from high temperatures. Do not subject the device to sudden changes in temperature or heavy vibration as this might damage electronic components. Examine the device for damage before using it. The unit should not be used if it has received an impact or has been damaged in any other way. Please observe national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or alteration to the device not carried out by the original supplier, will invalidate the

warranty or guarantee. The product may only be used by persons who have read and understood these instructions. The device specifications may change without any separate prior notice to this effect.

6. Disposal instructions

Electrical and electronic devices may only be disposed of in accordance with the European WEEE Directive and not with household rubbish. Components must be disposed of or recycled separately as dangerous, toxic elements can inflict sustained damage on the environment if they are disposed of incorrectly. As a consumer, you are bound by the Electrical and Electronic Devices Act (ElektroG) to return electrical and electronic goods free of charge at the end of their useful life to the manufacturer, the place of purchase or to specially set up, public collection points. The details in each case are governed by national law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating materials in this way, recycling and disposing of old devices, you are making an important contribution towards protecting our environment.

WEEE Directive: 2012/19/EU
WEEE Register No: DE 67896761

WD Plus GmbH hereby declares that the device 305862 complies with the basic requirements and other relevant regulations. A complete declaration of conformity can be found at : WD Plus GmbH, Wohlenbergstraße 16, 30179 Hanover, Germany

(FR) +49511/13221730

(IT) +49511/13221740

(ES) +49511/13221750

MO-FR 9:30am - 18pm CET

downloads.ganziinfach.de

WD Plus GmbH
