USER MANUAL DWOAS6PS DEWALT
English (original instructions) 5
Components
1 Pole saw attachment
2 Sprocket cover
3 Bar lock nut (x2)
4 Oil cap
5 Branch removal hook
6 Guide bar
7 Saw chain
8 Chain tensioning screw
9 Oil reservoir
10 Oil adjustment screw
11 Extension pole
12 Extension pole coupler
13 Knob
Composants
WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
WARNING: To reduce the risk of injury, read the instruction manual.
Intended Use
This pole saw attachment is to be used only with DEWALT powerhead. This pole saw has been designed for professional and residential trimming applications and is ideal for pruning applications and cutting limbs up to 8" (203 mm) in diameter.
DO nOT use this appliance for any job except that for which it is intended.
DO nOT use under wet conditions or in the presence of flammable liquids or gases.
DO nOT let children come into contact with the tool. Supervision is required when inexperienced operators use this tool.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of personal injury or property damage.
DANGER: Indicates an imminently hazardous section which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage.
WARNING: Read all safety warnings, instructions, indications and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1) Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2) Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of electric shock.
3) Personal Safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
English
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects,
that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 265 °F (130 °C) may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions.
Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce risk of injury:
• Before any use, be sure everyone using this unit reads and understands all safety instructions and other information contained in this manual.
- Save these instructions and review frequently.
WARNING: When using electric gardening tools, basic safety precautions should always be followed to reduce risk of fire, electric shock, and personal injury, including the following.
- Avoid Dangerous Environment – Don't use tools in damp or wet locations.
- Don't Use In Rain.
- Keep Children Away – All visitors should be kept at a distance of 100' (30 m) from work area.
- Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of rubber gloves and substantial footwear is recommended when working outdoors. Wear protective hair covering to contain long hair.
- Use Safety Glasses – Always use face or dust mask if operation is dusty.
- Use Right Tool – Do not use tool for any job except that for which it is intended.
-
Don't grasp the exposed cutting blades or cutting edges when picking up or holding the tool.
-
Don't Force Tool – It will do the job better and with less likelihood of a risk of injury at the rate for which it was designed.
- Don't Overreach – Keep proper footing and balance at all times.
- Stay Alert – Watch what you are doing. Use common sense. Do not operate tool when you are tired.
- Disconnect Tool – Remove the battery when not in use, before servicing, when changing accessories such as blades, and the like.
- Store Idle Tools Indoors – When not in use, tools should be stored indoors in dry, and high or locked-up place – out of reach of children.
- Maintain Tool With Care – Keep cutting edge sharp and clean for best performance and to reduce the risk of injury. Follow instructions for lubricating and changing accessories. Inspect tool power source periodically, and if damaged, have it repaired by an authorized service facility. Keep handles dry, clean, and free from oil and grease.
- Check Damaged Parts – Before further use of the tool, a guard or other part that is damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other condition that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced by an authorized service center unless indicated elsewhere in this manual.
SAVE THESE INSTRUCTIONS
WARNING - Do not operate near electrical power
The unit has not been designed to provide protection from electric shock in the event of contact with overhead electric lines, Consult local regulations for safe distances from overhead electric power lines and ensure that the operating position is safe and secure before operating the saw chain pole pruner.
- Keep all parts of the body away from the saw chain. Do not remove cut material or hold material to be cut when blades are moving. Make sure the switch is off when clearing jammed material. Blades coast after turn off. A moment of inattention while operating the pole saw may result in serious personal injury.
- Carry the pole saw by the handle with the saw chain stopped. When transporting or storing the pole saw always fit the saw chain device cover. Proper handling of the pole saw will reduce possible personal injury from the saw chain.
- Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact hidden wiring. A saw chain contacting a "live" wire may make exposed metal parts of the tool "live" and could give the operator an electric shock.
- Do not use the pole saw in bad weather conditions, especially when there is a risk of lightning. This decreases the risk of being struck by lightning.
• Always use two hands when operating the pole saw.
Hold the pole saw with both hands to avoid loss of control.
• Always use head protection when operating the pole saw overhead. Falling debris can result in serious personal injury.
SPECIFIC SAFETY RULES
WARNING: Some dust contains chemicals known to state of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• compounds in fertilizers,
• compounds in insecticides, herbicides and pesticides,
• arsenic and chromium from chemically treated lumber.
To reduce your exposure to these chemicals, wear approved safety equipment such as dust masks that are specially designed to filter out microscopic particles.
- Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling, and other construction activities. Wear protective clothing and wash exposed areas with soap and water. Allowing dust to get into your mouth, eyes, or lay on the skin may promote absorption of harmful chemicals.
WARNING: Use of this tool can generate and/or burse dust, which may cause serious and permanent respiratory or other injury. Always use approved respiratory protection appropriate for the dust exposure. Direct particles away from face and body.
CAUTION: Wear appropriate personal hearing protection during use. Under some conditions and duration of use, noise from this product may contribute to hearing loss.
Before Operating Pole Saw
- For safe operation, read and understand all instructions before using the pole saw. Follow all safety instructions. Failure to follow all safety instructions listed below, can result in serious personal injury.
- Watch what you are doing. Use common sense. Do not operate pole saw when you are tired.
- Use pole saw for cutting tree branches only. Do not use pole saw for purposes not intended. Do not use for cutting other items.
- Only well-instructed adults should operate pole saw. Never allow children to operate.
- Do not allow children or untrained individuals to use this unit.
- Wear the following safety gear when operating pole saw:
- heavy-duty gloves
- steel-toed safety footwear with non-skid soles
- safety glasses, goggles or face screen
- safety hard hat
- ear mufflers or ear plugs
ENGLISH
- face or dust mask (if working in dusty areas)
- Wear heavy long pants and boots. Do not wear loose fitting clothing, short pants, jewelry of any kind, or go barefoot.
-
Secure long hair to prevent entanglement in any moving parts.
• Before cutting, always provide the following:
-
clear work area
- secure footing
-
planned retreat path from falling limbs
-
Inspect tree before trimming. Make allowance for branches to fall freely to the ground.
- Do not use your pole saw to fell saplings.
While Operating Pole Saw
DANGER: To reduce the risk of electric shock use on wet surfaces. Do not expose to rain.
Store indoors.
DANGER: Avoid Unintentional Starting – with battery installed, don't carry appliance with with finger on switch. Be sure switch is off when installing battery.
- The extension pole should exclusively be used with the pole saw attachment. Only one extension pole should be used with the pole saw attachment. Do not use more than one extension pole. Do not use the extension pole with any other attachments.
- Stay alert. Use common sense while operating the unit.
- Keep work area clean. Cluttered areas invite injuries.
• Always remove battery from pole saw when finished cutting or when left unattended.
- Keep children, animals and bystanders at least 15 m away from pole saw. Only pole saw user should be in work area.
- Do not use the pole saw to cut down trees.
- Do not grasp the exposed saw chain when picking up or holding the pole saw.
- Keep finger off trigger until ready to make cut.
- Before starting pole saw, make sure chain is not touching anything.
- Keep all parts of body away from chain when pole saw is running.
- Do not force pole saw while cutting. Apply light pressure. It will do the job better and safer at the rate for which it was intended.
-
Carry pole saw from one place to another:
-
with battery removed,
- fingers off/away from trigger,
- by holding pole at balance point, and
-
with guide bar and chain to rear and with scabbard attached.
-
Do not cut small brush and saplings with the pole saw. Slender matter may catch in the chain and be whipped toward you. This could also pull you off balance.
-
Do not operate in poor lighting.
-
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure to hot surfaces.
- Keep all parts of your body away from any moving part.
- Do not, under any circumstance, use any attachment or accessory on this product, which was not provided with the product, or identified as appropriate for use with this product in this instruction manual.
- Inspect pole saw before each use and after dropping or other impacts. Ensure there are no significant defects or damage.
Do Not Operate Pole Saw:
- while under the influence of alcohol, medication, or drugs.
- in rain or in damp or wet areas.
- where highly flammable liquids or gases are present.
- if pole saw is damaged, adjusted incorrectly, or not fully and securely assembled.
- if trigger does not turn pole saw on and off. Chain must stop moving when you release trigger. Have faulty switch replaced by authorized service center. See
Accessories under Maintenance.
- while in a hurry.
- while in a tree or on a ladder.
- while on aerial booms, buckets or platforms.
- during high wind or storming weather.
GENERAL SAFETY RULES
DANGER: Shock Hazard. Serious injury or death from electrical ocution if power lines are contacted. Never use near any electrical source, wires, or power lines.
WARNING: For safe operation read and
understand owner's manual. Wear face shield (and/or safety glasses) and hard hat to protect against falling debris. Always have a clear work area, retreat path, and be aware of limb/branch location to avoid falling limbs and debris. Keep bystanders 50 feet (15 m) away when operating saw. To reduce the risk of electric shock do not use on wet surfaces. Do not expose to rain. Store indoors.
- To protect yourself from falling branches do not stand directly under the branch or limb being cut. This unit should not be held at an angle over 60^ from ground level.
- Keep the handles dry, clean, and free of oil.
- Before you start the unit, make sure the chain is not contacting any object.
- Make sure the cutting chain has stopped before setting the unit down.
Service
- Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. Refer to the Maintenance section of this manual.
- When servicing a tool, use only identical replacement parts.
Follow instructions in the Maintenance section of this manual.
Use of unauthorized parts or failure to follow maintenance instructions may create a risk of electric shock or injury.
Guard Against Kickback
WARNING: KICKBACK may occur when the nose or tip on the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut. Tip contact in some cases may cause a lightning fast reverse reaction, kicking the guide bar up and back towards the operator. Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator. Either of these reactions may cause you to lose control of the saw which could result in serious injury to user.
The following precautions should be followed to minimize kickback:
- Hold the saw firmly with both hands when the unit is running. Use a firm grip with thumbs and fingers encircling the saw powerhead handle and auxiliary handle. DO NOT use the pole as a grasping surface.
- Do not overreach.
- Keep proper footing and balance at all times.
- Don't let the nose of the guide bar contact a log, branch, ground or other obstruction.
- Do not extend pole saw handle above shoulder height.
- Use devices such as reduced kickback chain, chain braking system and special guide bars that reduce the risks associated with kickback.
- Only use replacement bars and chains specified by the manufacturer or the equivalent.
- Never let the moving chain contact any object at the tip of the guide bar.
- Keep the working area free from obstructions such as other trees, branches, rocks, fences, stumps, etc. Eliminate or avoid any obstruction that your saw chain could hit while you are cutting through a particular log or branch.
- Keep your saw chain sharp and properly tensioned. A loose or dull chain can increase the chance of kickback. Check tension at regular intervals with the motor stopped and battery removed.
- Begin and continue cutting only with the chain moving at full speed. If the chain is moving at a slower speed, there is a greater chance for kickback to occur.
- Cut one branch at a time.
- Use extreme caution when re-entering a previous cut. Engage spiked bumpers into wood and allow chain to reach full speed before proceeding with cut.
- Do not attempt plunge cuts or bore cuts.
- Watch for shifting branches or other forces that could close a cut and pinch or fall into chain.
Kickback Safety Features
WARNING: The following features are included on your pole saw to help reduce the hazard of kickback; however such features will not totally eliminate this dangerous reaction. As a pole saw user do not rely only on safety devices. You must follow all safety precautions, instructions, and maintenance in this manual to help
avoid kickback and other forces which can result in serious injury.
- Reduced-Kickback Guide Bar, designed with a small radius tip which reduces the size of the kickback danger zone on bar tip. A reduced- kickback guide bar is one which has been demonstrated to significantly reduce the number and seriousness of kickbacks when tested in accordance with safety requirements for electric chain saws.
- Reduced Kickback Chain, designed with a contoured depth gauge and guard link which deflect kickback force and allow wood to gradually ride into the cutter. A reduced-kickback chain is a chain which has met kickback performance requirements when tested on the representative sample of chain saws.
Pole Saw Names and Terms
- Drive Sprocket or Sprocket - The toothed part that drives the saw chain.
- Guide Bar - A solid railed structure that supports and guides the saw chain.
- Guide Bar Scabbard - Enclosure fitted over guide bar to prevent tooth contact when saw is not in use.
- Kickback - The backward or upward motion, or both of the guide bar occurring when the saw chain near the nose of the top area of the guide bar contacts any object such as a log or branch, or when the wood closes in and pinches the saw chain in the cut.
- Reduced Kickback Chain - A chain that complies with the kickback performance requirements. (when tested on a representative sample of chain saws.
- Reduced Kickback Guide Bar - A guide bar which has been demonstrated to reduce kickback significantly.
- Replacement Saw Chain - A chain that complies with kickback performance requirements when tested with specific chain saws. It may not meet performance requirements when used with other saws.
- Saw Chain - A loop of chain having cutting teeth, that cut the wood, and that is driven by the motor and is supported by the guide bar.
- Spiked Bumper (Spike) - The pointed tooth or teeth for use when pruning to pivot the saw and maintain position while sawing.
- Switch - A device that when operated will complete or interrupt an electrical power circuit to the motor of the chain saw.
- Switch Lockout - A movable stop that prevents the unintentional operation of the switch until manually actuated.
- Trimming (Pruning) - Process of cutting limbs from a tree.
- Undercut - An upward cut from underside of a log or limb. This is done while in normal cutting position and cutting with top of guide bar.
Storage
- Store indoors. The best storage place is one that is cool and dry away from direct sunlight, excess heat or cold and out of the reach of children.
- Always reduce the tension off the chain again after finishing work. The chain contracts as it cools down. If tension is not reduced, it can damage the saw.
ENGLISH
WARNING: Never modify the power tool or any part of damage or personal injury could result.
WARNING: ALWAYS use safety glasses. Everyday eyeglasses are NOT safety glasses. Also use face or dust mask if operation is dusty. ALWAYS WEAR CERTIFIED SAFETY EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratory protection.
WARNING: Some dust contains chemicals known to state of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• compounds in fertilizers,
• compounds in insecticides, herbicides and pesticides,
• arsenic and chromium from chemically treated lumber.
To reduce your exposure to these chemicals, wear approved safety equipment such as dust masks that are specially designed to filter out microscopic particles.
WARNING: Use of this tool can generate and/or expose dust, which may cause serious and permanent respiratory or other injury. Always use NIOSH/OSHA approved respiratory protection appropriate for the dust exposure. Direct particles away from face and body.
WARNING: Always wear proper personal hearing protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration of use, noise from this product may contribute to hearing loss.
CAUTION: When not in use, place tool on its side on a stable surface where it will not cause a tripping or falling hazard. Some tools with a large battery pack will stand upright but may be easily knocked over.
• Air vents often cover moving parts and should be avoided. Loose clothes, jewelry or long hair can be caught in moving parts.
The label on your tool may include the following symbols. The symbols and their definitions are as follows:
BPM.....beats per minute
V....volts
min......minutes
=== or DC......direct current
.../min.....per minute
RPM......revolutionsper minute
A.....amperes
Hz.....hertz
W.....watts
Wh....watt hours
n_0 ......no load speed
n......rated speed
⚠️ ......safety alert symbol
wearrespiratory protection
wear eye protection
☐ Class II Construction (double insulated)
○....wearhearing protection
readall
documentation
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
WARNING: Use only DEWALT battery packs and chargers.
Powerhead (Fig. B)
(DEWALT powerhead sold separately)
WARNING: To reduce risk of injury:
• Before any use, be sure everyone using this product reads and understands all safety instructions and other information contained in the powerhead and attachment manuals.
- Never apply power without an attachment being properly mounted to the powerhead.
WARNING: To reduce the risk of serious personal injury, turn unit off and remove the battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
Your attachment is designed such that the powerhead can separate from the pole saw attachment by turning the knob 13 counterclockwise, depressing the latching button 18 and gently pulling them apart by their poles 1, 14.
This should only be done with the power switch off and the battery pack removed. Inside the upper powerhead pole 14 is a mechanical coupling that will spin if the powerhead is turned on. This coupling can cause injury if contacted while the powerhead is operating.
NOTE: Ensure the attachment is fully engaged and the knob is fully tightened before operating. Check for proper engagement and tightness during use.
Assembling Pole Saw Attachment to the Powerhead (Fig. B)
WARNING: Sharp moving blade. To prevent accidental operation, insure that battery is disconnected from the handle and that the protective scabbard is in place on
the chain before performing the following operations.
Failure to do this could result in serious personal injury.
Combining the powerhead 14 to the pole saw attachment 1 creates a pole saw that is approximately 5.9 ft (1.8 m) in length.
To Attach the Powerhead to the Pole Saw Attachment
- The upper powerhead pole 14 is equipped with three latching holes 15, 16, 17 for the latching button 18.
- When installing the pole saw attachment pole 1 into the upper powerhead pole 14 and align the latching button 18 with one of the three latching holes 15, 16, 17.
NOTE: To properly engage the latching button 18 with the latching hole 15, slightly rotate the powerhead pole 14 and move it axially until the latching button engages the latching hole.
- Turn the knob 13 to secure the attachment.
- When properly assembled, the latching button should engage with one of the three latching holes. If it does not, do not use, disassemble and re-align the pole saw attachment 1 so the latching button 18 engages with one of the three latching holes 15, 16, 17.
Assembling the Extension Pole to the Pole Saw Attachment and the Powerhead (Fig. B, C)
CAUTION: The extension pole should exclusively be used with the pole saw attachment.
CAUTION: Only one extension pole should be used with the pole saw attachment.
To Attach the Powerhead to the Pole Saw Attachment
Adding the extension pole 11 to the powerhead 14 and pole saw attachment 1 creates a pole saw that is approximately 8.9 ft (2.7 m) in length.
To Attach the Powerhead to the Extension Pole and Pole Saw Attachment
- The upper powerhead pole 14 is equipped with three latching holes 15, 16, 17 for the latching button 18.
- When installing the extension pole 11 into the upper powerhead pole 14 and align the latching button 18 with one of the three latching holes 15, 16, 17.
- Turn the knob 13 to secure the extension pole.
To Attach the Pole Saw Attachment to the Extension Pole:
- When installing the pole saw attachment 1 into the extension pole 11, the pole saw attachment pole 1 is equipped with three latching holes 15, 16, 17 for the latching button 18.
- When installing the pole saw attachment pole 1 into the extension pole 11 and align the latching button 18 with one of the three latching holes 15, 16, 17.
-
Turn the knob 13 to secure the attachment.
-
When properly assembled, the latching button should engage with one of the three latching holes. If it does not, do not use, disassemble and re-align the pole saw attachment 1 so the latching button 18 engages one of the three latching holes 15, 16, 17 in the extension pole coupler 12.
WARNING: Always check to make sure that the knobs are completely secured in place. If the knobs are not completely secured it could result in the assemblies becoming disconnected creating a hazardous condition. Periodically check the connections to ensure that the knobs are completely secured in place.
DISASSEMBLY
WARNING: To reduce the risk of serious personal injury, turn unit off and remove the battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
Detaching Pole Saw Assembly (Fig. A–C)
WARNING: Sharp moving blade. To prevent accidental operation, insure that battery is disconnected from the handle and that the protective scabbard is in place on the chain before performing the following operations. Failure to do this could result in serious personal injury.
When detaching the assemblies, always detach the pole saw attachment 1 first.
To Remove the Extension Pole from the Pole Saw Attachment:
- Install scabbard 32 on guide bar and chain.
- When removing the pole saw attachment 1 from the extension pole 11, loosen the knob 13.
- Depress the latching button 18 located on the extension pole coupler 12, and pull the pole saw attachment 1 away from the extension pole 11.
To Remove the Powerhead from the extension pole:
- When removing the extension pole 11 from the powerhead 14, loosen the knob 13. Then depress the latching button 18 and pull the extension pole 11 away from the powerhead 14.
Installing the Guide Bar and Saw Chain (Fig. D–G)
CANTION: Sharp chain. Always wear protective gloves when handling the chain. The chain is sharp and can cut you when it is not running.
WARNING: Sharp moving chain. To prevent accidental operation, ensure that battery is removed from the tool before performing the following operations. Failure to do this could result in serious personal injury.
If the saw chain 7 and guide bar 6 are packed separately in the carton, the chain has to be attached to the bar, and both must be attached to the body of the tool.
- Place the pole saw attachment 1 on a flat, firm surface.
- Rotate the bar lock nuts 3 counterclockwise with a 13 mm wrench (not provided) and remove them.
English
- Using a flat-head screwdriver rotate the sprocket cover screw 23 counterclockwise and remove it.
- Take off the sprocket cover 2.
- Using a flat-head screwdriver turn chain tensioning screw 8 counterclockwise four turns.
- Wearing protective gloves, grasp the saw chain 7 and wrap it around the guide bar 6, ensuring the teeth are facing the correct direction.
- Ensure the chain is properly set in the slot around the entire guide bar.
- Place the saw chain around the sprocket 22. While lining up the slot on the guide bar with chain tensioning pin 24, and the two bar retaining bolts 25, on the base of the tool as shown in Figure F.
- Once in place, hold the bar still, replace the sprocket cover 2. Make sure bolt holes on the cover lines up with the two bar retaining bolts 25, on the main housing.
- Install the bar lock nuts 3 and rotate clockwise with a 13 mm wrench (not provided) until snug, then loosen the nuts one full turn, so the saw chain can be properly tensioned.
- Rotate the chain tensioning screw 8 clockwise to increase chain tension as shown in Fig. G. Make sure the saw chain 7 is snug around the guide bar 6. Tighten the bar lock nut 3 until snug.
- Follow the instructions in the section Adjusting Chain Tension.
Adjusting Chain Tension (Fig. A, E, G, H)
nOTE: Saw chain tensioning should be adjusted regularly before each use.
- With the pole saw still on a firm surface check the saw chain 7 tension. The tension is correct when the saw chain snaps back after being pulled 3 mm away from the guide bar 6 with light force from the middle finger and thumb as shown in Figure G. There should be no "sag" between the guide bar and the saw chain on the underside as shown in Figure H.
- To adjust saw chain tensioning, loosen bar lock nuts 3 as described in Installing the Guide Bar and Saw Chain section.
- Rotate the chain tensioning screw 8 in the front of the housing using a flat head screwdriver.
- Check the saw chain tensioning, adjust if needed.
- Do not over-tension the saw chain as this will lead to excessive wear and will reduce the life of the guide bar and saw chain. Overtensioning also reduces the amount of cuts you will get per battery charge.
- Once saw chain tensioning is correct, tighten bar lock nuts 3 until snug.
- A new chain stretches slightly during the first few hours of use. It is important to check the tension frequently (after disconnecting battery) during the first 2 hours of use.
Replacing the Saw Chain (Fig. D, E)
CAUTION: Sharp chain. Always wear protective gloves when handling the chain. The chain is sharp and can cut you when it is not running.
WARNING: Sharp moving chain. To prevent accidental operation, ensure that battery is removed from the tool before performing the following operations. Failure to do this could result in serious personal injury.
- To remove the saw chain 7, rotate the chain tensioning screw 8 in the front of the housing using a flat-head screwdriver. Turning the screw counterclockwise allows the guide bar 6 to recede and reduces the tension on the chain so that it may be removed.
- Place the pole saw on a flat, firm surface.
- Remove sprocket cover 2 as described in Installing the Guide Bar and Saw Chain section.
- Wearing protective gloves, grasp the saw chain and lift the worn saw chain out of the groove in the guide bar.
- Flip guide bar over every time you replace the chain to ensure even wear.
- Place the new chain in the slot of the guide bar, making sure the saw teeth are facing the correct direction by matching the arrow and graphic of the saw chain on the sprocket cover 2 shown in Figure D.
- Follow instructions for Installing the Guide Bar and Saw Chain.
Saw Chain and Guide Bar Oiling (Fig. A, I)
WARNING: If the oil reservoir runs empty, or the chain fails to get proper oil lubrication during use, the chain will overheat and cause damage to the unit and may result serious personal injury.
WARNING: Lack of proper bar and chain oiling can cause excessive heat from friction and can cause the chain to come off the bar while operating.
Auto Oiling System
This chain saw is equipped with an auto oiling system that keeps the saw chain and guide bar constantly lubricated. The oil reservoir 9 shows the level of the oil. If the oil level is less than a quarter full, remove the battery from the powerhead and refill the oil reservoir 9 with the correct type of oil. Always empty the oil reservoir 9 when finished cutting.
NOTE: Use a high quality bar and chain oil for proper saw chain and bar lubrication. As a temporary substitute, a non-detergent SAE30 weight motor oil can be used. The use of a vegetable based bar and chain oil is recommended when pruning trees. Mineral oil is not recommended because it may harm trees. Never use waste oil or very thick oil. These may damage your chain saw.
Filling the Oil Reservoir
- Unscrew counterclockwise and then remove the oil cap 4. Fill the oil reservoir 9 with the recommended bar and chain oil until full.
- Refit the oil cap and tighten clockwise.
- Periodically switch the tool off and check the oil level to ensure the bar and chain are being properly oiled.
Adjusting the Auto Oiling System
WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
The oil adjustment screw 10 is located on top of the gearbox assembly 26.
- Insert the supplied 2.4 mm hex wrench 31 into the oil adjustment screw 10.
- Turn the screw counterclockwise to increase oil flow to the bar and chain.
- Turn the screw clockwise to reduce the oil flow to the bar and chain.
Attaching and Adjusting the Shoulder Strap (Fig. J)
WARNING: The shoulder strap should only be slung and one shoulder and not across the body. See Fig J.
A shoulder strap 27 is recommended for any tool with a total weight exceeding 13 lbs. (6 kg). (Total weight includes the powerhead, attachment, and battery.) Attach the strap to the tool as shown in Fig. J and adjust for proper balance and support
- Attach the strap mount 29.
- Snap the shoulder strap latch 28 onto the strap mount 29 located on the unit, just in front of the ON/OFF trigger as shown in Fig. C. Adjust the strap so it fits over your shoulder and provides proper balance and support.
Transporting Chainsaw (Fig. L)
- Always turn unit off, remove the battery and cover the guide bar 6 with the scabbard 32 when transporting the saw.
OPERATION
WARNING: To reduce the risk of serious personal injury, turn unit off and remove the battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
Proper Hand Position (Fig. J, K, M, N)
WARNING: To reduce the risk of serious personal injury, ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal injury, ALWAYS hold securely in anticipation of a sudden reaction.
WARNING: Hold the tool using only the designated gripping surfaces: The powerhead handle and the auxiliary handle.
WARNING: Do not use the pole as a gripping surface.
Proper hand position requires one hand on the powerhead handle 20 and one hand on the auxiliary handle 21.
Operating the Pole Saw (Fig. A)
WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury.
CANTION: Always reduce the tension off the chain again after finishing work. The chain contracts as it cools down. If it is not slackened off, it can damage the pole saw.
IMPORTANT: Never operate a pole saw that is damaged or improperly adjusted or that is not completely and securely assembled. Be sure that the saw chain 7 stops moving when the trigger switch is released. Never adjust the guide bar 6 or saw chain when the motor is operating or the battery is attached.
Pole Saw Trimming/Pruning
WARNINGS:
- Never stand directly under the limb you are cutting. Always position yourself out of the path of falling debris.
• Always wear head, eye, foot and body protection. Wearing body protection helps reduce the risk of injury when operating this unit.
- Never stand on a ladder or other unstable support while using the pole saw. Always avoid any position which can cause you to lose your balance and cause severe injury.
- Keep other persons at least 50' (15 m) from the work area. Distractions can cause you to lose control.
- Electrocution Hazard. To prevent shock, do not operate within 50' (15 m) of overhead electrical lines. Always check surrounding area for hidden electrical lines.
- Do not hold pole saw switch handle above shoulder height.
Branch Removal Hook (Fig. A)
C?TION: The branch removal hook is not a belt hook.
Your pole saw includes a branch removal hook 5 for the intended purpose of helping to remove small to moderately sized pruned branches.
Pruning With the Pole Saw (Fig. A, M–O)
WARNING: Let the tool work at its own pace. Do not overload.
WARNING: When pruning trees: guard against knock which can result in severe injury or death.
See Guard Against Kickback, to avoid the risk of kickback. Do not overreach. Make sure your footing is firm. Keep feet apart. Divide your weight evenly on both feet.
- Use both hands to grip pole saw as shown in Fig. M, N. Use a firm grip. Thumbs and fingers must wrap around the powerhead handle 20 and auxiliary handle 21. Keep fingers away from sawdust exhaust chute 30 shown in Fig. O.
ENGLISH
- Never operate while in a tree, in any awkward position or on a ladder or other unstable surface. You may lose control of pole saw causing severe injury.
- Follow directions below to trim a tree.
a. Make sure pole saw is running at full speed before making a cut. When starting a cut, place moving saw chain 7 against limb. Hold pole saw firmly in place to avoid possible bouncing or skating (sideways movement) of pole saw.
b. Guide pole saw using light pressure. Make first cut 6" (152 mm) from tree trunk on underside of limb. Use top of guide bar 6 to make this cut. Cut 1/3 through diameter of limb. Then make the finish cut from the top. If you try to cut off thick branches from the bottom, the branch may close in and pinch the saw chain in the cut. If you try to cut off thick branches from the top, without a shallow undercut, the branch may splinter. Do not force pole saw. The motor will overload and can burn out. It will do the job better and safer at the rate for which it was intended.
c. Remove pole saw from cut while it is running at full speed. Stop pole saw by releasing trigger switch 33. Make sure saw chain has stopped before setting pole saw down.
MAINTENANCE
WARNING: To reduce the risk of serious personal injury, turn unit off and remove the battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
Your DEWALT power tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning.
Cleaning
WARNING: Blow dirt and dust out of all air vents with clean dry air at least once a week. To minimize the risk of eye injury, always wear ANSI Z87.1 approved eye protection when performing this procedure.
WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic parts of the tool. These chemicals may weaken the plastic materials used in these parts. Use a cloth dampened only with water and mild soap. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid.
Accessories
WARNING: Since accessories, other than those offered by DEWALT have not been tested with this product, use of such accessories with this tool could be hazardous. To reduce the risk of injury, onlyDEWALT recommended accessories should be used with this product.
Recommended accessories for use with your tool are available at extra cost from your local dealer or authorized service center. If you need assistance in locating any accessory, please contact DEWALT call 1-800-4-DEWALT(1-800-433-9258) or visit our website: www.dewalt.com.
Replacement chain and bar are available from your nearest authorized service center.
- This chain saw requires replacement 8" (203 mm) chain DWO1DT608.
Saw Chain and Guide Bar
After every few hours of use, remove the sprocket cover, guide bar and chain and clean thoroughly using a soft bristle brush. Ensure oiling hole on bar is clear of debris. When replacing dull chains with sharp chains it is good practice to flip the chain bar from bottom to top.
Saw Chain Sharpness
CANTION: Sharp chain. Always wear protective gloves when handling the chain. The chain is sharp and can cut you when it is not running.
IMPORTANT: The chain cutters will dull immediately if they touch the ground, stones, masonry or a nail while cutting.
To get the best possible performance from your chain saw it is important to keep the teeth of the saw chain sharp. Chain sharpening services are available from your nearest DEWALT service center.
NOTE: Each time the saw chain is sharpened, it loses some of the reduced kickback qualities and extra caution should be used. It is recommended that a saw chain be sharpened no more than four times.
Repairs
The charger and battery pack are not serviceable. There are no serviceable parts inside the charger or battery pack.
WARNING: To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment (including brush inspection and replacement, when applicable) should be performed by a DEWALTfactory service center or a DEWALTauthorized service center. Always use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
- WARRANTY SERVICE: Registering your product will help you obtain more efficient warranty service in case there is a problem with your product.
- CONFIRMATION OF OWNERSHIP: In case of an insurance loss, such as fire, flood or theft, your registration of ownership will serve as your proof of purchase.
- FOR YOUR SAFETY: Registering your product will allow us to contact you in the unlikely event a safety notification is required under the Federal Consumer Safety Act.
• Register online at www.dewalt.com
Three Year Limited Warranty
DEWALT will repair or replace, without charge, any defects due to faulty materials or workmanship for three years from the date of purchase (two years for batteries). This warranty does not cover part failure due to normal wear or tool abuse. For further detail of warranty coverage and warranty repair information, visit www.dewalt.com or call 1-800-4-DEWALT (1-800-433-9258). This warranty does not apply to accessories or damage caused where repairs have been made or attempted by others. THIS LIMITED WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so these limitations may not apply to you. This warranty gives you specific legal rights and you may have other rights which vary in certain states or provinces. In addition to the warranty DEWALT tools are covered by our:
1 YEAR FREE SERVICE
DEWALT will maintain the tool and replace worn parts caused by normal use, for free, any time during the first two years after purchase.
2 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360, DCB120, DCB122, DCB124, DCB127, DCB201, DCB203BT, DCB207, DCB361
3 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT, DCB206, DCB208, DCB230, DCB240, DCB606, DCB609, DCB612, DCB615
NOTE: Battery warranty voided if the battery pack is tampered with in any way. DEWAL is not responsible for any injury caused by tampering and may prosecute warranty fraud to the fullest extent permitted by law.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of your DEWALTPower Tool or Nailer for any reason, you can return it within 90 days from the date of purchase with a receipt for a full refund – no questions asked.
LATIN AMERICA: This warranty does not apply to products sold in Latin America. For products sold in Latin America, see country specific warranty information contained in the packaging, call the local company or see website for warranty information.
FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are missing, call 1-800-4-DEWALT (1-800-433-9258) for a free replacement.
FRAnÇAis
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360, DCB120, DCB122, DCB124, DCB127, DCB201, DCB203BT, DCB207, DCB361
CONTRAT D'ENTRETIEN GRATUIT DE TROIS ANS SUR LES BLOC-PILES DEWALT
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT, DCB206, DCB208, DCB230, DCB240, DCB606, DCB609, DCB612, DCB615
The label on your tool may include the following symbols. The symbols and their definitions are as follows:
BPM.....beats per minute
V....volts
min......minutes
--- or DC.....direct current
.../min.....per minute
RPM......revolutionsper minute
A.....amperes
Hz.....hertz
W.....watts
Wh....watt hours
n_0 ......no load speed
n......rated speed
⚠️ ......safety alert symbol
wearrespiratory
protection
...... wear eye protection
Class II Construction
(double insulated)
Wearhearing
protection
readall
documentation
Hotsurface.
Do not touch.
△...... avoid staring at light
\~ or AC......alternating current
Ah......amphours
ENSAMBLE Y AJUSTES
Eje Central Lázaro Cárdenas No. 18 - Local (55) 5588 9377
D, Col. Obrera
MERIDA, YUC
Calle 63 #459-A - Col. Centro (999) 928 5038
MONTERREY, N.L.
Av. Francisco I. Madero 831 Poniente - Col. (818) 375 23 13 Centro
PUEBLA, PUE
17 Norte #205 - Col. Centro (222) 246 3714
QUERETARO, QRO
Av. San Roque 274 - Col. San Gregorio (442) 2 17 63 14
SAN LUIS POTOSI, SLP
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360, DCB120, DCB122, DCB124, DCB127, DCB201, DCB203BT, DCB207, DCB361
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT, DCB206, DCB208, DCB230, DCB240, DCB606, DCB609, DCB612, DCB615
60V Max\* Li-Ion
Battery Packs
Blocs-piles DCB606, DCB609, DCB612, DCB615
Baterías
Chargers
Chargeurs DCB103, DCB104, DCB107, DCB112, DCB113, DCB115, DCB118, DCB132, DCB1106, DCB1112
Cargadores
* Maximum initial battery voltage (measured without a workload) is 20, 60 or 120 volts. Nominal voltage is 18, 54 or 108. (120V Max* is based on using 2 DEWALT 60V Max* lithium-ion batteries combined.)
NOTE: The Bluetooth ^® word mark and logos are registered trademarks owned by the Bluetooth ^® , SIG, Inc. and any use of such marks by DEWALTis under license. Other trademarks and trade names are those of their respective owners.
WARNING: Use of any other battery packs may create a risk of injury and fire.
