TVRC45PHBK - Remote control NEDIS - Free user manual and instructions

Product type	Replacement remote control for television
Brand	Nedis
Model	TVRC45PHBK
Approximate dimensions	17 x 4.5 x 2.5 cm
Approximate weight	70 g (with batteries)
Power supply	2 AAA batteries (not included)
Infrared range	Up to 8 meters (estimate)
Main functions	TV control, sound bar/audio device, automatic code search, manual programming, button remapping, streaming key customization
Number of keys	Approximately 35
LED indicator	Light indicator to confirm actions
Safety	Do not open, do not expose to water or humidity, do not use harsh chemicals
Care and cleaning	Clean with a soft, dry cloth; do not use chemical cleaners
Spare parts and repairability	No user-serviceable parts; replace the device if defective
Usage	Indoor only, non-professional
Compatibility	Works with most TVs and sound bars

Frequently Asked Questions - TVRC45PHBK NEDIS

How to insert batteries into the TVRC45PHBK remote control?

Open the battery compartment on the back of the remote control. Insert two AAA batteries (not included) respecting polarity (+/-). Close the cover.

How to automatically program the remote control for my TV?

Turn on the TV. Press and hold the up and down buttons for 3 seconds. The LED indicator lights up. Point the remote at the TV and hold the power button for 3 seconds. When the TV turns off, press OK to confirm.

How to manually program the remote control with a code?

Turn on the device. Press and hold the menu and mute buttons for 3 seconds. The LED indicator lights up. Enter the 4 or 5-digit code for your device (available in the online code list). If the indicator turns off, the code is correct. Test with the power button.

How to program the remote control for a sound bar?

Turn on the TV and sound bar. Press and hold the source/AV and mute buttons for 3 seconds. Point at the sound bar and hold the button corresponding to its brand (volume+, volume-, channel+, channel-). When the volume is muted, press OK.

How to remap a button on the remote control?

Ensure batteries in both remotes (original and Nedis) are charged. Press and hold the power and mute buttons on the Nedis for 3 seconds. Place both remotes facing each other (2-3 cm). Press the button to remap on the Nedis, then the corresponding button on the original remote. The indicator flashes 3 times. Repeat for up to 5 buttons, then hold power + mute for 3 seconds to save.

How to customize a streaming app button?

Turn on the TV. Press and hold the OK and mute buttons for 3 seconds. Press the streaming button to customize for 3 seconds. Launch the desired app via the TV menu, then press the streaming button again for 3 seconds. The indicator flashes twice and turns off.

How to reset the remote control to factory settings?

Press and hold the power and source/AV buttons for 3 seconds. The LED indicator turns off and all settings are reset.

What to do if the remote control does not respond?

Check that the batteries are correctly inserted and not discharged. Ensure there is no obstacle between the remote and the device. Reset the remote (see previous question) or reprogram it.

How to clean the Nedis TVRC45PHBK remote control?

Use a soft, dry cloth to clean the surface. Do not use harsh chemicals, alcohol, or solvents.

Does the remote control work with all TVs?

It is designed to work with most TVs and sound bars. If a code is not found, use the automatic search or manual programming. Check the online code list for compatibility.

USER MANUAL TVRC45PHBK NEDIS

TV Remote Control to replace your original remote

TVRC45SABK | TVRC45LGBK |
TVRC45PHBK | TVRC45SOBK |
TVRC45PASHBK | TVRC45TCBK |
TVRC45HIBK

ned.is/tvrc45sabk

ned.is/tvrc45lgbk

ned.is/tvrc45phbk

ned.is/tvrc45sobk

ned.is/tvrc45pashbk

ned.is/tvrc45 tcbk

ned.is/tvrc45hibk

Quick start guide 12

Kurzanleitung 17

TVRC45PASHBK|TVRC45TCBK|TVRC45HIBK

For more information see the extended manual

online:ned.is/tvrc45sabk Ined.is/tvrc45lgbk

I ned.is/tvrc45phbk I ned.is/tvrc45sobk I

ned.is/tvrc45pashbk |ned.is/tvrc45 tcbk

I ned.is/tvrc45hibk

Intended use

The Nedis TVRC45SABK | TVRC45LGBK | TVRC45PHBK |

TVRC45SOBK | TVRC45PASHBK | TVRC45TCBK | TVRC45HIBK is a

replacement remote control for your original TV remote.

For more information, see chapter Specifications.

This product is intended for indoor use only.

Any modification of the product may have consequences for safety, warranty and proper functioning.

The product is not intended for professional use.

Main parts (image A)

LEDindicator
On/off button
3 Volume up button
4 Volume down button
5 Menu button
Up button
OK button
8 Down button

9 Source / AV / input
button
10 Mute button
Page / channel up button
12 Page / channel down button
13 Streaming app buttons
14 Button 1

Safety instructions

WARNING

• Ensure you have fully read and understood the instructions in this document before you install or use the product. Keep the packaging and this document for future reference.
• Do not let children play with the packaging material. Always keep the packaging material out of the reach of children.
• The manufacturer is not liable for consequential damages or for damages to property or persons caused by non-observation of the safety instructions and improper use of the product.
• Only use the product as described in this manual.

• Do not open the product, there are no user serviceable parts inside.

• Do not use the product if a part is damaged or defective.
  Replace a damaged or defective product immediately.

• Do not drop the product and avoid bumping.
• Do not expose the product to water, rain, moisture, or high humidity.
• Do not use aggressive chemical cleaning agents when cleaning the product.

Before first use

1. Insert the two required AAA batteries (not included) into the battery compartment.
2. Aim the remote at your device.
3. Press the on/off button A 2 or the mute button A to test the remote.

If your device switches on or mutes, the remote is ready for use.

If your device does not switch off or mute, follow the steps in the next chapter.

Automatic search for the TV

For TVRC45SABK / TVRC45LGBK / TVRC45PHBK /

TVRC45SOBK / TVRC45PASHBK / TVRC45TCBK

1. Switch on the TV.
2. Press and hold the up button A 6 and the down button A 8 for 3 seconds.

The LED indicator A 1 lights up.

1. Aim the remote at your device.
2. Press and hold the on/off button A 2 for 3 seconds.

The LED indicator A 1 flashes once every 3 seconds when a new code is used.

When the TV switches off, the is code correct.

1. Press the OK button A to confirm.
   The LED indicator A switches off and the code is saved.
2. Check if the buttons control your device. If not, repeat steps 1-6.

For TVRC45HIBK

1. Switch on the TV.
2. Press and hold the on/off button A 2 and button 1 A 14 for 5 seconds.

The LED indicator A1 blinks 3 times.

1. Check if the buttons control your device. If not, repeat step 2.

If the buttons are still not working:

1. Press and hold the on/off button A 2 and each of the following buttons consecutively for 5 seconds.
   The number buttons

The volume up button

The volume down button

The page / channel up button A 11

The page / channel down button A12

The LED indicator A ① blinks 3 times after each button combination is pressed.

1. Check if the buttons control your device.

Automatic search for the sound bar/audio device

1. Switch on your TV and the sound bar/audio device.

Make sure audio is playing when programming your sound bar/audio device.

1. Press and hold the source / AV / input button A9 and the mute button A10 for 3 seconds.

The LED indicator A1 lights up.

1. Aim the remote at your device.
2. Press and hold the button corresponding to your sound bar/ audio device brand for 3 seconds.

Button First letter of the brand
Volume up button A3	A-F
Volume down button A4	G-L
Page / channel up button A11	M-R
Page / channel down button A12	S-Z

The LED indicator A 1 flashes once every 2 seconds when a new code is used.

When the volume of your device is muted, the correct code is within the batch of codes.

1. Press the OK button A to confirm.

The LED indicator A switches off and the code is saved.

1. Check if the buttons control your device. If not, repeat steps 1-6.

Programming the product to the device manually

1. Switch on your device.

Make sure audio is playing when programming your sound bar/audio device.

1. Scan the QR code on the front page to open the code list in the extended online manual.

2. Search for the code of your device in the code list.

3. Press and hold the menu button A 5 and the mute button

A10 for 3 seconds.

The LED indicator A 1 lights up.

1. Enter the code from the code list.

If the LED indicator A switches off, the code is correct.

If the LED indicator A 1 blinks 2 times then lights up, the code is declined. Repeat step 5 using another code.

1. Aim the remote at your device.
2. Press the on/off button A 2 or mute button A to test if the remote functions correctly with your TV or soundbar/ audio device.
3. Press the on/off button A 2 or the mute button A10

If the device switches off or mutes, the product is ready for use.

If the device does not switch off or mute, repeat steps 4-5 using another code.

Disconnecting the soundbar/audio device from the remote

To reset the volume buttons A3 4 10 to control the sound of your TV instead of your sound bar/audio device:

Press and hold the source / AV / input button A9 and the OK button A7 for 3 seconds.

The LED indicator A 1 flashes rapidly.

The audio code is deleted when the LED indicator A 1 switches off.

Customising streaming app buttons

1. Switch on the TV.
2. Press and hold the OK button A 7 and the mute button

A10 for 3 seconds.

The LED indicator A 1 lights up.

1. Press and hold the streaming app button for 3 seconds.
   The LED indicator A ① blinks 2 times and lights up.
2. Launch the streaming app through the menu using the arrow keys and OK button A ⑦.
3. Press and hold the streaming app button for 3 seconds.

The LED indicator A 1 blinks 2 times and switches off.

The button is now mapped to the selected app and launches the app when pressed.

Reset streaming app buttons

1. Switch on the TV.
2. Press and hold the OK button A 7 and the mute button

A10 for 3 seconds.

The LED indicator A 1 lights up.

1. Press and hold the streaming app button for 3 seconds.

The LED indicator A ① blinks 2 times and lights up.

1. Again, press and hold the streaming app button for 3 seconds.

The LED indicator A switches off and the button is reset to factory default.

Remapping a button manually

URC = your replacement remote control; RC = your original remote control

1. Make sure the URC and the RC batteries are not empty.
2. Press and hold the on/off button A 2 and the mute button A 10 of the URC for 3 seconds.
3. Hold both remotes close together. The infrared pointers of both remotes should be within 2-3 cm of each other.
4. Press the button on the URC that you want to remap. The LED indicator A① flashes rapidly.
5. Press the button on the RC that you want to remap to your URC.

The LED indicator A 1 blinks 3 times then blinks slowly. Repeat steps 4-5 to remap more buttons.

1. Press and hold the on/off button A 2 and the mute button

A 10 of the URC for 3 seconds to save the remapped buttons.

If you do not save, the newly remapped buttons will not work properly.

1. Check if the remapped buttons work properly. If not, repeat steps 1-7.

You can remap a maximum of 5 buttons. After remapping 5 buttons, you need to overwrite previously remapped buttons.

Resetting all remapped buttons

Press and hold the on/off button A2 and the OK button A7 for 3 seconds.

LED indicator A switches off and the buttons are reset to factory default.

Resetting the remote to factory settings

Press and hold the on/off button A2 and the source / AV / input button A9 for 3 seconds.

LED indicator A switches off and the buttons are reset to factory default.

Disposal

The product is designated for separate collection at an appropriate collection point. Do not dispose of the product with household waste. For more information, contact the retailer or the local authority responsible for the waste management.
