USER MANUAL PL-20 MK3 Laserworld

1. Product and package contents

Please check if all listed parts are included and undamaged. Included in delivery: Laser system, power cable, key, interlock bridge plug, waterproof ightcase, rain cover, manual, technical datasheet

2. Preliminary warning notices

1. Please use this device only according to these operating instructions.

2. Do not use the device if there are any visible damages on housing, connector panels,

power supplies or power cords.

3. This device must not be permanently connected to mains. Disconnect it from mains or

use the power button to switch if o if not in use.

4. Never look directly into the light source of a laser projector. Danger of damage to the

eyes or even blindness in extreme circumstances! Any warranty claims are void if the warranty label is removed or tampered with in any way.

3. Initial operations, safety instructions

1. Make sure to use correct voltage; see information on device & in this manual.

2. Make sure that the device is not connected to mains during installation.

3. Installation has to be done by technical experienced and qualied persons according to

safety regulations of the respective country.

4. Always ensure that maximum permissible exposure (MPE) is not exceeded in areas

accessible to the public or members of sta.

5. In some countries an additional inspection by technical control institutes could be

6. Connect an easily accessible interlock connector or circuit breaker to the projector.

7. The power supply should be easily accessible.

8. When installing the laser mount it with a minimum distance of 15 cm from walls and

9. For safe setup e.g. on walls or ceilings please use a safety cord. The safety cord should be

able to withstand tenfold the weight of the device. Please follow the accident prevention regulations of professional associations and/or comparable regulations for accident prevention.

10. If the device has been exposed to great temperature changes, do not switch it on

immediately. Condensation (or any moisture/water formed) may damage this device.

11. Never use dimmer, RC or other electronically switched sockets. Whenever possible, do not

use the laser projector together with large appliances (especially fog machines) on the Content:

1. Product and package contents 7

2. Preliminary warning notices 7

3. Initial operations, safety instructions 7

4. Working on the device 8

6. General Operation 9

7. Operation Modes 10

Final statement 11Manual: Purelight Series MK3 Manual: Purelight Series MK3 page 8 / 23 page 9 / 23 English English same mains!

12. Ensure sucient ventilation and do not place the device on any warm or heat radiating

surface. Especially the ventilation openings must not be covered!

13. Ensure that device does not get overheated. Make sure that the device is not exposed

to spotlights (especially moving heads). Heat of spotlights could overheat laser in a little while and leads to a degradation of performance.

4. Working on the device

1. This product has no user serviceable parts inside and should only be

maintained and serviced by a qualied engineer.

2. Be sure that the mains plug is not connected to the power

supply while installing the device.

3. Take o all reecting things like rings, watches, etc. before

starting to work with or at the projector.

4. Only use non-reecting tools to work on device.

5. Wear protective clothing (like goggles, gloves etc.)

according to laser power and wavelength of the laser.

• Moisture and heat can reduce lifetime of the laser system dramatically and expires any warranty claim.

• Quick on/o switching of this device will reduce durability of the laser diode dramatically.

• Avoid sharp knocks and shocks to this device an endsure sucient protection during transportation. Look after your Laserworld product.

• To increase durability of your laser, protect device against overheating: - Always ensure sucient ventilation. - Do not face spotlights (especially moving heads) to the device. - Check temperature after approx. 30 minutes with each new installation. If necessary install the projector at a place with dierent temperatures. - Switch o device when it is not needed. Diodes are switched on and can wear out even if there is no visible laser output.

• Please ensure the fans and heatsinks are clear from dust and debris otherwise the risk of overheating may occur. If the unit or air inlets appear to be blocked, please contact a qualied service engineer to maintain and service the product.

• Always place the laser behind fog machines and hazers

• Clean the exit window with glass cleaner from time to time

• This Laserworld Purelight Series unit is IP54 waterproof. To maintain the waterproofness, it is essential to follow these requirements: - all covers and aps need to be closed and screws and parts to ax the covers / aps need to be in place and rmly attached. - all connectors used to control the laser or apply power to it must also be rated at least IP54. The connectors must be connected in a way, that the IP rating must not be com- promised. - it is strongly recommended to utilize the rain cover that is included in delivery to pro- tect the laser system if it is used outdoors.

• If the housing has been opened, it requires professional re-sealing to maintain the IP ra- ting. Please contact your Laserworld partner for assistance.

• This laser system is NOT suitable for underwater use. It can not be submerged.

• Removal of the warranty label as well as damages to the device caused by improper handling, neglect of the safety instructions and service notes will void the warranty.

6. General Operation

Connect the power cord to the device and to the mains. Make sure that your device is pro- vided with the correct voltage. Wrong voltage could lead to irreparable damages. Please nd the correct voltage data in the synoptical table at the end of this manual. Make sure that the device is not directed to people or inammable objects during installation. To start the device, connect the interlock bridge, insert the key and switch it on, and switch the device on. The “Emission - Laser on“ LED at the front side of the device begins to light up when the device is ready for use.

There is a key switch at the back of the laser system. Please plug the key to the switch and turn it on. The laser device only runs when the key is inserted and switched on. Prevent misuse! Unplug the key when the laser is unattended to prevent misuse of the sys- tem.

This device has an integrated Scan Safety (SFS). Is the Scan Safety active (on), single be- ams are prevented. If the Scan Safety is switched o, it is possible to create full power single beams - be careful! Operating the laser system with disabled SFS may not be allowed in some countries. Always ensure that maximum permissible exposure (MPE) is not exceeded in areas accessible to the public or members of sta.

4. Modes / Functions

The dierent operation modes can be selected by using the rotating selector next to the ShowNET-Display (or FB4) at the back of the device. Any change of the operation mode for ShowNET devices requires a restart of the device (disconnect power and recon- nect it again). Do not change any ShowNET-Display settings during operation, as random and dangerous laser output can occur.

To turn o the device, use the power button („OFF“), turn the key to ‚OFF‘ and disconnect the power cable from the mains.Manual: Purelight Series MK3 Manual: Purelight Series MK3 page 10 / 23 page 11 / 23 English English Find information on how to operate your laser here: https://www.laserworld.com/en/online-manual Final statement Laserworld products are tested and product packaging is inspected before leaving our warehouse. Users must to follow the local safety regulations and warnings within this manual and adhere to any regulations within its place of use. Damages through inappropriate use will void any liability or warranty of our products. Due to continual product developments, please check for the latest update of this product manual at www.laserworld.com. If you do have any further questions, then please contact your dealer/place of purchase or use our contact section on our website. For service issues, please contact your dealer/place of purchase and ensure only genuine Laserworld spare parts are used in any service repairs. Errors and Omissions excepted and products are subject to change. Laserworld AG Kreuzlingerstrasse 5 8574 Lengwil Switzerland Board of Directors: Martin Werner Registered oce: 8574 Lengwil / Switzerland Company number: CH-440.3.020.548-6 Commercial Registry Kanton Thurgau CEO: Martin Werner VAT no. (Switzerland): 683 180 UID (Switzerland): CHE-113.954.889 VAT no. (Germany): DE 258030001 WEEE-Reg.-No. (Germany): DE 90759352 www.laserworld.com [e-mail] representative according to EMVG: tarm laser technologies tlt GmbH & Co. KG Lindenallee 27 D-44625 Herne
