USER MANUAL Pro 1200 BA5608 SOLAC

Solac is a registered Trade Mark

• (*) Only available in the model BA5609.

• If the model of your appliance does not have the accessories described above, they can also be bought separately from the Technical Assistance Service.

• Do not use the appliance if its accessories are not properly tted.

• Do not use the appliance if the accessories attached to it are defective. Replace them im- mediately.

• Do not use the appliance if the on/off switch does not work.

• Store this appliance out of reach of children and/or persons with physical, sensory or re- duced mental or lack of experience and knowl- edge.

• Keep the appliance in good condition. Check that the moving parts are not misaligned or jammed and make sure there are no broken parts or anomalies that may prevent the appli- ance from operating correctly.

• Use the appliance and its accessories and tools in accordance with these instructions, taking into account the working conditions and the work to be performed. Use the appliance for operations different from those intended could result in a hazardous situation.

• Do not use the appliance on any part of the body of a person or animal.

• Do not use the appliance with frozen goods or those containing bones.

• Do not use the device with the stick-blender more than 50 seconds at a time, pausing 2 minutes.

• Do not use the device with the chopper more than 30 seconds at a time, pausing 2 minutes.

• As a reference in the annexed table appears several recipes, that include the amount of food to process, and the operating time of the apparatus.

• Make sure that all products’ packaging has been removed.

• Before using the product for the rst time, clean the parts that will come into contact with food in the manner described in the cleaning section.

• Prepare the appliance according to the func- tion you wish to use. USE:

• Extend the cable completely before plugging it in.

• Connect the appliance to the mains.

• Turn the appliance on, by using the on/off but- ton.

• Select the desired speed.

• Work with the food you want to process. ELECTRONIC SPEED CONTROL:

• The speed of the appliance can be regulated by using the speed regulator control (A). This function is very useful, as it makes it possible to adapt the speed of the appliance to the type of work that needs to be done. TURBO FUNCTION:

• The appliance has a Turbo function (B2). By activating the Turbo function all the power of the motor becomes available, thus obtaining a ner nish in the nal texture of the product.

• Stop the appliance by releasing the pressure on the on/off button.

• Unplug the appliance from the mains.

• Clean the appliance. ACCESSORIES: STICK BLENDER ACCESSORY (FIG.1):

• This accessory is used for making sauces, soups, mayonnaise, milkshakes, baby food …

• Attach the stick to motor body and turn in the direction of the arrow (Fig.1.1).EN

• Put the food to be prepared in the jar and switch the appliance on.

• For further cleaning, detach and remove the stick by turning in the opposite direction of the arrow. CHOPPING ACCESSORY (FIG.2):

• This accessory is used to chop vegetables or meat…

• To avoid damage to the appliance, remove bones, nerves, cartilage, etc. from the meat.

• Put blades set and and the food to be prepared in the chopping container. (Fig.2.1 / 2.2).

• Put the globet adapter tting in the chopper un- til it ts into place. (Fig.2.3).

• Attach the unit to the cover pressing turn in the direction of the arrow and switch the appliance on (be careful: do not switch the appliance on if the whole unit is not properly tted and con- nected together). (Fig.2.4).

• Stop the appliance when the food reaches the desired texture.

• Detach the unit from the cover and release the the adapter tting.

• NOTE 1: not to exceed half of the chopper cup when working with solid foods.

• NOTE 2: In the case of working with liquid foods, do not exceed 300 ml. WHISK ACCESSORY (FIG.3):

• This accessory is used to whip cream, beat egg whites…

• Insert the whisk into the adapter tting (Fig.3.1). Attach the unit to the motor body and turn in the direction of the arrow (Fig.3.2).

• Put the food into a large receptacle and switch the appliance on. For best results, turn the whisk clockwise.

• Remove the whisk accessory and release the adapter tting.

• Note 1: Do not work at high speeds with this accessory attached, as this would cause de- fects in the whisk (spinning its wires). CLEANING

• Disconnect the appliance from the mains and allow it to cool before undertaking any cleaning task.

• Clean the equipment with a damp cloth with a few drops of washing-up liquid and then dry.

• Do not use solvents, or products with an acid or base pH such as bleach, or abrasive prod- ucts, for cleaning the appliance.

• Never submerge the appliance in water or any other liquid or place it under running water.

• During the cleaning process, take special care with the blades, as they are very sharp.

• It is advisable to clean the appliance regularly and remove any food remains.

• If the appliance is not in good condition of cleanliness, its surface may degrade and in- exorably affect the duration of the appliance’s useful life and could become unsafe to use.

• The following pieces may be washed in a dish- washer (using a soft cleaning program): - Measuring cup. - Chopper.

• The draining/drying position of the articles washable in the dishwasher or in the sink must allow the water to drain away easily.

• Then dry all parts before its assembly and stor- age.EN Recipe Recommended accessory Speed Quantity Preparation Time Mayonnaise Stick blender 4 250 ml Put 1 egg in the jug with a pinch of salt and some drops of vinegar or lemon. Add oil until the indicat- ed level. Turn the appliance on without moving until the oil binds. 30 s Béchamel sauce Stick blender 3 600 ml Melt 30 gr. of butter in a pan on a slow heat. Add 100 gr. of our and 30 gr. of fried onions (already cut up with the slicer). Slowly add 500 ml of milk. 20 s Whipped cream Whisk 2 250 ml Pour the very cold cream (0ºC to 5ºC) into a recipient and operate the blender by moving it clockwise. We recommend using minimum speed and when starts to take on consistency, going to the 2nd. Be careful, as if the time is exceeded the cream will turn into butter 1-2 min Stiff egg whites Whisk 2 5 egg whites Pour the egg whites into a jug and activate the blender. Mix in a vertical motion until the egg whites become stiff. 1-2 min Mashed potato Stick blender MAX 300 g The potatoes can be sliced by activating the blender directly in the saucepan directly. 30 s Baby food: fruit and biscuit mush Stick blender MAX 300 g Cut up and place 100 gr. of apple, 100 gr. of banana, 50 gr. of biscuits and the juice of one orange in the jug 25 s Bread- crumbs Stick blender MAX 80 g (1-2 cm) Cut up the stale bread before putting it in the jug. Blend until the desired texture is obtained. 50 s Grated cheese Chopper MAX 100 g Dice the cheese into 1 cm chunks and blend until the de- sired texture is obtained. 40 s Ground nuts Chopper MAX 100 g Remove the shells and grind until the desired texture is obtained 30 s Minced meat Chopper MAX 40 g Previously chop into 1 cm chunks Mince until the desired texture is obtained 10 sDESCRIPTION A Commande de vitesse B Boutons B1 Interrupteur marche/arrêt B2 Turbo C Corps moteur D Fouet E Verre doseur F Robot hachoir (*) F1 Groupe réducteur de l’accessoire de hachage F2 Jeu de lames du hachoir G Batteur (*) G1 Groupe réducteur de l’accessoire de battage

ASSISTANCE This product enjoys the recognition and protection of the legal guarantee in accordance with current legislation. To enforce your rights or interests you must go to any of our ofcial technical assistance services. You can nd the closest one by accessing the following web link: http://solac.com You can also request related information by contacting us by phone. You can download this instruction manual and its updates at http://solac.com
