BP4001 - Toaster BLAUPUNKT - Free user manual and instructions

USER MANUAL BP4001 BLAUPUNKT

White BLAUPUNKT toaster with black control buttons and a blank display (no text or symbols on device body)

Enjoy it.

ESTIMADO CLIENTE

White BLAUPUNKT toaster with black buttons and control panel (no visible text or symbols on body)

Enjoy it.

DEAR COSTUMER

Thank you for having chosen a BLAUPUNKT product.

The BLAUPUNKT products have been produced to think about the welfare of the consumer privileging the most raised standards of quality, functionality and assign. We are sure you will be happy with this appliance.

We assume that the user is familiar with the common procedures of handling household appliances. Before you start using your appliance for the first time, read the operating instructions carefully and preserve this booklet for later reference. Pass the manual on to whosoever might acquire the appliance at a future date.

KEEP THESE INSTRUCTIONS IN A SAFE PLACE AT ALL TIMES

Intended Usage

This appliance is intended for the toasting of slices of bread, rolls and waffles in domestic environments. It is not intended for use with other foodstuffs, other materials or for use in commercial or industrial applications. All other usages or modifications are regarded as being contrary to the operating instructions and carry with them a real risk of serious accidents.

Important Safe ty instructions

When using electrical appliance, basic safety precautions should always be followed, including the following:

• Read these instructions carefully.
• The appliance has been designed for home use only and must not be used for commercial or industrial purposes.

To avoid potentially fatal electric shocks

- Never insert cutlery or other metallic objects into the toaster slots.

• Ensure that the appliance never comes into contact with water when the power plug is inserted into a wall socket, especially if it is being used in a kitchen and close to the sink.
• Ensure that the power cable never becomes wet or damp during operation. Lay the cable such that it does not get clamped or otherwise damaged.
• Arrange for defective power plugs and/or cables to be replaced at once by qualified technicians or our Customer Service Department.
• After use, always remove the power plug from the wall socket, this prevents the unintentional switching on of the appliance.

To avoid the risks of fire or injury:

• The appliance can become hot when it is in use. Therefore, only touch the operating elements.
• Bakery products can burn! You should therefore never locate the appliance close to or underneath inflammable objects, especially not under curtains or suspended cupboards.
• The appliance may not be used in close vicinity to flammable material.
• Never cover the toaster when it is in use.
• This appliance can be used by children aged 8 years and above and persons with reduced physical or mental capabilities, if they are under supervision or if they have been instructed in the use of the appliance in a safe manner and understand the potential risks. Children must not carry out cleaning and maintenance of the appliance, unless they are 8 years or older and under supervision. Children younger than 8 years have to be kept away from the appliance and its power supply.
  • Children should be supervised to ensure that they do not play with the appliance.
• Operate the appliance only on a stable, non slippery and level surface.
• Do not use an external timing switch or a separate remote control system to operate the appliance.
• Unwind the power cable completely from the cable winder before using the appliance

INSTRUCTIONS FOR USE

Placing

• Unwrap the power cable from the cable winder in the underside of the appliance.
• Pass the cable through one of the two cable guide on the underside of the appliance. This will prevent jamming during usage.
• Place the toaster on a dry and level surface.

Before taking into use

Heat the appliance up at least five times at the maximum setting without the insertion of bread slices.

Please take note:

• The operating button only engages when the power cable is connected to a power socket.
• With the first usage a slight smell can arise (minimal smoke development is also possible). This is normal and dissipates after a short time. Provide for sufficient ventilation.

Adjusting the browning level

The desired level of browning, from "light" (1) to "dark" (6) can be adjusted infinitely with the browning regulator of the toasting time electronics.
Take note that, subject to the demand made on the toaster, the level of browning can vary somewhat with an unvarying adjustment of the browning regulator! The less the number of slices inserted, the higher is the browning level. Thus, if you are not intending to toast many slices, always adjust the browning regulator a little lower.

Tips on usage

- Toast mixed-flour breads at higher browning levels than white bread. Matured, dry bread browns faster than fresh bread.

• In the event of a malfunction and when cleaning the appliance, remove the power plug from the wall socket. Risk of electric shock!
• Loosen jammed slices of bread with a blunt wooden object (e.g. a wooden spatula or spoon). Do NOT touch the heater elements.
• Differences in bread sorts, moisture and the thickness of individual slices influence the browning of the toast. Therefore the bread for toasting should be kept in sealed packaging until required.

Toasting

• NEVER cover the toaster slots when operating the toaster! There is a danger of fire! The appliance could be irreparably damaged!
• After setting the desired browning level, insert the bread into the toaster slots.
• Press the operating button downwards. The control lamp integrated into the Cancel button glows.
• When the desired level of browning has been reached the toaster switches itself off automatically and the slices are ejected to the top.
• This appliance has a lifting function, which makes it easier and safer for you to take the hot slices of toast from the toaster slots. For this, slide the operator handle upwards.

Interrupting the toasting process (Cancel button)

If you wish to interrupt the toasting process, press the Cancel button. The toaster switches itself off.

Warming Function (Reheat button)

The warming function makes it possible for you to warm bread without browning it. For example toast that has gone cold. The bread is only briefly warmed.

• Insert the bread and press the operating handle down.
• Activate the button for the warming function. The control lamp integrated into the button for the warming function glows.
• The toaster switches itself off automatically, the control lamp extinguishes and the bread slices are elected.

Defrost Function (Defrost button)

Through activation of the defrost function frozen bread can also be thawed. With this, the toaster slowly warms the bread.

• Insert the bread and press the operating handle down.
• Activate the button for the defrost function. The control lamp integrated into the button for the

defrost function glows.

• The toaster switches itself off automatically, the control lamp extinguishes and the bread slices are elected.
• Dependent on the setting of the browning level, the bread is either thawed or browned.

Crumb tray

When toasting, crumbs that fall from the bread are collected in the crumb tray. To empty it, simply pull the crumb tray out to the side.

CLEANING AND CARE

Before cleaning, remove the power plug from the wall socket and allow the toaster to cool down.

Never submerse the appliance in water or other liquids. The device could also be irreparably damaged!

EN

Warning in regard to damage to the appliance!

Do not use aggressive or abrasive cleaning agents. These can damage the upper surfaces of the appliance.

• Clean the appliance housing only with a dry or lightly moistened cloth.
• In the case of stubborn soiling, use a mild detergent on the cloth.
  • To avoid the risk of fire, empty the crumb tray at regular intervals.

Storage

• Store the toaster at a cool and dry location.
• Clean the appliance as described in the previous chapter.
• Wrap the power cable around the cable retainer on the underside of the toaster.

TECHNICAL SPECIFICATIONS

Rated voltage: 230V\~

Rated frequency: 50 Hz

Rated power: 1000 W

CALSEI

PRODUCT DESCRIPTION

1. Operating handle
2. Cancel button
3. Button Reheat 4. Button Defrost
4. Toasting Control
5. Toaster slot
6. Crumb tray

GUARANTEE DOCUMENT

Thank you for purchasing this BLAUPUNKT product, this device has been checked in all its components meticulously, so we guarantee the correct operation, but for this to be the case we need that YOU

read the instruction book carefully, as this will contribute to the best performance of this article.

R.S.A guarantees to the buyer of this product, a total guarantee of TWO YEARS, governed by the established conditions whose regulation is found in Royal Legislative Decree 1/2007 of 16 December, which approves the revised text of the General Law for the Defense of Consumers and Users, articles 114 to 1271 R.S.A is committed to repairs are completely free, labor and spare parts, Including.

The Technical Assistance Service will resolve any repairs that may be required by this apparatus.

Carefully review the INSTRUCTION BOOK included, on the use, maintenance and conservation of the device.

Any anomaly that could occur due to the non-observance of such instructions will not be protected for the guarantee.

The date of sale of the device, for the purposes of warranty period, will be that which appears on the purchase invoice.

Guarantee operation: As regards all those compliance defects detected by the technical assistance, which are manifested within six months of the delivery of the goods, it is assumed that they already existed on that date, the intervention will be completely free, (unless this hypothesis is incompatible with the nature or nature of the conformity defect).

During the following eighteen months, it must be the user who demonstrates that the lack of conformity It was coming at the time of delivery.

MANUFACTURED CHINA FOR BLAUPUNKT

DECLARATION OF CONFORMITY

Manufacturer Name: RAMSONS, S.A.

Adress: Pedro Muñoz Torres n° 1

Post Code: 41006

SEVILLA

We declare under our responsibility that the product:

Product Description: EXTRA LARGE SLOT

TOASTER

Model: BP4001

Brand: BLAUPUNKT

It complies with the European Union legislation in compliance with the 2004/108 / EU guidelines

The standards apply: EN 55014-1: 2006+A1+A2:

EN 55014-2:1997+A1+A2:

EN 61000-3-2:2006+A1:+A2:

EN 61000-3-3:2013

Name: Vivek Sadhwani

Position : manager

Date:

Signature:

1 de October 2020

INFORMATION ON RECYCLING

Disposal of the old appliance, the European Directive 2002/96 / EC on waste equipment Electrical and Electronic (WEEE), establishes that old appliances can not be thrown as municipal waste without normal classification. Appliances have to be collected separately with the to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment.

The symbol "container with wheels" crossed out on the product reminds you of obligation, that when you dispose of the device must be collected separately.

Consumers should contact the local or retail authority to obtain information about the correct disposal of your old device.

Ramsons, S.A.

Pedro Muñoz Torres N° 1 NAVES HYTASA

41006 SEVILLA

Tín. 954 933 404 • Fax. [phone]

USER

DATE OF SALE

Seller's signature and stamp

IMPORTANT: To make the guarantee effective, the SELLER must fill out, sign and stamp this Certificate.

To receive assistance under the conditions set forth in this certificate, please submit to the Technical Service Authorized, this document next to the Purchase Invoice

BLAUPUNKT

BP4001

GRILLE-PAIN D'EXTRA LARGE SLOT

MANUEL D'INSTRUCTIONS

White BLAUPUNKT toaster with black buttons and control knob (no visible text or symbols on body)

Enjoy it.

CHER CLIENT

DÉCLARATION DE CONFORMITÉ

Nom du fabricant: RAMSONS, S.A.

MANUAL DE INSTRUÇÕES

White standard BlaupuWKT toaster with black buttons and control knob (no visible text or symbols on body)

Enjoy it.

ESTIMADO CLIENTE

Name: Vivek Sadhwani
