BA-2112 - Speaker HAMA - Free user manual and instructions

Product type	2.1 speaker (subwoofer + satellites)
Brand	Hama
Model	BA-2112
Total max music power	12 W
Configuration	1 subwoofer (8 W) + 2 satellites (2 x 2 W)
Frequency response	100 Hz - 20 kHz
Impedance	6 Ω
Distortion rate	≥ 1% (1 kHz, 1 W)
Power supply	5 V / 900 mA via USB (compliant with USB 3.0 standard or suitable charger)
Connectivity	Cinch (RCA) input, USB port (power)
Subwoofer dimensions (W x D x H)	23 x 15.2 x 17.3 cm
Subwoofer weight	approx. 730 g
Satellite dimensions (W x D x H)	9.3 x 6.3 x 11 cm
Satellites weight (total)	approx. 440 g
Total weight	approx. 1170 g
Safety instructions	Protect from moisture, shocks and overheating; do not open; keep out of reach of children
Maintenance and cleaning	Clean with a soft, dry cloth; do not use abrasive products
Included accessories	Not specified (probably USB cable)
Compliance	European directives 2012/19/EU and 2006/66/EC

Frequently Asked Questions - BA-2112 HAMA

How to connect the Hama BA-2112 speaker to my computer?

Plug the USB cable into a USB 3.0 port on your computer for power. Use a Cinch (RCA) cable to connect your computer's audio output to the speaker's Cinch input.

What is the total power of the system?

The maximum total music power is 12 W, distributed between the subwoofer (8 W) and the two satellites (2 x 2 W).

Can I use the speaker with a TV?

Yes, if your TV has a Cinch (RCA) audio output. Plug it into the speaker's Cinch input. Power the speaker via USB (from the TV or a suitable 5V/900mA charger).

What to do if the speaker does not turn on?

Check that the USB cable is properly connected to a 5V/900mA power source (computer USB port or wall charger). Make sure the cable is not damaged. If the problem persists, contact Hama service.

How to improve sound quality?

Place the subwoofer on a stable surface, away from walls to avoid vibrations. Move the satellites away from table edges. Reduce the source volume if distortion occurs.

Can I use this speaker with a mobile device?

Yes, if your mobile device has a 3.5 mm audio jack. Use a jack to Cinch (RCA) adapter to connect to the Cinch input. USB power can be provided by an external battery.

The speaker emits a humming sound, what to do?

Make sure the audio cable is properly connected and not bent. Keep the power cable away from audio cables. Check that the USB port provides stable power. If the problem persists, test with another audio source.

How to clean the speaker?

Unplug the speaker. Clean the surfaces with a soft, dry cloth. Do not use liquid or abrasive cleaning products. Avoid water entering the openings.

What cables are included in the box?

The manual does not specify the exact contents of the packaging. Generally, a USB cable for power is included. The Cinch audio cable may not be included.

Where to find Hama after-sales service?

For any questions, contact Hama product advisory service at [phone] (German/English). Check the Hama website for more information.

USER MANUAL BA-2112 HAMA

3

GB

Operatinginstruction

Note

Onlyconnectthespeakersystemtoa USB interfacewiththe3.0standard or a suitable USBcharger.

The following powersupply must be ensured: 5V900mA

1. SafetyNotes

• Protect the product from dirt, moisture and overheating and use it indry room only.
• Layallcablessothattheydonotposea tri p p i n g hazard.
• Donotbendorcrushthecable.
• Donotdroptheproductanddonotexposeitto anymajorshocks.
• Usetheproductforitsintendedpurposeonly.
• Keepthepackagingmaterialoutofthereachof childrenduetotheriskofsuffocation.
• Disposeofpackagingmaterialimmediately accordingtolocallyapplicableregulations.
• Donotopenthedeviceorcontinuetooperateitif itbecomesdamaged.

2.WarrantyDisclaimer

HamaGmbH& C o K G a ssumesnoliability and providesnowarrantyfordamageresultingfrom improperinstallation/mounting,improperuseof theproductorfromfailure t o o bservetheoperating instructionsand/orsafetynotes.

3. Service and Support

PleasecontactHamaProductConsultingifyouhave anyquestionsaboutthisproduct.

Hotline:[phone](German/English)

Furthersupportinformationcanbefoundhere:

www.hama.com

4.TechnicalData

Frequency100Hz-20kHz
Impedance6Ω
Distortionfactor≥1%(1K,1W)
Powersupply5V	=900mA
ConnectionsCinch,USB

Performance
Max.totalmusic performance	12 W
Subwoofer1x8W
Satellites/Centre	2 x 2

Size(BxTxH)/Weight
Total	ca.1170g
Subwoofer	23x 1 5.2x 1 7.3cm ca.730g
Satellites/Centre	930x 6 .3x 1 1 cm ca.440g

concernantl'assistance: w www.hama.com

Hotline:[phone](Alm/Ing)

Hotline:[phone](ty/eng)

Duhittarmersupport-informationhär:

www.hama.com

4.Tekniskadata

Frekvens100Hz- 2 0 k Hz
Impedans6Ω
Distorsion≥1%(1K,1W)
Spänningsförsörjning5V	= 900mA
AnslutningarCinch,USB

Effekt

Max.totalmusikeffekt12W

Subwoofer1x8W

Satellit/center2x2W

Storlek(Bx D x H) / vikt
Totaltca.1170g
Subwoofer	23x 1 5,2x 1 7,3cm ca.730g
Satellit/center	930x 6 ,3x 1 1 cm ca.440g

FIN Käyttöohje

Ohje

AftertheimplementationoftheEuropeanDirective2012/19/EUand2006/66/EUinthenationallegal system, the following applies:

Electricandelectronicdevicesaswellasbatteriesmustnotbedisposedofwithhouseholdwaste.

Consumersareobligedbylawtoreturnelectricalandelectronicdevicesaswellasbatteriesattheend oftheirservicelivestothepubliccollectingpointssetupforthispurposeorpointofsale.Detailstothis aredefinedbythenationallawoftherespectivecountry.

This symbol on the product, the instruction manual or the package indicates that a product is subject to the regulations.

Byrecycling, reusing thematerials or other forms of utilising old devices/Batteries, you are making an important contribution to protecting ourenvironment.

All listed brands are trademarks of the corresponding companies. Errors and omissions excepted, and subject to technical changes. Our general terms of delivery and payment are applied.
