USER MANUAL Smart Grip 14432 HAMILTON BEACH

1. Use iron only for its intended use.

2. Verify that the voltage in your home corresponds to that of your

3. To protect against risk of electric shock, do not immerse the iron

in water or other liquids.

4. The iron should always be turned to OFF before plugging or

unplugging from outlet. Never yank cord to disconnect from outlet; instead, grasp plug and pull to disconnect.

5. Do not allow cord to touch hot surfaces. Let iron cool completely

before putting away. Loop cord loosely around iron when storing.

6. Always disconnect iron from electrical outlet when filling with

water or emptying and when not in use.

7. Do not operate iron with a damaged cord or if the iron has been

dropped or damaged. To avoid the risk of electric shock, do not disassemble the iron. Call our toll-free customer service number for information on examination and repair. Incorrect reassembly can cause a risk of electric shock when the iron is used.

8. Close supervision is necessary for any appliance being used by

or near children. Do not leave iron unattended while connected or on an ironing board.

9. Burns can occur from touching hot metal parts, hot water, or

steam. Use caution when you turn a steam iron upside down— there may be hot water in the reservoir. SPECIAL INSTRUCTIONS

1. To avoid a circuit overload, do not operate another high-wattage

appliance on the same circuit.

2. If an extension cord is absolutely necessary, a 15-ampere cord

should be used. Cords rated for less amperage may overheat. Care should be taken to arrange the cord so that it cannot be pulled or tripped over. When using your flatiron, basic safety precautions should always be followed, including the following:

OTHER CONSUMER SAFETY INFORMATION

This product is intended for household use only. WARNING! Shock Hazard: This appliance has a polarized plug (one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or using an adaptor. If the plug does not fit, reverse the plug. If it still does not fit, have an elec- trician replace the outlet. Use the iron on an ironing board. Ironing on any other surface may damage that surface. Do not iron or vertical steam clothes that are being worn. Do not use vertical steam in the direction of people or pets.

• Steam vents should be cleaned before first use. Prepare iron for steam ironing, then iron over an old cloth for a few minutes while letting the iron steam. This will clean the vents.

• Many irons spit or sputter during the first few uses with tap water. This happens as the steam chamber becomes conditioned. This will stop after a few uses.

• During first use of the iron, it may appear to smoke. This will stop and does not indicate a defect or hazard. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 23 Parts and Features Heel Rest Water Tank Fill Area Water Tank Cord Self-Clean Button Soleplate Spray Nozzle Blast of Steam Button Spray Trigger Adjustable Steam Switch Power ON Light (blinks in Auto Standby mode) Temperature Control Dial Water Tank Door (open position) 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 34 How to Dry Iron

Set adjustable steam switch to NO STEAM position. Select desired temperature. Allow 2 minutes for iron to reach desired temperature before using. See Fabric Setting Chart. When finished, turn temperature control dial to OFF.

Unplug iron and allow to cool.

AUTOMATIC STANDBY (optional feature on select models): Select models are equipped with an automatic standby feature, which turns iron heat off when not in use (see chart below). When iron is moved, it will begin to heat again. To shut off iron completely, turn temperature control dial to “OFF” position and unplug. Iron Position Auto Standby Face Down (soleplate touching any surface) 30 seconds Upright (resting on heel) 15 minutes NOTICE: To avoid property dam- age to supporting surfaces, always use an ironing board. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 45 How to Steam Iron

Set adjustable steam switch to STEAM position. Select desired temperature. Allow 2 minutes for iron to reach desired temperature before using. See Fabric Setting Chart. For vertical steaming, hold iron six inches from garment and do not allow hot soleplate to touch deli- cate garments.

When finished, turn temperature control dial to OFF.

AUTOMATIC STANDBY (optional feature on select models): Select models are equipped with an automatic standby feature, which turns iron heat off when not in use (see chart below). When iron is moved, it will begin to heat again. To shut off iron completely, turn temperature control dial to “OFF” position and unplug.

Unplug iron and allow to cool. Empty any remaining water from iron. See Care and Cleaning. Iron Position Auto Standby Face Down (soleplate touching any surface) 30 seconds Upright (resting on heel) 15 minutes 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 56 Fabric Setting Chart NOTICE: To avoid garment damage, check garment label for fabric composition, ironing instructions, and suggested ironing temperature. The chart below is to be used only as a guide. If ironing a fabric not listed, first refer to your garment label’s guidelines, then set the temperature control dial accordingly.

TEMPERATURE SETTINGS FOR DRY IRONING

Synthetics Dry iron on reverse side of fabric. Silk/Wool Dry iron on reverse side of fabric.

TEMPERATURE SETTINGS FOR STEAM IRONING

Cotton Iron while damp using steam or spray. Linen Iron while damp on reverse side of fabric. Garment Label Symbols Iron High Temp Setting Medium Temp Setting Low Temp Setting Do not iron Do not use steam Fabric care labels on garments have symbols that show ironing instructions and recommended temperature settings. These symbols are shown below along with an explanation of their meaning. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 67 Care and Cleaning

NOTICE: To avoid damage to the iron soleplate:

• Never iron over zippers, pins, metal rivets, or snaps.

• Wipe with a soapy cloth to clean occasional buildup on the soleplate. Never use abrasive cleansers or metal scouring pads, as they may scratch the surface.

Self-Clean Feature To keep the steam vents clear of any buildup, follow these instructions each time you iron using steam.

Press and hold the self-clean button until tank is empty. Allow iron to heat on HIGH for 2 minutes. Turn iron OFF and unplug. Hold iron over sink. Set adjustable steam switch to NO STEAM position. Set adjustable steam switch to STEAM position. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 89 Troubleshooting PROBLEM Iron won’t heat. Water is leaking out of the iron. Iron won’t steam. Iron leaves spots on clothing. Wrinkles not removed. Fabric/clothing scorched. Twisted cord.

PROBABLE CAUSE/SOLUTION

• Is iron plugged in and the outlet working? Check outlet by plugging in a lamp.

• Has temperature control dial been turned to a fabric setting?

• Has auto standby feature activated? Move iron to turn back on.

• Do not overfill water tank.

• If steam ironing, is adjustable steam switch in the STEAM position, has a temperature been selected, and did iron have enough time to preheat? Allow iron to heat for 2 minutes before using.

• If dry ironing, make sure adjustable steam switch is in the NO STEAM position.

• Has iron had enough time to preheat? Allow iron to heat for 2 minutes before using.

• Is adjustable steam switch in the STEAM position?

• ALWAYS empty water tank after using. Water left in tank may discolor clothing and soleplate.

• Choose correct temperature setting for your fabric. See Fabric Setting Chart and Garment Label Symbols.

• Select a lower temperature setting. Allow iron to cool for 5 minutes before continuing.

• If cord becomes twisted, turn iron OFF and unplug. Let cool. Empty any water from iron. Hold cord in the middle of entire length. Let plug and iron dangle freely until cord uncoils. This will extend the life of your iron cord. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 910 Limited Warranty This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value. This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use. We exclude all claims for special, incidental and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental or consequential damages, so the foregoing limitations may not apply to you. To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance. 840178000 ENnv04.qxd:Layout 1 12/2/08 9:42 AM Page 1011 CONSERVER CES INSTRUCTIONS!
