Favourite WH05039L - Boiler Eldom - Free user manual and instructions

Product type	Electric storage water heater
Brand	Eldom
Model	Favourite WH05039L
Capacity	50 liters
Height	760 mm
Diameter	387 mm
Depth (center distance)	410 mm
Power supply	230 V / 50 Hz
Rated power	2000 W
Tank material	Enameled steel
Thermal insulation	Polyurethane (estimated)
Maximum working pressure	6 bar (estimated)
Water connection	G 1/2" (estimated)
Main functions	Water heating, adjustable thermostat, frost protection
Maintenance and cleaning	Annual draining and cleaning, check of magnesium anode
Safety	Safety valve, safety thermostat, overheat protection
Spare parts repairability	Magnesium anode, heating element, thermostat available
Protection rating	IP24 (estimated)
Weight	Approximately 18 kg (estimated)
Group volume	50 (according to table)
Electrical connection	Power cable not supplied (estimated)

Frequently Asked Questions - Favourite WH05039L Eldom

How to install the Favourite WH05039L water heater?

Installation must be carried out by a qualified professional. Fix the appliance to the wall using the supplied brackets, respect safety distances, and connect the cold water inlet and hot water outlet. Then connect the 230 V power supply with a 30 mA residual current circuit breaker.

What is the heating time for 50 liters?

With a power of 2000 W, the heating time to reach 60°C is approximately 1h30 to 2h, depending on the incoming cold water temperature.

How to adjust the water temperature?

Use the thermostat located on the front panel. Turn the knob to set the temperature between 30°C and 75°C. The recommended position is 60°C for a good balance between comfort and energy savings.

What to do if the water does not heat?

First check the power supply (circuit breaker, plug). If the appliance is powered, the thermostat or heating element may be defective. Contact a professional for replacement of these parts.

How to maintain the magnesium anode?

The anode should be checked once a year. If it is heavily corroded (more than 50% of its volume), replace it. A worn anode reduces the protection of the tank against corrosion.

What is the normal noise during operation?

A slight heating noise (sizzling) is normal during temperature rise. Clicking sounds may occur due to material expansion. If the noise is abnormal (whistling, knocking), check the pressure and bleed the air.

How to drain the water heater?

Turn off the power supply and close the cold water inlet. Open a hot water tap to relieve pressure. Connect a hose to the drain valve at the bottom of the appliance and open it. Let the water flow out completely.

What is the maximum supported pressure?

The maximum working pressure is generally 6 bar. Check the label on the appliance or the manual for the exact value. If your water pressure exceeds 4 bar, install a pressure reducer.

Can the water heater be used in frost protection mode?

Yes, the thermostat has a frost protection position (around 10°C). Use this position if you do not use the appliance for an extended period in winter to prevent the tank from freezing.

Where to find spare parts for this model?

Spare parts such as the magnesium anode, heating element, and thermostat are available from authorized Eldom dealers or on specialized websites. Use the reference WH05039L to order.

USER MANUAL Favourite WH05039L Eldom

Line drawing of a cylindrical device with internal components and a handle, no text or symbols present

1 φD 2 100 1 3 4 L

A M C 255 44

2 4 E ØD 2 100 C 1 3 F

255 C 5 44 A M

ØD 4 F

3

A C M 255 44 K B 1 3 2

1a 5 6 1b 7

Technical line drawing of a mechanical assembly with two circular components connected to a central hub, plus two cross-sectional views below (no text or symbols)

	○	○	○	○
	○	○	○	○

Table / Tabelle / Tableau / Tabel / Tabelul / Таблица / Tabela - № 1

Model / Modell / Modèle / Model / Model / Модель / Modeli		WV03039 / 72269WN	WV05039 / 72267WN / SV05044	WV08039 / 72268WN	WV08046 (WU08046) / 72265W (SV08044)	WV10046 (WU10046) / 72270W (SV10044)	WV12046 (WU12046) / 72266W (SV12044)	WV15046
Volume group / Volumengruppe / Volume / Capaciteitsgroep / Grup volumetric / Объемная группа / Grupi I vëllimit		30	50	80	80	100	120	150
Fig. / Afb. No		1 (1; 1a; 1b) / 1c / (1d)
Dimensions / Abmessungen / Dimensions / Afmetingen / Dimensiuni / Размеры / Dimensionet	A	560 / 568	760 / 768 / 595	1125 / 1133	835 / 825	1005 / 1000	1170 / 1165	1420
	C	155	155 / 155 / 175	155	185 / 175	185 / 175	185 / 175	185
	D	387	387 / 387 / 435	387	462 / 435	462 / 435	462 / 435	462
	E	80	80 / 80 / 85	80	96 / 85	96 / 85	96 / 85	96
	F	410	410 / 410 / 457	410	484 / 457	484 / 457	484 / 457	484

Table / Tabelle / Tableau / Tabel / Tabelul / Таблица / Tabela - № 1a

Model / Modell / Modèle / Model / Model / Модель / Modeli		WH05039L	WH08039L	WH08046L / WH08046BR / WU08046	WH10046L / WH10046BR / WU10046	WH12046L / WH12046BR / WU12046
Volume group / Volumengruppe / Volume / Capaciteitsgroep / Grup volumetric / Объемная группа / Grupi I vëllimit		50	80	80	100	120
Fig. / Afb. No		2		2 / 3 / 2
Dimensions / Abmessungen / Dimensions / Afmetingen / Dimensiuni / Размеры / Dimensionet /	A	760	1125	835	1005	1170
	C	155	155	185	185	185
	D	387	387	462	462	462
	E	80	80	96	96	96
	F	410	410	484	484	484
	M	405	770	415	587	753
	B	-	223	250	250	250
	K	-	617	262	434	600

4 9 10 L 8 10 J K F

5 9 8 10 J J K F

6 8 F J

7 M C 5 255 h 1 B K E 8 φD 100 W

M C 255 44 E 2 8 ØD 100 W

	○	○	○	○
	○	○	○	○

Table / Tabelle / Tableau / Tabel / Tabelul / Таблица № 2

I			WV08039SL	WV10046SL	WV12046SL	WV15046SL	WV08039S2L	WV12046S2L	WV15046S2L	WV10046S21L	WV12046S21L	WV15046S21L	WV08039TLG	WV08046TLG	WV10046TLG	WV12046TLG	WV15046TLG
II			80	100	120	150	80	120	150	100	120	150	80	80	100	120	150
III			4							5			6
IV[m2]	Enamel	S	0.49	0.65	0.65	0.89	0.49	0.65	0.89	0.36	0.53	0.53	0.18	0.24	0.24	0.3	0.41
	Email	S2	-	-	-	-	0.22	0.3	0.3	0.36	0.53	0.53	-	-	-	-	-
	Cr-Ni	S	0.6	0.87	0.87	1,08	0.6	0.87	1.08	0.56	0.66	0.66	-	-	-	-	-
		S2	-	-	-		-	0.34	0.34	0.56	0.66	0.66	-	-	-	-
V[mm]		F	250	250	250	250	250	250	250	250	250	250	425	190	365	466	666
		J	450	450	450	670	450	450	670	450	630	630	450	385	385	450	500
		K	-	-	-	-	770	780	999	365	355	355	-	-	-	-	-
		L	-	-	-	-	220	200	200	-	-	-	-	-	-	-	-

Table / Tabelle / Tableau / Tabel / Tabelul / Таблица

No 2a

I		WH08039SL	WH08039LSL	WH08046SL	WH08046LSL	WH10046SL	WH10046LSL	WH12046SL	WH12046LSL
II		80	80	80	80	100	100	120	120
III		7	7a	7	7a	7	7a	7	7a
IV [m^2]		0.36	0.36	0.35	0.35	0.35	0.35	0.59	0.59
V[mm]	D	387	387	462	462	462	462	462	462
	E	80	80	96	96	96	96	96	96
	M	770	770	415	415	587	587	753	753
	C	155	155	185	185	185	185	185	185
	K	223	144	250	190	250	190	250	190
	B	617	235	262	310	434	310	600	310
	W	410	410	484	484	484	484	484	484
