Hub+ - Stroller Joolz - Free user manual and instructions

Brand	Joolz
Model	Hub+
Category	Stroller
Product type	Urban all-terrain stroller
Recommended age	From 6 months up to 22 kg or 100 cm
Unfolded dimensions	85 x 53 x 96.5-106 cm
Maximum basket load	5 kg
Maximum child weight	22 kg
Maximum child height	100 cm
LED lighting power supply	2 AAA batteries (not included)
Lighting	Front and rear LED
Sun canopy	Very large, extra large
Wheels	Swivel front wheels, fixed rear wheels
Handlebar	Adjustable height (96.5-106 cm)
Main features	Reclinable seat, extra large sun canopy, rotating bumper bar, swivel front wheels, parking brake, compact fold
Safety	5-point harness, brake, front wheel lock, compliance EN 1888:2012
Care and cleaning	Clean the cover with warm water and soap, rinse with cold water. Treat wheels and metal parts with Teflon or silicone spray once a month
Warranty	Lifetime warranty if registered within 6 months of purchase, otherwise 2 years
Compatible accessories	Car seat, carry cot (Hub+ only)
Standards compliance	EN 1888:2012, ASTM F833-15, CAN SOR/2016-167, AS/NZS 2088:2013
Usage precautions	Do not use for jogging or roller skating. Always lock front wheels before folding
Repairability	Spare parts available from the manufacturer or authorized dealer

Frequently Asked Questions - Hub+ Joolz

How to fold the Joolz Hub+ stroller?

To fold the stroller, first lock the swivel front wheels. Then lower the handlebar and follow the folding instructions in the manual. Make sure your child is away from moving parts.

How to clean the stroller cover?

Clean the cover with warm water and soap. Rinse with cold water and let dry. Never use bleach or chemical detergents.

What type of batteries for the LED lighting?

The LED lighting operates with 2 AAA batteries. Batteries are not included. Observe polarity and do not mix new and used batteries.

Up to what weight and height can my child use the stroller?

The seat is designed for children at least 6 months old, up to a maximum weight of 22 kg and a maximum height of 100 cm.

Is the Joolz Hub+ stroller compatible with car seats?

Yes, the stroller is compatible with Joolz car seats and other approved brands. Only use accessories provided or approved by Joolz.

How to maintain the wheels for smooth rolling?

Regularly (about once a month) treat the wheels and metal parts with a Teflon or silicone spray to ensure smooth rolling.

What to do if a part of the stroller is damaged or missing?

Do not use the stroller if a part is damaged, worn, or missing. Contact your dealer or Joolz for spare parts.

Can I use the stroller for jogging?

No, the Joolz Hub+ stroller is not suitable for jogging or roller skating. It is designed for normal urban use.

How to lock the swivel front wheels?

The swivel front wheels are locked using a mechanism on each wheel. Make sure to lock them before folding the stroller to avoid tire deformation.

What is the warranty for the Joolz Hub+ stroller?

Joolz offers a lifetime warranty if you register your stroller at register.joolz.com within 6 months of purchase. Otherwise, you receive a 2-year warranty. The warranty covers material and manufacturing defects.

USER MANUAL Hub+ Joolz

designed in The Netherlands

Line drawing of a two-wheeled baby stroller with handlebars and wheels (no text or symbols)

en	instruction manual	ee	kasutusjuhend
de	Gebrauchsanweisung	lv	lietošanas instrukcija
nl	gebruiksaanwijzing	lt	instrukciju vadovas
fr	manuel d'instructions	sl	navodila za uporabo
cs	manual de instrucciones	hr	priručnik za upotrebu
pt	manual de instruções	cs	návod k použiti
it	manuale di istruzioni	bg	инструкция
sv	bruksanvisning	ro	manual de instructiuni
no	bruksanvisning	sr	priručnik za upotrebu
fi	käyttöopas	hu	használati útmutató
da	instruktioner	sk	návod na použitie
ru	инструкция по эксплуатации	gr	обnyíes хрňaŋς
pl	instrukcja obsługi	ar	دليل تليمات الاستعمال
vk	инструкция з експлуатації	za	handleiding

Brand ol:

Milk Design BV

Joolz HQ

Distelweg 89

1031 HD Amsterdam

The Netherlands

[e-mail]

131 206 304 887

Joolz USA Inc.

PO Box 4530

New York

NY10163-4530

[e-mail]

[phone]

joolz.com

facebook.com/my.joolz

At Joolz, we believe that good parenting is all about being happy. That's why we offer you the building blocks to spark your life with positivity. So, whatever defines your happiness, go after it and live it.

Our ergonomic pushchairs, car seats and (organic) accessories are designed to make sure you enjoy the ride.

let's grow together

JOOLZ POSITIVE DESIGN

index

introducing the Joolz Hub ^+ 8

Einführung des Joolz Hub ^+ - introduction de la Joolz Hub ^+

get me ready! 12

how to use the seat 14

how to use the seat harness 17

how to use the restraint system 18

Wie nutze ich den Sicherheitsgurt - comment utiliser le système de sécurité

how to use the buckle 18

how to use the brake 19

how to use the LED light 20

Verwendung des LED-Lichts - comment utiliser l'éclairage LED

how to change the battery 21

Batteriewechsel - comment changer la pile

compact storage

compact storage world facing 23

Kompaktes Lagern Vorwärtsgerichtet - Espace de stockage compact - en position face au monde

compact storage parent facing 25

Kompaktes Lagern Rückwärtsgerichtet - Espace de stockage compact - en position face aux parents

warnings 28

folded without seat and wheels

folded with seat and wheels

* for the USA the lbs maximum weight capacity has been tested

reusable packaging

hello bus, goodbye box

see all the possibilities on joolz.com

Simple line drawing of a toy car with wheels and a cutout, no text or symbols present

Line drawing of a double-decker bus with wheels and windows, no text or symbols present

10.66

lifetime warranty

register.joolz.com

lifetime warranty

stroll always & forever

apply your warranty within 6 months on register.joolz.com

Birth Forest

one pushchair, one tree

experience our meaningful journey on joolz.com

JOOZ

Birth Forest

one pushchair

one tree

get me ready

Illustration of a baby stroller with wheels and directional arrows indicating motion (no text or symbols)

2

Line drawing of a two-wheeled baby stroller with a magnified inset showing the blade and handle (no text or symbols)

3

Line drawing of a baby stroller with fan blades and wheels (no text or symbols)

4

5

Illustration of a baby stroller with hand positioning guide (no text or symbols)

WARNING: to avoid injury ensure that your child/children are safe from moving parts when unfolding, folding and adjusting this product.

how to use the seat 14

how to use the seat harness 17

how to use the restraint system 18

Wie nutze ich den Sicherheitsgurt - comment utiliser le système de sécurité

how to use the buckle 18

how to use the brake 19

how to use the LED light 20

Verwendung des LED-Lichts - comment utiliser l'éclairage LED

how to change the battery 21

Batteriewechsel - comment changer la pile

how to use the seat

Line drawing of a baby stroller with wheels and a leafy top (no text or symbols)

√

Line drawing of a baby stroller with wheels and a handle, no text or symbols present

√

Line drawing of a baby stroller with hand positioning and a close-up inset showing the blade being inserted (no text or symbols)

√

Line drawing of a stroller with a click button and arrow, no text or symbols present

√

Technical line drawing of a wheeled cart with wheels and a circular component inset (no text or symbols)

√

Illustration of a baby stroller with directional arrows indicating motion (no text or symbols)

√

Line drawing of a baby stroller with a fan and arrow indicating rotation (no text or symbols)

√

Line drawing of a baby stroller with fan and wheels (no text or symbols)

√

√

Line drawing of a baby stroller with wheels and a handle, no text or symbols present

√

Illustration of a baby stroller with fan blades and wheels, showing motion arrows (no text or symbols)

√

Line drawing of a baby stroller with a fan and wheels, showing a circular diagram with arrows indicating direction (no text or symbols)

how to use the seat harness

Line drawing of a baby stroller with a magnified inset showing the handle (no text or symbols)

Line drawing of a baby stroller with wheels and a pull arrow (no text or symbols)

Diagram of a mechanical device with a downward arrow and circular components, no text or symbols present.

Line drawing of a baby stroller with wheels and handle (no text or symbols)

Line drawing of a baby stroller with wheels and handle (no text or symbols)

Diagram of a mechanical device with two arms and a central shaft, enclosed in an arched frame (no text or symbols)

Line drawing of a baby stroller with wheels and a handle, no text or symbols present

Line drawing of a baby stroller with three wheels and canopy (no text or symbols)

Diagram of a vehicle interior with directional arrows indicating movement or force (no text or symbols)

JOOLZ

how to use the restraint system

Wie nutze ich den Sicherheitsgurt - comment utiliser le système de sécurité

√

Pure technical line drawing of a symmetrical mechanical or architectural component without any text, numbers, or symbols

√

Diagram of a car hood with internal components and directional arrows indicating movement (no text or symbols)

how to use the buckle

how to use the brake

WARNING: always apply the swivel lock on the front wheels when folding the pushchair. Failing to do so can result in obstruction of the tyres, leading to deformation, especially in a hot environment.

how to use the LED light

Verwendung des LED-Lichts - comment utiliser l'éclairage LED

√

Line drawing of a two-wheeled stroller with a canopy and wheels (no text or symbols)

Illustration showing hand using a tool to clean or inspect car interior (no text or symbols)

√

how to change the battery

Batteriewechsel - comment changer la pile

√

Line drawing of a baby stroller with fan and wheels (no text or symbols)

√

compact storage

compact storage world facing

23

compact storage parent facing

25

compact storage world facing

WARNING: always apply the swivel lock on the front wheels when folding the pushchair. Failing to do so can result in obstruction of the tyres, leading to deformation, especially in a hot environment.

Line drawing of a stroller with a hand tool and magnified detail view (no text or symbols)

Line drawing of a baby stroller with wheels and a side-mounted handle (no text or symbols)

JOOLZ

2322 Ir

Line drawing of a stroller with wheels and a magnified inset showing the handle mechanism (no text or symbols)

Line drawing of a baby stroller with wheels and a curved handle, no text or symbols present

Line drawing of a stroller with wheels and a handle, no text or symbols present

Line drawing of a person in a wheelchair with a directional arrow indicating motion (no text or symbols)

WARNING: to avoid injury ensure that your child/children are safe from moving parts when unfolding, folding and adjusting this product.

compact storage parent facing

Kompaktes Lagern Rückwärtsgerichtet - Espace de stockage compact - en position face aux parents

WARNING: always apply the swivel lock on the front wheels when folding the pushchair. Failing to do so can result in obstruction of the tyres, leading to deformation, especially in a hot environment.

Line drawing of a baby stroller with a curved arrow indicating rotation (no text or symbols)

5

Line drawing of a small wheeled vehicle with propeller blades and wheels, no text or symbols present

6

7

AUS

how to lock - only for Australia

WARNING: ensure that the storage latch is engaged when lifting or carrying the pushchair. To avoid injury ensure that your child/children are safe from moving parts when unfolding, folding and adjusting this product.

WARNING: to avoid injury ensure that your child/children are safe from moving parts when unfolding, folding and adjusting this product.

+ Never leave the child unattended.

+ This product is not suitable for running or skating.

+ To avoid injury, ensure that your child/children are kept away when adjusting, unfolding and folding this product.

+ Be aware of finger entrapment when folding or unfolding the pram/stroller. Due care should be exercised.

+ Ensure that all locking devices are engaged before use.

+ Check that the cot/pram/carriage, seat unit or car seat attachment devices are correctly engaged before use.

+ The Joolz Hubcarrycot and seat unit are only compatible with the Joolz Hub ^1 chassis and vice versa.

+ Any load attached to the pushbar and/or on the back of the backrest and/or on the sides of the vehicle will affect the stability of the vehicle.

+ Parcels or accessory items, or both, placed on the unit may cause the unit to become unstable. Excessive weight may cause a hazardous unstable condition.

+ The carrycot or seat unit can each carry only one child at a time

+ Only use car seats, replacement or spare parts and accessories that are supplied or approved by Joolz.

+ For car seats used in conjunction with a chassis they not replace a cot or a bed. Should your child need to sleep, then it should be placed in a suitable cot/pram or bed.

+ Check this product and accessories regularly for signs of damage and tear.

+ Do not use the pushchair if any of the parts are damaged, torn or missing.

+ Always apply the swivel lock on the front wheels before folding the pushchair. Failing to do so can lead to deformation of the tyres, especially in a hot environment.

+ The brakes should always be engaged when placing and removing the children.

+ The maximum weight of the shopping basket is 5 kg/11 lbs.

+ Make sure that children do not climb into the pushchair.

+ Do not let a child/children play with this product.

WARNING

FOR SEAT UNIT

+ The seat unit is intended for children from 6 months, up to maximum weight of

22 kg and maximum height of 100 cm.

+ For USA the seat unit is tested for

a maximum weight of 50 lbs. and maximum height of 40 inch.

+ The seat unit is not suitable for children under 6 months.

+ Avoid serious injury from falling or sliding out. Always use the restraint system.

Each LED requires 2 x 1.5V AAA batteries. Batteries not included.

WARNING

FOR LED

+ Dispose of used batteries immediately. Keep new and used batteries away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

+ Batteries should be replaced by adults only.

+ Non-rechargeable batteries are not to be recharged.

+ Rechargeable batteries should be charged under adult supervision.

+ Different types of batteries or new and used batteries are not to be mixed.

+ Batteries are to be inserted with the correct polarity (+ and -).

+ Exhausted batteries are to be removed from the toy.

+ The supply terminals are not to be short-circuited.

MAINTENANCE / WASHING INSTRUCTIONS

Clean the fabric with lukewarm water and soap. Rinse with fresh water and leave to dry. Never use bleach or other chemical detergents. Periodically (approximately once a month) treat the wheels and metal parts with Teflon or silicon spray to ensure the pushchair continues to run smoothly.

The aluminium parts of your Hub ^® pushchair are anodized to protect it from external influences such as corrosion. Anodized aluminium parts are vulnerable to acidic cleaners or grease, which can cause stains and discoloration of the aluminium parts. We therefore advise you to clean the aluminium parts of your pushchair with warm water and a soft cloth.

WARRANTY

Joolz offers lifetime warranty on the Joolz Hub*. The warranty covers all material and manufacturing faults, but not the exchange or return of the product. To be eligible for the lifetime warranty, call you have to do is register your Joolz pushchoir on register.joolz.com within six months of purchase and keep your original proof of purchase including a purchase date. If you do not register your Joolz pushchair within six months after purchase, you will receive a two-year warranty.

The warranty is only valid if you supply the following items to your retailer along with the defective product: 1) Your warranty certificate,
2) Any form of personal identification,
3) A copy of the receipt of purchase (including a purchase date),
4) A detailed description of the defect.

You will receive the warranty certificate after you have registered your Joolz pushchair on our website register.joolz.com.

If your retailer cannot assist you with your complaint, contact Joolz. Please note, any repairs do not extend the warranty period.

THE WARRANTY DOES NOT COVER:

1) Defects caused by ordinary wear and tear, such as worn wheels and fabrics by everyday use, scratches on the aluminium and/or metal and natural discolouration of materials over time or by not following the maintenance instructions.

2] Damage to wheels such as holes and tears.
3) Damage caused by accidents, improper use, negligence, fire, contact with liquids or another external cause.
4) Damage resulting from non-compliance with the instruction manual, instruction movies or other Joolz guidelines.
5) Damage caused by another product, including accessories.
6) Damage by service or repair by an unofficial representative of Joolz.

7|Theft.

8) Air transportation or freight damage.

Safety was an important consideration throughout the development of the Joalz Hub ^* pushchair and cat. Our products therefore meet the following safety standards:

Europe: EN 1888:2012 / EN 1466:2014/AC: 2015 United States: ASTM F833-15 / ASTM F2050-16 Canada: SOR/2016-167 Australia: AS/NZS 2088:2013

Please visit jaolz.com, facebook.com/myjoolz or contact your retailer for any questions and/or comments.

AUSTRALIA

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USAGE AND KEEP THEM FOR FUTURE REFERENCE.

WARNING

• To avoid injury or death: always apply the brakes whenever the pram/stroller is stationary.
• Do not leave children unattended
• Do not carry extra children or bags on this pram/stroller.
• Make sure children are clear of any moving parts if you adjust the pram/stroller.
• Use the teather strap to stop the pram/stroller from rolling away.
• Do not use the seat with any other models of pram/stroller.
• Be aware of finger entrapment when folding or unfolding the pram/stroller. Due care should be exercised.
• Regularly inspect the pram/stroller, chassis and accessories regularly for signs of damage and tear.
• Only use car seats, replacement or spare parts and accessories that are supplied or approved by Joolz. Using non-approved accessories is unsafe.
• Care should be taken if the pram/stroller is used on stairs or escalators.
• The pram/stroller should not be used near an open fire or exposed flame.
• The maximum weight of the shopping basket is 5 kg.
• The vehicle is designed for use on flat or gently sloping surfaces and may be unstable on higher sloping and uneven surfaces.
• Make sure storage latch is engaged when lifting or carrying the pram/stroller.

+ Use carry strap to safely transport folded stroller.

+ To use the tether strap stick your hand thru the loop and wrap the strap around your wrist.

WARNING

FOR THE STROLLER

• The stroller is intended for children from 6 months, up to maximum weight of 22 kg.
• Secure the child in the harness at all times
• The stroller is not recommended for a child under 6 months.

+ Never leave a harness buckled when not fitted to a child in the stroller because the harness can form loops which may pose a strangulation hazard.

Each LED requires 2 x 1.5V AAA batteries. Batteries not included.

WARNING

FOR LED

• The LED requires 2 AAA batteries. Batteries not included.
• Dispose of used batteries immediately. Keep new and used batteries away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
• Batteries should be replaced by adults only.
• Non-rechargeable batteries are not to be recharged.

• Rechargeable batteries should be charged under adult supervision.

• Different types of batteries or new and used batteries are not to be mixed.

• Batteries are to be inserted with the correct polarity (+ and -).
• Exhausted batteries are to be removed from the toy.
• The supply terminals are not to be short-circuited.

MAINTENANCE / WASHING INSTRUCTIONS

Clean the fabric with lukewarm water and soap. Rinse with fresh water and leave to dry. Never use bleach or other chemical detergents. Periodically (approximately once a month) treat the wheels and metal parts with Teflon or silicon spray to ensure the pushchair continues to run smoothly.

The aluminium parts of your Hub ^™ pushchair are anodized to protect it from external influences such as corrosion. Anodized aluminium parts are vulnerable to acidic cleaners or grease, which can cause stains and discoloration of the aluminium parts. We therefore advise you to clean the aluminium parts of your pushchair with warm water and a soft cloth.

WARRANTY

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Joolz offers lifetime warranty on the Joolz Hub?, The warranty covers all material and manufacturing faults, but not the exchange or return of the product. To be eligible for the lifetime warranty, all you have to do is register your Joolz pushchair on register.joolz.com within six months of purchase and keep your original proof of purchase including a purchase date. If you do not register your Joolz pushchair within six months after purchase, you will receive a two-year warranty.

The warranty is only valid if you supply the following items to Anstel Brands along with the defective product:

1) Your warranty certificate,
2) Any form of personal identification,
3) A copy of the receipt of purchase (including a purchase date),
4) A detailed description of the defect.

You will receive the warranty certificate after you have registered your Joolz pushchair on our website register.joolz.com.

Please contact Anstel Brands for any warranty claims. Please note, any repairs do not extend the warranty period.

THE WARRANTY DOES NOT COVER:

1) Defects caused by ordinary wear and tear, such as worn wheels and fabrics by everyday use, scratches on the aluminium and/or metal and natural discolouration of materials over time or by not following the maintenance instructions.
2) Damage to wheels such as holes and tears.
3) Damage caused by accidents, improper use, negligence, fire, contact with liquids or another external cause.
4) Damage resulting from non-compliance with the instruction manual, instruction movies or other Joolz guidelines.
5) Damage caused by another product, including accessories.
6) Damage by service or repair by an unofficial representative of Joolz.
7)Theft
8) Air transportation or freight damage

SAFETY

Safety was an important consideration throughout the development of the Joolz Hub ^+ pushchair and cat. Our products therefore meet the following safety standards:

Europe: EN 1888:2012 / EN 1466:2014/AC: 2015 United States: ASTM F833-15 / ASTM F2050-16

Canada: SOR/2016-167

Australia: AS/NZS 2088:2013

DEUTSCH

USA: ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

Australien: AS/NZS 2088:2013

LA GARANTIE NE COUVRE PAS:

MANUTENÇÃO/INSTRUÇÕES DE LAVAGEM

USA: ASTM F833-15 / ASTM F2050-16

Canada: SOR/2016-167

Australia: AS/NZS2088:2013

GARANTIEN DÄKKER IKKE:

USA: ASTM F833-15 / ASTM F2050-16

Canada: SOR/2016-167

Australian: AS/NZS 2088:2013

GWARANCJA NIE OBEJMUJE:

ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

Australia: AS/NZS 2088:2013

ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

Australia: AS/NZS 2088:2013

ASTM F833-15 / ASTM F2050-16

Kanādas standorti: SOR/2016-167

ASTM FB33-15 / ASTM F2050-16

ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

Australija: AS/NZS 2088:2013

Ako imate pitanja i/ili primjedbi, posjetite joolz.com, facebook.com/myjoolz ili se abratite prodajnom predstavniku.

ČEŠTINA

DÜLEŽITÉ: PŘED POUŽITÍM SI TYTO POKYNY POZORNĚ PROČTĚTE A USCHOVEJTE JE, ABYSTE DO NICH MOHLI POZDĚJI NAHLÍŽET.

⚠️ VAROVÁNÍ

USA: ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

ASTM FB33-15 / ASTM F2050-16

Kanada: SOR/2016-167

Australija: A5/NZ5 2088:2013

Posetite jaolz.com, facebook.com/myjaolz ili se obratite maloprodaji za sva pitanja i/ili komentare.

MAGYAR

FONTOS: HASZNÁLAT ELÖTT KÉRJÜK, OLVASSA EL AZ ALÁBBI UTASÍTÁSOKAT, ÉS A TOVÁBBI HASZNÁLAT ÉRDEKÉBEN ÖRIZZE MEG.

FIGYELMEZTETÉS

ASTM F833-15 / ASTM F2050-16

Kanada: SOR/2016-167

Austrália: AS/NZS 2088:2013

בִרָאַעְה taking cyd id as ucl, is cyl

.הכלההוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָהוּרָה

enjoy the ride #myjoolz
