USER MANUAL GSA 1500 Professional BOSCH
0−3000 Tool holder SDS Stroke mm 29 Max. cutting depth – in wood mm 220 – in steel (unalloyed) mm 20 – pipe diameter mm 220 Weight according to EPTA‑Procedure01:2014 kg 3.7 Protection class
The specifications apply to a rated voltage [U] of 230 V. These spe- cifications may vary at different voltages and in country-specific mod- els. Noise/vibration information Noise emission values determined according to EN62841‑2‑11. Typically, the A-weighted noise level of the power tool is: Sound pressure level 89dB(A); sound power level 100dB(A). Uncertainty K=5dB. Wear hearing protection! Vibration total values a
(triax vector sum) and uncertainty K determined according to EN62841‑2‑11: Cutting boards with saw blade S611DF:
Cutting wooden beams with saw blade S611DF:
