USER MANUAL PSA 9000 E BOSCH

OBJ_BUCH-1352-004.book Page 2 Friday, June 27, 2014 12:39 PM| 3 Bosch Power Tools 1 609 92A 0RC | (27.6.14) PSA 900 E PSA 9000 E

OBJ_BUCH-1352-004.book Page 3 Friday, June 27, 2014 12:39 PM1 609 92A 0RC | (27.6.14) Bosch Power Tools 4 |

(triax vector sum) and uncertainty K determined according to EN 60745: Cutting board: a

Cutting wooden beam: a

The vibration level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may be used to compare one tool with anoth- er. It may be used for a preliminary assessment of exposure. The declared vibration emission level represents the main applications of the tool. However if the tool is used for differ- ent applications, with different accessories or insertion tools or is poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over the total working period. An estimation of the level of exposure to vibration should al- so take into account the times when the tool is switched off or when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period. Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of work patterns. Sabre saw PSA 900 E PSA 9000 E Article number 3 603 CA6 0.. Rated power input W900 Stroke rate at no load n

0–2700 Tool holder SDS Stroke rate control

Stroke mm 28 Cutting depth, max. –in wood – in non-alloy steel – pipe diameter

Weight according to EPTA-Procedure 01/2003 kg 3.5 Protection class /II The values given are valid for a nominal voltage [U] of 230 V. For differ- ent voltages and models for specific countries, these values can vary. OBJ_BUCH-1352-004.book Page 11 Friday, June 27, 2014 12:39 PM12 | English 1 609 92A 0RC | (27.6.14) Bosch Power Tools Declaration of Conformity We declare under our sole responsibility that the product de- scribed under “Technical Data” is in conformity with all rele- vant provisions of the directives 2011/65/EU, 2014/30/EU, 2006/42/EC including their amendments and complies with the following standards: EN 60745-1, EN 60745-2-11. Technical file (2006/42/EC) at: Robert Bosch GmbH, PT/ETM9, 70764 Leinfelden-Echterdingen, GERMANY Robert Bosch GmbH, Power Tools Division 70764 Leinfelden-Echterdingen, GERMANY Leinfelden, 25.04.2014 Assembly Replacing/Inserting the Saw Blade Before any work on the machine itself, pull the mains plug. When mounting the saw blade, wear protective gloves. Danger of injury when touching the saw blade. When changing the saw blade, take care that the saw blade holder is free of material residue, e. g. wood or metal shavings. Selecting a Saw Blade An overview of recommended saw blades can be found at the end of these instructions. Use only ½" universal shank saw blades. The saw blade should not be longer than required for the intended cut. The shank thickness of the saw blade must be 0.8–1.6 mm. Use a thin saw blade for narrow curve cuts. Inserting the Saw Blade (see figure A) Press the SDS clamping lever 5 forward and guide the saw blade 1 behind the clamping plate 8 into the saw blade holder
